Wiring Systems and Power Management - Component Connector End Views - L Through O

Scheme 339

Scheme 339: License Lamp - Left (Sedan)

Connector Part Information Harness: License Lamp OEM: 34062-0001 Service: Service by Harness - See Part Catalog Description: 2-Way F Sealed (BK)
Terminal Part Information Terminal/Tray: Service by Harness - See Part Catalog Core/Insulation Crimp: N/A Release Tool/Test Probe: Pending

Pin	Wire	Circuit	Function
1	0.35 BN/WH	309	Left Park Lamp Supply Voltage
2	0.35 BK	1050	Ground

License Lamp - Left (Sedan)

Scheme 340

Scheme 340: License Lamp - Left (Wagon)

Connector Part Information Harness: License Lamp OEM: 90565978 Service: Service by Harness - See Part Catalog Description: 2-Way F Metri-Pack 150 Series, Sealed (BK)
Terminal Part Information Terminal/Tray: Service by Harness - See Part Catalog Core/Insulation Crimp: N/A Release Tool/Test Probe: 15315247/J-35616-2A (GY)

Pin	Wire	Circuit	Function
1	0.35 PU	709	Left Park Lamp Supply Voltage
2	0.35 BK	2050	Ground

License Lamp - Left (Wagon)

License Lamp - Right (Sedan)

Connector Part Information Harness: License Lamp OEM: 34062-0001 Service: Service by Harness - See Part Catalog Description: 2-Way F Sealed (BK)
Terminal Part Information Terminal/Tray: Service by Harness - See Part Catalog Core/Insulation Crimp: N/A Release Tool/Test Probe: N/A

Pin	Wire	Circuit	Function
1	0.35 BN/WH	309	Right Park Lamp Supply Voltage
2	0.35 BK	1050	Ground

License Lamp - Right (Sedan)

License Lamp - Right (Wagon)

Connector Part Information Harness: License Lamp OEM: 90565978 Service: Service by Harness - See Part Catalog Description: 2-Way F Metri-Pack 150 Series, Sealed (BK)
Terminal Part Information Terminal/Tray: Service by Harness - See Part Catalog Core/Insulation Crimp: N/A Release Tool/Test Probe: 15315247/J-35616-2A (GY)

Pin	Wire	Circuit	Function
1	0.35 PU	709	Right Park Lamp Supply Voltage
2	0.35 BK	1050	Ground

License Lamp - Right (Wagon)

Scheme 341

Scheme 341: Liftgate Close Switch (Wagon)

Connector Part Information Harness: Liftgate OEM: 90484986 Service: 90484986 Description: 4-Way F 64 MQS Series (BK)
Terminal Part Information Terminal/Tray: Service by Harness - See Part Catalog Core/Insulation Crimp: N/A Release Tool: 12094429 Test Probe: J-35616-64B (L-BU)

Pin	Wire	Circuit	Function
1	0.35 PU/WH	5801	Low Reference
2	0.35 GY/WH	3034	Backlight Lamp Control
3	0.35 GY/BK	1798	Low Reference
4	0.35 D-GN	3033	Liftgate Close Signal

Liftgate Close Switch (Wagon)

Scheme 342

Scheme 342: Liftgate Control Switch - Interior (Wagon)

Connector Part Information Harness: Driver Door Trim OEM: 13216377 Service: Service by Harness - See Part Catalog Description: 4-Way F 0.64 Micro Quadlok Series (BK)
Terminal Part Information Terminal/Tray: Service by Harness - See Part Catalog Core/Insulation Crimp: N/A Release Tool/Test Probe: 12094429/J-35616-64B (L-BU)

Pin	Wire	Circuit	Function
1	0.35 BK/WH	51	Low Reference
2	0.35 YE	1491	Backlight Lamps Control
3	0.35 D-GN	6112	Power Liftgate On/Off Switch Signal
4	0.35 D-GN/WH	5800	Liftgate Open/Close Switch Signal

Liftgate Control Switch - Interior (Wagon)

Scheme 343

Scheme 343: Liftgate Latch Assembly (Wagon)

