Wiring Systems and Power Management - Component Connector End Views - I Through K Cadillac CTS II

Body Electrical 27 illustrations ~535 words

Scheme 312

Scheme 312: I/P Compartment Lamp
Scheme 312: I/P Compartment Lamp
Connector Part Information Harness: Instrument Panel OEM: 12059247 Service: 12085535 Description: 2-Way F Metri-Pack 150 Series (GY)
Terminal Part Information Terminal/Tray: 12064971/5 Core/Insulation Crimp: E/C Release Tool: 12094429 Test Probe: J-35616-14 (GN)
PinWireCircuitFunction
A0.5 PU175Glove Box Lamp Control
B0.5 OG1732Courtesy Lamps Supply Voltage

I/P Compartment Lamp

Scheme 313

Scheme 313: I/P Compartment Lamp Switch
Scheme 313: I/P Compartment Lamp Switch
Connector Part Information Harness: Instrument Panel OEM: 12015197 Service: 12102626 Description: 2-Way F Metri-Pack 280 Series (BU)
Terminal Part Information Terminal/Tray: 12034046/2 Core/Insulation Crimp: E/A Release Tool: 12094430 Test Probe: J-35616-4A (PU)
PinWireCircuitFunction
A0.5 BK450Ground
B0.5 PU175Glove Box Lamp Control

I/P Compartment Lamp Switch

I/P Courtesy Lamp - Left

Connector Part Information Harness: Instrument Panel OEM: 12047662 Service: 12085535 Description: 2-Way F Metri-Pack 150 Series (BK)
Terminal Part Information Pin: A Terminal/Tray: 12047767/2 Core/Insulation Crimp: E/A Release Tool: 12094429 Test Probe: J-35616-14 (GN) Pin: B Terminal/Tray: 12064971/5 Core/Insulation Crimp: E/C Release Tool: 12094429 Test Probe: J-35616-14 (GN)
PinWireCircuitFunction
A0.8 GY/BK690Courtesy Lamp Relay Control
B0.5 BK350Ground

I/P Courtesy Lamp - Left

I/P Courtesy Lamp - Right

Connector Part Information Harness: Instrument Panel OEM: 12047662 Service: 12085535 Description: 2-Way F Metri-Pack 150 Series (BK)
Terminal Part Information Terminal/Tray: 12064971/5 Core/Insulation Crimp: E/C Release Tool: 12094429 Test Probe: J-35616-14 (GN)
PinWireCircuitFunction
A0.5 GY/BK690Courtesy Lamp Supply Voltage
B0.5 BK450Ground

I/P Courtesy Lamp - Right

Scheme 314

Scheme 314: I/P Dimmer Switch
Scheme 314: I/P Dimmer Switch
Connector Part Information Harness: Instrument Panel OEM: 12064993 Service: 12102485 Description: 6-Way F Micro-Pack 100 Series (BK)
Terminal Part Information Terminal/Tray: 12146447/3 Core/Insulation Crimp: E/C Release Tool: 12031876-1 Test Probe: J-35616-6 (BN)
PinWireCircuitFunction
50.35 OG/WH81212-Volt Reference or I/P Dimming Voltage Reference
60.35 YE6817LED Backlight Dimming Control
70.35 BK350Ground
80.35 PK/BK1597Courtesy Lamps Switch On Signal
90.35 D-GN44I/P Lamps Dimmer Switch Signal
100.35 BK/WH651Ground

I/P Dimmer Switch

Scheme 315

Scheme 315: Ignition Coil 1 (LF1 or LLT)
Scheme 315: Ignition Coil 1 (LF1 or LLT)
Connector Part Information Harness: Engine OEM: 15466325 Service: 88988737 Description: 4-Way F GT 150 Series, Sealed (BK)
Terminal Part Information Terminal/Tray: 12191819/8 Core/Insulation Crimp: 2/1 Release Tool/Test Probe: 15315247/J-35616-2A (GY)
PinWireCircuitFunction
A1 BK1350Ground
B0.5 BN2129Low Reference
C0.5 PU2121IC 1 Control
D1 PK/BK5291Ignition 1 Voltage

Ignition Coil 1 (LF1 or LLT)

Scheme 316

Scheme 316: Ignition Coil 1 (LSA)
Scheme 316: Ignition Coil 1 (LSA)
Connector Part Information Harness: Engine OEM: 15439568 Service: 88987184 Description: 4-Way F GT 150 Sealed (BK)
Terminal Part Information Terminal/Tray: 12191819/8 Core/Insulation Crimp: Pins A, D: 2/A; Pins B, C: E/A Release Tool: 15315247 Test Probe: J-35616-2A (GY)
PinWireCircuitFunction
A0.8 BK550Ground
B0.8 BN2129Low Reference
C0.5 PK2121IC 1 Control
D0.8 PK1239Ignition 1 Voltage

Ignition Coil 1 (LSA)

Ignition Coil 2 (LF1 or LLT)

Connector Part Information Harness: Engine OEM: 15466325 Service: 88988737 Description: 4-Way F GT 150 Series, Sealed (BK)
Terminal Part Information Terminal/Tray: 12191819/8 Core/Insulation Crimp: 2/1 Release Tool/Test Probe: 15315247/J-35616-2A (GY)
PinWireCircuitFunction
A1 BK1450Ground
B0.5 BN/WH2130Low Reference
C0.5 OG/WH2122IC 2 Control
D1 PK/BK5292Ignition 1 Voltage

