C106 Cadillac STS I

C106 Engine to POA Jumper Harness Connector End (LY7) Connector Part Information OEM: 12059472 Service: 12101830 7-Way F 150/280 Series GT (BK) Connector Part Information OEM: 12052200 12117321 7-Way M 150/480 Series (BK) Terminal Part Information Terminal: Terminal Seal: Release Tool: Core Crimp: Insulation Crimp: Test Probe: Terminal Part Information Terminal: Terminal Seal: Release Tool: Core Crimp: Insulation Crimp: Test Probe: Pin Wire Color Circuit No. Function Pin Wire Color Circuit No. Function A PK/BK 5291 Engine Main Relay Fused Control (2) A PK/BK 5291 Engine Main Relay Fused Control (2) B - - Not Used B - - Not Used C D-GN 59 A/C Compressor Clutch Supply Voltage C D-GN 59 A/C Compressor Clutch Supply Voltage D PK/BK 5292 Engine Main Relay Fused Control (3) D PK/BK 5292 Engine Main Relay Fused Control (3) E PU 6 Starter Solenoid Crank Voltage E PU 6 Starter Solenoid Feed F PK/BK 5293 Engine Main Relay Fused Control (4) F PK/BK 5293 Engine Main Relay Fused Control (4) G BK/WH 751 Signal Ground G BK/WH 1451 Signal Ground

Scheme 96
