Scheme 396
Scheme 396: Seat Adjuster Switch - Driver
| Connector Part Information Harness: Seat OEM: 15326931 Service: 15306309 Description: 10-Way F GT 280 Series (BK) |
|---|
| Terminal Part Information Terminal/Tray: Service by Harness - See Part Catalog Core/Insulation Crimp: N/A Release Tool/Test Probe: 15315247/J-35616-4A (PU) |
| Pin | Wire | Circuit | Function |
|---|
| A | 3 D-GN | 286 | Driver Seat Front Vertical Motor Up Control (without A45) |
| 0.35 D-GN | 1518 | Power Seat Front Vertical Up Switch Signal (A45) |
| B | 3 BK | 350 | Ground (without A45) |
| C | 3 L-GN | 284 | Driver Seat Horizontal Motor Rearward Control (without A45) |
| 0.35 L-GN | 1523 | Power Seat Horizontal Rearward Switch Signal (A45) |
| D | 3 TN | 285 | Driver Seat Horizontal Motor Forward Control (without A45) |
| 0.35 TN | 1522 | Power Seat Horizontal Forward Switch Signal (A45) |
| E | 0.35 OG | 3840 | Battery Positive Voltage (without A45) |
| 0.35 PU/WH | 6205 | Driver Position Switch High Reference (A45) |
| F | 3 YE | 282 | Driver Seat Rear Vertical Motor Up Control (without A45) |
| 0.35 YE | 1519 | Power Seat Rear Vertical Up Switch Signal (A45) |
| G | 3 L-GN | 276 | Driver Seat Recline Motor Forward Control (without A45) |
| 0.35 D-GN/WH | 1270 | Power Seat Recline Rearward Switch Signal (A45) |
| H | 3 L-BU | 277 | Recline Motor Rearward Control (without A45) |
| 0.35 GY/BK | 1269 | Power Seat Recline Forward Switch Signal (A45) |
| J | 3 L-BU/BK | 283 | Driver Seat Rear Vertical Motor Down Control (without A45) |
| 0.35 L-BU | 1521 | Power Seat Rear Vertical Down Switch Signal (A45) |
| K | 3 D-BU | 287 | Driver Seat Front Vertical Motor Down Control (without A45) |
| 0.35 D-BU | 1520 | Power Seat Front Vertical Down Switch Signal (A45) |
Seat Adjuster Switch - Driver
Seat Adjuster Switch - Passenger (AH8)
| Connector Part Information Harness: Seat OEM: 15326931 Service: 15306309 Description: 10-Way F GT 280 Series (BK) |
|---|
| Terminal Part Information Terminal/Tray: Service by Harness - See Part Catalog Core/Insulation Crimp: N/A Release Tool/Test Probe: 15315247/J-35616-4A (PU) |
| Pin | Wire | Circuit | Function |
|---|
| A | 3 D-BU | 287 | Driver Seat Front Vertical Motor Down Control |
| B | 3 BK | 450 | Ground |
| C | 3 L-GN | 284 | Driver Seat Horizontal Motor Rearward Control |
| D | 3 TN | 285 | Driver Seat Horizontal Motor Forward Control |
| E | 3 RD/WH | 3940 | Battery Positive Voltage |
| F | 3 L-BU/BK | 283 | Driver Seat Rear Vertical Motor Down Control |
| G | 3 L-GN | 276 | Recline Motor Forward Control |
| H | 3 L-BU | 277 | Driver Seat Recline Motor Rearward Control |
| J | 3 YE | 282 | Driver Seat Rear Vertical Motor Up Control |
| K | 3 D-GN | 286 | Driver Seat Front Vertical Motor Up Control |
Seat Adjuster Switch - Passenger (AH8)
Scheme 397
Scheme 397: Seat Back Ventilation Heating and Cooling Module - Driver (KB6)
| Connector Part Information Harness: Seat OEM: 12065423 Service: 12117371 Description: 3-Way M Metri-Pack 150 Series (NA) |
|---|
| Terminal Part Information Terminal/Tray: Service by Harness - See Part Catalog Core/Insulation Crimp: N/A Release Tool/Test Probe: 12094429/J-35616-3 (GY) |
| Pin | Wire | Circuit | Function |
|---|
| A | 0.35 OG | 5919 | Driver Seat Blower Speed Control |
| B | 0.35 BK | 350 | Ground |
| C | 0.35 PK | 539 | Ignition 1 Voltage |
Seat Back Ventilation Heating and Cooling Module - Driver (KB6)
Seat Back Ventilation Heating and Cooling Module - Passenger (KB6)
| Connector Part Information Harness: Seat OEM: 12065423 Service: 12117371 Description: 3-Way M Metri-Pack 150 Series (NA) |
|---|
| Terminal Part Information Terminal/Tray: Service by Harness - See Part Catalog Core/Insulation Crimp: N/A Release Tool/Test Probe: 12094429/J-35616-3 (GY) |
| Pin | Wire | Circuit | Function |
|---|
| A | 0.35 D-BU | 5915 | Passenger Seat Blower Speed Control |
| B | 0.35 BK | 450 | Ground |
| C | 0.35 PK | 539 | Ignition 1 Voltage |
Seat Back Ventilation Heating and Cooling Module - Passenger (KB6)
Scheme 398
Scheme 398: Seat Belt Pretensioner - Driver (LSA)
| Connector Part Information Harness: Seat OEM: 19153416 Service: Service by Harness - See Part Catalog Description: 2-Way F (BK) |
|---|
| Terminal Part Information Terminal/Tray: Service by Harness - See Part Catalog Core/Insulation Crimp: N/A Release Tool/Test Probe: N/A |
| Pin | Wire | Circuit | Function |
|---|
| 1 | 0.35 L-GN | 3477 | Seat Belt Pretensioner Low Control |
| 2 | 0.35 PK | 3478 | Seat Belt Pretensioner High Control |
Seat Belt Pretensioner - Driver (LSA)
Seat Belt Pretensioner - Passenger (LSA)
| Connector Part Information Harness: Seat OEM: 19153416 Service: Service by Harness - See Part Catalog Description: 2-Way F (BK) |
|---|
| Terminal Part Information Terminal/Tray: Service by Harness - See Part Catalog Core/Insulation Crimp: N/A Release Tool/Test Probe: N/A |
| Pin | Wire | Circuit | Function |
|---|
| 1 | 0.35 L-GN | 3475 | Seat Belt Pretensioner Low Control |
| 2 | 0.35 PK | 3476 | Seat Belt Pretensioner High Control |
Seat Belt Pretensioner - Passenger (LSA)
Scheme 399
Scheme 399: Seat Belt Retractor Pretensioner - Driver
| Connector Part Information Harness: Body OEM: 1376030-1 Service: 88988308 Description: 2-Way F Squib Unsealed (YE) |
|---|
| Terminal Part Information Terminal/Tray: Service by Pigtail - See Part Catalog Core/Insulation Crimp: N/A Release Tool/Test Probe: N/A |
| Pin | Wire | Circuit | Function |
|---|
| 1 | 0.35 TN/WH | 2118 | Seat Belt Retractor Pretensioner - Left - High Control |
| 2 | 0.35 OG/BK | 2119 | Seat Belt Retractor Pretensioner - Left - Low Control |
Seat Belt Retractor Pretensioner - Driver
Seat Belt Retractor Pretensioner - Passenger
| Connector Part Information Harness: Body OEM: 1376030-1 Service: 88988308 Description: 2-Way F Squib Unsealed (YE) |
|---|
| Terminal Part Information Terminal/Tray: Service by Pigtail - See Part Catalog Core/Insulation Crimp: N/A Release Tool/Test Probe: N/A |
| Pin | Wire | Circuit | Function |
|---|
| 1 | 0.35 L-GN | 2116 | Seat Belt Retractor Pretensioner - Right - High Control |
| 2 | 0.35 OG | 2117 | Seat Belt Retractor Pretensioner - Right - Low Control |
Seat Belt Retractor Pretensioner - Passenger
Scheme 400
Scheme 400: Seat Belt Switch - Driver
| Connector Part Information Harness: Seat OEM: 12047663 Service: 12085481 Description: 2-Way M Metri-Pack 150 Series (BK) |
|---|
| Terminal Part Information Terminal/Tray: 12047581/2 Core/Insulation Crimp: E/C Release Tool: 12094429 Test Probe: J-35616-3 (GY) |
| Pin | Wire | Circuit | Function |
|---|
| A | 0.35 TN/WH | 238 | Driver Seat Belt Switch Signal |
| B | 0.35 D-BU | 1363 | Driver Seat Belt Switch Low Reference |
Seat Belt Switch - Driver
Seat Belt Switch - Passenger
| Connector Part Information Harness: Seat OEM: 12047663 Service: 12085481 Description: 2-Way M Metri-Pack 150 Series (BK) |
|---|
| Terminal Part Information Terminal/Tray: 12047581/2 Core/Insulation Crimp: E/C Release Tool: 12094429 Test Probe: J-35616-3 (GY) |
| Pin | Wire | Circuit | Function |
|---|
| A | 0.35 OG | 1362 | Passenger Seat Belt Switch Signal |
| B | 0.35 L-BU/WH | 1361 | Passenger Seat Belt Switch Low Reference |
Seat Belt Switch - Passenger
Scheme 401
Scheme 401: Seat Bolster Adjuster Valve - Driver (W2E)
| Connector Part Information Harness: Seat OEM: 1-1241370-3 Service: 13505903 Description: 6-Way F MQS Series (BK) |
|---|
| Terminal Part Information Terminal/Tray: Service by Harness - See Part Catalog Core/Insulation Crimp: N/A Release Tool/Test Probe: Pending |
| Pin | Wire | Circuit | Function |
|---|
| 1 | 0.5 BK | 350 | Ground |
| 2 | 0.35 OG | 5891 | Driver Power Seat Bolster Motor Out Control |
| 3 | 0.35 PK | 5892 | Driver Power Seat Bolster Motor In Control |
| 4 | 0.35 D-BU | 5894 | Driver Seat Bolster Out Switch Signal |
| 5 | 0.35 BN | 5893 | Driver Seat Bolster In Switch Signal |
| 6 | 0.5 TN/WH | 5008 | Driver Adaptive Seat Pump Motor Supply Voltage |
Seat Bolster Adjuster Valve - Driver (W2E)
Seat Bolster Adjuster Valve - Passenger (W2E)
| Connector Part Information Harness: Seat OEM: 1-1241370-3 Service: 13505903 Description: 6-Way F MQS Series (BK) |
|---|
| Terminal Part Information Terminal/Tray: Service by Harness - See Part Catalog Core/Insulation Crimp: N/A Release Tool/Test Probe: Pending |
| Pin | Wire | Circuit | Function |
|---|
| 1 | 0.5 BK | 450 | Ground |
| 2 | 0.35 OG | 5891 | Driver Power Seat Bolster Motor Out Control |
| 3 | 0.35 PK | 5892 | Driver Power Seat Bolster Motor In Control |
| 4 | 0.35 D-BU | 5894 | Driver Seat Bolster Out Switch Signal |
| 5 | 0.35 BN | 5893 | Driver Seat Bolster In Switch Signal |
| 6 | 0.5 TN/WH | 5008 | Driver Adaptive Seat Pump Motor Supply Voltage |