Ignition Coil 2 (LF1 or LLT)

Ignition Coil 2 (LSA)

Connector Part Information Harness: Engine OEM: 15439568 Service: 88987184 Description: 4-Way F GT 150 Sealed (BK)
Terminal Part Information Terminal/Tray: 12191819/8 Core/Insulation Crimp: Pins A, D: 2/A; Pins B, C: E/A Release Tool: 15315247 Test Probe: J-35616-2A (GY)
PinWireCircuitFunction
A0.8 BK550Ground
B0.8 BN/WH2130Low Reference
C0.5 OG/WH2122IC 2 Control
D0.8 PK1339Ignition 1 Voltage

Ignition Coil 2 (LSA)

Ignition Coil 3 (LF1 or LLT)

Connector Part Information Harness: Engine OEM: 15466325 Service: 88988737 Description: 4-Way F GT 150 Series, Sealed (BK)
Terminal Part Information Terminal/Tray: 12191819/8 Core/Insulation Crimp: 2/1 Release Tool/Test Probe: 15315247/J-35616-2A (GY)
PinWireCircuitFunction
A1 BK1350Ground
B0.5 BN2129Low Reference
C0.5 D-BU2123IC 3 Control
D1 PK/BK5291Ignition 1 Voltage

Ignition Coil 3 (LF1 or LLT)

Ignition Coil 3 (LSA)

Connector Part Information Harness: Engine OEM: 15439568 Service: 88987184 Description: 4-Way F GT 150 Sealed (BK)
Terminal Part Information Terminal/Tray: 12191819/8 Core/Insulation Crimp: Pins A, D: 2/A; Pins B, C: E/A Release Tool: 15315247 Test Probe: J-35616-2A (GY)
PinWireCircuitFunction
A0.8 BK550Ground
B0.8 BN2129Low Reference
C0.5 L-BU2123IC 3 Control
D0.8 PK1239Ignition 1 Voltage

Ignition Coil 3 (LSA)

Ignition Coil 4 (LF1 or LLT)

Connector Part Information Harness: Engine OEM: 15466325 Service: 88988737 Description: 4-Way F GT 150 Series, Sealed (BK)
Terminal Part Information Terminal/Tray: 12191819/8 Core/Insulation Crimp: 2/1 Release Tool/Test Probe: 15315247/J-35616-2A (GY)
PinWireCircuitFunction
A1 BK1450Ground
B0.5 BN/WH2130Low Reference
C0.5 D-GN/WH2124IC 4 Control
D1 PK/BK5292Ignition 1 Voltage

Ignition Coil 4 (LF1 or LLT)

Ignition Coil 4 (LSA)

Connector Part Information Harness: Engine OEM: 15439568 Service: 88987184 Description: 4-Way F GT 150 Sealed (BK)
Terminal Part Information Terminal/Tray: 12191819/8 Core/Insulation Crimp: Pins A, D: 2/A; Pins B, C: E/A Release Tool: 15315247 Test Probe: J-35616-2A (GY)
PinWireCircuitFunction
A0.8 BK550Ground
B0.8 BN/WH2130Low Reference
C0.5 D-GN/WH2124IC 4 Control
D0.8 PK1339Ignition 1 Voltage

Ignition Coil 4 (LSA)

Ignition Coil 5 (LF1 or LLT)

Connector Part Information Harness: Engine OEM: 15466325 Service: 88988737 Description: 4-Way F GT 150 Series, Sealed (BK)
Terminal Part Information Terminal/Tray: 12191819/8 Core/Insulation Crimp: 2/1 Release Tool/Test Probe: 15315247/J-35616-2A (GY)
PinWireCircuitFunction
A1 BK1350Ground
B0.5 BN2129Low Reference
C0.5 D-GN2125IC 5 Control
D1 PK/BK5291Ignition 1 Voltage

Ignition Coil 5(LF1 or LLT)

Ignition Coil 5 (LSA)

Connector Part Information Harness: Engine OEM: 15439568 Service: 88987184 Description: 4-Way F GT 150 Sealed (BK)
Terminal Part Information Terminal/Tray: 12191819/8 Core/Insulation Crimp: Pins A, D: 2/A; Pins B, C: E/A Release Tool: 15315247 Test Probe: J-35616-2A (GY)
PinWireCircuitFunction
A0.8 BK550Ground
B0.8 BN2129Low Reference
C0.5 D-GN2125IC 5 Control
D0.8 PK1239Ignition 1 Voltage

Ignition Coil 5 (LSA)

Ignition Coil 6 (LF1 or LLT)

Connector Part Information Harness: Engine OEM: 15466325 Service: 88988737 Description: 4-Way F GT 150 Series, Sealed (BK)
Terminal Part Information Terminal/Tray: 12191819/8 Core/Insulation Crimp: 2/1 Release Tool/Test Probe: 15315247/J-35616-2A (GY)
PinWireCircuitFunction
A1 BK1450Ground
B0.5 BN/WH2130Low Reference
C0.5 L-BU/WH2126IC 6 Control
D1 PK/BK5292Ignition 1 Voltage

