- Connect vehicle diagnostic, testing and information system VAS5051 or VAG1551 scan tool to vehicle and select Control module for engine electronics "Address Word" 01. See «VEHICLE DIAGNOSTIC, TESTING AND INFORMATION SYSTEM VAS5051 OR VAG1551, CONNECTING AND SELECTING FUNCTIONS»(ref-216437-S40962647232006020800000) . The ignition must be switched ON.
When indicated on display
Scheme 95
- Press buttons -0- and -8- to select "Read Measuring Value Block" and press -Q- button to confirm input.
When indicated on display
Scheme 96
- Press buttons "086" for "display group number 086" and press -Q- button to confirm input.
When indicated on display
- Check readiness code in display field 1 Specified value: 0 0 0 0 0 0 0 0
| Display fields | ||||
|---|---|---|---|---|
| 1 | 2 | 3 | 4 | |
| Display Group 086: Readiness code | ||||
| Display | 0 0 0 0 0 0 0 0 | X X X X X X X X | X X X X X X X X | X X X X X X X X |
| Indicated | Ready-Bits completed tests | Cycle-Flags Performed cycles | Cycle -Flags Performed cycles | Cycle-Flags Performed cycles |
| Work area | 1 = not completed 0 = completed | 1 = not completed 0 = completed | 1 = not completed 0 = completed | 1 = not completed 0 = completed |
| Specified value | 0 0 0 0 0 0 0 0 | X X X X X X X X | X X X X X X X X | X X X X X X X X |
| Note | Readiness code significance below | |||
DISPLAY GROUP 086: READINESS CODE
Note for display field 1
This display field indicates which diagnosis was checked last after the DTC memory was erased or if the control module was replaced. After erasing the DTC memory, all values that can be checked will be reset to 1, after successful testing these values will be reset to 0.
Note for display fields 2, 3 and 4
These display fields indicate which diagnosis was checked after the last engine start. If the engine is switched off the diagnosis is set to position 1. All values that can be checked will be set to 0 after next diagnosis.
Scheme 97
Note. The readiness code is only set if all position are displayed with "0."
Scheme 98
Scheme 99
Scheme 100
If the specified value in display field 1
"00000000" is obtained
- Press -->button.
Indicated on display (function selection)
Scheme 101
- Check DTC memory. See «DIAGNOSTIC TROUBLE CODE (DTC) MEMORY, CHECKING AND ERASING»(ref-216437-S08471100802006020800000) (No malfunction should be stored in the DTC memory).
If specified value is not reached
- Generate readiness code. See «READINESS CODE, GENERATING»(ref-216437-S25676712792006020800000) .
