Wiring Systems and Power Management - Component Connector End Views - C Through D

Scheme 225

Scheme 225: Camshaft Position (CMP) Actuator Solenoid Valve - Bank 1 Exhaust (LF1 or LLT)

Connector Part Information Harness: Engine OEM: 7283-7526-30 Service: 88988588 Description: 2-Way F Sealed (BK)
Terminal Part Information Terminal/Tray: 7116-4026/11 Core/Insulation Crimp: E/1 Release Tool: 15313892 Test Probe: J-35616-18 (BK)

Pin	Wire	Circuit	Function
1	0.8 PK/BK	5293	Powertrain Main Relay Fused Supply (LLT)
1	0.5 L-GN	5282	Low Reference (LF1)
2	0.75 L-GN	5282	Camshaft Phaser Exhaust Solenoid (LLT)
2	0.5 BN/WH	6754	(LF1)

Camshaft Position (CMP) Actuator Solenoid Valve - Bank 1 Exhaust (LF1 or LLT)

Camshaft Position (CMP) Actuator Solenoid Valve - Bank 1 Intake (LF1/LLT)

Connector Part Information Harness: Engine OEM: 7283-7526-30 Service: 88988588 Description: 2-Way F Sealed (BK)
Terminal Part Information Terminal/Tray: 7116-4026/11 Core/Insulation Crimp: E/1 Release Tool: 15313892 Test Probe: J-35616-18 (BK)

Pin	Wire	Circuit	Function
1	0.8 PK/BK	5293	Powertrain Main Relay Fused Supply (LLT)
1	0.5 PU	5284	Low Reference (LF1)
2	0.75 PU	5284	Camshaft Phaser Intake Solenoid (LLT)
2	0.5 BN	6753	Camshaft Phaser Intake Solenoid (LF1)

Camshaft Position (CMP) Actuator Solenoid Valve - Bank 1 Intake (LF1/LLT)

Camshaft Position (CMP) Actuator Solenoid Valve - Bank 2 Exhaust (LF1/LLT)

Connector Part Information Harness: Engine OEM: 7283-7526-30 Service: 88988588 Description: 2-Way F Sealed (BK)
Terminal Part Information Terminal/Tray: 7116-4026/11 Core/Insulation Crimp: E/1 Release Tool: 15313892 Test Probe: J-35616-18 (BK)

Pin	Wire	Circuit	Function
1	0.8 PK/BK	5293	Powertrain Main Relay Fused Supply (LLT)
1	0.5 WH/BK	5283	Camshaft Phaser Exhaust Solenoid (LF1)
2	0.75 WH/BK	5283	Camshaft Phaser Exhaust Solenoid (LLT)
2	0.5 D-BU/WH	6756	Low Reference (LF1)

Camshaft Position (CMP) Actuator Solenoid Valve - Bank 2 Exhaust (LF1/LLT)

Camshaft Position (CMP) Actuator Solenoid Valve - Bank 2 Intake (LF1/LLT)

Connector Part Information Harness: Engine OEM: 7283-7526-30 Service: 88988588 Description: 2-Way F Sealed (BK)
Terminal Part Information Terminal/Tray: 7116-4026/11 Core/Insulation Crimp: E/1 Release Tool: 15313892 Test Probe: J-35616-18 (BK)

Pin	Wire	Circuit	Function
1	0.8 PK/BK	5293	Powertrain Main Relay Fused Supply (LLT)
1	0.5 OG/BK	5272	Camshaft Phaser Intake Solenoid (LF1)
2	0.75 OG/BK	5272	Camshaft Phaser Intake Solenoid (LLT)
2	0.5 D-BU	6755	Low Reference (LF1)

Camshaft Position (CMP) Actuator Solenoid Valve - Bank 2 Intake (LF1/LLT)

Scheme 226

Scheme 226: Camshaft Position (CMP) Sensor - Bank 1 Exhaust (LF1 or LLT)

Connector Part Information Harness: Engine OEM: 1928403968 Service: 88988595 Description: 3-Way F Kompakt 280 Series, Sealed (BK)
Terminal Part Information Terminal/Tray: 1928498056/8 Core/Insulation Crimp: E/1 Release Tool: J-38125-561 Test Probe: J-35616-35 (VT)

Pin	Wire	Circuit	Function
1	0.5 GY	5296	Low Reference (LF1)
1	0.5 TN	552	Low Reference (LLT)
2	0.5 D-GN	5273	CMP Exhaust Sensor Signal
3	0.5 YE/BK	5297	5-Volt Reference 1 (LF1)
3	0.5 GY	705	5-Volt Reference 2 (LLT)

Camshaft Position (CMP) Sensor - Bank 1 Exhaust (LF1 or LLT)

Camshaft Position (CMP) Sensor - Bank 1 Intake (LF1 or LLT)

Connector Part Information Harness: Engine OEM: 1928403968 Service: 88988595 Description: 3-Way F Kompakt 280 Series, Sealed (BK)
Terminal Part Information Terminal/Tray: 1928498056/8 Core/Insulation Crimp: E/1 Release Tool: J-38125-561 Test Probe: J-35616-35 (VT)

Pin	Wire	Circuit	Function
1	0.5 TN	5301	Low Reference (LF1)
1	0.5 TN	552	Low Reference (LLT)
2	0.5 OG	5275	CMP Intake Sensor
3	0.5 D-BU	5300	5-Volt Reference 1 (LF1)
3	0.5 GY	705	5-Volt Reference 2 (LLT)

Camshaft Position (CMP) Sensor - Bank 1 Intake (LF1 or LLT)

Camshaft Position (CMP) Sensor - Bank 2 Exhaust (LF1 or LLT)

Connector Part Information Harness: Engine OEM: 1928403968 Service: 88988595 Description: 3-Way F Kompakt 280 Series, Sealed (BK)
Terminal Part Information Terminal/Tray: 1928498056/8 Core/Insulation Crimp: E/1 Release Tool: J-38125-561 Test Probe: J-35616-35 (VT)

Pin	Wire	Circuit	Function
1	0.5 BN	5299	Low Reference (LF1)
1	0.5 TN	552	Low Reference (LLT)
2	0.5 PU	5274	CMP Exhaust Sensor
3	0.5 L-GN	5298	5-Volt Reference 1 (LF1)
3	0.5 GY	705	5-Volt Reference 2 (LLT)

Camshaft Position (CMP) Sensor - Bank 2 Exhaust (LF1 or LLT)

Camshaft Position (CMP) Sensor - Bank 2 Intake (LF1 or LLT)