Ignition Coil 6 (LF1 or LLT)

Ignition Coil 6 (LSA)

Connector Part Information Harness: Engine OEM: 15439568 Service: 88987184 Description: 4-Way F GT 150 Sealed (BK)
Terminal Part Information Terminal/Tray: 12191819/8 Core/Insulation Crimp: Pins A, D: 2/A; Pins B, C: E/A Release Tool: 15315247 Test Probe: J-35616-2A (GY)
PinWireCircuitFunction
A0.8 BK550Ground
B0.8 BN/WH2130Low Reference
C0.5 L-BU/WH2126IC 6 Control
D0.8 PK1339Ignition 1 Voltage

Ignition Coil 6 (LSA)

Ignition Coil 7 (LSA)

Connector Part Information Harness: Engine OEM: 15439568 Service: 88987184 Description: 4-Way F GT 150 Sealed (BK)
Terminal Part Information Terminal/Tray: 12191819/8 Core/Insulation Crimp: Pins A, D: 2/A; Pins B, C: E/A Release Tool: 15315247 Test Probe: J-35616-2A (GY)
PinWireCircuitFunction
A0.8 BK550Ground
B0.8 BN2129Low Reference
C0.5 OG2127IC 7 Control
D0.8 PK1239Ignition 1 Voltage

Ignition Coil 7 (LSA)

Ignition Coil 8 (LSA)

Connector Part Information Harness: Engine OEM: 15439568 Service: 88987184 Description: 4-Way F GT 150 Sealed (BK)
Terminal Part Information Terminal/Tray: 12191819/8 Core/Insulation Crimp: Pins A, D: 2/A: Pins B, C: E/A Release Tool: 15315247 Test Probe: J-35616-2A (GY)
PinWireCircuitFunction
A0.8 BK550Ground
B0.8 BN/WH2130Low Reference
C0.5 PU/WH2128IC 8 Control
D0.8 PK1339Ignition 1 Voltage

Ignition Coil 8 (LSA)

Scheme 317

Scheme 317: Ignition Lock Cylinder Control Actuator
Scheme 317: Ignition Lock Cylinder Control Actuator
Connector Part Information Harness: Steering Column OEM: 7283-7258-30 Service: Service by Harness - See Part Catalog Description: 2-Way F 1.5 GT Series (BK)
Terminal Part Information Terminal/Tray: Service by Harness - See Part Catalog Core/Insulation Crimp: N/A Release Tool/Test Probe: 15315247/J-35616-2A (GY)
PinWireCircuitFunction
10.35 PU/WH1630Steering Column Key Cylinder Lock Solenoid Control (MYA or MYB or MYD)
0.35 BK/WH651Ground (MV7 or MG9)
20.35 PU/WH5905Key Capture/Column Lock Shift Position Signal

Ignition Lock Cylinder Control Actuator

Scheme 318

Scheme 318: Ignition Switch
Scheme 318: Ignition Switch
Connector Part Information Harness: Steering Column OEM: HCMPB-C06-K Service: Service by Harness - See Part Catalog Description: 6-Way F HCM Series (BK)
Terminal Part Information Terminal/Tray: Service by Harness - See Part Catalog Core/Insulation Crimp: N/A Release Tool/Test Probe: 12094429/J-35616-64B (L-BU)
PinWireCircuitFunction
10.35 RD/WH3Ignition 1 Voltage
20.35 OG1940Battery Positive Voltage
30.35 BN4Accessory Voltage
40.35 WH1390Off/Run/Crank Voltage
50.35 L-GN80Key In Ignition Switch Signal (BTM)
60.35 WH/BK10735-Volt Reference

Ignition Switch

Scheme 319

Scheme 319: Inflatable Restraint Front End Sensor - Left
Scheme 319: Inflatable Restraint Front End Sensor - Left
Connector Part Information Harness: Instrument Panel OEM: 19151432 Service: 13314084 Description: 2-Way F Kaizen 0.64 Series, Sealed (D-GY)
Terminal Part Information Terminal/Tray: Service by Pigtail - See Part Catalog Core/Insulation Crimp: N/A Release Tool: 15315247 Test Probe: J-35616-2A (GY)
PinWireCircuitFunction
10.35 YE354Left Front Discriminating Sensor Signal
20.35 TN/OG5045Left Front Discriminating Sensor Low Reference

Inflatable Restraint Front End Sensor - Left

Inflatable Restraint Front End Sensor - Right

Connector Part Information Harness: Instrument Panel OEM: 19151432 Service: 13314084 Description: 2-Way F Kaizen 0.64 Series, Sealed (D-GY)
Terminal Part Information Terminal/Tray: Service by Pigtail - See Part Catalog Core/Insulation Crimp: N/A Release Tool: 15315247 Test Probe: J-35616-2A (GY)
PinWireCircuitFunction
10.35 D-GN1409Right Front Discriminating Sensor Signal
20.35 GY5600Right Front Discriminating Sensor Low Reference

