C111 Cadillac STS I

C111 Forward Lamp to I/P Harness Connector End (w/K59,TT6) Connector Part Information OEM: 7283-5553-30 Service: NS 6-Way F YESC/USCAR Class 3 Sealed (BK) Connector Part Information OEM: 7282-5553-30 NS 6-Way M YESC/USCAR Class 3 (BK) Terminal Part Information Terminal: Terminal Seal: Release Tool: Core Crimp: Insulation Crimp: Test Probe: Terminal Part Information Terminal: Terminal Seal: Release Tool: Core Crimp: Insulation Crimp: Test Probe: Pin Wire Color Circuit No. Function Pin Wire Color Circuit No. Function 1 TN/BK 2500 High Speed GMLAN Serial Data (+) (1) 1 TN/BK 2500 High Speed GMLAN Serial Data (+) (1) 2 TN 2501 High Speed GMLAN Serial Data (-) (1) 2 TN 2501 High Speed GMLAN Serial Data (-) (1) 3 TN/BK 2500 High Speed GMLAN Serial Data (+) (1) 3 TN/BK 2500 High Speed GMLAN Serial Data (+) (1) 4 TN 2501 High Speed GMLAN Serial Data (-) (1) 4 TN 2501 High Speed GMLAN Serial Data (-) (1) 5 YE 5727 High Speed GMLAN Serial Data Wake Up 5 YE 5727 High Speed GMLAN Serial Data Wake Up 6 - - Not Used 6 - - Not Used

Scheme 97