Connector Part Information Harness: Engine OEM: 1928403968 Service: 88988595 Description: 3-Way F Kompakt 280 Series, Sealed (BK)
Terminal Part Information Terminal/Tray: 1928498056/8 Core/Insulation Crimp: E/1 Release Too: J-38125-561 Test Probe: J-35616-35 (VT)

Pin	Wire	Circuit	Function
1	0.5 BN/WH	5303	Low Reference (LLT)
1	0.5 TN	552	Low Reference (LLT)
2	0.5 YE	5276	CMP Intake Sensor
3	0.5 L-BU	5302	5-Volt Reference 1 (LF1)
3	0.5 GY	705	5-Volt Reference 2 (LLT)

Camshaft Position (CMP) Sensor - Bank 2 Intake (LF1 or LLT)

Scheme 227

Scheme 227: Camshaft Position (CMP) Sensor (LSA)

Connector Part Information Harness: Engine OEM: 12059595 Service: 88986451 Description: 3-Way F Metri-Pack 150 Series, Sealed (BK)
Terminal Part Information Terminal/Tray: 1928498056/8 Core/Insulation Crimp: E/1 Test Probe: J-38125-561 Test Probe: J-35616-35 (VT)

Pin	Wire	Circuit	Function
A	0.35 D-BU	6259	5-Volt Reference
B	0.35 BN	6266	Low Reference
C	0.35 D-BU/WH	6265	CMP Sensor Signal

Camshaft Position (CMP) Sensor (LSA)

Scheme 228

Scheme 228: Cargo Lamp - Left

Connector Part Information Harness: Body OEM: 12052832 Service: 12101825 Description: 2-Way F Metri-Pack 150 Series (BK)
Terminal Part Information Terminal/Tray: 12064971/5 Core/Insulation Crimp: E/C Release Tool: 12094429 Test Probe: J-35616-14 (GN)

Pin	Wire	Circuit	Function
A	0.5 GY/BK	690	Courtesy Lamp Supply Voltage
B	0.5 BK	850	Ground

Cargo Lamp - Left

Cargo Lamp - Right

Connector Part Information Harness: Body OEM: 12052832 Service: 12101825 Description: 2-Way F Metri-Pack 150 Series (BK)
Terminal Part Information Terminal/Tray: 12064971/5 Core/Insulation Crimp: E/C Release Tool: 12094429 Test Probe: J-35616-14 (GN)

Pin	Wire	Circuit	Function
A	0.5 GY/BK	690	Courtesy Lamp Supply Voltage
B	0.5 BK	1050	Ground

Cargo Lamp - Right

Scheme 229

Scheme 229: Cellular Telephone Microphone (UE1/WXS)

Connector Part Information Harness: Headliner OEM: 12047663 Service: 12085481 Description: 2-Way M Metri-Pack 150 Series (BK)
Terminal Part Information Terminal/Tray: 12047581/2 Core/Insulation Crimp: E/C Release Tool: 12094429 Test Probe: J-35616-3 (GY)

Pin	Wire	Circuit	Function
A	0.35 BARE	514	Drain Wire
B	0.35 GY	655	Cellular Telephone Microphone Signal

Cellular Telephone Microphone (UE1/WXS)

Scheme 230

Scheme 230: Center High Mounted Stop Lamp (CHMSL) (Sedan)

Connector Part Information Harness: Body OEM: 12059252 Service: 12102749 Description: 2-Way M Metri-Pack 150 Series (RD)
Terminal Part Information Terminal/Tray: 12047581/2 Core/Insulation Crimp: E/C Release Tool: 12094429 Test Probe: J-35616-3 (GY)

Pin	Wire	Circuit	Function
A	0.5 L-BU	1320	CHMSL Supply Voltage
B	0.5 BK	1050	Ground

Center High Mounted Stop Lamp (CHMSL) (Sedan)

Center High Mounted Stop Lamp (CHMSL) (Wagon)

Connector Part Information Harness: Body OEM: 12059252 Service: 12102749 Description: 2-Way M Metri-Pack 150 Series (RD)
Terminal Part Information Terminal/Tray: 12047581/2 Core/Insulation Crimp: E/C Release Tool: 12094429 Test Probe: J-35616-3 (GY)

Pin	Wire	Circuit	Function
A	0.5 YE	820	CHMSL Supply Voltage
B	0.5 BK/WH	2051	Ground

Center High Mounted Stop Lamp (CHMSL) (Wagon)

Scheme 231

Scheme 231: Charge Air Cooler (CAC) Coolant Pump (LSA)

Connector Part Information Harness: Intercooler Jumper OEM: 12131678 Service: 89046833 Description: 2-Way F Mini Timer Series, Sealed (BK)
Terminal Part Information Terminal/Tray: 12047581/2 Core/Insulation Crimp: E/C Release Tool: 12094429 Test Probe: J-35616-3 (GY)

Pin	Wire	Circuit	Function
1	0.5 BK	1551	Ground
2	0.5 TN	2022	Charge Air Cooler Coolant Pump Supply Voltage

Charge Air Cooler (CAC) Coolant Pump (LSA)

Scheme 232

Scheme 232: Cigar Lighter - Front (DT4)

Connector Part Information Harness: Instrument Panel OEM: 12176836 Service: 15305923 Description: 3-Way F Metri-Pack 280 Series (GY)
Terminal Part Information Terminal/Tray: 12110844/4 Core/Insulation Crimp: C/A Release Tool: 15315247 Test Probe: J-35616-4A (PU)

Pin	Wire	Circuit	Function
A	1 RD/WH	2040	Battery Positive Voltage
B			Not Used
C	1 BK	450	Ground

Cigar Lighter - Front (DT4)

Scheme 233

Scheme 233: Clutch Pedal Position (CPP) Sensor (MV7 or MG9)

Connector Part Information Harness: Clutch Pedal Jumper OEM: 15332132 Service: 88953364 Description: 3-Way F GT 150 Series (BK)
Terminal Part Information Terminal/Tray: 12191812/19 Core/Insulation Crimp: E/C Release Tool: 15315247 Test Probe: J-35616-2A (GY)

Pin	Wire	Circuit	Function
A	0.35 GY/BN	7345	Manual Transmission Clutch Position Sensor Low Reference
B	0.35 L-GN	6338	Manual Transmission Clutch Position Sensor Signal
C	0.35 D-BU/YE	7346	Manual Transmission Clutch Position Sensor 5-Volt Reference 1

Clutch Pedal Position (CPP) Sensor (MV7 or MG9)