Inflatable Restraint Front End Sensor - Right

Scheme 320

Scheme 320: Inflatable Restraint Front Passenger Presence System (PPS) Module
Scheme 320: Inflatable Restraint Front Passenger Presence System (PPS) Module
Connector Part Information Harness: Passenger Seat OEM: 19153764 Service: Service by Harness - See Part Catalog Description: 4-Way M Low Profile 1.5 Series (BK)
Terminal Part Information Terminal/Tray: Service by Harness - See Part Catalog Core/Insulation Crimp: N/A Release Tool/Test Probe: 15315247/J-35616-3 (GY)
PinWireCircuitFunction
1Not Used
20.35 D-GN5060Low Speed GMLAN Serial Data
30.35 RD/WH1740Battery Positive Voltage
40.35 BK/WH451Ground

Inflatable Restraint Front Passenger Presence System (PPS) Module

Scheme 321

Scheme 321: Inflatable Restraint I/P Module X1
Scheme 321: Inflatable Restraint I/P Module X1
Connector Part Information Harness: I/P Inflator OEM: 252922343 Service: Service by Harness - See Part Catalog Description: 4-Way M Metri-Pack 280 Series (YE)
Terminal Part Information Terminal/Tray: Service by Harness - See Part Catalog Core/Insulation Crimp: N/A Release Tool/Test Probe: Not Available
PinWireCircuitFunction
10.35 YE3025I/P Module - Stage 1 - High Control
20.35 OG3024I/P Module - Stage 1 - Low Control

Inflatable Restraint I/P Module X1

Inflatable Restraint I/P Module X2

Connector Part Information Harness: I/P Inflator OEM: 252922343 Service: Service by Harness - See Part Catalog Description: 4-Way M Metri-Pack 280 Series (YE)
Terminal Part Information Terminal/Tray: Service by Harness - See Part Catalog Core/Insulation Crimp: N/A Release Tool/Test Probe: Not Available
PinWireCircuitFunction
10.35 PU3026I/P Module - Stage 2 - Low Control
20.35 GY3027I/P Module - Stage 2 - High Control

Inflatable Restraint I/P Module X2

Scheme 322

Scheme 322: Inflatable Restraint Roof Rail Module - Left
Scheme 322: Inflatable Restraint Roof Rail Module - Left
Connector Part Information Harness: Body OEM: 12186799 Service: 15306012 Description: 2-Way M 280 Series (YE)
Terminal Part Information Terminal/Tray: Service by Pigtail - See Part Catalog Core/Insulation Crimp: N/A Release Tool/Test Probe: 12094429/J-35616-5 (PU)
PinWireCircuitFunction
A0.5 PU/WH5019Roof Rail Module - Left - High Control
B0.5 PK5020Roof Rail Module - Left - Low Control

Inflatable Restraint Roof Rail Module - Left

Inflatable Restraint Roof Rail Module - Right

Connector Part Information Harness: Body OEM: 12186799 Service: 15306012 Description: 2-Way M 280 Series (YE)
Terminal Part Information Terminal/Tray: Service by Pigtail - See Part Catalog Core/Insulation Crimp: N/A Release Tool/Test Probe: 12094429/J-35616-5 (PU)
PinWireCircuitFunction
A0.5 YE/BK5021Roof Rail Module - Right - High Control
B0.5 WH/BK5022Roof Rail Module - Right - Low Control

Inflatable Restraint Roof Rail Module - Right

Scheme 323

Scheme 323: Inflatable Restraint Sensing and Diagnostic Module (SDM) X1
Scheme 323: Inflatable Restraint Sensing and Diagnostic Module (SDM) X1
Connector Part Information Harness: Body OEM: 13503133 (Sedan) OEM: 13503460 (Wagon) Service: Service by Pigtail - See Part Catalog Description: 24-Way F Kaizen 0.64 Series, Sealed (YE)
Terminal Part Information Terminal/Tray: Service by Pigtail - See Part Catalog Core/Insulation Crimp: N/A Release Tool/Test Probe: Not Available
PinWireCircuitFunction
10.35 WH3023Steering Wheel Module Stage 2 High Control
20.35 PK3022Steering Wheel Module Stage 2 Low Control
30.35 BN3020Steering Wheel Module Stage 2 Low Control
40.35 TN3021Steering Wheel Module Stage 2 High Control
50.35 YE3025I/P Module Stage 1 High Control
60.35 OG3024I/P Module Stage 1 Low Control
70.35 PU3026I/P Module Stage 2 Low Control
80.35 GY3027I/P Module Stage 2 High Control
90.35 RD/WH1740Battery Positive Voltage
10-14Not Available
150.35 D-GN5060Low Speed GM LAN Serial Data
160.35 D-GN5060Low Speed GM LAN Serial Data
170.5 PK1739Ignition Voltage
18Not Available
190.5 BK/WH1751Ground
20-24Not Available

