22 11 011 Replacing left engine mount (N52K)
Necessary preliminary tasks
- Secure engine in «INSTALLATION POSITION»(/bmw/z4/e89-2009-2013/remont/mechanical/#engine-repair-n52__11-00-670-securing-engine-in)
- Remove underbody protection at front and rear
Release screws (1) and remove engine mount.
Tightening torque 22 11 1AZ .
Scheme 808
Installation
Rubber section (1) of engine mount must point to middle of vehicle.
Scheme 809
22 11 110 Replacing left engine support arm (N52K)
Necessary preliminary tasks
- Secure engine in «INSTALLATION POSITION»(/bmw/z4/e89-2009-2013/remont/mechanical/#engine-repair-n52__11-00-670-securing-engine-in)
- Remove underbody protection at front and rear
Release grounding strap (1) from engine support arm.
Unfasten screws (2).
Remove engine support arm.
Installation
Aluminum screws/bolts must be replaced.
Tightening torque 22 11 3AZ
Scheme 810
22 11 001 Replacing right engine mount (N52K)
Necessary preliminary tasks
- Secure engine in «INSTALLATION POSITION»(/bmw/z4/e89-2009-2013/remont/mechanical/#engine-repair-n52__11-00-670-securing-engine-in)
- Remove front underbody protection
Release screws (1) and remove engine mount.
Tightening torque 22 11 1AZ .
Installation
Rubber section (1) of engine mount must point to middle of vehicle.
Scheme 811
22 11 100 Replacing right engine support arm (N52K)
Necessary preliminary tasks
- Secure engine in «INSTALLATION POSITION»(/bmw/z4/e89-2009-2013/remont/mechanical/#engine-repair-n52__11-00-670-securing-engine-in)
- Remove front underbody protection
Release screws (1).
Remove engine support arm from engine.
Installation
Aluminum screws/bolts must be replaced.
Tightening torque 22 11 3AZ
Scheme 812
22 31 050 Replacing cross member for transmission mounting
Note. Operations are identical to Replacing rubber mount . See 2231001 REPLACING RUBBER MOUNT FOR TRANSMISSION MOUNTING or 2231001 REPLACING RUBBER MOUNT FOR TRANSMISSION MOUNTING (AUTOMATIC TRANSMISSION) for transmission mounting.
22 31 001 Replacing rubber mount for transmission mounting
Necessary preliminary work
- Remove rear «UNDERBODY PROTECTION»(/bmw/z4/e89-2009-2013/remont/axle-shafts/#rear-axle-repair__51-47-491-removing-and-installingreplacing)
- Remove heat shield
- Support transmission with jack.
Remove screws and nuts.
Remove transmission cross member.
Remove rubber mount from transmission cross member.
Tightening torque 22 32 3AZ/4AZ .
Scheme 813
22 31 001 Replacing rubber mount for transmission mounting (automatic transmission)
Necessary preliminary work
- Remove rear «UNDERBODY PROTECTION»(/bmw/z4/e89-2009-2013/remont/axle-shafts/#rear-axle-repair__51-47-491-removing-and-installingreplacing)
- Remove heat shield
- Support transmission with jack.
Unfasten screws (1) and nuts (2).
Remove transmission cross member.
Remove rubber mount from transmission cross member.
Tightening torque 22 32 3AZ/4AZ .
Scheme 814
Note. Operations are identical to Replacing rubber mount See 2231001 REPLACING RUBBER MOUNT FOR TRANSMISSION MOUNTING or 2231001 REPLACING RUBBER MOUNT FOR TRANSMISSION MOUNTING (AUTOMATIC TRANSMISSION) for transmission mounting.
Necessary preliminary work
- Remove rear «UNDERBODY PROTECTION»(/bmw/z4/e89-2009-2013/remont/axle-shafts/#rear-axle-repair__51-47-491-removing-and-installingreplacing)
- Remove heat shield
- Support transmission with jack.
Remove screws and nuts.
Remove transmission cross member.
Remove rubber mount from transmission cross member.
Tightening torque 22 32 3AZ/4AZ .
Necessary preliminary work
- Remove rear «UNDERBODY PROTECTION»(/bmw/z4/e89-2009-2013/remont/axle-shafts/#rear-axle-repair__51-47-491-removing-and-installingreplacing)
- Remove heat shield
- Support transmission with jack.
Unfasten screws (1) and nuts (2).
Remove transmission cross member.
Remove rubber mount from transmission cross member.
Tightening torque 22 32 3AZ/4AZ .