Connector Part Information Harness: Liftgate OEM: 15476196 Service: 88988498 Description: 6-Way F GT 280 Series, Sealed (BK)
Terminal Part Information Pins: 1, 3 Terminal/Tray: 15304719/19 Core/Insulation Crimp: 2/5 Release Tool: 15315247 Test Probe: J-35616-4A (PU) Pins: 4-6 Terminal/Tray: 15304719/19 Core/Insulation Crimp: E/5 Release Tool: 15315247 Test Probe: J-35616-4A (PU)

Pin	Wire	Circuit	Function
1	2 BN	5790	Liftgate Cinch Latch Motor Open Control
2	0.35 PU/WH	5801	Low Reference
3	2 L-BU	5791	Liftgate Cinch Latch Motor Close Control
4	0.35 D-GN	5512	Latch Sector Switch Signal
5	0.35 GY	7000	Latch Pawl Switch Signal
6	0.35 PK/BK	6000	Latch Ratchet Switch Signal

Liftgate Latch Assembly (Wagon)

Scheme 344

Scheme 344: Liftgate Module (LGM) X1

Connector Part Information Harness: Liftgate OEM: 15136073 Service: 15136073 Description: 16-Way F (BK)
Terminal Part Information Terminal/Tray: SAITS-A03T-M064/14 Core/Insulation Crimp: P/P Release Tool: J38125-215A Test Probe: 64B

Pin	Wire	Circuit	Function
1	0.35 L-GN	6112	Power Liftgate On/Off Switch Signal
2			Not Used
3	0.35 D-GN	3033	Liftgate Close Signal
4	0.35 D-GN	5512	Liftgate Ajar Switch Signal
5	0.35 PK/BK	6000	Liftgate Ajar Switch Signal
6	0.35 GY	7000	Liftgate Ajar Switch Signal
7	0.35 L-GN	5060	Low Speed GM LAN Serial Data
8	0.5 WH/BK	6126	Liftgate Object Sensor Signal
9-13			Not Used
14	0.35 GY	5797	Rear Closure Handle Switch Open Signal
15			Not Used
16	0.35 PU/WH	5801	Low Reference

Liftgate Module (LGM) X1

Scheme 345

Scheme 345: Liftgate Module (LGM) X2

Connector Part Information Harness: Liftgate OEM: 15134094 Service: 88988497 Description: 6-Way F 2.8 Series (BK)
Terminal Part Information Pin: 4 Terminal/Tray: 8100-4443/22 Core/Insulation Crimp: E/A Release Tool/Test Probe: 15315247/J-35616-35 (VT) Pins: 1, 2 Terminal/Tray: 8100-4445/22 Core/Insulation Crimp: 4/4 Release Tool/Test Probe: 15315247/J-35616-35 (VT) Pins: 3, 6 Terminal/Tray: 8100-4445/22 Core/Insulation Crimp: F/D Release Tool/Test Probe: 15315247/J-35616-35 (VT)

Pin	Wire	Circuit	Function
1	2 BN	5790	Liftgate Cinch Latch Motor Open Control
2	2 L-BU	5791	Liftgate Cinch Latch Motor Close Control
3	3 RD/WH	5440	Battery Positive Voltage
4	0.35 RD/WH	3140	Battery Positive Voltage
5			Not Used
6	3 BK	2050	Ground

Liftgate Module (LGM) X2

Scheme 346

Scheme 346: Liftgate Module (LGM) X3

Connector Part Information Harness: Liftgate OEM: 19179972 Service: 19179972 Description: 14-Way F 64/2.8 YESC Series (L-GY)
Terminal Part Information Pins: 11, 13 Terminal/Tray: 7116-4720-02/14 Core/Insulation Crimp: H/H Release Tool/Test Probe: 15315247/J-35616-64B (L-BU) Pins: 1, 2 Terminal/Tray: 7116-4112-02/9 Core/Insulation Crimp: C/D Release Tool/Test Probe: 12094430/J-35616-35 (VT)