Inflatable Restraint Sensing and Diagnostic Module (SDM) X1

Scheme 324

Scheme 324: Inflatable Restraint Sensing and Diagnostic Module (SDM) X2
Scheme 324: Inflatable Restraint Sensing and Diagnostic Module (SDM) X2
Connector Part Information Harness: Body OEM: 13504385 (Sedan without LSA) OEM: 13502177 (Sedan with LSA) OEM: 13503461 (Wagon) Service: Service by Pigtail - See Part Catalog Description: 54-Way F 0.64 Series, Sealed (YE)
Terminal Part Information Terminal/Tray: Service by Pigtail - See Part Catalog Core/Insulation Crimp: N/A Release Tool/Test Probe: Not Available
PinWireCircuitFunction
1-8Not Available
90.35 TN/WH3477Seat Belt Pretensioner - Low Control (LSA)
100.35 PK/BK3478Seat Belt Pretensioner - High Control (LSA)
110.35 PK3476Seat Belt Pretensioner - Low Control (LSA)
120.35 L-GN3475Seat Belt Pretensioner - High Control (LSA)
130.35 BN2137Side Impact Module - LF - High Control
140.35 YE/BK2138Side Impact Module - LF - Low Control
150.35 L-GN2136Side Impact Module - RF - High Control
160.35 TNWH2135Side Impact Module - RF - Low Control
170.5 PU/WH5019Roof Rail Module Left - High Control
180.5 PK5020Roof Rail Module Left - Low Control
190.35 WH2132Side Impact Sensor - Left - Signal (LHD)
0.35 PU/WH6628Low Reference (RHD)
200.35 PU/WH6628Low Reference (LHD)
0.35 WH2132Side Impact Sensor - Left - Signal (RHD)
210.35 WH/BK6629Low Reference (LHD)
0.35 D-GN2134Side Impact Sensor - Right - Signal (RHD)
220.35 D-GN2134Side Impact Sensor - Right - Signal (LHD)
0.35 WH/BK6629Low Reference (RHD)
230.35 YE354Left Front Discriminating Sensor Signal
240.35 TN/OG5045Low Reference
250.35 GY5600Right Front Side Impact Sensing Module Signal
260.35 D-GN1409Right Front Side Impact Sensing Module Signal
270.35 L-BU6622Left Rear Side Impact Sensing Module Signal
280.35 L-GN/BK6623Left Rear Side Impact Sensing Module Signal
290.35 PK/BK6627Right Rear Side Impact Sensing Module Low Reference
300.35 L-BU/WH6626Right Rear Side Impact Sensing Module High Reference
31-36Not Available
370.35 TN/WH2118Seat Belt Retractor Pretensioner - Driver - High Control
380.35 OG/BK2119Seat Belt Retractor Pretensioner - Driver - Low Control
390.35 OG2117Seat Belt Retractor Pretensioner - Passenger - Low Control
400.35 L-GN2116Seat Belt Retractor Pretensioner - Passenger - High Control
410.35 TN/WH238Driver Seat Belt Switch Signal
420.35 L-GN5055Driver Seat Position Switch Signal (early production Wagon)
430.35 D-BU1363Seat Belt Switch - Left - Low Reference
440.35 L-BU1361Passenger Seat Belt Switch Low Reference
450.35 OG1362Seat Belt Switch Signal
460.35 L-BU5056Passenger Seat Position Switch Signal (early production Wagon)
47-51Not Available
530.5 YE/BK5021Roof Rail Module Right - High Control
540.5 WH/BK5022Roof Rail Module Right - Low Control

Inflatable Restraint Sensing and Diagnostic Module (SDM) X2

Scheme 325

Scheme 325: Inflatable Restraint Side Impact Module - Left
Scheme 325: Inflatable Restraint Side Impact Module - Left
Connector Part Information Harness: Seat OEM: 12186799 Service: Service by Pigtail - See Part Catalog Description: 2-Way F (YE)
Terminal Part Information Terminal/Tray: Service by Pigtail - See Part Catalog Core/Insulation Crimp: N/A Release Tool/Test Probe: N/A
PinWireCircuitFunction
A0.5 YE/BK2138Side Impact Module - Left Front - Low Control
B0.5 BN2137Side Impact Module - Left Front - High Control

Inflatable Restraint Side Impact Module - Left

Inflatable Restraint Side Impact Module - Right

Connector Part Information Harness: Seat OEM: 12186799 Service: Service by Pigtail - See Part Catalog Description: 2-Way F (YE)
Terminal Part Information Terminal/Tray: Service by Pigtail - See Part Catalog Core/Insulation Crimp: N/A Release Tool/Test Probe: N/A
PinWireCircuitFunction
A0.5 YE/BK2136Side Impact Module - Right Front - Low Control
B0.5 BN2135Side Impact Module - Right Front - High Control

Inflatable Restraint Side Impact Module - Right

Inflatable Restraint Side Impact Sensor (SIS) - Left Front

Connector Part Information Harness: Door OEM: 19151432 Service: 13314084 Description: 2-Way F Kaizen 0.64 Series, Sealed (D-GY)
Terminal Part Information Terminal/Tray: Service by Harness - See Part Catalog Core/Insulation Crimp: N/A Release Tool/Test Probe: N/A
PinWireCircuitFunction
10.35 WH2132Side Impact Sensing Module - Left - Signal (LHD)
0.35 D-GN2134Side Impact Sensing Module - Left - Signal (RHD)
20.35 PU/WH6628Side Impact Sensing Module - Left - Low (LHD)
0.35 WH/BK6629Side Impact Sensing Module - Left - Low (RHD)

