C500 Body to Left Front Door Harness Connector End Connector Part Information OEM: 7283-6447-40 Service: NS 14-Way F Hybrid (BK) Connector Part Information OEM: 7282-6385-40 NS 14-Way M Hybrid (BK) Terminal Part Information Terminal: Terminal Seal: Release Tool: Core Crimp: Insulation Crimp: Test Probe: Terminal Part Information Terminal: Terminal Seal: Release Tool: Core Crimp: Insulation Crimp: Test Probe: Pin Wire Color Circuit No. Function Pin Wire Color Circuit No. Function 1 RD/WH 1040 Battery Positive Voltage 1 RD/WH 1040 Battery Positive Voltage 2 RD/WH 640 Battery Positive Voltage 2 RD/WH 640 Battery Positive Voltage 3 PK 1691 Automatic Day/Night Mirror Low Reference 3 PK 1691 Automatic Day/Night Mirror Low Reference 4 BK/WH 351 Signal Ground 4 BK/WH 351 Ground 5 YE 1956 Left Front Tweeter Speaker (-) 5 YE 1956 Left Front Tweeter Speaker (-) 6 TN 1856 Left Front Tweeter Speaker (+) 6 TN 1856 Left Front Tweeter Speaker (+) 7 BK 350 Ground 7 BK 350 Ground 8 D-BU 5882 Left Front Door Handle Switch Signal (2) 8 D-BU 5882 Left Front Door Handle Switch Signal (2) 9 PK 5709 Keyless Entry Antenna Signal (4) 9 PK 5709 Keyless Entry Antenna Signal (4) 10 PK/BK 5713 Keyless Entry Antenna Low Reference (4) 10 PK/BK 5713 Keyless Entry Antenna Low Reference (4) 11 PU/WH 5754 Amplifier Powered Woofer Control (1) (w/YQ3/YQ4/YQ6/YQ7) 11 PU/WH 5754 Amplifier Powered Woofer Control (1) (w/YQ3/YQ4/YQ6/YQ7) 12 GY 1690 Automatic Day/Night Mirror Signal 12 GY 1690 Automatic Day/Night Mirror Signal 13 D-GN 5060 Low Speed GMLAN Serial Data 13 D-GN 5060 Low Speed GMLAN Serial Data 14 BK/WH 850 Ground (w/YQ3/YQ4/YQ6/YQ7) 14 BK/WH 850 Ground (w/YQ3/YQ4/YQ6/YQ7)