Seat Bolster Adjuster Valve - Passenger (W2E)
Scheme 402
Scheme 402: Seat Bolster Switch - Driver Back (W2E)
| Connector Part Information Harness: Seat OEM: 12041429 Service: 12167129 Description: 5-Way F Metri-Pack 280 Series (BK) |
|---|
| Terminal Part Information Terminal/Tray: Service by Harness - See Part Catalog Core/Insulation Crimp: N/A Release Tool/Test Probe: 12094430/J-35616-4A (PU) |
| Pin | Wire | Circuit | Function |
|---|
| A | | | Not Used |
| B | 0.35 PK | 5892 | Bolster Deflate |
| C | | | Not Used |
| D | 0.5 RD/WH | 3840 | Battery Voltage |
| E | 0.35 OG | 5891 | Bolster Inflate |
Seat Bolster Switch - Driver Back (W2E)
Seat Bolster Switch - Driver Cushion (W2E)
| Connector Part Information Harness: Seat OEM: 12041429 Service: 12167129 Description: 5-Way F Metri-Pack 280 Series (BK) |
|---|
| Terminal Part Information Terminal/Tray: Service by Harness - See Part Catalog Core/Insulation Crimp: N/A Release Tool/Test Probe: 12094430/J-35616-4A (PU) |
| Pin | Wire | Circuit | Function |
|---|
| A | | | Not Used |
| B | 0.35 BN | 5893 | Bolster Deflate |
| C | | | Not Used |
| D | 0.5 RD/WH | 3840 | Battery Voltage |
| E | 0.35 D-BU | 5894 | Bolster Inflate |
Seat Bolster Switch - Driver Cushion (W2E)
Seat Bolster Switch - Passenger Back (W2E)
| Connector Part Information Harness: Seat OEM: 12041429 Service: 12167129 Description: 5-Way F Metri-Pack 280 Series (BK) |
|---|
| Terminal Part Information Terminal/Tray: Service by Harness - See Part Catalog Core/Insulation Crimp: N/A Release Tool/Test Probe: 12094430/J-35616-4A (PU) |
| Pin | Wire | Circuit | Function |
|---|
| A | | | Not Used |
| B | 0.35 PK | 5892 | Bolster Deflate |
| C | | | Not Used |
| D | 0.5 RD/WH | 3840 | Battery Voltage |
| E | 0.35 OG | 5891 | Bolster Inflate |
Seat Bolster Switch - Passenger Back (W2E)
Seat Bolster Switch - Passenger Cushion (W2E)
| Connector Part Information Harness: Seat OEM: 12041429 Service: 12167129 Description: 5-Way F Metri-Pack 280 Series (BK) |
|---|
| Terminal Part Information Terminal/Tray: Service by Harness - See Part Catalog Core/Insulation Crimp: N/A Release Tool/Test Probe: 12094430/J-35616-4A (PU) |
| Pin | Wire | Circuit | Function |
|---|
| A | | | Not Used |
| B | 0.35 BN | 5893 | Bolster Deflate |
| C | | | Not Used |
| D | 0.5 RD/WH | 3840 | Battery Voltage |
| E | 0.35 D-BU | 5894 | Bolster Inflate |
Seat Bolster Switch - Passenger Cushion (W2E)
Seat Cushion Ventilation Heating and Cooling Module - Driver (KB6)
| Connector Part Information Harness: Seat OEM: 12065423 Service: 12117371 Description: 3-Way M Metri-Pack 150 Series (NA) |
|---|
| Terminal Part Information Terminal/Tray: Service by Harness - See Part Catalog Core/Insulation Crimp: N/A Release Tool/Test Probe: 12094429/J-35616-3 (GY) |
| Pin | Wire | Circuit | Function |
|---|
| A | 0.35 OG | 5919 | Driver Seat Blower Speed Control |
| B | 0.35 BK | 450 | Ground |
| C | 0.35 PK | 539 | Ignition 1 Voltage |
Seat Cushion Ventilation Heating and Cooling Module - Driver (KB6)
Seat Cushion Ventilation Heating and Cooling Module - Passenger (KB6)
| Connector Part Information Harness: Seat OEM: 12065423 Service: 12117371 Description: 3-Way M Metri-Pack 150 Series (NA) |
|---|
| Terminal Part Information Terminal/Tray: Service by Harness - See Part Catalog Core/Insulation Crimp: N/A Release Tool/Test Probe: 12094429/J-35616-3 (GY) |
| Pin | Wire | Circuit | Function |
|---|
| A | 0.35 D-BU | 5915 | Passenger Seat Blower Speed Control |
| B | 0.35 BK | 350 | Ground |
| C | 0.35 PK | 539 | Ignition 1 Voltage |
Seat Cushion Ventilation Heating and Cooling Module - Passenger (KB6)
Scheme 403
Scheme 403: Seat Front Vertical Motor - Driver
| Connector Part Information Harness: Seat OEM: 1438992-1 Service: Service by Harness - See Part Catalog Description: 5-Way F MQS/MPQ Mixed Series (BK) |
|---|
| Terminal Part Information Terminal/Tray: Service by Harness - See Part Catalog Core/Insulation Crimp: N/A Release Tool/Test Probe: 12031876-1/J-35616-4A (PU) |
| Pin | Wire | Circuit | Function |
|---|
| 1 | 3 D-GN | 286 | Driver Seat Front Vertical Motor Up Control |
| 2-4 | | | Not Used |
| 5 | 3 D-BU | 287 | Driver Seat Front Vertical Motor Down Control |
Seat Front Vertical Motor - Driver
Seat Front Vertical Motor - Passenger (AH8)
| Connector Part Information Harness: Seat OEM: 1438992-1 Service: Service by Harness - See Part Catalog Description: 5-Way F MQS/MPQ Mixed Series (BK) |
|---|
| Terminal Part Information Terminal/Tray: Service by Harness - See Part Catalog N/A Release Tool/Test Probe: 12031876-1/J-35616-4A (PU) |
| Pin | Wire | Circuit | Function |
|---|
| 1 | 3 D-BU | 287 | Seat Front Vertical Motor Down Control |
| 2-4 | | | Not Used |
| 5 | 3 D-GN | 286 | Seat Front Vertical Motor Up Control |
Seat Front Vertical Motor - Passenger (AH8)
Scheme 404
Scheme 404: Seat Front Vertical Motor Position Sensor - Driver (A45)
| Connector Part Information Harness: Seat OEM: 12047781 Service: 12101864 Description: 3-Way F Metri-Pack 150 Series (BK) |
|---|
| Terminal Part Information Terminal/Tray: 15326030/2 Core/Insulation Crimp: E/C Release Tool/Test Probe: 12094429/J-35616-14 (GN) |
| Pin | Wire | Circuit | Function |
|---|
| A | 0.35 TN | 6207 | Memory Sensor High Reference |
| B | 0.35 BN/WH | 557 | Front Vertical Seat Motor Position Sensor Signal |
| C | 0.35 GY | 6206 | Memory Sensor Low Reference |
Seat Front Vertical Motor Position Sensor - Driver (A45)
Seat Horizontal Motor - Driver
| Connector Part Information Harness: Seat OEM: 1438992-5 Service: Service by Harness - See Part Catalog Description: 5-Way F (BU) |
|---|
| Terminal Part Information Terminal/Tray: Service by Harness - See Part Catalog N/A Release Tool/Test Probe: 12031876-1/J-35616-4A (PU) |
| Pin | Wire | Circuit | Function |
|---|
| 1 | 1 TN | 285 | Driver Seat Horizontal Motor Forward Control |
| 2-4 | | | Not Used |
| 5 | 1 L-GN | 284 | Driver Seat Horizontal Motor Rearward Control |
Seat Horizontal Motor - Driver
Seat Horizontal Motor - Passenger (AH8 or AL2)
| Connector Part Information Harness: Seat OEM: 1438992-5 Service: Service by Harness - See Part Catalog Description: 5-Way F (BU) |
|---|
| Terminal Part Information Terminal/Tray: Service by Harness - See Part Catalog Core/Insulation Crimp: N/A Release Tool/Test Probe: 12031876-1/J-35616-4A (PU) |
| Pin | Wire | Circuit | Function |
|---|
| 1 | 3 TN | 285 | Seat Horizontal Motor Forward Control |
| 2-4 | | | Not Used |
| 5 | 3 L-GN | 284 | Seat Horizontal Motor Rearward Control |
Seat Horizontal Motor - Passenger (AH8 or AL2)
Seat Horizontal Motor Position Sensor - Driver (A45)
| Connector Part Information Harness: Seat OEM: 12047781 Service: 12101864 Description: 3-Way F Metri-Pack 150 Series (BK) |
|---|
| Terminal Part Information Terminal/Tray: 15326030/2 Core/Insulation Crimp: E/C Release Tool/Test Probe: 12094429/J-35616-14 (GN) |
| Pin | Wire | Circuit | Function |
|---|
| A | 0.35 TN | 6207 | Memory Sensor High Reference |
| B | 0.35 D-GN | 569 | Horizontal Seat Motor Position Sensor Signal |
| C | 0.35 GY | 6206 | Memory Sensor Low Reference |
Seat Horizontal Motor Position Sensor - Driver (A45)
Seat Lumbar Adjuster Valve - Driver (W2E)
| Connector Part Information Harness: Seat OEM: 1-1241370-3 Service: 13505903 Description: 6-Way F MQS Series (BK) |
|---|
| Terminal Part Information Terminal/Tray: Service by Harness - See Part Catalog Core/Insulation Crimp: N/A Release Tool/Test Probe: Pending |
| Pin | Wire | Circuit | Function |
|---|
| 1 | 0.35 WH | 1066 | Driver Seat Lumbar Up Switch Signal |
| 2 | 0.35 D-BU | 1064 | Driver Seat Lumbar Rearward Switch Signal |
| 3 | 0.35 YE/BK | 1067 | Driver Seat Lumbar Down Switch Signal |
| 4 | 0.35 YE | 1065 | Driver Seat Lumbar Forward Switch Signal |
| 5 | 0.5 BK | 350 | Ground |
| 6 | 0.5 TN/WH | 5008 | Driver Adaptive Seat Pump Motor Supply Voltage |
Seat Lumbar Adjuster Valve - Driver (W2E)
Seat Lumbar Adjuster Valve - Passenger (W2E)
| Connector Part Information Harness: Seat OEM: 1-1241370-3 Service: 13505903 Description: 6-Way F MQS Series (BK) |
|---|
| Terminal Part Information Terminal/Tray: Service by Harness - See Part Catalog Core/Insulation Crimp: N/A Release Tool/Test Probe: Pending |
| Pin | Wire | Circuit | Function |
|---|
| 1 | 0.35 WH | 1066 | Driver Seat Lumbar Up Switch Signal |
| 2 | 0.35 D-BU | 1064 | Driver Seat Lumbar Rearward Switch Signal |
| 3 | 0.35 YE/BK | 1067 | Driver Seat Lumbar Down Switch Signal |
| 4 | 0.35 YE | 1065 | Driver Seat Lumbar Forward Switch Signal |
| 5 | 0.5 BK | 450 | Ground |
| 6 | 0.5 TN/WH | 5008 | Driver Adaptive Seat Pump Motor Supply Voltage |
Seat Lumbar Adjuster Valve - Passenger (W2E)
Seat Lumbar Adjuster Switch - Driver (AL2 without W2E)
