C303 Chevrolet SSR I

C303 Headliner Harness to Body Harness Connector End Connector Part Information 15304690 18-Way F GT 150 280 (GY) Connector Part Information 15336467 18-Way M Global Terminal/Mixed (GY) Pin Wire Color Circuit No. Function Pin Wire Color Circuit No. Function A1 L-BU 908 Folding Top Outer Latch Striker Position Switch Disengaged Signal A1 L-BU 908 Folding Top Outer Latch Striker Position Switch - Disengaged Signal A2 - - Not Used A2 - - Not Used A3 L-BU 1803 I/P Module Suppression Indicator - Supply A3 L-BU 1803 I/P Module Suppression Indicator - Supply A4 YE 903 Folding Top Outer Latch Striker Position Switch Released Signal A4 YE 903 Folding Top Outer Latch Striker Position Switch Released Signal A5 D-BU 904 Folding Top Outer Latch Actuator Control A5 D-BU 904 Folding Top Outer Latch Actuator Control A6 BK 905 Folding Top Outer Latch Actuator Control A6 BK 905 Folding Top Outer Latch Actuator Control A7 PK 639 Ignition 1 Voltage (DF4) A7 PK 639 Ignition 1 Voltage (DF4) A8 PK 1691 Automatic Day/Night Mirror Low Reference (DF4) A8 PK 1691 Automatic Day/Night Mirror Low Reference (DF4) A9 L-GN 24 Backup Lamp Supply Voltage (DF4) A9 L-GN 24 Backup Lamp Supply Voltage (DF4) B1 GY 1690 Automatic Day/Night Mirror Signal (DF4) B1 GY 1690 Automatic Day/Night Mirror Signal (DF4) B2 OG 3140 Battery Positive Voltage (DF4) B2 OG 3140 Battery Positive Voltage (DF4) B3 PK 353 I/P Module Suppression Indicator Control B3 PK 353 I/P Module Suppression Indicator Control B4 BK 1450 Ground B4 BK 1450 Ground B5 GY 1698 Enable Signal B5 GY 1698 Enable Signal B6 WH 906 Folding Top Outer Latch Position Switch Latched Signal B6 WH 906 Folding Top Outer Latch Position Switch Latched Signal B7 OG 1732 Inadvertent Courtesy Lamps Supply Voltage B7 OG 1732 Inadvertent Courtesy Lamps Supply Voltage B8 GY/BK 690 Courtesy Lamp Supply Voltage B8 GY/BK 690 Courtesy Lamp Supply Voltage B9 D-BU 907 Folding Top Outer Latch Position Switch Over Center Signal B9 D-BU 907 Folding Top Outer Latch Position Switch Over Center Signal

Scheme 90

Scheme 91
