Engine - Special Tools (n52) BMW Z4 E89

Adapter MW

Replaced by: 0491003

Note. For pressure gauge for checking the oil pressure - Replaced by 11 4 (0 491 003)

Storage Location

B9

Adapter Minimum set: Mechanical tools MW

Note. (Adapter) For connecting pipe bend 13 6 054 to pressure gauge 13 3 061 or BMW diagnosis and information system for checking oil pressure

A4

Scheme 438

Assembly tool Minimum set: Mechanical tools MW

Note. For installing and removing connecting rod with piston

B47

A47

SI number

01 02 04 (069)

Scheme 439

Bush Minimum set: Mechanical tools MW

Note. For fitting valve stem seal

B15

01 06 98 (306)

Scheme 440

Note. (Assembly bushes with case) For installing pistons of 85 mm diameter (urgently required for pistons with U-Flex ring)

Scheme 441

Consisting of

4 = 0493142 Bush

Note. (Assembly bush) Diameter 85.50 mm, stage 2

1 = 0493139 Bush

Note. (Assembly bush) Diameter 85.00 mm

2 = 0493140 Bush

Note. (Assembly bush) Diameter 85.08 mm, repair

3 = 0493141 Bush

Note. (Assembly bush) Diameter 85.25 mm, stage 1

9 = 0493323 Case

Note. (Case) For storing assembly bushes, gauge 11 6 270 and lever dial gauge 11 6 250

Bush MW

Note. (Assembly bush set) For fitting pistons (diameter 82 mm) with connecting rod into the crankcase. Engine: N52B25

01 02 06 (244)

Consisting of

1 = 0495526 Bush

Note. (assembly bush 82.00 mm)

2 = 0495527 Bush

Note. (assembly bush 82.25 mm)

Scheme 442

Clip MW

Note. (Removal and fitting tool) For removing and installing cylinder head.

B51

01 17 04 (130)

Scheme 443

0490613 110220 Compression tester Minimum set: Mechanical tools MW

Note. (Compression pressure testing set) For all petrol and diesel engines.

01 09 92 (558)

Consisting of

4 = 0490620 Probe

Note. (Test probe) For recording compression testers 11 0 224 and 11 0 160/engine: S14, S38, S50 - Replaced by 11 0 235 (0 493 129)

4 = 0490616 Card

Note. (Cards) 100 pieces For recording compression tester 11 0 221

4 = 0490622 Card

Note. (Cards) 100 pieces For recording compression tester 11 0 224

2 = 0494517 Adapter

Note. Measuring "absolute compression" at all cylinders. Engine: W17

2 = 0493634 Case

Note. With foam material insert for recording compression tester

16 = 0495279 Adapter

Note. M67, M67TU engine

Scheme 444

4 = 0490614 Compression tester

Note. (Compression tester) For diesel engines.

4 = 0490615 Probe

Note. (Test probe) For recording compression testers 11 0 221 and 11 0 160/engine: M21, M41, M47, M51, M57, M57T2

4 = 0490617 Compression tester

Note. (Compression tester) For petrol engines.

4 = 0490618 Hose

Note. (Extension hose) For rubber tapered section with fitting 11 0 228

4 = 0490619 Probe

Note. (Test probe) For recording compression testers 11 0 224 and 11 0 160/engine: M10, M20, M30, M40, M42, M43, M44, M50, M52, M60, M62, M70, M73, N62, S50US, S52US, S62

4 = 0490621 Tapered section

Note. (Rubber tapered section) For recording compression testers 11 0 224 and 11 0 160.

4 = 0490625 Valve

Note. (Non-return valve)

4 = 0490626 Filter

Note. (Filter) 3 x 3 mm

9 = 0493129 Probe

Note. (Test probe, screw-in) For measuring "absolute compression" at all cylinders, engine: S14, S38, S50B30, S50B32, S50US, S52US, S54, S85

2 = 0493387 Probe

Note. (Test probe) For recording compression tester 11 0 221 or DIS pressure sensor/engine: M47, M57, M57TU, M57T2

0490593 110160 Compression tester MW

Replaced by: 0490613

Note. (Compression recorder) manufacturer VDO - Replaced by 11 0 220 (0 490 613)

