C212 Cadillac STS I

C212 Body to Console Harness Connector End Connector Part Information OEM: 7282-3442-40 Service: NS 12-Way M YESC (GY) Connector Part Information OEM: 7283-5540-40 NS 12-Way F YESC 1.5 Series (GY) Terminal Part Information Terminal: Terminal Seal: Release Tool: Core Crimp: Insulation Crimp: Test Probe: Terminal Part Information Terminal: Terminal Seal: Release Tool: Core Crimp: Insulation Crimp: Test Probe: Pin Wire Color Circuit No. Function Pin Wire Color Circuit No. Function 1 OG 5756 Center Console Speaker (+) (w/YQ3/YQ4/YQ6/YQ7) 1 OG 5756 Center Console Speaker (+) (w/YQ3/YQ4/YQ6/YQ7) 2 PU/WH 5715 Keyless Entry Active Antenna Supply Voltage 2 PU/WH 5715 Keyless Entry Active Antenna Supply Voltage 3 YE 1491 Backlight Lamp Control 3 YE 1491 Backlight Lamp Control 4 OG/BK 5718 Keyless Entry Active Antenna Low Reference 4 OG/BK 5718 Keyless Entry Active Antenna Low Reference 5 GY 5717 Keyless Entry Active Antenna Data Signal 5 GY 5717 Keyless Entry Active Antenna Data Signal 6 L-BU 5716 Keyless Entry Active Antenna Clock Signal 6 L-BU 5716 Keyless Entry Active Antenna Clock Signal 7 OG/BK 5766 Console Center Speaker (-) (w/YQ3/YQ4/YQ6/YQ7) 7 OG/BK 5766 Console Center Speaker (-) (w/YQ3/YQ4/YQ6/YQ7) 8 YE 18 Left Rear Stop/Turn Lamp Supply Voltage 8 YE 18 Left Rear Stop/Turn Lamp Supply Voltage 9 TN 219 Keyless Entry Antenna Low Reference (1) 9 TN 219 Keyless Entry Antenna Low Reference (1) 10 BK 450 Ground 10 BK 450 Ground 11 PU 218 Keyless Entry Antenna Signal (1) 11 PU 218 Keyless Entry Antenna Signal (1) 12 WH 111 Hazard Switch Signal 12 WH 111 Hazard Switch Signal

Scheme 106