| Connector Part Information Harness: Seat OEM: 12041429 Service: 12167129 Description: 5-Way F Metri-Pack 280 Series (BK) |
|---|
| Terminal Part Information Terminal/Tray: Service by Harness - See Part Catalog Core/Insulation Crimp: N/A Release Tool/Test Probe: 12094430/J-35616-4A (PU) |
| Pin | Wire | Circuit | Function |
|---|
| A | | | Not Used |
| B | 0.35 YE | 1065 | Driver Seat Lumbar Forward Switch Signal |
| C | | | Not Used |
| D | 0.35 PU/WH | 6205 | Driver Position Switch High Reference |
| E | 0.35 D-BU | 1064 | Driver Seat Lumbar Rearward Switch Signal |
Seat Lumbar Adjuster Switch - Driver (AL2 without W2E)
Seat Lumbar Adjuster Switch - Passenger (AL2 without W2E)
| Connector Part Information Harness: Seat OEM: 12041429 Service: 12167129 Description: 5-Way F Metri-Pack 280 Series (BK) |
|---|
| Terminal Part Information Terminal/Tray: Service by Harness - See Part Catalog Core/Insulation Crimp: N/A Release Tool/Test Probe: 12094430/J-35616-4A (PU) |
| Pin | Wire | Circuit | Function |
|---|
| A | 3 BK | 450 | Ground |
| B | 3 D-BU | 211 | Passenger Seat Lumbar Motor Forward Control |
| C | 3 BK | 450 | Ground |
| D | 3 RD/WH | 3940 | Battery Positive Voltage |
| E | 3 WH | 210 | Passenger Seat Lumbar Motor Rearward Control |
Seat Lumbar Adjuster Switch - Passenger (AL2 without W2E)
Scheme 405
Scheme 405: Seat Lumbar Horizontal Motor - Driver - X1 (AL2 without W2E)
| Connector Part Information Harness: Seat OEM: 12020556 Service: 12101820 Description: 2-Way F Metri-Pack 480 Series (BK) |
|---|
| Terminal Part Information Terminal/Tray: Service by Harness - See Part Catalog Core/Insulation Crimp: N/A Release Tool/Test Probe: 12094430/J-35616-40 (BU) |
| Pin | Wire | Circuit | Function |
|---|
| A | 1 D-BU | 611 | Driver Seat Lumbar Motor Forward Control |
| B | 1 PK | 610 | Driver Seat Lumbar Motor Rearward Control |
Seat Lumbar Horizontal Motor - Driver - X1 (AL2 without W2E)
Scheme 406
Scheme 406: Seat Lumbar Horizontal Motor - Driver - X2 (AL2 with A45 without W2E)
| Connector Part Information Harness: Seat OEM: 50-57-9703 Service: Service by Harness - See Part Catalog Description: 2-Way F Metri-Pack 480 Series (BK) |
|---|
| Terminal Part Information Terminal/Tray: Service by Harness - See Part Catalog Core/Insulation Crimp: N/A Release Tool/Test Probe: Pending |
| Pin | Wire | Circuit | Function |
|---|
| 1 | 0.35 GY | 6206 | Memory Seat Sensor Low Reference |
| 2 | 0.35 YE | 1063 | Memory Seat Lumbar Horizontal Position Sensor Signal |
| 3 | 0.35 TN | 6207 | Memory Sensor High Reference |
Seat Lumbar Horizontal Motor - Driver - X2 (AL2 with A45 without W2E)
Seat Lumbar Horizontal Motor - Passenger (AL2 without W2E)
| Connector Part Information Harness: Seat OEM: 12020556 Service: 12101820 Description: 2-Way F Metri-Pack 480 Series (BK) |
|---|
| Terminal Part Information Terminal/Tray: Service by Harness - See Part Catalog Core/Insulation Crimp: N/A Release Tool/Test Probe: 12094430/J-35616-40 (BU) |
| Pin | Wire | Circuit | Function |
|---|
| A | 3 D-BU | 211 | Passenger Seat Lumbar Motor Forward Control |
| B | 3 WH | 210 | Passenger Seat Lumbar Motor Rearward Control |
Seat Lumbar Horizontal Motor - Passenger (AL2 without W2E)
Scheme 407
Scheme 407: Seat Lumbar Switch - Driver (W2E)
| Connector Part Information Harness: Seat OEM: 12052854 Service: 15862656 Description: 7-Way F Metri-Pack 280 Series (BK) |
|---|
| Terminal Part Information Terminal/Tray: Service by Harness - See Part Catalog Core/Insulation Crimp: N/A Release Tool/Test Probe: 12094430/J-35616-4A (PU) |
| Pin | Wire | Circuit | Function |
|---|
| A | 0.35 YE/BK | 1067 | Lumbar Down |
| B | 0.35 D-BU | 1064 | Lumbar Increase |
| C | 0.35 YE | 1065 | Lumbar Decrease |
| D-E | | | Not Used |
| F | 0.35 WH | 1066 | Lumbar Up |
| G | 0.5 RD/WH | 3840 | Battery Voltage |
Seat Lumbar Switch - Driver (W2E)
Seat Lumbar Switch - Passenger (W2E)
| Connector Part Information Harness: Seat OEM: 12052854 Service: 15862656 Description: 7-Way F Metri-Pack 280 Series (BK) |
|---|
| Terminal Part Information Terminal/Tray: Service by Harness - See Part Catalog Core/Insulation Crimp: N/A Release Tool/Test Probe: N/A |
| Pin | Wire | Circuit | Function |
|---|
| A | 0.35 YE/BK | 1067 | Lumbar Down |
| B | 0.35 YE | 1065 | Lumbar Increase |
| C | 0.35 D-BU | 1064 | Lumbar Decrease |
| D-E | | | Not Used |
| F | 0.35 WH | 1066 | Lumbar Up |
| G | 0.5 RD/WH | 3840 | Battery Voltage |
Seat Lumbar Switch - Passenger (W2E)
Seat Rear Vertical Motor - Driver
| Connector Part Information Harness: Seat OEM: 1438992-4 Service: Service by Harness - See Part Catalog Description: 5-Way F (WH) |
|---|
| Terminal Part Information Terminal/Tray: Service by Harness - See Part Catalog Core/Insulation Crimp: N/A Release Tool/Test Probe: 12031876-1/J-35616-4A (PU) |
| Pin | Wire | Circuit | Function |
|---|
| 1 | 1 L-BU/BK | 283 | Driver Seat Rear Vertical Motor Down Control |
| 2-4 | | | Not Used |
| 5 | 1 YE | 282 | Driver Seat Rear Vertical Motor Up Control |
Seat Rear Vertical Motor - Driver
Seat Rear Vertical Motor - Passenger (AH8)
| Connector Part Information Harness: Seat OEM: 1438992-4 Service: Service by Harness - See Part Catalog Description: 5-Way F (WH) |
|---|
| Terminal Part Information Terminal/Tray: Service by Harness - See Part Catalog Core/Insulation Crimp: N/A Release Tool/Test Probe: 12031876-1/J-35616-4A (PU) |
| Pin | Wire | Circuit | Function |
|---|
| 1 | 3 YE | 282 | Seat Rear Vertical Motor Up Control |
| 2-4 | | | Not Used |
| 5 | 3 L-BU/BK | 283 | Seat Rear Vertical Motor Down Control |
Seat Rear Vertical Motor - Passenger (AH8)
Seat Rear Vertical Position Sensor - Driver (A45)
| Connector Part Information Harness: Seat OEM: 12065422 Service: 12101864 Description: 3-Way F Metri-Pack 150 Series (NA) |
|---|
| Terminal Part Information Terminal/Tray: Service by Harness - See Part Catalog Core/Insulation Crimp: N/A Release Tool/Test Probe: 12094429/J-35616-14 (GN) |
| Pin | Wire | Circuit | Function |
|---|
| A | 0.35 GY | 6206 | Memory Sensor Low Reference |
| B | 0.35 TN/BK | 568 | Rear Vertical Seat Motor Position Sensor Signal |
| C | 0.35 TN | 6207 | Memory Sensor High Reference |
Seat Rear Vertical Position Sensor - Driver (A45)
Seat Recline Motor - Driver
| Connector Part Information Harness: Seat OEM: 1438992-1 Service: Service by Harness - See Part Catalog Description: 5-Way F (BK) |
|---|
| Terminal Part Information Terminal/Tray: Service by Harness - See Part Catalog Core/Insulation Crimp: N/A Release Tool/Test Probe: 12031876-1/J-35616-4A (PU) |
| Pin | Wire | Circuit | Function |
|---|
| 1 | 1 L-BU | 277 | Driver Seat Recline Motor Rearward Control |
| 2-4 | | | Not Used |
| 5 | 1 L-GN | 276 | Driver Seat Recline Motor Forward Control |
Seat Recline Motor - Driver
Seat Recline Motor - Passenger (AH8)
| Connector Part Information Harness: Seat OEM: 1438992-1 Service: Service by Harness - See Part Catalog Description: 5-Way F (BK) |
|---|
| Terminal Part Information Terminal/Tray: Service by Harness - See Part Catalog Core/Insulation Crimp: N/A Release Tool/Test Probe: 12031876-1/J-35616-4A (PU) |
| Pin | Wire | Circuit | Function |
|---|
| 1 | 3 L-GN | 276 | Seat Recline Motor Forward Control |
| 2-4 | | | Not Used |
| 5 | 3 L-BU | 277 | Seat Recline Motor Rearward Control |
Seat Recline Motor - Passenger (AH8)
Scheme 408
Scheme 408: Seat Recline Position Sensor - Driver (A45)
| Connector Part Information Harness: Seatback OEM: 31067-1010 Service: Service by Harness - See Part Catalog Description: 3-Way F Metri-Pack 150 Series (BK) |
|---|
| Terminal Part Information Terminal/Tray: Service by Harness - See Part Catalog Core/Insulation Crimp: N/A Release Tool/Test Probe: Pending |
| Pin | Wire | Circuit | Function |
|---|
| A | 0.35 GY | 6206 | Memory Sensor Low Reference |
| B | 0.35 WH/BK | 570 | Driver Seat Recline Motor Position Sensor Signal |
| C | 0.35 TN | 6207 | Memory Sensor High Reference |
Seat Recline Position Sensor - Driver (A45)
Scheme 409
Scheme 409: Shock Absorber Actuator - Left Front (F55)
| Connector Part Information Harness: Forward Lamp OEM: 15305168 Service: 12167117 Description: 2-Way F Metri-Pack 150 Series (GY) Suspension Damper Adapter OEM: 15359261 Service: 19180262 Description: 2-Way M Metri-Pack 150 Series (GY) |
|---|
| Terminal Part Information Terminal/Tray: 12048074/2 Core/Insulation Crimp: E/1 Release Tool: 12094429 Test Probe: J-35616-2A (GY) |
| Pin | Wire | Circuit | Function |
|---|
| A | 0.8 OG/BK | 1448 | Left Front Damper Control |
| B | 0.8 L-GN | 1005 | Left Front Damper Low Reference |
Shock Absorber Actuator - Left Front (F55)
Shock Absorber Actuator - Left Rear (F55)