Consisting of

1 = 0490594 Card

Note. (Cards) For compression pressure inscriber Discontinuation and replaced by 11 0 220 (0 490 613)

2 = 0490595 Pressure gauge

Note. Compression pressure inscriber Discontinuation and replaced by 11 0 220 (0 490 613)

3 = 0490596 Guard

Note. (Rubber protection) Still available as replacement Discontinuation and replaced by 11 0 220 (0 490 613)

4 = 0490597 Lines

Note. Discontinuation and replaced by 11 0 220 (0 490 613)

5 = 0490598 Adapter

Note. (test adapter for petrol engine) Engine: all, except M70 Discontinuation and replaced by 11 0 220 (0 490 613)

6 = 0490599 Adapter

Note. (test adapter for petrol engine) Engine: M70 Discontinuation and replaced by 11 0 220 (0 490 613)

7 = 0490600 Adapter

Note. (Test adapter extension) Discontinuation and replaced by 11 0 220 (0 490 613)

Scheme 445

0496671 117110 Device MW

Note. For removing and installing throttle return springs for intermediate levers.

01 18 09 (578)

Scheme 446

0490826 112110 Device MW

Replaced by: 0490504

Note. For retightening the connecting rod and cylinder head bolts - Replaced by 00 9 120 (0 490 504)

Consisting of

1 = 0490827 Extension

Note. (Extension 1/1") Replaced by 00 9 120 (0 490 504)

2 = 0490828 Washer

Note. (Graduated disc 180°) Replaced by 00 9 120 (0 490 504)

3 = 0490829 Sleeve

Note. (Guide sleeve) Replaced by 00 9 120 (0 490 504)

4 = 0490830 Nut

Note. (Knurled nut) Replaced by 00 9 120 (0 490 504)

5 = 0490831 Wrench socket

Note. (Socket wrench insert WAF 10) Replaced by 00 9 120 (0 490 504)

6 = 0490832 Washer

Note. (Graduated disc up to 270°) Replaced by 00 9 120 (0 490 504)

7 = 0490833 Tab

Scheme 447

Note. For counter-holding on the cylinder head Replaced by 00 9 120 (0 490 504)

8 = 0490834 Adapter

Note. (Adapter) Replaced by 00 9 120 (0 490 504)

0495049 114450 Device Minimum set: Mechanical tools MW

Note. (Locating fixture) For securing sliding blocks during installation.

A52

01 17 04 (130)

Scheme 448

0495014 114340 Device MW

Note. (Pressure testing fixture) For pressure-testing cylinder head.

01 17 04 (130)

Consisting of

2 = 0495016 Plate

Note. (Plate with thrust piece)

1 = 0495015 Plate

Note. (base plate with seal)

3 = 0495017 Hose

Note. (Hose with air connection)

4 = 0495724 Plate

Note. (Adapter plate with valve) N54

5 = 0495725 Screw

Note. (set of screws)N54

Scheme 449

0495024 114370 Device MW

Note. (pressing fixture) For pressing out sealant for bedplate.

A52

01 17 04 (130)

Scheme 450

0494362 119000 Device Minimum set: Mechanical tools MW

Note. (Cylinder head expander tool)

Individual

01 03 02 (833)

Consisting of

17 = 0495028 Cage

Note. (Valve spring cage) Engine N52

1 = 0494366 Device

5 = 0494370 Quick fastener

7 = 0494372 Shaped part

Note. (Shaped part)

8 = 0494373 Shaped part

Note. (Shaped part) Shaped part made of plastic

9 = 0494374 Lever

2 = 0494367 Rod

3 = 0494368 Adapter

Note. (Sliding block)

4 = 0494369 Tab

6 = 0494371 Insert

Note. (Aluminum strip)

Scheme 451

10 = 0494375 Hook

11 = 0494376 Cage

Note. (Valve spring cage) Engine M41, M51, S50

12 = 0494377 Cage

Note. (Valve spring cage) Engine M43, M73

13 = 0494378 Cage

Note. (Valve spring cage) Engine M44, M52, M54, M56, M62, S52, S54, S62

14 = 0494379 Cage

Note. (Valve spring cage) Engine M47, M47TU, M57, M57TU, N40, N42, N62, N73

15 = 0494380 Cage

Note. (Valve spring cage) Engine M21, M40

0495003 114270 Device Minimum set: Mechanical tools MW

Replaced by: 0496671

Note. (Assembly and disassembly tool) For removing and installing pressure spring for intermediate lever. Is replaced by 11 7 110 (0 496 671)

