FASTENER TIGHTENING SPECIFICATIONS
| Components | Fastener Size | Nm |
|---|
| Bracket For the EVAP Canister 1 |
| Bolt 2 | | 40 + 90° |
| Nut | | 8 |
| Bracket for Engine Mount 2 | | 20 + 90° |
| Engine Mount 2 | | 40 + 90° |
| Bolts/nuts |
| M6 | 10 |
| M7 | 15 |
| M8 | 22 |
| M10 | 40 |
| M12 | 65 |
| 1 For bolt tightening clarification, refer to SUBFRAME OVERVIEW and see items -3 and 5- 2 Replace |
Manual Transmission on the Engine
Scheme 177
| Item | Bolt | Nm |
|---|
| 1 | M12x65 | 80 |
| 2 | Starter, securing. Refer to [For transmission(s) 02E] Removal and Installation |
| 3 | M10x65 | 40 |
| 4 | M10x75 | 40 |
| 5 1) | M12x95 | 80 |
| A, B | Alignment sleeves for centering |
| 1) Install in transmission from engine side. |