| Connector Part Information Harness: Body OEM: 15305168 Service: 12167117 Description: 2-Way F Metri-Pack 150 Series (GY) Suspension Damper Adapter OEM: 15359261 Service: 88953232 Description: 2-Way M Metri-Pack 150 Series (GY) |
|---|
| Terminal Part Information Terminal/Tray: 12048074/2 Core/Insulation Crimp: E/1 Release Tool: 12094429 Test Probe: J-35616-2A (GY) |
| Pin | Wire | Circuit | Function |
|---|
| A | 0.8 OG | 1010 | Left Rear Damper Control |
| B | 0.8 OG/BK | 1013 | Left Rear Damper Low Reference |
Shock Absorber Actuator - Left Rear (F55)
Shock Absorber Actuator - Right Front (F55)
| Connector Part Information Harness: Body OEM: 15305168 Service: 12167117 Description: 2-Way F Metri-Pack 150 Series (GY) Suspension Damper Adapter OEM: 15359261 Service: 88953232 Description: 2-Way M Metri-Pack 150 Series (GY) |
|---|
| Terminal Part Information Terminal/Tray: 12048074/2 Core/Insulation Crimp: E/1 Release Too: 12094429 Test Probe: J-35616-2A (GY) |
| Pin | Wire | Circuit | Function |
|---|
| A | 0.8 WH/BK | 1006 | Right Front Damper Control |
| B | 0.8 BN | 1009 | Right Front Damper Low Reference |
Shock Absorber Actuator - Right Front (F55)
Shock Absorber Actuator - Right Rear (F55)
| Connector Part Information Harness: Body OEM: 15305168 Service: 12167117 Description: 2-Way F Metri-Pack 150 Series (GY) Suspension Damper Adapter OEM: 15359261 Service: 88953232 Description: 2-Way M Metri-Pack 150 Series (GY) |
|---|
| Terminal Part Information Terminal/Tray: 12048074/2 Core/Insulation Crimp: E/1 Release Tool: 12094429 Test Probe: J-35616-2A (GY) |
| Pin | Wire | Circuit | Function |
|---|
| A | 0.8 YE | 1014 | Right Rear Damper Control |
| B | 0.8 PK | 1017 | Right Rear Damper Low Reference |
Shock Absorber Actuator - Right Rear (F55)
Scheme 410
Scheme 410: Side Marker Lamp - Left Front
| Connector Part Information Harness: Headlamp OEM: 12059247 Service: 12085535 Description: 2-Way F Metri-Pack 150 Series (BK) |
|---|
| Terminal Part Information Terminal/Tray: 12064971/5 Core/Insulation Crimp: E/C Release Tool: 12094429 Test Probe: J-35616-14 (GN) |
| Pin | Wire | Circuit | Function |
|---|
| A | 0.35 BK | 709 | Left Marker Lamp Supply Voltage |
| B | 0.35 BK | 150 | Ground |
Side Marker Lamp - Left Front
Side Marker Lamp - Right Front
| Connector Part Information Harness: Headlamp OEM: 12059247 Service: 12085535 Description: 2-Way F Metri-Pack 150 Series (GY) |
|---|
| Terminal Part Information Terminal/Tray: 12064971/5 Core/Insulation Crimp: E/C Release Tool: 12094429 Test Probe: J-35616-14 (BK) |
| Pin | Wire | Circuit | Function |
|---|
| A | 0.35 BK | 309 | Right Marker Lamp Supply Voltage |
| B | 0.35 BK | 250 | Ground |
Side Marker Lamp - Right Front
Scheme 411
Scheme 411: Skip Shift Solenoid (MG9)
| Connector Part Information Harness: Engine OEM: 12052646 Service: 12101857 Description: 2-Way F Metri-Pack 150 Series (WH) |
|---|
| Terminal Part Information Terminal/Tray: 12048074/2 Core/Insulation Crimp: E/1 Release Tool: 12094429 Test Probe: J-35616-2A (GY) |
| Pin | Wire | Circuit | Function |
|---|
| A | 0.5 GY | 587 | Skip Shift Signal |
| B | 0.5 PK/BK | 5294 | Battery Positive Voltage |
Skip Shift Solenoid (MG9)
Scheme 412
Scheme 412: Speaker - Center I/P
| Connector Part Information Harness: Instrument Panel OEM: 12064869 Service: 12117323 Description: 2-Way F Metri-Pack 150 Series (BU) |
|---|
| Terminal Part Information Terminal/Tray: 12064971/5 Core/Insulation Crimp: E/C Release Tool: 12094429 Test Probe: J-35616-14 (GN) |
| Pin | Wire | Circuit | Function |
|---|
| A | 0.5 L-BU | 1960 | Front Center Speaker Output (-) |
| B | 0.5 YE | 1860 | Front Center Speaker Output (+) |
Speaker - Left Front (UQA) (Sedan)
| Connector Part Information Harness: Door OEM: 12064869 Service: 12117323 Description: 2-Way F Metri-Pack 150 Series (BU) |
|---|
| Terminal Part Information Terminal/Tray: 12064971/5 Core/Insulation Crimp: E/C Release Tool: 12094429 Test Probe: J-35616-14 (GN) |
| Pin | Wire | Circuit | Function |
|---|
| A | 0.8 GY | 118 | Left Front Speaker Output (-) |
| B | 0.8 TN | 201 | Left Front Speaker Output (+) |
Speaker - Left Front (UQA) (Sedan)
Scheme 413
Scheme 413: Speaker - Left Front (UQA) (Wagon)
| Connector Part Information Harness: Door OEM: 12052832 Service: 12101825 Description: 2-Way F Metri-Pack 150 Series (BK) |
|---|
| Terminal Part Information Terminal/Tray: 12064971/5 Core/Insulation Crimp: E/C Release Tool: 12094429 Test Probe: J-35616-14 (GN) |
| Pin | Wire | Circuit | Function |
|---|
| A | 0.5 GY | 118 | Left Front Speaker Output (-) |
| B | 0.5 TN | 201 | Left Front Speaker Output (+) |
Speaker - Left Front (UQA) (Wagon)
Speaker - Left Front (UQS)
| Connector Part Information Harness: Door OEM: 12052832 Service: 12101825 Description: 2-Way F Metri-Pack 150 Series (BK) |
|---|
| Terminal Part Information Terminal/Tray: 12064971/5 Core/Insulation Crimp: E/C Release Tool/Test Probe: 12094429/J-35616-14 (GN) |
| Pin | Wire | Circuit | Function |
|---|
| A | 0.5 GY | 118 | Left Front Speaker Output (-) |
| B | 0.5 TN | 201 | Left Front Speaker Output (+) |
Speaker - Left Front (UQS)
Speaker - Left Front Tweeter (UQA) (Sedan)
| Connector Part Information Harness: Instrument Panel OEM: 12052832 Service: 12101825 Description: 2-Way F Metri-Pack 150 Series (BK) |
|---|
| Terminal Part Information Terminal/Tray: 12064971/5 Core/Insulation Crimp: E/C Release Tool: 12094429 Test Probe: J-35616-14 (GN) |
| Pin | Wire | Circuit | Function |
|---|
| A | 0.5 GY | 118 | Left Front Speaker Output (-) |
| B | 0.5 TN | 201 | Left Front Speaker Output (+) |
Speaker - Left Front Tweeter (UQA)
Speaker - Left Front Tweeter (UQA) (Wagon)
| Connector Part Information Harness: Door OEM: 12064869 Service: 12117323 Description: 2-Way F Metri-Pack 150 Series (BU) |
|---|
| Terminal Part Information Terminal/Tray: 12064971/5 Core/Insulation Crimp: E/C Release Tool: 12094429 Test Probe: J-35616-14 (GN) |
| Pin | Wire | Circuit | Function |
|---|
| A | 0.8 GY | 1956 | Left Front Speaker Output (-) |
| B | 0.8 TN | 1856 | Left Front Speaker Output (+) |
Speaker - Left Front Tweeter (UQA) (Wagon)
Speaker - Left Front Tweeter (UQS)
| Connector Part Information Harness: Door OEM: 12064869 Service: 12117323 Description: 2-Way F Metri-Pack 150 Series (BU) |
|---|
| Terminal Part Information Terminal/Tray: 12064971/5 Core/Insulation Crimp: E/C Release Tool: 12094429 Test Probe: J-35616-14 (GN) |
| Pin | Wire | Circuit | Function |
|---|
| A | 0.8 GY | 1956 | Left Front Speaker Output (-) |
| B | 0.8 TN | 1856 | Left Front Speaker Output (+) |
Speaker - Left Front Tweeter (UQS)
Speaker - Left Rear
| Connector Part Information Harness: Door OEM: 12052832 Service: 12101825 Description: 2-Way F Metri-Pack 150 Series (BK) |
|---|
| Terminal Part Information Terminal/Tray: 15326030/2 Core/Insulation Crimp: E/C Release Tool: 12094429 Test Probe: J-35616-14 (GN) |
| Pin | Wire | Circuit | Function |
|---|
| A | 0.5 L-BU | 115 | Left Rear Speaker Output (-) |
| B | 0.5 D-BU | 46 | Left Rear Speaker Output (+) |
Speaker - Left Rear Compartment (UQS)
| Connector Part Information Harness: Body OEM: 12064869 Service: 12117323 Description: 2-Way F Metri-Pack 150 Series (BU) |
|---|
| Terminal Part Information Terminal/Tray: 12064971/5 Core/Insulation Crimp: E/C Release Tool: 12094429 Test Probe: J-35616-14 (GN) |
| Pin | Wire | Circuit | Function |
|---|
| A | 0.5 WH | 1959 | Left Rear Midrange Speaker Output (-) |
| B | 0.5 TN | 1859 | Left Rear Midrange Speaker Output (+) |
Speaker - Left Rear Compartment (UQS)
Scheme 414
Scheme 414: Speaker - Rear Subwoofer (Sedan with UQA)
| Connector Part Information Harness: Body OEM: 12129081 Service: 12129081 Description: 2-Way F Metri-Pack 280 Series, Flexlock (BK) |
|---|
| Terminal Part Information Terminal/Tray: 12110842/4 Core/Insulation Crimp: A/B Release Tool: 15315247 Test Probe: J-35616-4A (PU) |
| Pin | Wire | Circuit | Function |
|---|
| A | 2 L-GN/BK | 1794 | Rear Subwoofer Speaker Output (-) |
| B | 2 D-BU/WH | 346 | Rear Subwoofer Speaker Output (+) |
Speaker - Rear Subwoofer (Sedan with UQA)
Scheme 415
Scheme 415: Speaker - Rear Subwoofer (Sedan with UQS)
| Connector Part Information Harness: Body OEM: 6098-2180 Service: 88988384 Description: 5-Way F 090 Series (BK) |
|---|
| Terminal Part Information Terminal/Tray: 7116-4101-08/9 Core/Insulation Crimp: E/A Release Tool/Test Probe: 12094430/J-35616-2A (GY) |
| Pin | Wire | Circuit | Function |
|---|
| 1 | 1 RD/WH | 4440 | Battery Positive Voltage |
| 2 | 1 BK | 850 | Ground |
| 3 | 0.35 OG | 5748 | Radio Audio Mute Signal |
| 4 | 0.5 L-GN/BK | 1794 | Rear Subwoofer Speaker Output (-) |
| 5 | 0.5 D-BU/WH | 346 | Rear Subwoofer Speaker Output (+) |
Speaker - Rear Subwoofer (Sedan with UQS)
Scheme 416
Scheme 416: Speaker - Rear Subwoofer (Wagon with UQS)