C51

B51

01 17 04 (130)

Scheme 452

0491008 114080 Device MW

Replaced by: 0491007

Note. For installation of the dipstick guide tube - Replaced by 11 4 070 (0 491 007)

0493971 119340 Device Minimum set: Mechanical tools MW

Note. (Device) For tensioning timing chain when adjusting timing

B43

01 01 01 (662)

Consisting of

1 = 0494032 Bolt

2 = 0494033 Spindle

Scheme 453

0495019 114360 Device Minimum set: Mechanical tools MW

Note. (Removal and mounting device) For removal and installation of cover of vacuum pump.

01 17 04 (130)

Consisting of

2 = 0495021 Adapter

Note. (Adapter with knurled screw)

1 = 0495020 Clip

3 = 0495022 Spindle

Note. (pressure spindle)

4 = 0495023 Spindle

Note. (Drawing spindle)

Scheme 454

0495050 114460 Device Minimum set: Mechanical tools MW

Note. (Locating device) For locating the upper and lower bearing strips when installing the exhaust camshaft.

01 17 04 (130)

Consisting of

1 = 0495099 Tool

Note. (Press-down tool, 2nd cylinder)

2 = 0495100 Bolt

Note. (Screws M7 (2 pieces))

3 = 0495101 Synchronizing key

Note. (Synchronizing keys 6 pieces)

Scheme 455

0493751 119150 Extension Minimum set: Mechanical tools MW

Note. (Socket wrench extension) For loosening and tightening the oxygen sensor

A42

01 15 00 (609)

Scheme 456

0493933 119200 Extractor Minimum set: Mechanical tools MW

Note. For RSS out of engine block at rear

C43

01 01 01 (662)

Scheme 457

0493934 119220 Extractor Minimum set: Mechanical tools MW

Note. For radial shaft seal out of engine block at front

C43

01 01 01 (662)

Consisting of

1 = 0494040 Bolt

Note. Replaced by 11 9 225 (0 496 261)

1 = 0494041 Bolt

Note. (screws (6 pieces))

1 = 0494039 Synchronizing key

4 = 0494042 Bolt

Note. (Screws (3 pieces))

5 = 0496261 Bolt

6 = 0496262 Puller

Scheme 458

0490646 110340 Fitting aid MW

Replaced by: 0494362

Note. (fitting accessories) For removing and fitting the valve springs. Replaced by 11 9 000 (0 494 362)

01 12 93 (701)

Consisting of

3 = 0490649 Hook

Note. (hook) Length 220 mm - Engine: all, except M10 Replaced by 11 9 000 (0 494 362)

5 = 0490651 Cage

Note. (Valve spring cage) Engine: M44, M52, M62, S62, S54 Replaced by 11 9 000 (0 494 362)

1 = 0490647 Cage

Note. (Valve spring cage) Engine: M43, M73

2 = 0490648 Lever

Note. (compression lever) Engine: all, except M10

6 = 0493285 Cage

Note. (Valve spring cage) Engine: M47, M47TU, M57, N40, N42, M67, M67TU

4 = 0490650 Cage

Scheme 459

Note. (valve spring cage) Replaced by 11 0345, engine: M52

0496084 111240 Fitting aid Minimum set: Mechanical tools MW

Note. (installation set) For installing elasto-belt.

01 01 07 (333)

Consisting of

1 = 0496085 Fitting aid

Note. (Mounting tool)

2 = 0496086 Guard

Note. (Belt guard)

Scheme 460

11-4290 Gauge

0495008 114290 Gauge Minimum set: Mechanical tools MW

Note. For disconnecting camshaft sensor gears.

A52

A51

01 17 04 (130)

Scheme 461

0496942 117440 Gauge Minimum set: Mechanical tools MW

Note. For fixing the camshaft at the top dead center.