Scheme 234

Scheme 234: Control Solenoid Valve Assembly X1 (MYA or MYB or MYD)

Connector Part Information Harness: Engine OEM: 15131300 Service: 15131300 Description: 16-Way F 1.5 Series, Sealed (BK)
Terminal Part Information Pins: 4, 12 Terminal/Tray: 1928498135/19 Core/Insulation Crimp: J/J Release Tool/Test Probe: J-38125-213/J-35616-64B (L-BU) Pins: 6, 9 Terminal/Tray: 15304719/19 Core/Insulation Crimp: E/5 Release Tool/Test Probe: 15315247/J-35616-4A (PU) Pins: 1, 3-6, 9-14 Terminal/Tray: 2 2124 472200 Core/Insulation Crimp: Pins 3-5, 10-14 - See Terminal Repair Kit Core/Insulation Crimp: Pins 5, 6, 9 - E/1 Release Tool/Test Probe: See Terminal Repair Kit

Connector Part Information Harness: Engine OEM: 15131300 Service: 15131300 Description: 16-Way F 1.5 Series, Sealed (BK)

Terminal Part Information Pins: 4, 12 Terminal/Tray: 1928498135/19 Core/Insulation Crimp: J/J Release Tool/Test Probe: J-38125-213/J-35616-64B (L-BU) Pins: 6, 9 Terminal/Tray: 15304719/19 Core/Insulation Crimp: E/5 Release Tool/Test Probe: 15315247/J-35616-4A (PU) Pins: 1, 3-6, 9-14 Terminal/Tray: 2 2124 472200 Core/Insulation Crimp: Pins 3-5, 10-14 - See Terminal Repair Kit Core/Insulation Crimp: Pins 5, 6, 9 - E/1 Release Tool/Test Probe: See Terminal Repair Kit

Pin	Wire	Circuit	Function
1-2			Not Used
3	0.5 OG/BK	1786	Ignition Lock Cylinder Control Actuator Signal
4	0.8 RD/WH	440	Battery Positive Voltage
5	0.8 BK/WH	1551	Ground
6	0.35 WH	17	Stop Lamp Switch Signal or Stop Lamp Supply Voltage
7-8			Not Used
9	0.35 D-BU	5985	Accessory Wakeup Serial Data
10	0.5 TN/BK	2500	High Speed GMLAN Serial Data Bus+
11	0.5 TN	2501	High Speed GMLAN Serial Data Bus
12	0.5 PK	339	Ignition 1 Voltage
13	0.5 TN	2501	High Speed GMLAN Serial Data Bus
14	0.5 TN/BK	2500	High Speed GMLAN Serial Data Bus+
15-16			Not Used

Control Solenoid Valve Assembly X1 (MYA or MYB or MYD)

Scheme 235

Scheme 235: Control Solenoid Valve Assembly X2 (MYA or MYB or MYD)

Connector Part Information Harness: Transmission OEM: 15336500 Service: 89046635 Description: 6-Way F Metri-Pack 150.2 Series (GN)
Terminal Part Information Terminal/Tray: Service by Harness - See Part Catalog Core/Insulation Crimp: Non-Serviceable Release Tool/Test Probe: Non-Serviceable

Pin	Wire	Function
A	0.35 GY	Ground
B	0.35 BK	Transmission Range Switch Signal P
C	0.35 YE	Transmission Range Switch Signal C
D	0.35 RD	Transmission Range Switch Signal B
E	0.35 GN	Transmission Range Switch Signal A
F	0.35WH	Park/Neutral Switch Signal

Control Solenoid Valve Assembly X2 (MYA or MYB or MYD)

Scheme 236

Scheme 236: Control Solenoid Valve Assembly X3 (MYA or MYB or MYD)

Connector Part Information Harness: Transmission OEM: 13539487 Service: Service by Harness - See Part Catalog Description: 3-Way F Metri-Pack 150 Series (BK)
Terminal Part Information Terminal/Tray: Service by Harness - See Part Catalog Core/Insulation Crimp: Non-Serviceable Release Tool/Test Probe: Non-Serviceable

Pin	Wire	Function
A	0.35 GN	Input Speed Sensor (ISS) Signal
B	0.35 RD	Input Speed Sensor (ISS)/Output Speed Sensor (OSS) Control
C	0.35 BK	Output Speed Sensor (OSS) Signal

Control Solenoid Valve Assembly X3 (MYA or MYB or MYD)

Scheme 237

Scheme 237: Courtesy Lamp - Left Front Door

Connector Part Information Harness: Door Trim OEM: 12047662 Service: 12085535 Description: 2-Way F Metri-Pack 150 Series (BK)
Terminal Part Information Terminal/Tray: 12064971/5 Core/Insulation Crimp: E/C Release Tool: 12094429 Test Probe: J-35616-14 (GN)

Pin	Wire	Circuit	Function
A	0.5 BN	6573	Driver Door Courtesy Lamp Control High
B	0.5 L-BU/WH	6576	Driver Door Courtesy Lamp Control Low

Courtesy Lamp - Left Front Door

Courtesy Lamp - Right Front Door

Connector Part Information Harness: Door Trim OEM: 12047662 Service: 12085535 Description: 2-Way F Metri-Pack 150 Series (BK)
Terminal Part Information Terminal/Tray: 12064971/5 Core/Insulation Crimp: E/C Release Tool: 12094429 Test Probe: J-35616-14 (GN)

Pin	Wire	Circuit	Function
A	0.5 BN/WH	6574	Passenger Door Courtesy Lamp Control High
B	0.5 L-BU	6575	Passenger Door Courtesy Lamp Control Low

Courtesy Lamp - Right Front Door

Courtesy Lamp - Left Rear Door

Connector Part Information Harness: Door Trim OEM: 12047662 Service: 12085535 Description: 2-Way F Metri-Pack 150 Series (BK)
Terminal Part Information Terminal/Tray: 12064971/5 Core/Insulation Crimp: E/C Release Tool: 12094429 Test Probe: J-35616-14 (GN)

Pin	Wire	Circuit	Function
A	0.35 GY/BK	690	Courtesy Lamp Relay Control
B	0.35 BK	350	Ground

Courtesy Lamp - Left Rear Door

Scheme 238

Scheme 238: Courtesy Lamp - Rear Compartment (Sedan)

Connector Part Information Harness: Body OEM: 12047781 Service: 12101864 Description: 3-Way F Metri-Pack 150 Series (BK)
Terminal Part Information Terminal/Tray: 15326030/2 Core/Insulation Crimp: E/C Release Tool/Test Probe: 12094429/J-35616-14 (GN)

