FASTENER TIGHTENING SPECIFICATIONS
| Component | Fastener Size | Nm |
|---|---|---|
| Bolts and nuts | ||
| M6 | 9 | |
| M7 | 15 | |
| M8 | 20 | |
| M10 | 40 | |
| M12 | 65 | |
| Engine mount 1 | 90 + 90° | |
| Engine support | 40 | |
| Heat shield | 10 | |
| Mounting plate | 20 | |
| Subframe | 55 | |
| 1 Always replace | ||
POWER STEERING FLUID HOSE BRACKET FOR VEHICLES WITH HYDRAULIC POWER STEERING - TIGHTENING SPECIFICATION
Tighten the nut -2- for the hydraulic oil hose bracket -1- to 9 Nm.
Scheme 403
Tighten the ground bolt -1- to 9 Nm.
Scheme 404
Tighten the nut -arrow- to 9 Nm.
Scheme 405
| Item | Bolt | Nm |
|---|---|---|
| 1 | M10 x 50 1) | 65 |
| 2 through 6 | M12 x 100 2) | 30 + 90° |
| 7 | M12 x 125 2) | 30 + 90° |
| 8, 11 | M10 x 60 2) | 15 + 90° |
| 9, 10 | M10 x 95 2) | 15 + 90° |
| A | Alignment sleeves for centering | |
| 1) Bolt class 10.9, the steel bolt may be used again unlimited number of times. 2) The aluminum bolts can be used 2 times ENGINE, INSTALLING. | ||
Scheme 406
| Item | Bolt | Nm |
|---|---|---|
| 1 | M10 x 50 1) | 65 |
| 2 ••• 6 | M12 x 100 2) | 30 + 90° |
| 7 | M12 x 125 2) | 30 + 90° |
| 8 | M10 x 60 2) | 15 + 90° |
| 9, 10 | M10 x 95 2) | 15 + 90° |
| A | Alignment sleeves for centering | |
| 1) Bolt class 10.9, the steel bolt may be used again unlimited number of times. 2) The aluminum bolts can be used 2 times ENGINE, INSTALLING. | ||