01 07 10 (634)

Scheme 462

0495004 114280 Gauge Minimum set: Mechanical tools MW

Note. For locating camshaft in TDC setting.

B52

01 17 04 (130)

Consisting of

4 = 0495723 Bolt

Note. (Set of screws M6) Engine: N54

1 = 0495005 Gauge

2 = 0495006 Adapter

3 = 0495007 Retaining bracket

5 = 0496673 Bridge

Note. For securing camshaft at TDC.

Scheme 463

0494999 114250 Gauge Minimum set: Mechanical tools MW

Note. (Gauge with adapter plate) For securing the oil spray nozzles.

01 17 04 (130)

Consisting of

1 = 0495000 Gauge

2 = 0495001 Plate

Note. (Adapter plate)

Scheme 464

0493938 119260 Holder Minimum set: Mechanical tools MW

Note. (Counter support with screw connection) For holding the flywheel when gearbox is removed

B43

01 01 01 (662)

Consisting of

1 = 0494034 Holder

Note. (Individual counter support)

2 = 0494035 Screw

Note. (Bolt (thread M10) with washer) For screwing counter support

3 = 0494129 Bush

Note. (Bush for counter support) For counter support, for retaining flywheel when gearbox is removed Engine: N62, N73

4 = 0494130 Screw

Note. (Bolt (thread M12)) For counter support for retaining flywheel when gearbox is removed

5 = 0494793 Bush

6 = 0495216 Bush

Scheme 465

Note. For counter support, for retaining flywheel when gearbox is removed Engine: M57TU2

0493587 118180 Holder Minimum set: Mechanical tools MW

Note. (Counter support) Blocking flywheel when releasing and tightening down central bolts on vibration absorber

C45

C46

01 12 99 (452)

Consisting of

1 = 0494432 Basic body

Note. (Basic body) E65/M67, E38/M67 Discontinuation Replaced by 11 8 183 (0 494 434)

2 = 0494433 Shaped part

Note. (Shaped part)

3 = 0494434 Basic body

4 = 0494435 Adapter

Note. E65/M67

5 = 0494716 Adapter

Note. (Adapter with adjusting sleeve) E46 M47TU

Scheme 466

0493940 119280 Holder Minimum set: Mechanical tools MW

Note. (Counter support) For the crankshaft when releasing/tightening the central bolt

B43

C43

A43

01 01 01 (662)

Scheme 467

Scheme 468

0490853 112220 Holder MW

Replaced by: 0490855

Note. (Counter support) - Nov. 88 Replaced by 11 2 240 (0 490 855)

0495010 114491 Holder MW

Note. (Installation bracket)

A51

Scheme 469

0495071 110290 Holder Minimum set: Mechanical tools MW

Note. (Counter support) For removing and installing triangular drive (vacuum pump) on crankcase.

A52

01 17 04 (130)

Scheme 470

Scheme 471

0490579 110070 Lifting gear Minimum set: Mechanical tools MW

Note. (Lifting gear) For removing and installing engines

01 16 96 (107)

Consisting of

4 = 0493753 Shackle

Note. (Shackle) 2 x

1 = 0490580 Lifting gear

Note. (cross-member)

2 = 0490581 Chain

Note. (Chain) Version: long

3 = 0490582 Chain

Note. (Chain) Version: short

Scheme 472

0490561 110000 Lifting gear Minimum set: Mechanical tools MW

Note. (Hoist) For removing and installing engines.

01 13 94 (888)

Consisting of

1 = 0490562 Lifting gear

Note. (Cross-member)

2 = 0490563 Chain

Note. (Chain) Version: long

3 = 0490564 Chain

Note. (Chain) Version: short

4 = 0490565 Shackle

Note. (Shackle) 2 x

Scheme 473

0490567 110020 Lifting gear Minimum set: Mechanical tools MW

Note. For removing and installing engines.