| Connector Part Information Harness: Body OEM: 22715965 Service: 89046647 Description: 5-Way F 090 Series (BK) |
|---|
| Terminal Part Information Pins: A, B Terminal/Tray: 15304713/19 Core/Insulation Crimp: 4/4 Release Tool/Test Probe: 15315247/J-35616-4A (PU) Pins: C-E Terminal/Tray: 15304711/8 Core/Insulation Crimp: E/A Release Tool/Test Probe: 15315247/J-35616-4A (PU) |
| Pin | Wire | Circuit | Function |
|---|
| A | 2 RD/WH | 4440 | Battery Positive Voltage |
| B | 2 BK | 850 | Ground |
| C | 0.35 OG | 5748 | Radio Audio Mute Signal |
| D | 0.5 L-GN/BK | 1794 | Rear Subwoofer Speaker Output (-) |
| E | 0.5 D-BU/WH | 346 | Rear Subwoofer Speaker Output (+) |
Speaker - Rear Subwoofer (Wagon with UQS)
Speaker - Right Front (Sedan with UQA)
| Connector Part Information Harness: Door OEM: 12064869 Service: 12117323 Description: 2-Way F Metri-Pack 150 Series (BU) |
|---|
| Terminal Part Information Terminal/Tray: 12064971/5 Core/Insulation Crimp: E/C Release Too: 12094429 Test Probe: J-35616-14 (GN) |
| Pin | Wire | Circuit | Function |
|---|
| A | 0.8 D-GN | 117 | Left Front Speaker Output (-) |
| B | 0.8 L-GN | 200 | Left Front Speaker Output (+) |
Speaker - Right Front (Sedan with UQA)
Speaker - Right Front (Wagon with UQA)
| Connector Part Information Harness: Door OEM: 12052832 Service: 12101825 Description: 2-Way F Metri-Pack 150 Series (BK) |
|---|
| Terminal Part Information Terminal/Tray: 12064971/5 Core/Insulation Crimp: E/C Release Tool: 12094429 Test Probe: J-35616-14 (GN) |
| Pin | Wire | Circuit | Function |
|---|
| A | 0.5 D-GN | 117 | Left Front Speaker Output (-) |
| B | 0.5 L-GN | 200 | Left Front Speaker Output (+) |
Speaker - Right Front (Wagon with UQA)
Speaker - Right Front Tweeter (Sedan with UQA)
| Connector Part Information Harness: Instrument Panel OEM: 12052832 Service: 12101825 Description: 2-Way F Metri-Pack 150 Series (BK) |
|---|
| Terminal Part Information Terminal/Tray: 12064971/5 Core/Insulation Crimp: E/C Release Tool: 12094429 Test Probe: J-35616-14 (GN) |
| Pin | Wire | Circuit | Function |
|---|
| A | 0.5 D-GN | 117 | Left Front Speaker Output (-) |
| B | 0.5 L-GN | 200 | Left Front Speaker Output (+) |
Speaker - Right Front Tweeter (Sedan with UQA)
Speaker - Right Front Tweeter (Wagon with UQA)
| Connector Part Information Harness: Door OEM: 12064869 Service: 12117323 Description: 2-Way F Metri-Pack 150 Series (BU) |
|---|
| Terminal Part Information Terminal/Tray: 12064971/5 Core/Insulation Crimp: E/C Release Tool: 12094429 Test Probe: J-35616-14 (GN) |
| Pin | Wire | Circuit | Function |
|---|
| A | 0.8 PU | 1952 | Right Front Tweeter Speaker (-) |
| B | 0.5 L-GN | 1852 | Right Front Tweeter Speaker (+) |
Speaker - Right Front Tweeter (Wagon with UQA)
Speaker - Right Front Tweeter (UQS)
| Connector Part Information Harness: Instrument Panel OEM: 12064869 Service: 12117323 Description: 2-Way F Metri-Pack 150 Series (BU) |
|---|
| Terminal Part Information Terminal/Tray: 12064971/5 Core/Insulation Crimp: E/C Release Tool: 12094429 Test Probe: J-35616-14 (GN) |
| Pin | Wire | Circuit | Function |
|---|
| A | 0.5 PU | 1952 | Right Front Tweeter Speaker (-) |
| B | 0.5 L-GN | 1852 | Right Front Tweeter Speaker (+) |
Speaker - Right Front Tweeter (UQS)
Speaker - Right Rear
| Connector Part Information Harness: Door OEM: 12052832 Service: 12101825 Description: 2-Way F Metri-Pack 150 Series (BK) |
|---|
| Terminal Part Information Terminal/Tray: 12064971/5 Core/Insulation Crimp: E/C Release Tool: 12094429 Test Probe: J-35616-14 (GN) |
| Pin | Wire | Circuit | Function |
|---|
| A | 0.5 L-BU | 115 | Right Rear Speaker Output (-) |
| B | 0.5 D-BU | 46 | Right Rear Speaker Output (+) |
Speaker - Right Rear Compartment (UQS)
| Connector Part Information Harness: Body OEM: 12064869 Service: 12117323 Description: 2-Way F Metri-Pack 150 Series (BU) |
|---|
| Terminal Part Information Terminal/Tray: 12064971/5 Core/Insulation Crimp: E/C Release Tool: 12094429 Test Probe: J-35616-14 (GN) |
| Pin | Wire | Circuit | Function |
|---|
| A | 0.5 OG | 1955 | Right Rear Midrange Speaker Output (-) |
| B | 0.5 TN | 1855 | Right Rear Midrange Speaker Output (+) |
Speaker - Right Rear Compartment (UQS)
Starter Motor X1
| Terminal Part Information Harness: Engine Terminal: 19180412 (LLT or LF1) Terminal: 12176593 (LSA) Core/Insulation Crimp: N/A Description: Ring Terminal |
| Pin | Wire | Circuit | Function |
|---|
| 1 | 50 RD | 1 | Battery Positive Voltage (LLT or LF1) |
| 32 BK | 1 | Battery Positive Voltage (LSA) |
Scheme 417
Scheme 417: Starter Motor X2 (LF1 or LLT)
| Connector Part Information Harness: Engine OEM: 12089916 Service: 12101763 Description: 1-Way F Metri-Pack 280 Series, Sealed (BK) Terminal Part Information Terminal: 12129493/2 Core/Insulation Crimp: 4/5 Release Tool/Test Probe: 12094430/J-35616-4A (PU) |
| Pin | Wire | Circuit | Function |
|---|
| A | 3 PU | 6 | Starter Solenoid Crank Voltage |
Starter Motor X2 (LF1 or LLT)
Starter Motor X2 (LSA)
| Connector Part Information Harness: Engine OEM: 15481001 Service: 88988118 Description: 1-Way F Metri-Pack 280 Series, Sealed (BK) Terminal Part Information Terminal: 15317554 Core/Insulation Crimp: N/A Description: Ring Terminal |
| Pin | Wire | Circuit | Function |
|---|
| A | 3 PU | 6 | Starter Solenoid Crank Voltage |
Scheme 418
Scheme 418: Steering Wheel Control Switch - Left
| Connector Part Information Harness: Steering Wheel OEM: 50-57-9408 Service: 89046705 Description: 8-Way F SL Series (BK) |
|---|
| Terminal Part Information Terminal/Tray: Service by Assembly - See Part Catalog Core/Insulation Crimp: N/A Release Tool/Test Probe: Pending |
| Pin | Wire | Circuit | Function |
|---|
| 1 | 0.35 PU | 1375 | Remote Radio Control Supply Voltage |
| 2 | 0.35 GY | 1884 | Cruise Control Switch Signal |
| 3 | 0.35 PU/WH | 7005 | LED Dimming Signal |
| 4 | 0.35 BK | 350 | Ground |
| 5 | 0.35 PU | 1375 | Remote Radio Control Supply Voltage |
| 6 | 0.35 D-BU | 1796 | Steering Wheel Controls Signal |
| 7 | 0.35 D-GN/WH | 7158 | Cruise Control Indicator Dimming Signal |
| 8 | | | Not Used |
Steering Wheel Control Switch - Left
Scheme 419
Scheme 419: Steering Wheel Control Switch - Right
| Connector Part Information Harness: Steering Wheel OEM: 50-57-9405 Service: 89046734 Description: 5-Way F SL Series (BK) |
|---|
| Terminal Part Information Terminal/Tray: Service by Assembly - See Part Catalog Core/Insulation Crimp: N/A Release Tool/Test Probe: Pending |
| Pin | Wire | Circuit | Function |
|---|
| 1 | 0.35 PU | 1375 | Remote Radio Control Supply Voltage |
| 2 | 0.35 D-BU | 1796 | Steering Wheel Controls Signal |
| 3 | 0.35 PU/WH | 7005 | LED Dimming Signal |
| 4 | 0.35 BK | 350 | Ground |
| 5 | 0.35 PU | 1375 | Remote Radio Control Supply Voltage |
Steering Wheel Control Switch - Right
Scheme 420
Scheme 420: Steering Wheel Position Sensor
| Connector Part Information Harness: Steering Column OEM: 19115612 Service: 19178090 Description: 6-Way F 0.64 Series (WH) |
|---|
| Terminal Part Information Terminal/Tray: Service by Harness - See Part Catalog Core/Insulation Crimp: N/A Release Tool/Test Probe: Pending |
| Pin | Wire | Circuit | Function |
|---|
| 1 | | | Not Used |
| 2 | 0.35 L-GN/BK | 6432 | CAN Bus Low Serial Data |
| 3 | 0.35 TN/WH | 6433 | CAN Bus High Serial Data |
| 4 | | | Not Used |
| 5 | 0.35 GY | 1056 | Steering Wheel Position Sensor 5-Volt Reference Voltage |
| 6 | 0.35 BK/WH | 351 | Ground |
Steering Wheel Position Sensor
Scheme 421
Scheme 421: Steering Wheel/Column Tilt/Telescope Actuator X1 (A45 with N38)
| Connector Part Information Harness: Steering Column OEM: 15326886 Service: 88988300 Description: 4-Way F GT 280 Series (BK) |
|---|
| Terminal Part Information Terminal/Tray: Service by Harness - See Part Catalog Core/Insulation Crimp: N/A Release Tool/Test Probe: 15315247/J-35616-4A (PU) |
| Pin | Wire | Circuit | Function |
|---|
| A | 1 BN | 2112 | Steering Column Tilt Motor Control - Down |
| B | 1 PK | 2111 | Steering Column Tilt Motor Control - Up |
| C | 1 OG | 2098 | Steering Column Telescope Motor Forward |
| D | 1 TN | 2110 | Steering Column Telescope Motor Control - Reverse |
Steering Wheel/Column Tilt/Telescope Actuator X1 (A45 with N38)
Scheme 422
Scheme 422: Steering Wheel/Column Tilt/Telescope Actuator X2 (A45 with N38)
| Connector Part Information Harness: Steering Column OEM: 15332135 Service: 15306414 Description: 4-Way F GT 150 Series (BK) |
|---|
| Terminal Part Information Terminal/Tray: Service by Harness - See Part Catalog Core/Insulation Crimp: N/A Release Tool/Test Probe: 15315247/J-35616-2A (GY) |
| Pin | Wire | Circuit | Function |
|---|
| A | 0.35 OG | 2154 | Steering Column Tilt Sensor Signal |
| B | 0.35 GY | 6206 | Memory Sensor Low Reference |