Pin	Wire	Circuit	Function
1	3 WH	5798	Power Liftgate Motor Open Control
2	3 BN/WH	5799	Power Liftgate Motor Close Control
3-10			Not Used
11	0.35 GY/BK	1798	Low Reference
12			Not Used
13	0.35 GY/WH	3034	Backlight Lamp Control
14			Not Used

Liftgate Module (LGM) X3

Scheme 347

Scheme 347: Liftgate Motor Assembly (Wagon)

Connector Part Information Harness: Body OEM: 19177524 Service: 88953160 Description: 2-Way F GT 280 Series (BK)
Terminal Part Information Terminal/Tray: 15304713/19 Core/Insulation Crimp: F/D Release Tool: 15315247 Test Probe: J-35616-4A (PU)

Pin	Wire	Circuit	Function
A	3 WH	5798	Power Liftgate Motor Open Control
B	3 BN/WH	5799	Power Liftgate Motor Close Control

Liftgate Motor Assembly (Wagon)

Scheme 348

Scheme 348: Liftgate Object Sensor - Left (Wagon)

Connector Part Information Harness: Liftgate OEM: 12047663 Service: 12085481 Description: 2-Way M Metri-Pack 150 Series (BK)
Terminal Part Information Terminal/Tray: 12047581/2 Core/Insulation Crimp: E/C Release Tool: 12094429 Test Probe: J-35616-3 (GY)

Pin	Wire	Circuit	Function
A	0.5 PU/WH	5801	Low Reference
B	0.5 PK/BK	5802	Liftgate Object Sensor Signal

Liftgate Object Sensor - Left (Wagon)

Liftgate Object Sensor - Right (Wagon)

Connector Part Information Harness: Liftgate OEM: 12047663 Service: 12085481 Description: 2-Way M Metri-Pack 150 Series (BK)
Terminal Part Information Terminal/Tray: 12047581/2 Core/Insulation Crimp: E/C Release Tool: 12094429 Test Probe: J-35616-3 (GY)

Pin	Wire	Circuit	Function
A	0.5 WH/BK	6126	Liftgate Object Sensor Signal
B	0.5 PK/BK	5802	Liftgate Object Sensor Signal

Liftgate Object Sensor - Right (Wagon)

Scheme 349

Scheme 349: Manifold Absolute Pressure (MAP) Sensor (LF1)

Connector Part Information Harness: Engine OEM: 15365614 Service: 88988583 Description: 3-Way F Kompakt 2.8 Series, Sealed (BK)
Terminal Part Information Terminal/Tray: 1928498056/8 Core/Insulation Crimp: E/1 Release Tool/Test Probe: J-38125-561/J-35616-35 (VT)

Pin	Wire	Circuit	Function
1	0.8 GY	2704	5-Volt Reference 2
2	0.8 OG/BK	469	Low Reference
3	0.8 L-GN	432	MAP Sensor Signal

Manifold Absolute Pressure (MAP) Sensor (LF1)

Scheme 350

Scheme 350: Manifold Absolute Pressure (MAP) Sensor (LSA)

Connector Part Information Harness: Engine OEM: 89047242 Service: 88988583 Description: 3-Way F ()
Terminal Part Information Terminal/Tray: 1928498056/8 Core/Insulation Crimp: E/1 Release Tool/Test Probe: J-38125-561/J-35616-35 (VT)

Pin	Wire	Circuit	Function
1	0.8 GY	2704	5-Volt Reference 2
2	0.8 OG/BK	469	Low Reference
3	0.8 L-GN	432	MAP Sensor Signal

Manifold Absolute Pressure (MAP) Sensor (LSA)

Scheme 351

Scheme 351: Manual Transmission Fluid Temperature Sensor (MG9)

Connector Part Information Harness: Engine OEM: 15449028 Service: 88987993 Description: 2-Way F GT 150 Series, Sealed (BK)
Terminal Part Information Terminal/Tray: 15326267/19 Core/Insulation Crimp: E/4 Release Tool: 15315247 Test Probe: J-35616-2A (GY)