01 13 94 (888)

Consisting of

1 = 0490568 Lifting gear

Note. (Cross-member)

2 = 0490569 Chain

Note. (Chain)

3 = 0490570 Chain

Note. (Chain) Version: long

4 = 0490571 Chain

Note. (Chain) Version: short

5 = 0490572 Shackle

Note. (Shackle) 2 pieces

Scheme 474

0490739 111310 Mandrel MW

Note. (Drift) For driving needle bearing out of crankcase (M20) and pressing out propeller shaft centering mount

Scheme 475

0493973 119360 Mandrel Minimum set: Mechanical tools MW

Note. For driving valve into engine block (sealing compound)

A43

01 01 01 (662)

Scheme 476

0490818 112030 Mandrel Minimum set: Mechanical tools MW

Note. (drift) For driving guide bearing into crankshaft (S14, S38, M10, M20, M21, M30, M40, M42, M50, M51 M52) and driving centering mount into propeller shaft

A15

Scheme 477

0495013 114494 Mandrel MW

Note. (Installation drift)

A51

0495070 110300 Mandrel Minimum set: Mechanical tools MW

Note. (Alignment pin) For securing the flywheel at the TDC setting

A52

01 17 04 (130)

Scheme 478

0490721 111170 Mandrel MW

Note. (Mandrel) Replaced by 11 1 200

0490723 111190 Mandrel MW

Note. (Drift) Replaced by 11 1 200

0490718 111140 Mandrel MW

Replaced by: 0490724

Note. (Drift) Replaced by 11 1 200 (0 490 724)

0495105 114480 Oddments tray Minimum set: Mechanical tools MW

Note. (Boards (2 pieces)) For setting down the individual components of the cylinder head.

01 17 04 (130)

Consisting of

1 = 0495106 Oddments tray

Note. (Board for intake side)

2 = 0495107 Oddments tray

Note. (Board for exhaust side)

Scheme 479

0493936 119240 Oil filter wrench Minimum set: Mechanical tools MW

Note. For unfastening and tightening oil filter cover

A43

01 01 01 (662)

Scheme 480

0490973 113340 Pin Minimum set: Mechanical tools MW

Note. (lock pin (2 pieces)) For retaining the chain tensioner piston (e.g. when removing and installing the cylinder head) and to lock the drive belt tensioner

B5

C5

01 09 91 (416)

Scheme 481

0491012 114120 Pin Minimum set: Mechanical tools MW

Note. (lock pin) For chain tensioners, for locking the chain tensioner piston (e.g. during cylinder head removal and fitting)

B5

C5

01 12 93 (701)

Scheme 482

0495736 118540 Plate MW

Note. (Fixture) For mounting engine on assembly stand.

01 20 06 (299)

Consisting of

1 = 0495737 Fixture

Note. (Engine mount)

2 = 0495738 Screw

Note. (Set of screws (4 x))

Scheme 483

0495048 114440 Plate MW

Replaced by: 0495736

Note. (Fixture) For mounting engine on assembly stand. Is replaced by 11 8 540 (0 495 736)

01 17 04 (130)

Scheme 484

0490824 112090 Pliers MW

Replaced by: 0490796

Note. For removal of the valve stem seals - Replaced by 11 1 480 (0 490 796)

Scheme 485

0490728 111250 Pliers MW

Replaced by: 0490796

Note. For removing and installing the valve stem seal. Only free for motorcycle! Replaced by 11 1 480 (0 490 796)

0490796 111480 Pliers Minimum set: Mechanical tools MW

Note. For removing valve stem seal

B10

01 01 93 (621)

Scheme 486

0495011 114492 Pliers MW

Note. (Removal pliers)

A51

0495012 114493 Pliers MW

Note. (Installation pliers)

A51

0495027 114430 Plug Minimum set: Mechanical tools MW

Note. (Seal plugs (2x)) For sealing off oil holes in oil pump.

A52

01 17 04 (130)

Scheme 487

0496266 110370 Puller Minimum set: Mechanical tools MW

Note. For removing front radial shaft seal.

C23

01 15 07 (390)

Consisting of

1 = 0496275 Bell housing

Note. (thread housing)

2 = 0496276 Spindle

Scheme 488

0495728 118530 Removal and fitting aid Minimum set: Mechanical tools MW

Note. (Removal and mounting tool) For removal and installation of sealing cap of vacuum pump.