| C | 0.35 TN | 6207 | Memory Sensor High Reference |
| D | 0.35 OG | 2153 | Steering Column Telescope Sensor Signal |
Steering Wheel/Column Tilt/Telescope Actuator X2 (A45 with N38)
Scheme 423
Scheme 423: Steering Wheel/Column Tilt/Telescope Switch (A45 with N38)
| Connector Part Information Harness: Steering Column OEM: AIT2PB-06-1AK Service: 19167753 Description: 6-Way F AIT II Series (BK) |
|---|
| Terminal Part Information Terminal/Tray: Service by Harness - See Part Catalog Core/Insulation Crimp: N/A Release Tool/Test Probe: Pending |
| Pin | Wire | Circuit | Function |
|---|
| 1 | 0.35 RD/WH | 6205 | Driver Position Switch High Reference |
| 2 | 0.35 GY | 2096 | Steering Column Tilt and Telescope Up Switch Signal |
| 3 | 0.35 PK | 2094 | Steering Column Tilt and Telescope Forward Switch Signal |
| 4 | | | Not Used |
| 5 | 0.35 OG | 2095 | Steering Column Tilt and Telescope Reverse Switch Signal |
| 6 | 0.35 YE | 2097 | Steering Column Tilt and Telescope Down Switch Signal |
Steering Wheel/Column Tilt/Telescope Switch (A45 with N38)
Scheme 424
Scheme 424: Sunload Sensor
| Connector Part Information Harness: Combo Jumper Harness OEM: 12064760 Service: 12085208 Description: 4-Way F Metri-Pack 150 Series (BK) |
|---|
| Terminal Part Information Terminal/Tray: 12064971/5 Core/Insulation Crimp: E/C Release Tool: 12094429 Test Probe: J-35616-14 (GN) |
| Pin | Wire | Circuit | Function |
|---|
| A | 0.35 L-BU/BK | 590 | Driver Sunload Sensor Signal |
| B | 0.35 GY | 1548 | Passenger Sunload Sensor Signal |
| C | 0.35 YE | 61 | Low Reference |
| D | 0.35 L-GN/BK | 1137 | DRL Ambient Light Sensor Signal |
Scheme 425
Scheme 425: Sunroof Control Module (C3U)
| Connector Part Information Harness: Sunroof OEM: 7383-5909-40 Service: Service by Harness - See Part Catalog Description: 10-Way F 1.5 Series (L-GY) |
|---|
| Terminal Part Information Terminal/Tray: Service by Harness - See Part Catalog Core/Insulation Crimp: N/A Release Tool/Test Probe: Pending |
| Pin | Wire | Circuit | Function |
|---|
| 1 | 1 BK | 850 | Ground (Sedan) |
| 1 BK | 1050 | Ground (Wagon) |
| 2 | 0.35 BK | 850 | Ground (Sedan) |
| 0.35 BK | 1050 | Ground (Wagon) |
| 3 | 0.35 D-GN | 801 | RAP Fuse Supply Voltage |
| 4 | | | Not Used |
| 5 | 0.35 OG | 5029 | Sunroof Switch - Data 3 |
| 6 | 1 RD/WH | 3240 | Battery Positive Voltage |
| 7 | 0.35 D-GN | 7006 | Inter Device Dedicated Bus Serial Data |
| 8-9 | | | Not Used |
| 10 | 0.35 L-BU | 5027 | Sunroof Switch - Data 1 |
Sunroof Control Module (C3U)
Sunroof Shade Module (C3U)
| Connector Part Information Harness: Sunroof OEM: 7383-5909-40 Service: Service by Harness - See Part Catalog Description: 10-Way F 1.5 Series (L-GY) |
|---|
| Terminal Part Information Terminal/Tray: Service by Harness - See Part Catalog Core/Insulation Crimp: N/A Release Tool/Test Probe: Pending |
| Pin | Wire | Circuit | Function |
|---|
| 1 | 1 BK | 850 | Ground (Sedan) |
| 1 BK | 1050 | Ground (Wagon) |
| 2 | | | Not Used |
| 3 | 0.8 D-GN | 801 | RAP Fuse Supply Voltage |
| 4 | | | Not Used |
| 5 | 0.35 PU | 5032 | Sunroof Switch - Data 6 |
| 6 | 1 RD/WH | 3240 | Battery Positive Voltage |
| 7 | 0.35 D-GN | 7006 | Inter Device Dedicated Bus Serial Data |
| 8-9 | | | Not Used |
| 10 | 0.35 TN | 5030 | Sunroof Switch - Data 4 |
Sunroof Shade Module (C3U)
Scheme 426
Scheme 426: Sunroof Switch (C3U)
| Connector Part Information Harness: Headliner OEM: 13607185 Service: 12167130 Description: 5-Way F Metri-Pack 150 Series (BU) |
|---|
| Terminal Part Information Terminal/Tray: 12103359/18 Core/Insulation Crimp: E/C Release Tool: 12094429 Test Probe: J-35616-14 (GN) |
| Pin | Wire | Circuit | Function |
|---|
| A | 0.35 GY | 8 | I/P Lamp Supply Voltage - I/P Lamps Dimmer Switch Signal |
| B | 0.35 BK | 1050 | Ground |
| C | | | Not Used |
| D | 0.35 OG | 5029 | Sunroof Switch - Data 3 |
| E | 0.35 L-BU | 5027 | Sunroof Switch - Data 1 |
Sunroof Shade Switch (C3U)
| Connector Part Information Harness: Headliner OEM: 12124997 Service: 12167130 Description: 5-Way F Metri-Pack 150 Series (BK) |
|---|
| Terminal Part Information Terminal/Tray: 12103359/18 Core/Insulation Crimp: E/C Release Tool: 12094429 Test Probe: J-35616-14 (GN) |
| Pin | Wire | Circuit | Function |
|---|
| A | 0.35 GY | 8 | I/P Dimmer Switch Signal |
| B | 0.35 BK | 1050 | Ground |
| C | | | Not Used |
| D | 0.35 TN | 5030 | Sunroof Switch - Data 4 |
| E | 0.35 PU | 5032 | Sunroof Switch - Data 6 |
Sunroof Shade Switch (C3U)
Scheme 427
Scheme 427: Sunshade - Left
| Connector Part Information Harness: Headliner OEM: 12047663 Service: 12085481 Description: 2-Way M Metri-Pack 150 Series (BK) |
|---|
| Terminal Part Information Terminal/Tray: 12047581/2 Core/Insulation Crimp: E/C Release Tool: 12094429 Test Probe: J-35616-3 (GY) |
| Pin | Wire | Circuit | Function |
|---|
| A | 0.5 OG | 1732 | Courtesy Lamps Supply Voltage |
| B | 0.5 BK | 1050 | Ground |
Sunshade - Right
| Connector Part Information Harness: Headliner OEM: 12047663 Service: 12085481 Description: 2-Way M Metri-Pack 150 Series (BK) |
|---|
| Terminal Part Information Terminal/Tray: 12047581/2 Core/Insulation Crimp: E/C Release Tool: 12094429 Test Probe: J-35616-3 (GY) |
| Pin | Wire | Circuit | Function |
|---|
| A | 0.5 OG | 1732 | Courtesy Lamps Supply Voltage |
| B | 0.5 BK | 1050 | Ground |
Scheme 428
Scheme 428: Supercharger Air Inlet Pressure Sensor (LSA)
| Connector Part Information Harness: Fuel Injector OEM: 1928403966 Service: 88988583 Description: 3-Way F (BK) |
|---|
| Terminal Part Information Terminal/Tray: Service by Harness - See Part Catalog Core/Insulation Crimp: N/A Release Tool/Test Probe: N/A |
| Pin | Wire | Circuit | Function |
|---|
| 1 | 0.35 YE/BK | 7124 | 5-Volt Reference |
| 2 | 0.35 D-GN | 7125 | Low Reference |
| 3 | 0.35 BN | 7123 | Supercharger Air Inlet Pressure Sensor Signal |
Supercharger Air Inlet Pressure Sensor (LSA)
Scheme 429
Scheme 429: Supercharger Bypass Valve Solenoid (LSA)
| Connector Part Information Harness: Engine OEM: 184006-2 Service: 88988501 Description: 2-Way M Sealed (GY) |
|---|
| Terminal Part Information Terminal/Tray: 184095-1/7 Core/Insulation Crimp: E/D Release Tool: 12094429 Test Probe: J-35616-33 (YE) |
| Pin | Wire | Circuit | Function |
|---|
| 1 | 0.35 PK/BK | 5294 | Battery Positive Voltage |
| 2 | 0.35 L-BU | 7126 | Low Reference |
Supercharger Bypass Valve Solenoid (LSA)
Scheme 430
Scheme 430: Suspension Position Sensor - Left Front (F55)
| Connector Part Information Harness: Forward Lamp OEM: 15326556 Service: 88953359 Description: 3-Way F GT 150 Series (BK) |
|---|
| Terminal Part Information Terminal/Tray: 15326267/19 Core/Insulation Crimp: E/4 Release Tool: 15315247 Test Probe: J-35616-2A (GY) |
| Pin | Wire | Circuit | Function |
|---|
| A | 0.35 PU/WH | 1205 | Left Front Suspension Position Sensor Voltage Reference |
| B | 0.35 TN/WH | 1207 | Left Front Suspension Position Sensor Signal |
| C | 0.35 L-BU/BK | 1206 | Left Front Suspension Position Sensor Low Reference |
Suspension Position Sensor - Left Front (F55)
Suspension Position Sensor - Left Rear (F55)
| Connector Part Information Harness: Body OEM: 15326556 Service: 88953359 Description: 3-Way F GT 150 Series (BK) |
|---|
| Terminal Part Information Terminal/Tray: 15326267/19 Core/Insulation Crimp: E/4 Release Tool: 15315247 Test Probe: J-35616-2A (GY) |
| Pin | Wire | Circuit | Function |
|---|
| A | 0.35 OG/BK | 1208 | Left Rear Suspension Position Sensor Voltage Reference |
| B | 0.35 L-GN/WH | 1210 | Left Rear Suspension Position Sensor Signal |
| C | 0.35 L-GN/BK | 1209 | Left Rear Suspension Position Sensor Low Reference |
Suspension Position Sensor - Left Rear (F55)
Suspension Position Sensor - Right Front (F55)
| Connector Part Information Harness: Forward Lamp OEM: 15326556 Service: 88953359 Description: 3-Way F GT 150 Series (BK) |
|---|
| Terminal Part Information Terminal/Tray: 15326267/19 Core/Insulation Crimp: E/4 Release Tool: 15315247 Test Probe: J-35616-2A (GY) |
| Pin | Wire | Circuit | Function |
|---|
| A | 0.35 PU/WH | 1211 | Right Front Suspension Position Sensor Voltage Reference |
| B | 0.35 TN/WH | 1213 | Right Front Suspension Position Sensor Signal |
| C | 0.35 L-BU/BK | 1212 | Right Front Suspension Position Sensor Low Reference |
Suspension Position Sensor - Right Front (F55)
Suspension Position Sensor - Right Rear (F55)
| Connector Part Information Harness: Body OEM: 15326556 Service: 88953359 Description: 3-Way F GT 150 Series (BK) |
|---|
| Terminal Part Information Terminal/Tray: 15326267/19 Core/Insulation Crimp: E/4 Release Tool: 15315247 Test Probe: J-35616-2A (GY) |
| Pin | Wire | Circuit | Function |
|---|
| A | 0.35 OG/BK | 1214 | Right Rear Suspension Position Sensor Voltage Reference |
