C201 Cadillac STS I

C201 Body to I/P Harness Right Center Connector End Connector Part Information OEM: 7283-6376-30 Service: NS 26-Way F Hybrid (BK) Connector Part Information OEM: 7282-6376-30 NS 26-Way M Hybrid (GY) Terminal Part Information Terminal: Terminal Seal: Release Tool: Core Crimp: Insulation Crimp: Test Probe: Terminal Part Information Terminal: Terminal Seal: Release Tool: Core Crimp: Insulation Crimp: Test Probe: Pin Wire Color Circuit No. Function Pin Wire Color Circuit No. Function 1 L-BU 1960 Front Center Speaker (-) (w/YQ2, YQ3/YQ4/YQ6/YQ7) 1 L-BU 1960 Front Center Speaker (-) 2 YE 1860 Front Center Speaker (+) (w/YQ2, YQ3/YQ4/YQ6/YQ7) 2 YE 1860 Front Center Speaker (+) 3 L-BU/WH 1314 Left Front Turn Signal Lamp Supply Voltage 3 L-BU/WH 1314 Left Front Turn Signal Lamp Supply Voltage 4 D-BU/WH 1315 Right Front Turn Signal Lamp Supply Voltage 4 D-BU/WH 1315 Right Front Turn Signal Lamp Supply Voltage 5 D-GN/WH 1932 Shift Select Switch Park Signal 5 D-GN/WH 1932 Shift Select Switch Park Signal D-GN/WH 1932 Shift Select Switch Park Signal (w/UA2) 6 D-GN 5525 Tap Up/Tap Down Enable Signal 6 D-GN 5525 Tap Up/Tap Down Enable Signal 7 GN/YE 6847 Shift Select Switch Park Supply Voltage 7 GN/YE 6847 Shift Select Switch Park Supply Voltage 8 PK 3 Run/Crank Ignition 1 Voltage 8 PK 3 Run/Crank Ignition 1 Voltage 9 - - Not Used 9 - - Not Used 10 D-GN 1947 Left Front Low Level Audio (-) (w/YQ2, YQ3/YQ4/YQ6/YQ7) 10 D-GN 1947 Left Front Low Level Audio (-) 11 TN 511 Left Front Low Level Audio Signal (w/YQ2, YQ3/YQ4/YQ6/YQ7) 11 TN 511 Left Front Low Level Audio Signal 12 L-BU/WH 5725 Ignition Mode Switch Mode Voltage Backup 12 L-BU/WH 5725 Ignition Mode Switch Mode Voltage Backup 13 L-BU 5726 Ignition Mode Switch Mode Control Backup 13 L-BU 5726 Ignition Mode Switch Mode Control Backup 14 PK 5165 Antenna 14-Volt Switched Supply Voltage 14 PK 5165 Antenna 14-Volt Switched Supply Voltage 15 BN 253 Trunk Release Relay Control 15 BN 253 Trunk Release Relay Control 16 - - Not Used 16 - - Not Used 17 BK/WH 851 Signal Ground 17 BK/WH 851 Signal Ground BK/WH 851 Signal Ground 18 D-GN/WH 512 Right Front Low Level Audio Signal 18 D-GN/WH 512 Right Front Low Level Audio Signal 19 BARE 2012 Right Front Audio Drain Wire 19 BARE 2012 Right Front Audio Drain Wire 20 L-GN 1948 Right Front Low Level Audio (-) 20 L-GN 1948 Right Front Low Level Audio (-) 21-25 - - Not Used 21-25 - - Not Used 26 RD/WH 2240 Battery Positive Voltage 26 RD/WH 2240 Battery Positive Voltage RD/WH 2240 Battery Positive Voltage

Scheme 104