01 20 06 (299)

Consisting of

8 = 0496704 Bush

In conjunction with: 11 8 530

1 = 0495729 Plate

Note. (Base plate)

2 = 0495730 Plate

Note. (Pressure plate)

3 = 0495731 Spindle

Note. (Spindle (pressure plate))

4 = 0495732 Spindle

Note. (Spindle (removal plate))

5 = 0495733 Screw

Note. (Set of screws M10 (N54))

6 = 0495734 Screw

Note. (Set of screws M11 incl. sleeve (N53))

7 = 0495735 Plate

Scheme 489

Note. (Removal plate)

0491018 114180 Screwdriver insert Minimum set: Mechanical tools MW

Note. (Screwdriver insert Torx T60) For releasing and tightening down dual-mass flywheel - model year: from Jan 94

A11

01 02 94 (777)

Scheme 490

0490746 111380 Sleeve Minimum set: Mechanical tools MW

Note. (Assembly sleeve) For fitting the valve stem seal, diameter 7 mm

Scheme 491

0490743 111350 Sleeve MW

Replaced by: 0490744

Note. (Assembly sleeves) For fitting the valve stem seal - Replaced by 11 1 360 (0 490 744)

0495747 118580 Socket wrench Minimum set: Mechanical tools MW

Note. (wrench socket Torx T60) For removing and installing cylinder head (outside diameter 13.5 mm).

B20

A20

01 20 06 (299)

Scheme 492

0495002 114260 Socket wrench MW

Note. For removing and installing lambda oxygen sensors.

A52

01 17 04 (130)

Scheme 493

0493935 119230 Tool Minimum set: Mechanical tools MW

Note. (Pulling device) For radial shaft seal at front of engine block

C43

01 01 01 (662)

Consisting of

1 = 0494021 Bush

2 = 0494022 Spindle

4 = 0494024 Bolt

Note. (Screws (3 pieces))

5 = 0496670 Spindle

Note. N55

3 = 0494023 Nut

Scheme 494

0495102 114470 Tool Minimum set: Mechanical tools MW

Note. (cleaning kit) For cleaning sealing surfaces on magnesium crankcase/cylinder head.

01 17 04 (130)

Consisting of

2 = 0495104 Extractor

Note. (grindstone)

1 = 0495103 Scraper

Scheme 495

0493248 116370 Tool Minimum set: Mechanical tools MW

Note. (Extractor tool) For pulling off the valve stem seal

B15

01 06 98 (306)

Scheme 496

0493881 119180 Tool Minimum set: Mechanical tools MW

Note. (pulling tool) For pulling radial shaft seal into engine block, rear

C43

01 01 01 (662)

Consisting of

5 = 0496660 Ring

Note. For fitting rear radial shaft seal - rim offset 6.6 mm (N55).

1 = 0494028 Bush

2 = 0494029 Thrust piece

3 = 0494030 Nut

4 = 0494031 Screw

Note. (screws (2 x))

Scheme 497

0495009 114490 Tool set MW

Note. (Tool set) For removal and installation of gudgeon pin circlips.

01 17 04 (130)

Consisting of

0495010

0495011

0495012

0495013

0495018 114350 Torque wrench MW

Note. For installing camshaft bearing strips.

A51

01 17 04 (130)

Scheme 498

0495750 118640 Torx Minimum set: Mechanical tools MW

Note. (Torx) E10 For removing and installing oil pump triangular drive.

B19

01 20 06 (299)

Scheme 499

0495110 115190 Torx Minimum set: Mechanical tools MW

Replaced by: 0495747

Note. (Torx) T60 For assembly and disassembly of cylinder head. Replaced by 11 8 580 (0 495 747)

A51

01 17 04 (130)

Scheme 500

0495026 114420 Torx Minimum set: Mechanical tools MW

Note. (Torx) T50 For assembly and disassembly of cylinder head.

A51

01 17 04 (130)

Scheme 501

0495111 115200 Washer Minimum set: Mechanical tools MW

Note. (Shim) For slackening and tightening the central bolt.

B51

01 17 04 (130)

Consisting of

2 = 0495211 Screw

Note. (Screws M8x40 mm (3 x))

1 = 0495210 Washer

Note. (Shim)

Scheme 502

0491074 117020 Wrench socket Minimum set: Mechanical tools MW

Note. (Wrench socket 22 mm) For loosening and tightening the oxygen sensor

Scheme 503