| B | 0.35 L-GN/WH | 1216 | Right Rear Suspension Position Sensor Signal |
| C | 0.35 L-GN/BK | 1215 | Right Rear Suspension Position Sensor Low Reference |
Suspension Position Sensor - Right Rear (F55)
Scheme 431
Scheme 431: Tail Lamp - Left (T90)
| Connector Part Information Harness: Body OEM: 12064766 Service: 12101875 Description: 8-Way F Metri-Pack 150 Series (BU) |
|---|
| Terminal Part Information Terminal/Tray: 15326030/2 Core/Insulation Crimp: Pins B, D-G: E/C; Pin H: E/A Release Tool/Test Probe: 12094429/J-35616-14 (GN) |
| Pin | Wire | Circuit | Function |
|---|
| A | | | Not Used |
| B | 0.35 L-BU | 20 | Stop Lamp Supply Voltage |
| C | | | Not Used |
| D | 0.35 YE | 5356 | Left Tail Lamp Outage Detection Signal |
| E | 0.8 L-GN | 24 | Backup Lamp Supply Voltage |
| F | 0.35 PU | 709 | Right Park Lamp Supply Voltage |
| G | 0.35 L-BU | 14 | Left Turn Signal Lamps Supply Voltage |
| H | 0.5 BK | 850 | Ground |
Tail Lamp - Left (without T90)
| Connector Part Information Harness: Body OEM: 12064766 Service: 12101875 Description: 8-Way F Metri-Pack 150 Series (BU) |
|---|
| Terminal Part Information Terminal/Tray: 15326030/2 Core/Insulation Crimp: Pins B-D: E/C; Pins E, F: E/A Release Tool/Test Probe: 12094429/J-35616-14 (GN) |
| Pin | Wire | Circuit | Function |
|---|
| A | | | Not Used |
| B | 0.35 YE | 18 | Left Rear Stop/Turn Lamp Supply Voltage |
| C | 0.5 BK | 850 | Ground |
| D | 0.35 YE | 5356 | Left Tail Lamp Outage Detection Signal |
| E | 0.8 L-GN | 24 | Backup Lamp Supply Voltage |
| F | 0.8 PU | 709 | Left Park Lamp Supply Voltage |
| G-H | | | Not Used |
Tail Lamp - Left (without T90)
Tail Lamp - Right (T90)
| Connector Part Information Harness: Body OEM: 12064766 Service: 12101875 Description: 8-Way F Metri-Pack 150 Series (BU) |
|---|
| Terminal Part Information Terminal/Tray: 15326030/2 Core/Insulation Crimp: Pins B, D-G: E/C; Pin H: E/A Release Tool/Test Probe: 12094429/J-35616-14 (GN) |
| Pin | Wire | Circuit | Function |
|---|
| A | | | Not Used |
| B | 0.35 L-BU | 20 | Stop Lamp Supply Voltage |
| C | | | Not Used |
| D | 0.35 PU | 5357 | Right Tail Lamp Outage Detection Signal |
| E | 0.35 L-GN | 24 | Backup Lamp Supply Voltage |
| F | 0.35 BN/WH | 309 | Right Park Lamp Supply Voltage |
| G | 0.35 D-BU | 15 | Right Turn Signal Lamps Supply Voltage |
| H | 0.8 BK | 1050 | Ground |
Tail Lamp - Right (without T90)
| Connector Part Information Harness: Body OEM: 12064766 Service: 12101875 Description: 8-Way F Metri-Pack 150 Series (BU) |
|---|
| Terminal Part Information Terminal/Tray: 15326030/2 Core/Insulation Crimp: Pins B, D, F: E/C; Pins C, E: E/A Release Tool/Test Probe: 12094429/J-35616-14 (GN) |
| Pin | Wire | Circuit | Function |
|---|
| A | | | Not Used |
| B | 0.35 D-GN | 19 | Right Rear Stop/Turn Lamp Supply Voltage |
| C | 0.8 BK | 1050 | Ground |
| D | 0.35 PU | 5357 | Right Tail Lamp Outage Detection Signal |
| E | 0.8 L-GN | 24 | Backup Lamp Supply Voltage |
| F | 0.35 BN/WH | 309 | Right Park Lamp Supply Voltage |
| G-H | | | Not Used |
Tail Lamp - Right (without T90)
Scheme 432
Scheme 432: Theft Deterrent Alarm Siren (UA2)
| Connector Part Information Harness: Body OEM: 19676401 Service: 88953370 Description: 4-Way F MQS Socket Housing, Sealed (BK) |
|---|
| Terminal Part Information Terminal/Tray: 962885-5/15 Core/Insulation Crimp: 6/6 Release Tool: 12094429 Test Probe: J-35616-64B (L-BU) |
| Pin | Wire | Circuit | Function |
|---|
| 1 | 0.35 PK | 539 | Ignition 1 Voltage |
| 2 | 0.35 RD/WH | 4540 | Battery Positive Voltage |
| 3 | 0.35 TN/BK | 5168 | Power Sounder Enable Signal |
| 4 | 0.35 BK | 850 | Ground |
Theft Deterrent Alarm Siren (UA2)
Scheme 433
Scheme 433: Theft Deterrent Module (TDM) (without BTM)
| Connector Part Information Harness: Steering Column OEM: 50-57-9705 Service: 88988353 Description: 5-Way F SL Series (BK) |
|---|
| Terminal Part Information Terminal/Tray: Service by Harness - See Part Catalog Core/Insulation Crimp: N/A Release Tool/Test Probe: Pending |
| Pin | Wire | Circuit | Function |
|---|
| 1 | 0.35 OG | 1940 | Battery Positive Voltage |
| 2 | 0.35 BN | 4 | Accessory Voltage |
| 3 | 0.35 BK/WH | 651 | Ground |
| 4 | | | Not Used |
| 5 | 0.35 D-GN | 5060 | Low Speed GMLAN Serial Data |
Theft Deterrent Module (TDM) (without BTM)
Scheme 434
Scheme 434: Throttle Body
| Connector Part Information Harness: Engine OEM: 15355297 Service: 13504128 Description: 6-Way F GT 150 Series, Sealed (BK) |
|---|
| Terminal Part Information Terminal/Tray: 12191819/8 Core/Insulation Crimp: E/A Release Tool: 15315247 Test Probe: J-35616-2A (GY) |
| Pin | Wire | Circuit | Function |
|---|
| A | 0.5 BN | 582 | TAC Motor Control - 2 |
| B | 0.5 YE | 581 | TAC Motor Control - 1 |
| C | 0.5 TN | 2752 | Low Reference |
| D | 0.5 D-GN | 485 | TP Sensor 1 Signal |
| E | 0.5 GY | 2701 | 5-Volt Reference 3 |
| F | 0.5 PU | 486 | TP Sensor 2 Signal |
Scheme 435
Scheme 435: Throttle Inlet Absolute Pressure Sensor (LF1)
| Connector Part Information Harness: Engine OEM: 13639747 Service: 19181248 Description: 3-Way F 2.8 Timer Series, Sealed (BK) |
|---|
| Terminal Part Information Terminal/Tray: Pending Core/Insulation Crimp: Pending Release Tool/Test Probe: Pending |
| Pin | Wire | Circuit | Function |
|---|
| 1 | 0.5 GY/WH | 3201 | Throttle Inlet Absolute Pressure Sensor 5V Reference |
| 2 | 0.5 TNWH | 3202 | Throttle Inlet Absolute Pressure Sensor 5V Return |
| 3 | 0.5 YE/WH | 3200 | Throttle Inlet Absolute Pressure Sensor Signal |
Throttle Inlet Absolute Pressure Sensor (LF1)
Scheme 436
Scheme 436: Transfer Case Clutch Coil X1 (MX7)
| Connector Part Information Harness: Engine OEM: 19177517 Service: Pending Description: 2-Way F GT 280 Series, Sealed (BK) |
|---|
| Terminal Part Information Terminal/Tray: 15304719/19 Core/Insulation Crimp: 2/5 Release Tool: 15315247 Test Probe: J-35616-4A (PU) |
| Pin | Wire | Circuit | Function |
|---|
| A | 1 YE/WH | 7483 | Clutch Coil Control |
| B | 1 YE/BK | 7482 | Clutch Coil Return |
Transfer Case Clutch Coil X1 (MX7)
Scheme 437
Scheme 437: Transfer Case Clutch Coil X2 (MX7)
| Connector Part Information Harness: Engine OEM: 13510085 Service: 19179278 Description: 2-Way F GT 150 Series Sealed (BK) |
|---|
| Terminal Part Information Terminal/Tray: 12191819/8 Core/Insulation Crimp: E/A Release Tool: 15315247 Test Probe: J-35616-2A (GY) |
| Pin | Wire | Circuit | Function |
|---|
| A | 0.5 D-GN/WH | 7480 | Clutch Calibration Resistor 5-Volt Reference |
| B | 0.5 D-GN | 7481 | Clutch Calibration Resistor Signal |
Transfer Case Clutch Coil X2 (MX7)
Scheme 438
Scheme 438: Transfer Case Fluid Temperature Sensor (MX7)
| Connector Part Information Harness: Engine OEM: 15355317 Service: 19178093 Description: 2-Way F GT 150 Series, Sealed (BK) |
|---|
| Terminal Part Information Terminal/Tray: 15326267/19 Core/Insulation Crimp: E/4 Release Tool: 15315247 Test Probe: J-35616-2A (GY) |
| Pin | Wire | Circuit | Function |
|---|
| A | 0.5 PU | 7485 | Oil Temperature Sensor Signal |
| B | 0.5 PU/WH | 7484 | Oil Temperature Sensor 5-Volt Reference |
Transfer Case Fluid Temperature Sensor (MX7)
Scheme 439
Scheme 439: Transfer Case Shift Control Module X1 (MX7)
| Connector Part Information Harness: Instrument Panel OEM: 7283-6456-90 Service: 88952778 Description: 16-Way F Kaizen YESC Series (BU) |
|---|
| Terminal Part Information Pins: 6, 15 Terminal/Tray: 7116-4101-08/9 Core/Insulation Crimp: E/A Release Tool/Test Probe: 12094430/J-35616-2A (GY) Pins: 8, 16 Terminal/Tray: 7116-4100-08/9 Core/Insulation Crimp: E/C Release Tool/Test Probe: 12094430/J-35616-2A (GY) |
| Pin | Wire | Circuit | Function |
|---|
| 1 | 0.35 PU | 7485 | Oil Temperature Sensor Signal |
| 2 | | | Not Used |
| 3 | 0.5 PK | 339 | Ignition 1 Voltage |
| 4 | 1 YE/BK | 7482 | Clutch Coil Return |
| 5 | 1 YE/WH | 7483 | Clutch Coil Control |
| 6 | 0.35 D-BU | 5985 | Accessory Wakeup Serial Data |
| 7 | 0.5 TN | 2501 | High Speed GMLAN Serial Data Bus |
| 8 | 0.5 TN/BK | 2500 | High Speed GMLAN Serial Data Bus+ |
| 9 | 0.35 PU/WH | 7484 | Oil Temperature Sensor 5-Volt Reference |
| 10 | | | Not Used |
| 11 | 0.35 D-GN | 7481 | Clutch Calibration Resistor Signal |
| 12 | 0.35 D-GN/WH | 7480 | Clutch Calibration Resistor 5-Volt Reference |
| 13-14 | | | Not Used |
| 15 | 0.5 TN | 2501 | High Speed GMLAN Serial Data Bus |
| 16 | 0.5 TN/BK | 2500 | High Speed GMLAN Serial Data Bus+ |
Transfer Case Shift Control Module X1 (MX7)
Scheme 440
Scheme 440: Transfer Case Shift Control Module X2 (MX7)
| Connector Part Information Harness: Instrument Panel OEM: 15466671 Service: 19149301 Description: 4-Way F GT 280 Series (L-GY) |
|---|
| Terminal Part Information Terminal/Tray: 15304711/8 Core/Insulation Crimp: 2/A Release Tool: 15315247 Test Probe: J-35616-4A (PU) |
