Basic Setting Audi A8 D3

Testing & Diagnostics 7 illustrations ~432 words

With the ignition ON and engine not running, the following operation can be performed in the "Basic setting" mode (function 04)

  1. Adaptation of throttle valve control module to Engine Control Module (ECM), see Display Group 60

With the engine running, the following operations can be performed in the basic setting mode "Function 04"

  1. Learning process (adaptation) for oxygen sensor control, see «CHECKING OXYGEN SENSOR ADAPTATION AND OXYGEN SENSOR CONTROL»(ref-216438-S32485856092006020800000) .
  2. Troubleshooting by targeted activation and deactivation of oxygen sensor control, see «OXYGEN SENSOR AND OXYGEN SENSOR CONTROL BEFORE THREE WAY CATALYTIC CONVERTER (TWC), CHECKING»(ref-216438-S09911970222006020800000) .

Test requirements for operations with engine running

  1. No DTCs stored in DTC memory
  2. Coolant temperature at least 85 °C
  3. Electrical consumers switched off (radiator fan must not run during test)
  4. A/C switched off
  5. Gear selector lever in P or N position
  6. Wheels in straight -ahead position
  1. Connect vehicle diagnostic, testing and information system VAS 5051 or VAG1551 scan tool and select engine electronics control module by entering address word "01". See «VEHICLE DIAGNOSTIC, TESTING AND INFORMATION SYSTEM VAS5051 OR VAG1551, CONNECTING AND SELECTING FUNCTIONS»(ref-216437-S40962647232006020800000) . When doing this the engine must be idling.
  2. Check and erase DTC memory. See «DIAGNOSTIC TROUBLE CODE (DTC) MEMORY, CHECKING AND ERASING»(ref-216437-S08471100802006020800000) . There should be no malfunctions stored in the DTC memory. (If necessary repair malfunctions, erase DTC memory and switch off engine. Start engine again, road test the vehicle and check DTC memory again to check).
  3. Leave engine idling.

Indicated on display

Scheme 77

Scheme 77
  1. Press buttons -0- and -4- to select function "Basic Setting" and confirm entry by pressing -Q- button.

Indicated on display

Scheme 78

Scheme 78

Scheme 79

Scheme 79

Scheme 80

Scheme 80

Scheme 81

Scheme 81

Scheme 82

Scheme 82

Scheme 83

Scheme 83
  1. Select required display group number from the Display Group Overview in "Read Measuring Value Block" section. NOTE: Display Group 000 is used here as an example to illustrate the procedure.
  2. Press buttons -0- three times. (000 is to select Display Group 000) NOTE: When the display group is selected the EVAP valve is closed and the air conditioner compressor is switched off. Indicated on display
  3. Confirm entry by pressing -Q- button. Indicated on display
  4. Allow engine to idle for a few minutes; coolant temperature at least 85° C (185° F) (at least 180 in display field 1). NOTE: When the PRINT button is pressed the current display will be printed out. Press C button before selecting further display groups.
  5. If readouts in all display fields match specifications, Press --> button. Indicated on display
  6. Press buttons -0- and -6- to select function "End Output" and confirm entry with -Q- button. Indicated on display