Pin	Wire	Circuit	Function
A	0.35 OG/BK	586	Low Reference
B	0.35 TN/WH	585	Sensor Signal

Manual Transmission Fluid Temperature Sensor (MG9)

Scheme 352

Scheme 352: Mass Air Flow (MAF)/Intake Air Temperature (IAT) Sensor (LF1)

Connector Part Information Harness: Engine OEM: 13519912 Service: 13501881 Description: 5-Way F GT 150 Sealed 4.0 (BK)
Terminal Part Information Terminal/Tray: 12191819/8 Core/Insulation Crimp: E/1 Release Tool: 15315247 Test Probe: J-35616-2A (GY)

Pin	Wire	Circuit	Function
A	0.5 BK	2760	Low Reference
B	0.5 L-BU	6289	IAT Sensor Signal
C	0.5 YE	492	MAF Sensor Signal
D	0.5 PK/BK	5294	PWR/TRN Relay Power
E	0.5 BK/WH	1551	Ground

Mass Air Flow (MAF)/Intake Air Temperature (IAT) Sensor (LF1)

Mass Air Flow (MAF)/Intake Air Temperature (IAT) Sensor (LLT)

Connector Part Information Harness: Engine OEM: 13520906 Service: 19151493 Description: 5-Way F GT 150 Sealed 4.0 (BK)
Terminal Part Information Terminal/Tray: 12191819/8 Core/Insulation Crimp: Pins A, B, D, E: E/A; Pin C: 2/1 Release Tool/Test Probe: 15315247/J-35616-2A (GY)

Pin	Wire	Circuit	Function
A	0.5 YE	492	MAF Sensor Signal
B	0.5 PK	339	Ignition 1 Voltage
C	0.8 BK/WH	1551	Ground
D	0.5 L-BU	6289	IAT Sensor Signal
E	0.5 TN	2760	Low Reference

Mass Air Flow (MAF)/Intake Air Temperature (IAT) Sensor (LLT)

Mass Air Flow (MAF)/Intake Air Temperature (IAT) Sensor (LSA)

Connector Part Information Harness: Engine OEM: 7287-2216-10 Service: 13501881 Description: 5-Way F GT 150 Sealed 4.0 (BK)
Terminal Part Information Terminal/Tray: 12191819/8 Core/Insulation Crimp: Pins A, B, D, E: E/A; Pin C: 2/A Release Tool: 15315247 Test Probe: J-35616-2A (GY) Pin: C Terminal/Tray: 12191812/19 Core/Insulation Crimp: C/A Release Tool: 15315247 Test Probe: J-35616-2A (GY)

Pin	Wire	Circuit	Function
A	0.5 TN	2760	Low Reference
B	0.5 TN	472	IAT Sensor Signal
C	0.5 YE	492	MAF Sensor Signal
D	0.8 PK/BK	5294	Battery Positive Voltage
E	0.8 BK	1550	Ground

Mass Air Flow (MAF)/Intake Air Temperature (IAT) Sensor (LSA)

Scheme 353

Scheme 353: Memory Seat Module (MSM) (A45) X1

Connector Part Information Harness: Seat OEM: 15134091 Service: Service by Harness - See Part Catalog Description: 16-Way F (BK)
Terminal Part Information Terminal/Tray: Service by Harness - See Part Catalog Core/Insulation Crimp: N/A Release Tool/Test Probe: Pending

Pin	Wire	Circuit	Function
1-5			Not Used
6	0.8 PK	2077	Driver Seat Cushion Heated/Cool Ventilation Module Heat Control (KA1/KB6)
7	1 TN	2110	Steering Column Telescope Motor Control - Reverse
8	1 OG	2098	Steering Column Telescope Motor Forward
9	1 TN	285	Driver Seat Horizontal Motor Forward Control
10	1 L-GN	284	Driver Seat Horizontal Motor Rearward Control
11	0.8 L-GN	2078	Driver Seat Cushion Heated/Cool Ventilation Module Cool Control (KA1/KB6)
12	1 D-GN	286	Driver Seat Front Vertical Motor Up Control
13	1 D-BU	287	Driver Seat Front Vertical Motor Down Control
14	0.8 D-BU	2479	Passenger Seat Cushion Heated/Cool Ventilation Module Heat Control (KA1/KB6)
15	1 YE	282	Driver Seat Rear Vertical Motor Up Control
16	1 L-BU/BK	283	Driver Seat Rear Vertical Motor Down Control