Inflatable Restraint Side Impact Sensor (SIS) - Left Front

Inflatable Restraint Side Impact Sensor (SIS) - Left Rear

Connector Part Information Harness: Door OEM: 19151432 Service: 13314084 Description: 2-Way F Kaizen 0.64 Series, Sealed (D-GY)
Terminal Part Information Terminal/Tray: Service by Harness - See Part Catalog Core/Insulation Crimp: N/A Release Tool/Test Probe: N/A
PinWireCircuitFunction
10.35 L-BU6622Left Rear Side Impact Sensing Module Signal
20.35 L-GN/BK6623Left Rear Side Impact Sensing Module Low Reference

Inflatable Restraint Side Impact Sensor (SIS) - Left Rear

Inflatable Restraint Side Impact Sensor (SIS) - Right Front

Connector Part Information Harness: Door OEM: 19151432 Service: 13314084 Description: 2-Way F Kaizen 0.64 Series, Sealed (D-GY)
Terminal Part Information Terminal/Tray: Service by Harness - See Part Catalog Core/Insulation Crimp: N/A Release Tool/Test Probe: N/A
PinWireCircuitFunction
10.35 D-GN2134Side Impact Sensing Module - Right - Signal (LHD)
0.35 WH2132Side Impact Sensing Module - Right - Signal (RHD)
20.35 WH/BK6629Side Impact Sensing Module - Right - Low Reference (LHD)
0.35 PU/WH6628Side Impact Sensing Module - Right - Low Reference (RHD)

Inflatable Restraint Side Impact Sensor (SIS) - Right Front

Inflatable Restraint Side Impact Sensor (SIS) - Right Rear

Connector Part Information Harness: Door OEM: 19151432 Service: 13314084 Description: 2-Way F Kaizen 0.64 Series, Sealed (D-GY)
Terminal Part Information Terminal/Tray: Service by Pigtail - See Part Catalog Core/Insulation Crimp: N/A Release Tool/Test Probe: N/A
PinWireCircuitFunction
10.35 L-BU/WH6626Right Rear Side Impact Sensing Module Signal
20.35 PK/BK6627Right Rear Side Impact Sensing Module Low Reference

Inflatable Restraint Side Impact Sensor (SIS) - Right Rear

Scheme 326

Scheme 326: Inflatable Restraint Steering Wheel Module X1
Scheme 326: Inflatable Restraint Steering Wheel Module X1
Connector Part Information Harness: Steering Wheel Coil OEM: 54560236 Service: Service by Assembly - See Part Catalog Description: 2-Way F FFB90-4 Type B (GY)
Terminal Part Information Terminal/Tray: Service by Assembly - See Part Catalog Core/Insulation Crimp: N/A Release Tool/Test Probe: N/A
PinWireCircuitFunction
10.35 TN3021Steering Wheel Module - Stage 1 - High Control
20.35 BN3020Steering Wheel Module - Stage 1 - Low Control

Inflatable Restraint Steering Wheel Module X1

Scheme 327

Scheme 327: Inflatable Restraint Steering Wheel Module X2
Scheme 327: Inflatable Restraint Steering Wheel Module X2
Connector Part Information Harness: Steering Wheel Coil OEM: 54560222 Service: Service by Assembly - See Part Catalog Description: 2-Way F FFB90-4 Type G (PK)
Terminal Part Information Terminal/Tray: Service by Assembly - See Part Catalog Core/Insulation Crimp: N/A Release Tool/Test Probe: N/A
PinWireCircuitFunction
10.35 WH3023Steering Wheel Module - Stage 2 - High Control
20.35 PK3022Steering Wheel Module - Stage 2 - Low Control

Inflatable Restraint Steering Wheel Module X2

Scheme 328

Scheme 328: Inflatable Restraint Steering Wheel Module Coil X1
Scheme 328: Inflatable Restraint Steering Wheel Module Coil X1
Connector Part Information Harness: Steering Column OEM: 15269795 Service: 13316186 Description: 10-Way F AIT II Series (BK)
Terminal Part Information Terminal/Tray: Service by Harness - See Part Catalog Core/Insulation Crimp: N/A Release Tool/Test Probe: J-38125-215A/J-35616-64B (L-BU)
PinWireCircuitFunction
10.35 TN28Horn Relay Control
20.35 PU1375Remote Radio Control Supply Voltage
30.35 PU/WH7005LED Dimming Signal
40.5 BK650Ground
50.35 GY1884Cruise Control Switch Signal
60.35 D-GN/WH7158Cruise Control Indicator Dimming Signal
70.35 D-BU1796Steering Wheel Controls Signal
80.35 YE1996Remote Shift Selector Signal
9-10Not Used

Inflatable Restraint Steering Wheel Module Coil X1

Inflatable Restraint Steering Wheel Module Coil X2

Connector Part Information Harness: Steering Wheel OEM: 15269795 Service: 13316186 Description: 10-Way F AIT II Series (BK)
Terminal Part Information Terminal/Tray: Service by Harness - See Part Catalog Core/Insulation Crimp: N/A Release Tool/Test Probe: J-38125-215A/J-35616-64B (L-BU)
PinWireCircuitFunction
1-2Not Used
30.35 YE1996Remote Shift Selector Signal (KB7)
40.35 D-BU1796Steering Wheel Controls Signal
50.35 D-GN/WH7158Cruise Control Indicator Dimming Signal
60.35 GY1884Cruise Control Switch Signal
70.35 BK650Ground
80.35 PU/WH7005LED Dimming Signal
90.35 PU1375Remote Radio Control Supply Voltage
100.35 TN28Horn Relay Control