Pin	Wire	Circuit	Function
A			Not Used
B	0.35 OG/BK	744	Rear Compartment Lid Ajar Switch Signal
C	0.5 OG	1732	Courtesy Lamps Supply Voltage

Courtesy Lamp - Rear Compartment (Sedan)

Courtesy Lamp - Right Rear Door

Connector Part Information Harness: Door Trim OEM: 12047662 Service: 12085535 Description: 2-Way F Metri-Pack 150 Series (BK)
Terminal Part Information Terminal/Tray: 12064971/5 Core/Insulation Crimp: E/C Release Tool: 12094429 Test Probe: J-35616-14 (GN)

Pin	Wire	Circuit	Function
A	0.35 GY/BK	690	Courtesy Lamp Relay Control
B	0.35 BK	450	Ground

Courtesy Lamp - Right Rear Door

Scheme 239

Scheme 239: Courtesy/Reading Lamps - 2nd Row (Wagon)

Connector Part Information Harness: Headliner OEM: 19115647 Service: 13316151 Description: 6-Way F 1.5 Series (BK)
Terminal Part Information Terminal/Tray: See Terminal Repair Kit Core/Insulation Crimp: See Terminal Repair Kit Release Tool/Test Probe: See Terminal Repair Kit

Pin	Wire	Circuit	Function
1	0.5 OG	1732	Courtesy Lamps Supply Voltage
2	0.5 GY/BK	690	Courtesy Lamp Relay Control
3-5			Not Used
6	0.5 BK	1050	Ground

Courtesy/Reading Lamps - 2nd Row (Wagon)

Courtesy/Reading Lamps - Left Front

Connector Part Information Harness: Headliner OEM: 12047781 Service: 12101864 Description: 3-Way F Metri-Pack 150 Series (BK)
Terminal Part Information Terminal/Tray: 15326030/2 Core/Insulation Crimp: E/C Release Tool/Test Probe: 12094429/J-35616-14 (GN)

Pin	Wire	Circuit	Function
A	0.5 GY/BK	690	Courtesy Lamp Low Control/Front Interior Lamp Control/Rear Courtesy Lamp Relay Control
B	0.5 BK	1050	Ground
C	0.5 OG	1732	Courtesy Lamps Supply Voltage

Courtesy/Reading Lamps - Left Front

Courtesy/Reading Lamps - Left Rear (Sedan)

Connector Part Information Harness: Headliner OEM: 12047781 Service: 12101864 Description: 3-Way F Metri-Pack 150 Series (BK)
Terminal Part Information Terminal/Tray: 15326030/2 Core/Insulation Crimp: E/C Release Tool/Test Probe: 12094429/J-35616-14 (GN)

Pin	Wire	Circuit	Function
A	0.5 GY/BK	690	Courtesy Lamp Low Control/Front Interior Lamp Control/Rear Courtesy Lamp Relay Control
B	0.5 BK	1050	Ground
C	0.5 OG	1732	Courtesy Lamps Supply Voltage

Courtesy/Reading Lamps - Left Rear (Sedan)

Courtesy/Reading Lamps - Right Front

Connector Part Information Harness: Headliner OEM: 12047781 Service: 12101864 Description: 3-Way F Metri-Pack 150 Series (BK)
Terminal Part Information Terminal/Tray: 15326030/2 Core/Insulation Crimp: E/C Release Tool/Test Probe: 12094429/J-35616-14 (GN)

Pin	Wire	Circuit	Function
A	0.5 GY/BK	690	Courtesy Lamp Low Control/Front Interior Lamp Control/Rear Courtesy Lamp Relay Control
B	0.5 BK	1050	Ground
C	0.5 OG	1732	Courtesy Lamps Supply Voltage

Courtesy/Reading Lamps - Right Front

Courtesy/Reading Lamps - Right Rear (Sedan)

Connector Part Information Harness: Headliner OEM: 12047781 Service: 12101864 Description: 3-Way F Metri-Pack 150 Series (BK)
Terminal Part Information Terminal/Tray: 15326030/2 Core/Insulation Crimp: E/C Release Tool/Test Probe: 12094429/J-35616-14 (GN)

Pin	Wire	Circuit	Function
A	0.5 GY/BK	690	Courtesy Lamp Low Control/Front Interior Lamp Control/Rear Courtesy Lamp Relay Control
B	0.5 BK	1050	Ground
C	0.5 OG	1732	Courtesy Lamps Supply Voltage

Courtesy/Reading Lamps - Right Rear (Sedan)

Scheme 240

Scheme 240: Crankshaft Position (CKP) Sensor (LF1 or LLT)

Connector Part Information Harness: Engine OEM: 31403-3710 Service: 88988337 Description: 3-Way F 064 Series, Sealed (BK)
Terminal Part Information Terminal/Tray: 33468-0003/23 Core/Insulation Crimp: See Terminal Repair Kit Release Tool: J-38125-213 Test Probe: J-35616-64B (L-BU)

Pin	Wire	Circuit	Function
1	0.5 BK	452	Low Reference
2	0.5 YE	573	CKP Sensor Signal
3	0.5 GY	605	5-Volt Reference 3

Crankshaft Position (CKP) Sensor (LF1 or LLT)

Scheme 241

Scheme 241: Crankshaft Position (CKP) Sensor (LSA)

Connector Part Information Harness: Engine OEM: 12129946 Service: 88987997 Description: 3-Way F Sealed (BK)
Terminal Part Information Terminal/Tray: 33468-0003/23 Core/Insulation Crimp: H/H Release Tool: J-38125-213 Test Probe: J-35616-64B (L-BU)

Pin	Wire	Circuit	Function
A	0.35 WH/BK	6271	CKP Sensor Signal
B	0.35 GY/BK	6272	Low Reference
C	0.35 PU/WH	6270	5-Volt Reference

Crankshaft Position (CKP) Sensor (LSA)

Scheme 242

Scheme 242: Data Link Connector (DLC)

Connector Part Information Harness: Instrument Panel OEM: 12110250 Service: 12110250 Description: 16-Way F Metri-Pack 150 Series (BK)
Terminal Part Information Terminal/Tray: 12129484/19 Core/Insulation Crimp: E/C Release Tool: 12094429 Test Probe: J-35616-14 (GN)

Pin	Wire	Circuit	Function
1	0.35 D-GN	5060	Low Speed GMLAN Serial Data
2-3			Not Used
4	0.5 BK	350	Ground
5	0.35 BK/WH	651	Ground
6	0.35 TN/BK	2500	High Speed GMLAN Serial Data Bus+
7-13			Not Used
14	0.35 TN	2501	High Speed GMLAN Serial Data Bus
15			Not Used
16	0.35 RD/WH	540	Battery Positive Voltage

