C100 Chevrolet SSR I

C100 Engine Harness to I/P Harness Connector End Connector Part Information 15336418 38-Way F GT 150 280 Sealed 4.0 5.2 (BK) Connector Part Information 15317380 38-Way M GT 150 280 Sealed 4.0 5.2 (BK) Pin Wire Color Circuit No. Function Pin Wire Color Circuit No. Function A1 OG 440 Battery Positive Voltage A1 OG 440 Battery Positive Voltage A2 D-BU 473 High Speed Cooling Fan Relay Control A2 D-BU 473 High Speed Cooling Fan Relay Control A3 GY 2709 5-Volt Reference A3 GY 2709 5-Volt Reference A4-A7 - - Not Used A4-A7 - - Not Used A8 D-GN 890 Fuel Tank Pressure Sensor Signal A8 D-GN 890 Fuel Tank Pressure Sensor Signal B1 GY 397 Cruise Control On Switch Signal B1 GY 397 Cruise Control On Switch Signal B2-B7 - - Not Used B2-B7 - - Not Used B8 YE 710 Class 2 Serial Data Secondary B8 YE 710 Class 2 Serial Data Secondary B9 L-BU 1320 Stop Lamp Supply Voltage B9 L-BU 1320 Stop Lamp Supply Voltage B10 D-GN 335 Low Speed Cooling Fan Relay Control B10 D-BU 335 Low Speed Cooling Fan Relay Control B11 YE/BK 1827 Vehicle Speed Signal B11 YE/BK 1827 Vehicle Speed Signal B12 GY/BK 87 Cruise Control Resume/Accel Switch Signal B12 GY/BK 87 Cruise Control Resume/Accel Switch Signal C1 WH 121 Engine Speed Signal C1 WH 121 Engine Speed Signal C2 - - Not Used C2 - - Not Used C3 BK 2759 Fuel Tank Pressure Sensor Low Reference C3 BK 2759 Fuel Tank Pressure Sensor Low Reference C4 PK 1020 Ignition 0 Voltage C4 PK 1020 Ignition 0 Voltage C5 BN/WH 419 MIL Control C5 BN/WH 419 MIL Control C6-C7 - - Not Used C6-C7 - - Not Used C8 PU 420 TCC Brake Switch/Cruise Control Release Signal C8 PU 420 TCC Brake Switch/Cruise Control Release Signal C9 - - Not Used C9 - - Not Used C10 PU 1589 Fuel Level Sensor Signal C10 PU 1589 Fuel Level Sensor Signal C11 D-GN 1049 ECM/PCM/VCM Class 2 Serial Data C11 D-GN 1049 ECM/PCM/VCM Class 2 Serial Data C12 D-GN/WH 817 Vehicle Speed Signal C12 WH 817 Vehicle Speed Signal D1 D-BU 84 Cruise Control Set/Coast Switch Signal D1 D-BU 84 Cruise Control Set/Coast Switch Signal D2-D5 - - Not Used D2-D5 - - Not Used D6 D-GN 1433 PNP Start Switch Signal D6 D-GN 1433 PNP Start Switch Signal D7 - - Not Used D7 - - Not Used D8 OG 440 Battery Positive Voltage D8 OG 440 Battery Positive Voltage

Scheme 79

Scheme 80