Inflatable Restraint Steering Wheel Module Coil X2

Scheme 329

Scheme 329: Inflatable Restraint Steering Wheel Module Coil X3
Scheme 329: Inflatable Restraint Steering Wheel Module Coil X3
Connector Part Information Harness: Steering Column OEM: 15393421 Service: 88987853 Description: 4-Way F Micro-Pack 064 Series (YE)
Terminal Part Information Terminal/Tray: Service by Pigtail - See Part Catalog Core/Insulation Crimp: N/A Release Tool/Test Probe: N/A
PinWireCircuitFunction
10.35 TN3021Steering Wheel Module - Stage 1 - High Control
20.35 BN3020Steering Wheel Module - Stage 1 - Low Control
30.35 WH3023Steering Wheel Module - Stage 2 - High Control
40.35 PK3022Steering Wheel Module - Stage 2 - Low Control

Inflatable Restraint Steering Wheel Module Coil X3

Scheme 330

Scheme 330: Inside Rearview Mirror (ISRVM)
Scheme 330: Inside Rearview Mirror (ISRVM)
Connector Part Information Harness: Headliner OEM: 917981-2 Service: 15306351 Description: 16-Way F 040/070 Hybrid Series (BK)
Terminal Part Information Terminal/Tray: 15445905/23 Core/Insulation Crimp: J/J Release Tool/Test Probe: 12180559/J-35616-16 (L-GN)
PinWireCircuitFunction
1-7Not Used
80.35 BK/WH1051Ground
90.5 L-GN24Backup Lamp Supply Voltage
10Not Used
110.35 D-GN/WH2514Keypad Signal (UE1)
120.35 L-GN/BK2515Keypad Supply Voltage (UE1)
130.35 PK43Accessory Voltage
140.35 YE/BK2516Keypad Green LED Signal (UE1)
150.35 BN/WH2517Keypad Red LED Signal (UE1)
16Not Used

Inside Rearview Mirror (ISRVM)

Scheme 331

Scheme 331: Instrument Panel Cluster (IPC)
Scheme 331: Instrument Panel Cluster (IPC)
Connector Part Information Harness: Instrument Panel OEM: 15126711 Service: 15126711 Description: 20-Way F 64 Series (BK)
Terminal Part Information Terminal/Tray: SAITS-A03T-M064/14 Core/Insulation Crimp: 9/9 Release Tool/Test Probe: J-38125-215A/J-35616-64B (L-BU)
PinWireCircuitFunction
10.5 TN/WH33Brake Warning Indicator Control
20.35 PK893DIC Select Menu Switch Signal
30.35 PU/WH7484Differential Oil Temperature Sensor 5-Volt Reference (LSA)
40.35 D-GN5060Low Speed GMLAN Serial Data
50.35 D-GN5060Low Speed GMLAN Serial Data
60.35 PU7485Oil Temperature Sensor Signal (LSA)
7-8Not Used
90.35 D-BU/WH5970Washer Fluid Heated Control Switch LED Supply Voltage (XA7)
100.5 TN185Low Washer Fluid Indicator Control
110.35 D-GN/WH1358DIC Switch Signal
120.35 BN897DIC Switch Low Reference
130.35 BN/WH419MIL Control
14-16Not Used
170.35 BK/WH651Ground
18Not Used
190.35 RD/WH540Battery Positive Voltage
200.35 PK1739Ignition 1 Voltage

Instrument Panel Cluster (IPC)

Scheme 332

Scheme 332: Intake Air Temperature Sensor (LSA)
Scheme 332: Intake Air Temperature Sensor (LSA)
Connector Part Information Harness: Engine OEM: 15449027 Service: 13501880 Description: 2-Way F GT 150 Series, Sealed (BK)
Terminal Part Information Terminal/Tray: 15326267/19 Core/Insulation Crimp: E/1 Release Too: 15315247 Test Probe: J-35616-2A (GY)
PinWireCircuitFunction
A0.8 L-BU6118IAT Sensor Signal
B0.8 YE/BK6120Low Reference

Intake Air Temperature Sensor (LSA)

Scheme 333

Scheme 333: Intrusion Sensor (UA2)
Scheme 333: Intrusion Sensor (UA2)
Connector Part Information Harness: Headliner OEM: 15326747 Service: 15306385 Description: 3-Way F Micro-Pack 064 Series (BK)
Terminal Part Information Terminal/Tray: 12177007/19 Core/Insulation Crimp: E/2 Release Tool: 12180559-1 Test Probe: J-35616-64B (L-BU)
PinWireCircuitFunction
A0.35 RD/WH4540Battery Positive Voltage
B0.35 PU5059Intrusion Sensor Alarm On Signal
C0.35 YE5058Intrusion Sensor Armed Signal

Intrusion Sensor (UA2)