Data Link Connector (DLC)

Scheme 243

Scheme 243: Data Link Resistor (LF1 or LLT without J77, or LSA)

Connector Part Information Harness: Body OEM: 15326801 Service: 19179278 Description: 2-Way F GT 150 Series (BK)
Terminal Part Information Terminal/Tray: 12191819/8 Core/Insulation Crimp: H/H Release Tool: 15315247 Test Probe: J-35616-2A (GY)

Pin	Wire	Circuit	Function
A	0.35 TN/BK	2500	High Speed GMLAN Serial Data Bus+
B	0.35 TN	2501	High Speed GMLAN Serial Data Bus

Data Link Resistor (LF1 or LLT without J77, or LSA)

Scheme 244

Scheme 244: Daytime Running Lamp (DRL) - Left (T4F)

Connector Part Information Harness: Headlamp OEM: 09441733 Service: Service by Assembly - See Part Catalog Description: 2-Way F (GY)
Terminal Part Information Terminal/Tray: Service by Assembly - See Part Catalog Core/Insulation Crimp: N/A Release Tool/Test Probe: 15315247/J-35616-2A (GY)

Pin	Wire	Circuit	Function
A	0.5 BK	5364	Left DRL/Turn Supply Voltage
B	0.5 BK	150	Ground

Daytime Running Lamp (DRL) - Left (T4F)

Daytime Running Lamp (DRL) - Right (T4F)

Connector Part Information Harness: Headlamp OEM: 09441733 Service: Service by Assembly - See Part Catalog Description: 2-Way F (GY)
Terminal Part Information Terminal/Tray: Service by Assembly - See Part Catalog Core/Insulation Crimp: N/A Release Tool/Test Probe: 15315247/J-35616-2A (GY)

Pin	Wire	Circuit	Function
A	0.5 BK	5365	Right DRL/Turn Supply Voltage
B	0.5 BK	250	Ground

Daytime Running Lamp (DRL) - Right (T4F)

Scheme 245

Scheme 245: Differential Cooler Pump (KNR)

Connector Part Information Harness: Differential Cooler OEM: 7282-5548-30 Service: 88953303 Description: 2-Way M YESC Weather Pack Series (BK)
Terminal Part Information Terminal/Tray: 7114-4102-08/9 Core/Insulation Crimp: E/1 Release Tool: 12094430 Test Probe: J-35616-3 (GY)

Pin	Wire	Circuit	Function
1	1 PK	239	Run/Crank Ignition 1 Voltage
2	1 BK	1050	Ground

Differential Cooler Pump (KNR)

Differential Temperature Switch (KNR)

Connector Part Information Harness: Differential Cooler OEM: 19177503 Service: 19179278 Description: 2-Way F GT 150 Series (BK)
Terminal Part Information Terminal/Tray: Service by Harness - See Part Catalog Core/Insulation Crimp: N/A Release Tool/Test Probe: Pending

Pin	Wire	Circuit	Function
A	1 BK	1050	Ground
B	1 BK	1050	Ground

Differential Temperature Switch (KNR)

Scheme 246

Scheme 246: Door Handle Switch - Driver

Connector Part Information Harness: Door OEM: 15326833 Service: 15326833 Description: 6-Way M GT 150 Series, Sealed (BK)
Terminal Part Information Terminal/Tray: 15326269/19 Core/Insulation Crimp: E/4 Release Tool/Test Probe: 15315247/J-35616-3 (GY)

Pin	Wire	Circuit	Function
A	0.35 PK	5709	Keyless Entry Antenna - Signal (UHA/UHF)
B	0.35 PK/BK	5713	Keyless Entry Antenna - Low Reference (UHA/UHF)
C	0.35 BK/WH	351	Ground
D	0.35 BN	5881	Driver Door Handle Switch Signal
E	0.35 D-BU	5882	Driver Door Handle Switch Signal
F	0.35 BK/WH	351	Ground

Door Handle Switch - Driver

Scheme 247

Scheme 247: Door Handle Switch - Left Rear (ATH)

Connector Part Information Harness: Door OEM: 7282-8851-30 Service: Service by Harness - See Part Catalog Description: 2-Way M 064 RH Series (BK)
Terminal Part Information Terminal/Tray: Service by Harness - See Part Catalog Core/Insulation Crimp: N/A Release Tool/Test Probe: Not Available

Pin	Wire	Circuit	Function
1	0.35 BK	350	Ground
2	0.35 BN	6157	Easy Keyless Entry Unlock Signal

Door Handle Switch - Left Rear (ATH)

Door Handle Switch - Passenger

Connector Part Information Harness: Door OEM: 15326833 Service: 15326833 Description: 6-Way M GT 150 Series, Sealed (BK)
Terminal Part Information Terminal/Tray: 15326269/19 Core/Insulation Crimp: E/4 Release Tool/Test Probe: 15315247/J-35616-3 (GY)

Pin	Wire	Circuit	Function
A	0.35 YE	5710	Keyless Entry Antenna - Signal (ATH)
B	0.35 YE/BK	5714	Keyless Entry Antenna - Low Reference (ATH)
C	0.35 BK/WH	451	Ground
D	0.35 GY	5878	Passenger Door Handle Switch Signal
E	0.35 PK	5879	Passenger Door Handle Switch Signal
F	0.35 BK/WH	451	Ground

Door Handle Switch - Passenger

Door Handle Switch - Right Rear (ATH)

Connector Part Information Harness: Door OEM: 7282-8851-30 Service: Service by Harness - See Part Catalog Description: 2-Way M 064 RH Series (BK)
Terminal Part Information Terminal/Tray: Service by Harness - See Part Catalog Core/Insulation Crimp: N/A Release Tool/Test Probe: Not Available

Pin	Wire	Circuit	Function
1	0.35 BK	450	Ground
2	0.35 GY	6158	Easy Keyless Entry Unlock Signal

Door Handle Switch - Right Rear (ATH)

Scheme 248

Scheme 248: Door Latch - Driver

Connector Part Information Harness: Door OEM: 6-1355688-1 Service: 88952463 Description: 10-Way F Sealed (BK)
Terminal Part Information Terminal/Tray: 4-969005-1/16 Core/Insulation Crimp: E/1 Release Tool: J-38125-560 Test Probe: J-35616-33 (YE)

