4.2L - Engine Assembly - Engine Code(s): Caua (Coupe): Overview Audi S5 I facelift

Mechanical 1 illustration ~124 words

Scheme 48

Scheme 48: SUBFRAME MOUNT OVERVIEW
Scheme 48: SUBFRAME MOUNT OVERVIEW
  1. Bolt 20 Nm
  2. Retaining Plate For the engine mount If the engine mount is faulty, replace the retaining plate Check the retaining plate on the opposite side; replace if necessary
  3. Rubber Stop Not available individually
  4. Bolt 40 Nm
  5. Engine Support
  6. Bolt 10 Nm
  7. Heat Shield
  8. Lower Left Coolant Pipe
  9. Bolt Tightening specification item 26 «COOLANT PIPES OVERVIEW»(ref-520122-S19289710182012123100000)
  10. Bolt Replace 90 Nm plus an additional 90° turn
  11. Engine Mount With the electro-hydraulic engine mount solenoid valve Left electrohydraulic engine mount solenoid valve -N144- or right electro-hydraulic engine mount solenoid valve -N145- Removing and installing, refer to «LEFT ENGINE MOUNT»(ref-520157-S10200322532012123100000) , «RIGHT ENGINE MOUNT»(ref-520157-S05734076172012123100000) Replace in pairs
  12. Subframe
  13. Bolt 55 Nm
  14. Bolt 55 Nm
