2.0L - Engine Assembly - Engine Code(s): Cdma (Coupe): Adjustments Audi TT 8J facelift

SUBFRAME MOUNT, CHECKING ADJUSTMENT

Procedure

Release the EVAP canister -B arrow-, remove it upward -A arrow- and lay it aside.

Scheme 347

Note. Ignore -1 and 2-.

Check dimensions on right mount for engine and transmission

1. Both bolt heads -2- must be parallel to edge of engine mount support arm -3-.
2. A distance of -x- = 16 mm must be present between engine mount -1- and engine support -4-.

Note. Distance -x- = 16 mm can also be checked with corresponding round stock.

The distance measured if too small or too large, adjust the subframe. Refer to SUBFRAME MOUNT, ADJUSTING .