Pin	Wire	Circuit	Function
1	1 D-GN	6165	All Door Deadbolt Motor Lock Control (LHD with UA2)
1	0.35 GY/BK	745	Left Front Door Ajar Switch Signal (RHD with ATH or UA2)
2	1 TN	294	(LHD with UA2)
2	0.35 TN	126	Door Lock Actuator Unlock Control (RHD with ATH or UA2)
3	0.8 OG/BK	6152	Driver Door Latch Unlatch Motor Control (LHD with UA2)
3	0.35 BK	350	Ground (RHD with ATH or UA2)
4	0.8 L-GN/BK	5703	Door Unlatch Motor Control (1) (LHD with UA2)
4	0.35 L-GN	262	Driver Door Key Switch Signal (RHD ATH or UA2)
5			Not Used
6	0.35 GY/BK	745	Left Front Door Ajar Switch Signal (ATG or ATH or UA2)
6	1 D-GN	6165	All Door Deadbolt Motor Lock Control (RHD ATH or UA2)
7	0.35 TN	126	Door Open Switch Signal (ATG or ATH or UA2)
7	1 TN	294	Door Lock Actuator Unlock Control (RHD ATH or UA2)
8	0.35 BK	350	Ground (ATG or ATH or UA2)
8	0.8 OG/BK	6152	Driver Door Latch Unlatch Motor Control (RHD ATH or UA2)
9	0.35 L-GN	262	Door Key Switch Signal (ATG or ATH or UA2)
9	0.8 L-GN/BK	5703	Door Unlatch Motor Control (1) (RHD ATH or UA2)
10			Not Used

Door Latch - Driver

Scheme 249

Scheme 249: Door Latch - Left Rear

Connector Part Information Harness: Door OEM: 6-1355683-1 Service: 88986251 Description: 6-Way F 1.2 Timer Series (BK)
Terminal Part Information Terminal/Tray: 4-969005-1/16 Core/Insulation Crimp: E/1 Release Tool/Test Probe: J-38125-560/J-35616-14 (GN)

Pin	Wire	Circuit	Function
1	0.35 D-GN	6165	All Door Deadbolt Motor Lock Control
2	0.35 TN	294	Door Lock Actuator Unlock Control
3	0.35 GY	295	Door Lock Actuator Lock Control
4	0.35 L-BU/BK	747	Door Ajar Switch Signal
5	0.35 D-BU/WH	1179	Door Open Switch Signal
6	0.35 BK	350	Ground

Door Latch - Left Rear

Door Latch - Passenger

Connector Part Information Harness: Door OEM: 6-1355688-1 Service: 88952463 Description: 10-Way F Sealed (BK)
Terminal Part Information Terminal/Tray: 4-969005-1/16 Core/Insulation Crimp: E/1 Release Tool: J-38125-560 Test Probe: J-35616-33 (YE)

Pin	Wire	Circuit	Function
1	0.35 TN/WH	746	Door Ajar Switch Signal (LHD with ATG or ATH or UA2)
1	1 D-GN	6165	All Door Deadbolt Motor Lock Control (RHD with UA2)
2	0.35 L-GN	1177	Door Open Switch Signal (LHD with ATG or ATH or UA2)
2	1 TN	294	Door Lock Actuator Unlock Control (RHD with UA2)
3	0.35 BK	450	Ground (LHD with ATG or ATH or UA2)
3	0.8 OG/BK	6153	Passenger Door Latch Unlatch Motor Control (RHD with ATH or UA2)
4	0.8 D-BU	5876	Door Unlatch Motor Control (2) (RHD with ATH or UA2)
5	0.8 D-BU	5876	Door Unlatch Motor Control (2) (LHD with ATG without UA2)
6	1 D-GN	6165	All Door Deadbolt Motor Lock Control (LHD)
	0.8 OG/BK	6153	Passenger Door Latch Unlatch Motor Control (LHD with ATG)
	0.35 GY	5133	Door Lock Actuator Deadbolt Control (RHD with ATH or UA2)
7	1 TN	294	Door Lock Actuator Unlock Control (LHD with UA2)
7	0.35 TN	294	Door Lock Actuator Unlock Control (RHD with ATH or UA2)
8	0.8 OG/BK	6153	Passenger Door Latch Unlatch Motor Control (LHD with ATH or UA2)
8	0.35 TN	294	Door Lock Actuator Unlock Control (RHD with ATH or UA2)
9	0.8 D-BU	5876	Door Unlatch Motor Control (2) (LHD with ATH or UA2)
9	0.35 D-BU	5876	Door Latch Enable Control (LHD)
10			Not Used

Door Latch - Passenger

Door Latch - Right Rear

Connector Part Information Harness: Door OEM: 6-1355683-1 Service: 88986251 Description: 6-Way F 1.2 Timer Series (BK)
Terminal Part Information Terminal/Tray: 4-969005-1/16 Core/Insulation Crimp: E/1 Release Tool/Test Probe: J-38125-560/J-35616-14 (GN)

Pin	Wire	Circuit	Function
1	0.35 L-GN/BK	748	Door Ajar Switch Signal
2	0.35 D-BU/WH	1179	Door Open Switch Signal
3	0.35 BK	450	Ground
4	0.35 GY	5133	Door Lock Actuator Deadbolt Control (UA2)
5	0.35 TN	294	Door Lock Actuator Unlock Control
6	0.35 GY	295	Door Lock Actuator Lock Control

Door Latch - Right Rear

Scheme 250

Scheme 250: Door Lock/Window Switch - Driver X1

Connector Part Information Harness: Door Trim OEM: 15134094 Service: 88988497 Description: 6-Way F 2.8 Series (BK)
Terminal Part Information Terminal/Tray: 8100-4444/22 Core/Insulation Crimp: 2/A Release Tool: 15315247 Test Probe: J-35616-35 (VT)

Pin	Wire	Circuit	Function
1-3			Not Used
4	1 RD/WH	4240	Battery Positive Voltage
5			Not Used
6	0.8 BK	350	Ground

Door Lock/Window Switch - Driver X1

Scheme 251

Scheme 251: Door Lock/Window Switch - Driver X2

Connector Part Information Harness: Door Trim OEM: 15136074 Service: 15136074 Description: 16-Way F Kaizen 64 Series (BN)
Terminal Part Information Terminal/Tray: SAITS-A03T-M064/14 Core/Insulation Crimp: 9/9 Release Tool/Test Probe: J-38125-215A/J-35616-64B (L-BU)