Memory Seat Module (MSM) (A45) X1

Memory Seat Module (MSM) (A45) X2

Connector Part Information Harness: Seat OEM: 15134094 Service: Service by Harness - See Part Catalog Description: 6-Way F 2.8 Series (BK)
Terminal Part Information Terminal/Tray: Service by Harness - See Part Catalog Core/Insulation Crimp: N/A Release Tool/Test Probe: Pending

Pin	Wire	Circuit	Function
1	0.35 GY	6206	Memory Sensor Low Reference
2			Not Used
3	0.35 YE	2080	Driver Seat Cushion Temperature Sensor Low Reference (KA1/KB6)
4-5			Not Used
6	0.35 PK	2435	Passenger Seat Cushion Temperature Sensor Low Reference (KA1/KB6)

Memory Seat Module (MSM) (A45) X2

Scheme 354

Scheme 354: Memory Seat Module (MSM) (A45) X3

Connector Part Information Harness: Seat OEM: 15134095 Service: Service by Harness - See Part Catalog Description: 6-Way F (BN)
Terminal Part Information Terminal/Tray: Service by Harness - See Part Catalog Core/Insulation Crimp: N/A Release Tool/Test Probe: Pending

Pin	Wire	Circuit	Function
1	3 BK	350	Ground
2	2 RD/WH	3740	Battery Positive Voltage
3	0.35 PU/WH	6205	Driver Position Switch High Reference
4	3 BK	350	Ground
5	3 RD/WH	3840	Battery Positive Voltage
6	0.35 RD/WH	3140	Battery Positive Voltage

Memory Seat Module (MSM) (A45) X3

Scheme 355

Scheme 355: Memory Seat Module (MSM) (A45) X4

Connector Part Information Harness: Seat OEM: 15134092 Service: Service by Harness - See Part Catalog Description: 16-Way F (GN)
Terminal Part Information Terminal/Tray: Service by Harness - See Part Catalog Core/Insulation Crimp: N/A Release Tool/Test Probe: Pending

Pin	Wire	Circuit	Function
1-6			Not Used
7	1 BN	2112	Steering Column Tilt Motor Control - Down
8	1 PK	2111	Steering Column Tilt Motor Control - Up
9-11			Not Used
12	1 D-BU	611	Driver Seat Lumbar Motor Forward Control (without W2E)
13	1 PK	610	Driver Seat Lumbar Motor Rearward Control (without W2E)
14	0.8 PK	2480	Passenger Seat Cushion Heated/Cool Ventilation Module Cool Control (KA1/KB6)
15	1 L-GN	276	Driver Seat Recline Motor Forward Control
16	1 L-BU	277	Driver Seat Recline Motor Rearward Control

Memory Seat Module (MSM) (A45) X4

Scheme 356

Scheme 356: Memory Seat Module (MSM) (A45) X5

Connector Part Information Harness: Seat OEM: 15126711 Service: Service by Harness - See Part Catalog Description: 20-Way F 64 Series (BK)
Terminal Part Information Terminal/Tray: Service by Harness - See Part Catalog Core/Insulation Crimp: N/A Release Tool/Test Probe: Pending

