3.0L - Engine Assembly - Engine Code(s): Ccba (Cabriolet): Overview Audi S5 I facelift

Mechanical 2 illustrations

Scheme 407

Scheme 407: SUBFRAME MOUNT OVERVIEW
Scheme 407: SUBFRAME MOUNT OVERVIEW
  1. Bolt 20 Nm
  2. Mounting Plate For the engine mount If the engine mount is faulty, replace the retaining plate Check the retaining plate on the opposite side; replace if necessary
  3. Bolt 40 Nm
  4. Engine Support
  5. Bolt 10 Nm
  6. Heat Shield
  7. Bolt 90 Nm plus an additional 90° turn Replace
  8. Engine Mount Removing and installing: Left «LEFT ENGINE MOUNT»(ref-522408-S31442098592013011400000) , right «RIGHT ENGINE MOUNT»(ref-522408-S18862323622013011400000) Replace in pairs
  9. Subframe
  10. Bolt 55 Nm

Scheme 408

Scheme 408
Scheme 408

Tighten the nut -2- for the hydraulic oil hose bracket -1- to 9 Nm.