Pin	Wire	Circuit	Function
1-2			Not Used
3	0.5 BN	6132	Local Interconnect Network 1
4	0.35 L-GN	262	Driver Door Key Switch Signal
5-6			Not Used
7	0.5 OG/BK	6152	Driver Door Latch Unlatch Motor Control
8	0.5 L-GN/BK	5703	Driver Door Latch Enable Control
9	0.35 D-GN	5060	Low Speed GMLAN Serial Data
10	0.5 BN	6573	Driver Door Courtesy Lamp Control High
11	0.35 TN	126	Left Front Door Open Switch Signal
12			Not Used
13	0.35 GY/BK	745	Left Front Door Ajar Switch Signal
14			Not Used
15	0.5 L-BU/WH	6576	Driver Door Courtesy Lamp Control Low
16			Not Used

Door Lock/Window Switch - Driver X2

Scheme 252

Scheme 252: Door Lock/Window Switch - Driver X3

Connector Part Information Harness: Door Trim OEM: 15127042 Service: 15127042 Description: 10-Way F YESC Kaizen Series (BK)
Terminal Part Information Terminal/Tray: SAITS-A03T-M064/14 Core/Insulation Crimp: 9/9 Release Tool/Test Probe: J-38125-215A/J-35616-64B (L-BU)

Pin	Wire	Circuit	Function
1	0.35 D-BU/WH	6160	Outside Left Mirror Vertical Position Control
2	0.35 D-GN/WH	6159	Outside Left Mirror Horizontal Position Control
3-5			Not Used
6	0.35 WH	7197	Outside Left Mirror Drive Motor Common
7	0.5 WH	606	Driver Mirror Heating Element Supply Voltage
8-10			Not Used

Door Lock/Window Switch - Driver X3

Scheme 253

Scheme 253: Door Lock/Window Switch - Driver X4 (A45)

Connector Part Information Harness: Memory Seat Switch OEM: 15127039 Service: Service by Assembly - See Part Catalog Description: 14-Way F (L-GY)
Terminal Part Information Terminal/Tray: Service by Assembly - See Part Catalog Core/Insulation Crimp: N/A Release Tool/Test Probe: Not Available

Pin	Wire	Circuit	Function
1-3			Not Used
4	0.35 D-BU/WH	5978	Memory Seat Switch Dimming Return
5	0.35 OG	614	Memory Seat Switch Signal
6-12			Not Used
13	0.35 TN	6064	Memory Seat Switch Dimming
14	0.35 GY/BK	5979	Memory Seat Switch Exit Signal

Door Lock/Window Switch - Driver X4 (A45)

Scheme 254

Scheme 254: Door Lock/Window Switch - Driver X5

Connector Part Information Harness: Door Trim OEM: 15127041 Service: Pending Description: 10-Way F 0.64 YESC Kaizen Series (GN)
Terminal Part Information Terminal/Tray: SAITS-A03T-M064/14 Core/Insulation Crimp: 9/9 Release Tool/Test Probe: J-38125-215A/J-35616-64B (L-BU)

Pin	Wire	Circuit	Function
1	0.5 PK	6190	Lift Glass/Trunk Exterior Release Signal (Sedan)
1	0.35 DGN/WH	5800	Liftgate Open/Close Switch Signal (Wagon)
2			Not Used
3	0.5 BK/WH	51	Ground
4-6			Not Used
7	0.5 YE	1491	Backlight Lamps Control
8-10			Not Used

Door Lock/Window Switch - Driver X5

Scheme 255

Scheme 255: Door Lock/Window Switch - Driver X6

Connector Part Information Harness: Door Trim OEM: 15127038 Service: 15127038 Description: 14-Way F (BU)
Terminal Part Information Terminal/Tray: SAITS-A03T-M064/14 Core/Insulation Crimp: 9/9 Release Tool/Test Probe: J-38125-215A/J-35616-64B (L-BU)

Pin	Wire	Circuit	Function
1	0.35 BN	6663	Low Reference
2	0.35 BN	5881	Left Front Door Handle Switch Signal
3			Not Used
4	0.35 D-BU	5882	Left Front Door Handle Switch Signal
5-8			Not Used
9	0.35 WH	901	IC 2 Control (TSQ)
10	0.35 L-BU/BK	6662	Low Reference
11-14			Not Used

Door Lock/Window Switch - Driver X6

Scheme 256

Scheme 256: Door Lock/Window Switch - Driver X7 (A45 or DL7 or D26)

Connector Part Information Harness: Door Trim OEM: 15127040 Service: 15127040 Description: 10-Way F (WH)
Terminal Part Information Terminal/Tray: SAITS-A03T-M064/14 Core/Insulation Crimp: 9/9 Release Tool/Test Probe: J-38125-215A/J-35616-64B (L-BU)

Pin	Wire	Circuit	Function
1	0.35 YE	190	Driver Folding Mirror Motor Extend Control (DL7/D26)
2	0.35 L-BU	191	Driver Folding Mirror Motor Retract Control (DL7/D26)
3			Not Used
4	0.35 D-GN	784	Driver Mirror Vertical Position Sensor Signal (A45)
5	0.35 GY	786	Driver Mirror Horizontal Position Sensor Signal (A45)
6			Not Used
7	0.35 D-BU	672	5-Volt Reference (A45)
8-9			Not Used
10	0.35 BN	673	Low Reference (A45)

Door Lock/Window Switch - Driver X7 (A45 or DL7 or D26)

Door Lock/Window Switch - Passenger X1

Connector Part Information Harness: Door Trim OEM: 15134094 Service: 88988497 Description: 6-Way F 2.8 Series (BK)
Terminal Part Information Terminal/Tray: 8100-4444/22 Core/Insulation Crimp: 2/A Release Tool/Test Probe: 15315247/J-35616-35 (VT)

Pin	Wire	Circuit	Function
1-3			Not Used
4	1 RD/WH	4040	Battery Positive Voltage
5			Not Used
6	0.8 BK	450	Ground

Door Lock/Window Switch - Passenger X1

Door Lock/Window Switch - Passenger X2

Connector Part Information Harness: Door Trim OEM: 15136074 Service: 15136074 Description: 16-Way F Kaizen 64 Series (BN)
Terminal Part Information Terminal/Tray: SAITS-A03T-M064/14 Core/Insulation Crimp: 9/9 Release Tool/Test Probe: J-38125-215A/J-35616-64B (L-BU)