Pin	Wire	Circuit	Function
1	0.35 YE/BK	2079	Seat Cushion Temperature Sensor Signal (KA1/KB6)
2	0.35 GY	2434	Passenger Seat Cushion Temperature Sensor Signal (KA1/KB6)
3-8			Not Used
9	0.35 OG/BK	2153	Steering Column Telescope Sensor Signal
10			Not Used
11	0.35 TN	6207	Memory Sensor High Reference
12-13			Not Used
14	0.35 BN/WH	557	Front Vertical Seat Motor Position Sensor Signal
15	0.35 TN/BK	568	Rear Vertical Seat Motor Position Sensor Signal
16	0.35 D-GN	569	Horizontal Seat Motor Position Sensor Signal
17	0.35 WH/BK	570	Driver Seat Recline Motor Position Sensor Signal
18			Not Used
19	0.35 YE	1063	Driver Seat Lumbar Horizontal Position Sensor Signal (without W2E)
20	0.35 OG	2154	Steering Column Tilt Sensor Signal

Memory Seat Module (MSM) (A45) X5

Scheme 357

Scheme 357: Memory Seat Module (MSM) (A45) X6

Connector Part Information Harness: Seat OEM: 15126710 Service: Service by Harness - See Part Catalog Description: 20-Way F USCAR 64 Series (GY)
Terminal Part Information Terminal/Tray: Service by Harness - See Part Catalog Core/Insulation Crimp: N/A Release Tool/Test Probe: Pending

Pin	Wire	Circuit	Function
1			Not Used
2	0.35 D-BU	5915	Passenger Seat Blower Speed Control (KB6)
3-5			Not Used
6	0.35 YE	1065	Driver Seat Lumbar Forward Switch Signal (without W2E)
7			Not Used
8	0.35 GY	2096	Steering Column Tilt and Telescope Up Switch Signal
9	0.35 PK	2094	Steering Column Tilt and Telescope Forward Switch Signal
10			Not Used
11	0.35 OG	5919	Driver Seat Blower Speed Control
12-15			Not Used
16	0.35 D-BU	1064	Driver Seat Lumbar Rearward Switch Signal (without W2E)
17			Not Used
18	0.35 YE	2097	Steering Column Tilt and Telescope Down Switch Signal
19	0.35 OG	2095	Steering Column Tilt and Telescope Reverse Switch Signal
20			Not Used

Memory Seat Module (MSM) (A45) X6

Scheme 358

Scheme 358: Memory Seat Module (MSM) (A45) X7

Connector Part Information Harness: Seat OEM: 15126709 Service: Service by Harness - See Part Catalog Description: 20-Way F USCAR 64 Series (BN)
Terminal Part Information Terminal/Tray: Service by Harness - See Part Catalog Core/Insulation Crimp: N/A Release Tool/Test Probe: Pending

Pin	Wire	Circuit	Function
1-6			Not Used
7	0.35 D-GN	1518	Power Seat Front Vertical Up Switch Signal
8	0.35 YE	1519	Power Seat Rear Vertical Up Switch Signal
9	0.35 TN	1522	Power Seat Horizontal Forward Switch Signal
10	0.35 GY/BK	1269	Power Seat Recline Forward Switch Signal
11-15			Not Used
16	0.35 D-GN	5060	Low Speed GMLAN Serial Data
17	0.35 D-BU	1520	Power Seat Front Vertical Down Switch Signal
18	0.35 L-BU	1521	Power Seat Rear Vertical Down Switch Signal
19	0.35 L-GN	1523	Power Seat Horizontal Rearward Switch Signal
20	0.35 D-GN/WH	1270	Power Seat Recline Rearward Switch Signal

Memory Seat Module (MSM) (A45) X7

Scheme 359

Scheme 359: Mode Actuator

Connector Part Information Harness: HVAC OEM: 7283-5830-30 Service: 89046839 Description: 5-Way F (BK)
Terminal Part Information Terminal/Tray: Service by Harness - See Part Catalog Core/Insulation Crimp: N/A Release Tool/Test Probe: J-38125-561/J-35616-35 (VT)

Pin	Wire	Circuit	Function
1	0.35 GY	605	5-Volt Reference 3
2	0.35 YE	61	Low Reference
3	0.35 YE/BK	1814	Lower Mode Door Position Signal
4	0.35 OG	2273	Mode Door Control
5	0.35 YE/GN	1318	Lower Mode Door Control

Mode Actuator

Scheme 360

Scheme 360: Navigation and Traffic Data Antenna (U2X)

