2.0L - Engine Assembly - Engine Code(s): Cdma (Roadster): Overview Audi TT 8J facelift

Scheme 948

1. Bolt Transmission support to transmission Tightening specifications, refer to «Specifications»(ref-505730-S30849944692012100100000)
2. Bolts Pendulum supports to transmission Different lengths Tightening specifications, refer to «Specifications»(ref-505730-S30849944692012100100000)
3. Engine Support With support arm Illustration does not correspond to version in vehicle
4. Bolt 45 Nm Different lengths Engine support to engine
5. Engine Mount With support arm
6. Bolt Replace 40 Nm plus an additional 90° turn Engine mount to body
7. Bracket
8. Bolt Replace 20 Nm plus an additional 90° turn Bracket to engine mount
9. Bolt Replace 20 Nm plus an additional 90° turn Bracket to body
10. Bolt Replace 40 Nm plus an additional 90° turn Engine mount to body
11. Bolts Replace 60 Nm plus an additional 90° turn Engine mount to engine support
12. Pendulum Support
13. Bolt Pendulum supports to subframe Tightening specifications, refer to «Specifications»(ref-505730-S30849944692012100100000)
14. Bolt Transmission mount to transmission support Tightening specifications, refer to «Specifications»(ref-505730-S30849944692012100100000)
15. Bolt Transmission mount to body Tightening specifications, refer to «Specifications»(ref-505730-S30849944692012100100000)
16. Transmission Mount With support arm The S-Tronic transmission is shown in the illustration
17. Bolt Transmission support to transmission Tightening specifications, refer to «Specifications»(ref-505730-S30849944692012100100000)
18. Bolt Transmission support to transmission Tightening specifications, refer to «Specifications»(ref-505730-S30849944692012100100000)
19. Transmission Support