Pin	Wire	Circuit	Function
1-2			Not Used
3	0.5 D-BU	6133	Local Interconnect Network 2
4-6			Not Used
7	0.5 OG/BK	6153	Passenger Door Latch Unlatch Motor Control
8	0.5 D-BU	5876	Front Passenger Door Latch Enable Control
9	0.35 D-GN	5060	Low Speed GMLAN Serial Data
10	0.5 BN/WH	6574	Passenger Door Courtesy Lamp Control High
11	0.35 L-GN	1177	Right Front Door Open Switch Signal/Door Open Switch Signal
12			Not Used
13	0.35 TN/WH	746	Right Front Door Ajar Switch Signal
14			Not Used
15	0.5 L-BU	6575	Passenger Door Courtesy Lamp Control Low
16			Not Used

Door Lock/Window Switch - Passenger X2

Door Lock/Window Switch - Passenger X3

Connector Part Information Harness: Door Trim OEM: 15127042 Service: 15127042 Description: 10-Way F YESC Kaizen Series (BK)
Terminal Part Information Terminal/Tray: SAITS-A03T-M064/14 Core/Insulation Crimp: 9/9 Release Tool/Test Probe: J-38125-215A/J-35616-64B (L-BU)

Pin	Wire	Circuit	Function
1	0.35 OG/BK	6162	Outside Right Mirror Vertical Position Control
2	0.35 GY/BK	6161	Outside Right Mirror Horizontal Position Control
3-5			Not Used
6	0.35 WH	7196	Outside Right Mirror Drive Motor Common
7	0.5 PU	607	Passenger Mirror Heating Element Supply Voltage
8-10			Not Used

Door Lock/Window Switch - Passenger X3

Door Lock/Window Switch - Passenger X6

Connector Part Information Harness: Door Trim OEM: 15127038 Service: 15127038 Description: 14-Way F Kaizen 64 Series (BU)
Terminal Part Information Terminal/Tray: SAITS-A03T-M064/14 Core/Insulation Crimp: 9/9 Release Tool/Test Probe: J-38125-215A/J-35616-64B (L-BU)

Pin	Wire	Circuit	Function
1	0.35 WH/BK	6660	Passenger Door Unlatch Switch Low Reference
2	0.35 GY	5878	Right Front Door Handle Switch Signal
3			Not Used
4	0.35 PK	5879	Right Front Door Handle Switch Signal
5-8			Not Used
9	0.35 WH	901	IC 2 Control (TSQ)
10	0.35 TN/WH	6661	Left Rear Door Unlatch Switch Low Reference
11-14			Not Used

Door Lock/Window Switch - Passenger X6

Door Lock/Window Switch - Passenger X7 (A45 or DL7 or D26)

Connector Part Information Harness: Door Trim OEM: 15127040 Service: 15127040 Description: 10-Way F (WH)
Terminal Part Information Terminal/Tray: SAITS-A03T-M064/14 Core/Insulation Crimp: 9/9 Release Tool/Test Probe: J-38125-215A/J-35616-64B (L-BU)

Pin	Wire	Circuit	Function
1	0.35 YE	5004	Passenger Folding Mirror Motor Extend Control (DL7/D26)
2	0.35 L-BU	5023	Passenger Folding Mirror Motor Retract Control (DL7/D26)
3			Not Used
4	0.35 BN	787	Passenger Mirror Vertical Position Sensor Signal (A45)
5	0.35 L-BU/BK	785	Passenger Mirror Horizontal Position Sensor Signal (A45)
6			Not Used
7	0.35 YE	674	5-Volt Reference (A45)
8-9			Not Used
10	0.35 L-GN	675	Low Reference (A45)

Door Lock/Window Switch - Passenger X7 (A45 or DL7 or D26)

Scheme 257

Scheme 257: Driver Information Center (DIC) Switch

Connector Part Information Harness: Instrument Panel OEM: HCMPB-06-K Service: 19115655 Description: 6-Way F HCM Series (BK)
Terminal Part Information Terminal/Tray: SHCM-A03T-P025/20 Core/Insulation Crimp: J/J Release Tool/Test Probe: 12094429/J-35616-64B (L-BU)

Pin	Wire	Circuit	Function
1	0.35 D-GN/WH	1358	DIC Switch Signal
2	0.35 BN	897	DIC Switch Low Reference
3	0.35 PK	893	DIC Select Menu Switch Signal
4			Not Used
5	0.35 YE	6817	LED Backlight Dimming Control
6	0.35 BK	350	Ground

Driver Information Center (DIC) Switch

Wiring Systems and Power Management - Component Connector End Views - C Through D Cadillac CTS II

Scheme 225

Camshaft Position (CMP) Actuator Solenoid Valve - Bank 1 Intake (LF1/LLT)

Camshaft Position (CMP) Actuator Solenoid Valve - Bank 2 Exhaust (LF1/LLT)

Camshaft Position (CMP) Actuator Solenoid Valve - Bank 2 Intake (LF1/LLT)

Scheme 226

Camshaft Position (CMP) Sensor - Bank 1 Intake (LF1 or LLT)

Camshaft Position (CMP) Sensor - Bank 2 Exhaust (LF1 or LLT)

Camshaft Position (CMP) Sensor - Bank 2 Intake (LF1 or LLT)

Scheme 227

Scheme 228

Cargo Lamp - Right

Scheme 229

Scheme 230

Center High Mounted Stop Lamp (CHMSL) (Wagon)

Scheme 231

Scheme 232

Scheme 233

Scheme 234

Scheme 235

Scheme 236

Scheme 237

Courtesy Lamp - Right Front Door

Courtesy Lamp - Left Rear Door

Scheme 238

Courtesy Lamp - Right Rear Door

Scheme 239

Courtesy/Reading Lamps - Left Front

Courtesy/Reading Lamps - Left Rear (Sedan)

Courtesy/Reading Lamps - Right Front

Courtesy/Reading Lamps - Right Rear (Sedan)

Scheme 240

Scheme 241

Scheme 242

Scheme 243

Scheme 244

Daytime Running Lamp (DRL) - Right (T4F)

Scheme 245

Differential Temperature Switch (KNR)

Scheme 246

Scheme 247

Door Handle Switch - Passenger

Door Handle Switch - Right Rear (ATH)

Scheme 248

Scheme 249

Door Latch - Passenger

Door Latch - Right Rear

Scheme 250

Scheme 251

Scheme 252

Scheme 253

Scheme 254

Scheme 255

Scheme 256

Door Lock/Window Switch - Passenger X1

Door Lock/Window Switch - Passenger X2

Door Lock/Window Switch - Passenger X3

Door Lock/Window Switch - Passenger X6

Door Lock/Window Switch - Passenger X7 (A45 or DL7 or D26)

Scheme 257

More articles — Electrical

Login / Signup

Enter the code

You have successfully logged in!