Connector Part Information Harness: Body OEM: 7282-6454-40 Service: 89046743 Description: 6-Way M 1.5 Series (L-GY)
Terminal Part Information Terminal/Tray: 7114-4100-08/9 Core/Insulation Crimp: E/C Release Tool/Test Probe: 15315247/J-35616-3 (GY)

Pin	Wire	Circuit	Function
1	0.35 BARE	1782	Drain Wire
2	0.35 GY		COAX
3	0.35 BN		COAX
4	0.35 YE		COAX
6	0.35 YE		COAX

Navigation and Traffic Data Antenna (U2X)

Scheme 361

Scheme 361: Noise Compensation Microphone (UQS)

Connector Part Information Harness: Headliner OEM: 12059254 Service: 12126020 Description: 2-Way M Metri-Pack 150 Series (GN)
Terminal Part Information Terminal/Tray: 12047581/2 Core/Insulation Crimp: E/C Release Tool: 12094429 Test Probe: J-35616-3 (GY)

Pin	Wire	Circuit	Function
A	0.35 BARE	1489	Drain Wire
B	0.35 D-GN	1488	Noise Compensation Microphone Supply Voltage

Noise Compensation Microphone (UQS)

Scheme 362

Scheme 362: Object Alarm Sensor - Left Rear Corner (UD7)

Connector Part Information Harness: Rear Fascia OEM: 31403-3700 Service: 88988337 Description: 3-Way F MX64 Series, Sealed (BK)
Terminal Part Information Terminal/Tray: SAITS-A03T-M064/14 Core/Insulation Crimp: 9/9 Release Tool/Test Probe: J-38125-215A/J-35616-64B (L-BU)

Pin	Wire	Circuit	Function
1	0.35 D-BU	2374	Object Sensor Supply Voltage
2	0.35 GY	2379	Object Sensor Low Reference
3	0.35 YE	2375	Left Rear Corner Object Sensor Signal

Object Alarm Sensor - Left Rear Corner (UD7)

Object Alarm Sensor - Left Rear Middle (UD7)

Connector Part Information Harness: Rear Fascia OEM: 31403-3700 Service: 88988337 Description: 3-Way F MX64 Series, Sealed (BK)
Terminal Part Information Terminal/Tray: 33468-0001/23 Core/Insulation Crimp: H/H Release Tool/Test Probe: J-38125-213/J-35616-64B (L-BU)

Pin	Wire	Circuit	Function
1	0.35 D-BU	2374	Object Sensor Supply Voltage
2	0.35 GY	2379	Object Sensor Low Reference
3	0.35 OG	2376	Left Rear Middle Object Sensor Signal

Object Alarm Sensor - Left Rear Middle (UD7)

Object Alarm Sensor - Right Rear Corner (UD7)

Connector Part Information Harness: Rear Fascia OEM: 31403-3700 Service: 88988337 Description: 3-Way F MX64 Series Sealed (BK)
Terminal Part Information Terminal/Tray: 33468-0001/23 Core/Insulation Crimp: H/H Release Tool/Test Probe: J-38125-213/J-35616-64B (L-BU)

Pin	Wire	Circuit	Function
1	0.35 D-BU	2374	Object Sensor Supply Voltage
2	0.35 GY	2379	Object Sensor Low Reference
3	0.35 PU	2378	Right Rear Corner Object Sensor Signal

Object Alarm Sensor - Right Rear Corner (UD7)

Object Alarm Sensor - Right Rear Middle (UD7)

Connector Part Information Harness: Rear Fascia OEM: 31403-3700 Service: 88988337 Description: 3-Way F MX64 Series, Sealed (BK)
Terminal Part Information Terminal/Tray: 33468-0001/23 Core/Insulation Crimp: H/H Release Tool/Test Probe: J-38125-213/J-35616-64B (L-BU)

Pin	Wire	Circuit	Function
1	0.35 D-BU	2374	Object Sensor Supply Voltage
2	0.35 GY	2379	Object Sensor Low Reference
3	0.35 D-GN	2377	Right Rear Middle Object Sensor Signal

