2.5L - Engine Assembly - Engine Code(s): Cepb (Coupe): Overview Audi TT 8J facelift

Mechanical 1 illustration ~216 words

Scheme 178

Scheme 178: SUBFRAME OVERVIEW
Scheme 178: SUBFRAME OVERVIEW
  1. Bolt Replace 40 Nm plus an additional 90° turn
  2. Bolt Replace 40 Nm plus an additional 90° turn
  3. Bolt Replace 40 Nm plus an additional 90° turn
  4. Bracket For the EVAP canister
  5. Bolt Tightening specification «COOLANT PIPES OVERVIEW => List Item:Bolt»(ref-505591-S09781795262012100100000)
  6. Nut 8 Nm
  7. Engine Mount Adjustment, checking, refer to «SUBFRAME MOUNT, CHECKING ADJUSTMENT»(ref-505668-S13197297582012100100000) Adjusting, refer to «SUBFRAME MOUNT, ADJUSTING»(ref-505668-S27211101422012100100000) Removing and installing, refer to «ENGINE MOUNT»(ref-505668-S10963839962012100100000)
  8. Bracket
  9. Bolt Replace 20 Nm plus an additional 90° turn
  10. Bolt Replace 20 Nm plus an additional 90° turn
  11. Bolt Replace 40 Nm plus an additional 90° turn
  12. Pendulum Support Removing and installing, refer to «Removal and Installation»(ref-505583-S42547525412012100100000) or to «Removal and Installation»(ref-505585-S14685324552012100100000)
  13. Bolt Tightening specification, refer to «Description and Operation»(ref-505583-S27362515362012100100000) or to «Description and Operation»(ref-505585-S16619293972012100100000)
  14. Bolt Tightening specification, refer to «Description and Operation»(ref-505583-S27362515362012100100000) or to «Description and Operation»(ref-505585-S16619293972012100100000)
  15. Bolt Tightening specification, refer to «Description and Operation»(ref-505583-S27362515362012100100000) or to «Description and Operation»(ref-505585-S16619293972012100100000)
  16. Bolt Tightening specification, refer to «Description and Operation»(ref-505583-S27362515362012100100000) or to «Description and Operation»(ref-505585-S16619293972012100100000)
  17. Bolt Tightening specification, refer to «Description and Operation»(ref-505583-S27362515362012100100000) or to «Description and Operation»(ref-505585-S16619293972012100100000)
  18. Transmission Mount Adjustment, checking, refer to «SUBFRAME MOUNT, CHECKING ADJUSTMENT»(ref-505668-S13197297582012100100000) Adjusting, refer to «SUBFRAME MOUNT, ADJUSTING»(ref-505668-S27211101422012100100000) Removing and installing, refer to «Removal and Installation»(ref-505583-S42547525412012100100000) or to «Removal and Installation»(ref-505585-S14685324552012100100000)