| Pin | Wire | Circuit | Function |
|---|
| A-B | | | Not Used |
| C | 1 RD/WH | 2640 | Battery Positive Voltage |
| D | 1 BK | 350 | Ground |
Transfer Case Shift Control Module X2 (MX7)
Scheme 441
Scheme 441: Turn Signal Lamp - Left Front
| Connector Part Information Harness: Headlamp OEM: 9442003 Service: Service by Harness - See Part Catalog Description: 2-Way F (BK) |
|---|
| Terminal Part Information Terminal/Tray: Service by Harness - See Part Catalog Core/Insulation Crimp: N/A Release Tool/Test Probe: Pending |
| Pin | Wire | Circuit | Function |
|---|
| A | 0.8 BK | 1314 | Left Front Turn Signal Lamp Supply Voltage |
| B | 0.8 BK | 150 | Ground |
Turn Signal Lamp - Left Front
Turn Signal Lamp - Right Front
| Connector Part Information Harness: Headlamp OEM: 9442003 Service: Service by Harness - See Part Catalog Description: 2-Way F (BK) |
|---|
| Terminal Part Information Terminal/Tray: Service by Harness - See Part Catalog Core/Insulation Crimp: N/A Release Tool/Test Probe: N/A |
| Pin | Wire | Circuit | Function |
|---|
| A | 0.8 BK | 1315 | Right Front Turn Signal Lamp Supply Voltage |
| B | 0.8 BK | 250 | Ground |
Turn Signal Lamp - Right Front
Scheme 442
Scheme 442: Turn Signal Repeater Lamp - Left (T90)
| Connector Part Information Harness: Repeater Jumper Harness OEM: E-5229 Service: 889888059 Description: 2-Way F Sleeve Assembly (GY) |
|---|
| Terminal Part Information Terminal/Tray: 7116-4102-08/9 Core/Insulation Crimp: E/1 Release Tool: 12094430 Test Probe: J-35616-2A (GY) |
| Pin | Wire | Circuit | Function |
|---|
| 1 | 0.5 L-BU/WH | 1314 | Left Front Turn Signal Lamp Supply Voltage |
| 2 | 0.5 BK | 150 | Ground |
Turn Signal Repeater Lamp - Left (T90)
Turn Signal Repeater Lamp - Right (T90)
| Connector Part Information Harness: Repeater Jumper Harness OEM: E-5229 Service: 889888059 Description: 2-Way F Sleeve Assembly (GY) |
|---|
| Terminal Part Information Terminal/Tray: 7116-4102-08/9 Core/Insulation Crimp: E/1 Release Tool: 12094430 Test Probe: J-35616-2A (GY) |
| Pin | Wire | Circuit | Function |
|---|
| 1 | 0.5 D-BU/WH | 1315 | Right Front Turn Signal Lamp Supply Voltage |
| 2 | 0.5 BK | 250 | Ground |
Turn Signal Repeater Lamp - Right (T90)
Scheme 443
Scheme 443: Turn Signal/Multifunction Switch X1
| Connector Part Information Harness: Steering Column OEM: AIT2PB-10-1FS Service: Service by Harness - See Part Catalog Description: 10-Way F AIT II Series (NA) |
|---|
| Terminal Part Information Terminal/Tray: SAIT-A03T-M064/14 Core/Insulation Crimp: P/P Release Tool/Test Probe: J-38125-215A/J-35616-64B (L-BU) |
| Pin | Wire | Circuit | Function |
|---|
| 1 | 0.35 BK/WH | 651 | Ground |
| 2 | 0.35 L-BU/WH | 1414 | Left Front Turn Signal Switch Signal |
| 3 | 0.35 D-BU/WH | 1415 | Right Front Turn Signal Switch Signal |
| 4 | 0.35 D-GN | 306 | Headlamp Switch Headlamps Off Signal |
| 5 | 0.35 WH | 103 | Headlamp Switch Headlamps On Signal |
| 6 | 0.35 BN/WH | 301 | Rear Park Lamps Supply Voltage/Park Lamp Switch On Signal |
| 7 | 0.35 OG | 192 | Front Fog Lamp Switch Signal (T3U) |
| 8 | 0.35 L-BU | 187 | Rear Fog Lamp Switch Signal (T79) |
| 9 | 0.35 BK/WH | 651 | Ground |
| 10 | 0.35 BK/WH | 651 | Ground (T3U or T79) |
Turn Signal/Multifunction Switch X1
Scheme 444
Scheme 444: Turn Signal/Multifunction Switch X2
| Connector Part Information Harness: Steering Column OEM: AIT2PB-10-1BH Service: Service by Harness - See Part Catalog Description: 10-Way F AIT II Series (GY) |
|---|
| Terminal Part Information Terminal/Tray: SAIT-A03T-M064/14 Core/Insulation Crimp: P/P Release Tool/Test Probe: J-38125-215A/J-35616-64B (L-BU) |
| Pin | Wire | Circuit | Function |
|---|
| 1-6 | | | Not Used |
| 7 | 0.35 PU | 524 | Headlamp Dimmer Switch High Beam Signal |
| 8 | 0.35 BK/WH | 651 | Ground |
| 9 | | | Not Used |
| 10 | 0.35 BN | 1356 | Flash To Pass Switch Signal |
Turn Signal/Multifunction Switch X2
Scheme 445
Scheme 445: Variable Effort Steering Actuator (MX7)
| Connector Part Information Harness: Engine OEM: 963040-1 Service: 88988390 Description: 2-Way F Junior Power Timer Series (BU) |
|---|
| Terminal Part Information Terminal/Tray: 4-964286-1/16 Core/Insulation Crimp: E/1 Release Tool: 12093647 Test Probe: J-35616-4A (PU) |
| Pin | Wire | Circuit | Function |
|---|
| 1 | 0.5 WH | 1294 | Variable Effort Steering Actuator Supply Voltage |
| 2 | 0.5 BN | 1295 | Variable Effort Steering Actuator Control |
Variable Effort Steering Actuator (MX7)
Scheme 446
Scheme 446: Vehicle Communication Interface Module (VCIM) X1 (UE1)
| Connector Part Information Harness: Instrument Panel OEM: 917981-1 Service: 15306351 Description: 16-Way F .040/.070 Hybrid Series (WH) |
|---|
| Terminal Part Information Terminal/Tray: 175266-5/15 Core/Insulation Crimp: Pins 1-3, 6, 10-12: J/J; Pins 7, 15: K/K Release Tool: 15315247 Test Probe: J-35616-16 (L-GN) |
| Pin | Wire | Circuit | Function |
|---|
| 1 | 0.35 D-GN | 5060 | Low Speed GMLAN Serial Data |
| 2 | 0.35 BN/WH | 2517 | Keypad Red LED Signal |
| 3 | 0.35 YE/BK | 2516 | Keypad Green LED Signal |
| 4-5 | | | Not Used |
| 6 | 0.35 L-GN/BK | 2515 | Keypad Supply Voltage |
| 7 | 0.8 BK/WH | 851 | Ground |
| 8-9 | | | Not Used |
| 10 | 0.35 TN/BK | 2500 | High Speed GMLAN Serial Data Bus+ |
| 11 | 0.35 D-GN/WH | 2514 | Keypad Signal |
| 12 | 0.35 TN | 2501 | High Speed GMLAN Serial Data Bus |
| 13-14 | | | Not Used |
| 15 | 0.8 RD/WH | 3340 | Battery Positive Voltage |
| 16 | | | Not Used |
Vehicle Communication Interface Module (VCIM) X1 (UE1)
Scheme 447
Scheme 447: Vehicle Communication Interface Module (VCIM) X2 (UE1)
| Connector Part Information Harness: Instrument Panel OEM: 917975-1 Service: 88952886 Description: 12-Way F .040/.070 Hybrid Series (WH) |
|---|
| Terminal Part Information Terminal/Tray: 175266-5/15 Core/Insulation Crimp: J/J Release Tool: 15315247 Test Probe: J-35616-16 (L-GN) |
| Pin | Wire | Circuit | Function |
|---|
| 1 | 0.35 OG/BK | 1406 | Remote Playback Device Left Audio Signal |
| 2 | 0.35 L-BU | 1405 | Remote Playback Device Audio Common Signal |
| 3 | 0.35 TN/BK | 2500 | High Speed GMLAN Serial Data Bus+ |
| 4 | 0.35 TN | 2501 | High Speed GMLAN Serial Data Bus |
| 5-7 | | | Not Used |
| 8 | 0.35 BARE | 814 | Drain Wire |
| 9 | 0.35 GY | 655 | Cellular Microphone Signal |
| 10 | 0.35 BARE | 514 | Ground |
| 11-12 | | | Not Used |
Vehicle Communication Interface Module (VCIM) X2 (UE1)
Scheme 448
Scheme 448: Vehicle Communication Interface Module (VCIM) X3 (UE1)
| Connector Part Information Harness: Instrument Panel OEM: 917983-2 Service: 88988722 Description: 16-Way M MKII Hybrid (BK) |
|---|
| Terminal Part Information Terminal/Tray: 175266-5/15 Core/Insulation Crimp: J/J Release Tool: 15315247 Test Probe: J-35616-16 (L-GN) |
| Pin | Wire | Circuit | Function |
|---|
| 1 | | | Not Used |
| 2 | 0.35 PK | 5149 | Voice Recognition Audio Signal |
| 3 | | | Not Used |
| 4 | 0.35 PK/BK | 5152 | Voice Recognition Audio Low Reference |
| 5 | 0.35 BARE | 1792 | Drain Wire (UAV) |
| 6-16 | | | Not Used |
Vehicle Communication Interface Module (VCIM) X3 (UE1)
Scheme 449
Scheme 449: Vehicle Inclination Sensor (UA2)
| Connector Part Information Harness: Body OEM: 15324229 Service: 15306167 Description: 4-Way F Timer Micro-Pack Series (BK) |
|---|
| Terminal Part Information Terminal/Tray: 962943-5/16 Core/Insulation Crimp: See Terminal Repair Kit Release Tool: J-38125-560 Test Probe: J-35616-33 (YE) |
| Pin | Wire | Circuit | Function |
|---|
| 1 | 0.35 RD/WH | 4540 | Battery Positive Voltage |
| 2 | | | Not Used |
| 3 | 0.35 L-BU | 5362 | Inclination Sensor Signal |
| 4 | 0.35 YE | 5058 | Intrusion Sensor Armed Signal |
Vehicle Inclination Sensor (UA2)
Scheme 450
Scheme 450: Vehicle Speed Sensor (VSS) (MG9)
| Connector Part Information Harness: Engine OEM: 12162195 Service: 88987993 Description: 2-Way F Metri-Pack 150.2 Series, Sealed (BK) |
|---|
| Terminal Part Information Terminal/Tray: 4-964286-1/16 Core/Insulation Crimp: E/1 Release Tool: 12093647 Test Probe: J-35616-4A (PU) |
| Pin | Wire | Circuit | Function |
|---|
| A | 0.35 PU | 401 | VSS High Signal |
| B | 0.35 YE | 400 | VSS Low Signal |
Vehicle Speed Sensor (VSS) (MG9)
Scheme 451
Scheme 451: Vehicle Speed Sensor (VSS) (MV7)
| Connector Part Information Harness: Engine OEM: 1928402868 Service: 15306391 Description: 3-Way F 2.8 Junior Power Timer Series, Sealed (BK) |
|---|
| Terminal Part Information Terminal/Tray: 4-964286-1/16 Core/Insulation Crimp: E/1 Release Tool: 12093647 Test Probe: J-35616-4A (PU) |
| Pin | Wire | Circuit | Function |
|---|
| 1 | 0.5 PU/WH | 821 | VSS High Signal |
| 2 | 0.8 BK/WH | 1551 | Ground |
| 3 | 0.35 GY | 5294 | Battery Positive Voltage |
Vehicle Speed Sensor (VSS) (MV7)