Object Alarm Sensor - Right Rear Middle (UD7)

Scheme 363

Scheme 363: Outside Rearview Mirror - Driver

Connector Part Information Harness: Door OEM: 7282-7696-40 Service: 19115699 Description: 12-Way M (L-GY)
Terminal Part Information Terminal/Tray: Service by Harness - See Part Catalog Core/Insulation Crimp: N/A Release Tool/Test Probe: 15315247/J-35616-65B (L-BU)

Pin	Wire	Circuit	Function
1	0.35 D-BU/WH	6160	Outside Left Mirror Vertical Position Control
2	0.35 WH	7197	Outside Left Mirror Drive Motor Common
3	0.35 D-GN/WH	6159	Outside Left Mirror Horizontal Position Control
4	0.35 YE	190	Driver Folding Mirror Motor Extend Control (DL7/D26)
5	0.35 L-BU	191	Driver Folding Mirror Motor Retract Control (DL7/D26)
6	0.8 BK	350	Ground
7	0.8 WH	606	Driver Mirror Heating Element Supply Voltage (DR5)
8			Not Used
9	0.35 D-BU	672	5-Volt Reference (A45)
10	0.35 D-GN	784	Driver Mirror Vertical Position Sensor Signal (A45)
11	0.35 GY	786	Driver Mirror Horizontal Position Sensor Signal (A45)
12	0.35 BN	673	Low Reference (A45)

Outside Rearview Mirror - Driver

Outside Rearview Mirror - Passenger

Connector Part Information Harness: Door OEM: 7282-7696-40 Service: 19115699 Description: 12-Way M (L-GY)
Terminal Part Information Terminal/Tray: Service by Harness - See Part Catalog Core/Insulation Crimp: N/A Release Tool/Test Probe: 15315247/J-35616-65B (L-BU)

Pin	Wire	Circuit	Function
1	0.35 OG/BK	6162	Outside Right Mirror Vertical Position Control
2	0.35 WH	7196	Outside Right Mirror Drive Motor Common
3	0.35 GY/BK	6161	Outside Right Mirror Horizontal Position Control
4	0.35 YE	5004	Passenger Folding Mirror Motor Extend Control (DL7/D26)
5	0.35 L-BU	5023	Passenger Folding Mirror Motor Retract Control (DL7/D26)
6	0.8 BK	450	Ground
7	0.8 PU	607	Passenger Mirror Heating Element Supply Voltage (DR5)
8			Not Used
9	0.35 YE	674	5-Volt Reference (A45)
10	0.35 BN	787	Passenger Mirror Vertical Position Sensor Signal (A45)
11	0.35 L-BU/BK	785	Passenger Mirror Horizontal Position Sensor Signal (A45)
12	0.35 L-GN	675	Low Reference (A45)

Outside Rearview Mirror - Passenger

Wiring Systems and Power Management - Component Connector End Views - L Through O Cadillac CTS II

Scheme 339

Scheme 340

License Lamp - Right (Sedan)

License Lamp - Right (Wagon)

Scheme 341

Scheme 342

Scheme 343

Scheme 344

Scheme 345

Scheme 346

Scheme 347

Scheme 348

Liftgate Object Sensor - Right (Wagon)

Scheme 349

Scheme 350

Scheme 351

Scheme 352

Mass Air Flow (MAF)/Intake Air Temperature (IAT) Sensor (LLT)

Mass Air Flow (MAF)/Intake Air Temperature (IAT) Sensor (LSA)

Scheme 353

Memory Seat Module (MSM) (A45) X2

Scheme 354

Scheme 355

Scheme 356

Scheme 357

Scheme 358

Scheme 359

Scheme 360

Scheme 361

Scheme 362

Object Alarm Sensor - Left Rear Middle (UD7)

Object Alarm Sensor - Right Rear Corner (UD7)

Object Alarm Sensor - Right Rear Middle (UD7)

Scheme 363

Outside Rearview Mirror - Passenger

More articles — Electrical

Login / Signup

Enter the code

You have successfully logged in!
