C310 Cadillac STS I

C310 Body to Sunroof Connector End (w/CF5) Connector Part Information OEM: 7282-5628-40 Service: NS 3-Way M YESC Hybrid (GY) Connector Part Information OEM: 7283-5628-40 NS 3-Way F YESC Class 3 (L-GY) Terminal Part Information Terminal: Terminal Seal: Release Tool: Core Crimp: Insulation Crimp: Test Probe: Terminal Part Information Terminal: Terminal Seal: Release Tool: Core Crimp: Insulation Crimp: Test Probe: Pin Wire Color Circuit No. Function Pin Wire Color Circuit No. Function 1 BK 1050 Ground 1 BK 1050 Ground 2 TN 755 Sunroof Enable Signal 2 BK 755 Sunroof Enable Signal 3 RD/WH 2640 Battery Positive Voltage 3 D-BU 2640 Battery Positive Voltage

Scheme 115