Scheme 334

Scheme 334: Keyless Entry Antenna - Center Console Active (BTM)
Scheme 334: Keyless Entry Antenna - Center Console Active (BTM)
Connector Part Information Harness: Console OEM: IL-AG5-5S-S3C9 Service: Service by Harness - See Part Catalog Description: 5-Way F (GN)
Terminal Part Information Terminal/Tray: Service by Harness - See Part Catalog Core/Insulation Crimp: N/A Release Tool/Test Probe: J-38125-211/J-35616-64B (L-BU)
PinWireCircuitFunction
1Not Used
20.35 PU/WH5715Keyless Entry Active Antenna Supply Voltage
30.35 GY5717Keyless Entry Active Antenna Data Signal
40.35 L-BU5716Keyless Entry Active Antenna Clock Signal
50.35 OG/BK5718Keyless Entry Active Antenna Low Reference

Keyless Entry Antenna - Center Console Active (BTM)

Scheme 335

Scheme 335: Keyless Entry Antenna - Center Console Passive (BTM)
Scheme 335: Keyless Entry Antenna - Center Console Passive (BTM)
Connector Part Information Harness: Console OEM: 12162017 Service: 12101937 Description: 2-Way F Metri-Pack 150 Series, Sealed (GY)
Terminal Part Information Terminal/Tray: 12048074/2 Core/Insulation Crimp: E/1 Release Tool: 12094429 Test Probe: J-35616-14 (GN)
PinWireCircuitFunction
A0.35 PU218Keyless Entry/Tire Pressure Antenna Signal
B0.35 TN219Keyless Entry Antenna Low Reference

Keyless Entry Antenna - Center Console Passive (BTM)

Scheme 336

Scheme 336: Keyless Entry Antenna - Driver Door Handle (ATH)
Scheme 336: Keyless Entry Antenna - Driver Door Handle (ATH)
Connector Part Information Harness: Door Handle OEM: 174352-2 Service: Service by Assembly - See Part Catalog Description: 2-Way F Econoseal J-Mark II Series, Sealed (BK)
Terminal Part Information Terminal/Tray: Service by Assembly - See Part Catalog Core/Insulation Crimp: N/A Release Tool/Test Probe: N/A
PinWireCircuitFunction
10.35 YE5709Keyless Entry Antenna Signal
20.35 WH5713Keyless Entry Antenna Low Reference

Keyless Entry Antenna - Driver Door Handle (ATH)

Keyless Entry Antenna - Headliner (Wagon with BTM)

Connector Part Information Harness: Headliner OEM: 12162017 Service: 12101937 Description: 2-Way F Metri-Pack 150 Series, Sealed (GY)
Terminal Part Information Terminal/Tray: 12048074/2 Core/Insulation Crimp: E/1 Release Tool/Test Probe: 12094429/J-35616-14 (GN)
PinWireCircuitFunction
A0.35 L-GN5707Keyless Entry Antenna - Signal
B0.35 L-GN/BK5711Low Reference

Keyless Entry Antenna - Headliner (Wagon with BTM)

Keyless Entry Antenna - Passenger Door Handle (ATH)

Connector Part Information Harness: Door Handle OEM: 174352-2 Service: Service by Assembly - See Part Catalog Description: 2-Way F Econoseal J-Mark II Series, Sealed (BK)
Terminal Part Information Terminal/Tray: Service by Assembly - See Part Catalog Core/Insulation Crimp: N/A Release Tool/Test Probe: N/A
PinWireCircuitFunction
10.35 YE5710Keyless Entry Antenna Signal
20.35 WH5714Keyless Entry Antenna Low Reference

Keyless Entry Antenna - Passenger Door Handle (ATH)

Scheme 337

Scheme 337: Keyless Entry Antenna - Rear Compartment (ATH)
Scheme 337: Keyless Entry Antenna - Rear Compartment (ATH)
Connector Part Information Harness: Rear Fascia OEM: 12162017 Service: 12101937 Description: 2-Way F Metri-Pack 150 Series, Sealed (GY)
Terminal Part Information Terminal/Tray: 12048074/2 Core/Insulation Crimp: E/1 Release Tool: 12094429 Test Probe: J-35616-14 (GN)
PinWireCircuitFunction
A0.35 OG5708Keyless Entry Antenna Signal
B0.35 OG/BK5712Keyless Entry Antenna Low Reference

Keyless Entry Antenna - Rear Compartment (ATH)

Scheme 338

Scheme 338: Knock Sensor (KS) 1
Scheme 338: Knock Sensor (KS) 1
Connector Part Information Harness: Engine OEM: 15374222 Service: 88988142 Description: 2-Way F GT 150 Sealed (NA)
Terminal Part Information Terminal/Tray: 12191819/8 Core/Insulation Crimp: E/1 Release Tool: 15315247 Test Probe: J-35616-2A (GY)
PinWireCircuitFunction
A0.5 D-BU496KS 1 Signal
B0.5 GY1716KS 1 Signal

Knock Sensor (KS) 1

Knock Sensor (KS) 2

Connector Part Information Harness: Engine OEM: 15374222 Service: 88988142 Description: 2-Way F GT 150 Sealed (NA)
Terminal Part Information Terminal/Tray: 12191819/8 Core/Insulation Crimp: E/1 Release Tool: 15315247 Test Probe: J-35616-2A (GY)
PinWireCircuitFunction
A0.5 L-BU1876KS 2 Signal
B0.5 GY2303KS 2 Signal

Knock Sensor (KS) 2

More articles — Electrical
