C500 Chevrolet SSR I

C500 Driver Door Harness to I/P Harness Connector End Connector Part Information 15304692 18-Way F GT 150 280 Series (BK) Connector Part Information 15336468 18-Way M GT 150 280 Series (BK) Pin Wire Color Circuit No. Function Pin Wire Color Circuit No. Function A1 GY/BK 745 Left Front Door Ajar Switch Signal A1 GY/BK 745 Left Front Door Ajar Switch Signal A2 - - Not Used A2 - - Not Used A3 L-GN/BK 394 Door Handle Switch Signal - LF A3 L-GN/BK 394 Door Handle Switch Signal - LF A4 - - Not Used A4 - - Not Used A5 BK 1350 Ground A5 BK 1350 Ground A6 GY 118 Left Front Speaker Output (-) A6 GY 118 Left Front Speaker Signal (-) A7 OG 267 Heated Mirror/Rear Defog Relay Coil Supply Voltage A7 OG 267 Heated Mirror/Rear Defog Relay Coil Supply Voltage A8 GY 1690 Automatic Day/Night Mirror Signal (W/DF4) A8 GY 1690 Automatic Day/Night Mirror Signal (W/DF4) A9 PK 1691 Automatic Day/Night Mirror Low Reference (W/DF4) A9 PK 1691 Automatic Day/Night Mirror Low Reference (W/DF4) B1 OG 4140 Battery Positive Voltage B1 OG 4140 Battery Positive Voltage B2 RD/WH 881 Passenger Mirror Motor Right Control B2 RD/WH 881 Passenger Mirror Motor Right Control B3 L-BU/WH 1497 Passenger Mirror Motor Left/Down Control B3 L-BU/WH 1497 Passenger Mirror Motor Left/Down Control B4 L-BU 164 Power Window Motor Left Front Up Control B4 D-BU 164 Power Window Motor Left Front Up Control B5 BN 165 Power Window Motor Left Front Down Control B5 BN 165 Power Window Motor Left Front Down Control B6 TN 201 Left Front Speaker Output (+) B6 TN 201 Left Front Speaker (+) (1) B7 BN/WH 1498 Passenger Mirror Motor Left/Down Control B7 BN/WH 1498 Passenger Mirror Motor Left/Down Control B8 L-BU 915 Power Window Left Position Sensor 2 B8 L-BU 915 Power Window Left Position Sensor 2 B9 L-GN 916 Power Window Left Position Sensor 1 B9 L-GN 916 Power Window Left Position Sensor 1

Scheme 93
