C108 Chevrolet SSR I

C108 Engine Harness to Ignition Coil Harness Connector End Connector Part Information 12047938 7-Way F Metri-Pack 150 Series, Sealed (L-GY) Connector Part Information 15326169 7-Way M Metri-Pack 150 Series, Sealed (L-GY) Pin Wire Color Circuit No. Function Pin Wire Color Circuit No. Function A BK 550 Ground A BK 151 Ground B RD/WH 2122 IC 2 Control B RD 2127 IC 2 Control C D-GN/WH 2124 IC 4 Control C D-GN 2125 IC 4 Control D - - Not Used D - - Not Used E BN/WH 2130 Low Reference E BN 2129 Low Reference F L-BU/WH 2126 IC 6 Control F L-BU 2123 IC 6 Control G PU/WH 2128 IC 8 Control G PU 2121 IC 8 Control H PK 1339 Ignition 1 Voltage H PK 1239 Ignition 1 Voltage

Scheme 83

Scheme 84
