C175 Engine Harness to Transmission Connector End Connector Part Information 12191511 20-Way F Micro-Pack 100 Series (GY) Connector Part Information 12160782 20-Way M Micro-Pack 100 Series (GY) Pin Wire Color Circuit No. Function Pin Wire Color Circuit No. Function A D-GN 1222 1-2 Shift Solenoid Valve Control A D-GN 1222 1-2 Shift Solenoid Valve Control B YE/BK 1223 2-3 Shift Solenoid Valve Control B YE/BK 1223 2-3 Shift Solenoid Valve Control C RD/BK 1228 PC Solenoid Valve High Control (Sol. A) C RD/BK 1228 PC Solenoid Valve High Control (Sol. A) D L-BU/WH 1229 PC Solenoid Valve Low Control (Sol. A) D L-BU/WH 1229 PC Solenoid Valve Low Control (Sol. A) E PK 1020 Off/Run/Crank Voltage E PK 1020 Off/Run/Crank Voltage L YE/BK 1227 Transmission Fluid Temperature Sensor Signal L YE/BK 1227 Transmission Fluid Temperature Sensor Signal M BK 2762 Low Reference M BK 2762 Low Reference N PK 1224 Transmission Fluid Pressure Switch Signal A N PK 1224 Transmission Fluid Pressure Switch Signal A P RD 1226 Transmission Fluid Pressure Switch Signal C P RD 1226 Transmission Fluid Pressure Switch Signal C R D-BU 1225 Transmission Fluid Pressure Switch Signal B R D-BU 1225 Transmission Fluid Pressure Switch Signal B S WH 687 3-2 Shift Solenoid Valve Control S WH 687 3-2 Shift Solenoid Valve Control T TN/BK 422 Torque Converter Clutch Solenoid Control T TN/BK 422 Torque Converter Clutch Solenoid Control U BN 418 Torque Converter Clutch PWM Solenoid Control U BN 418 Torque Converter Clutch PWM Solenoid Control
