Note. If the correct coding for the vehicle is not displayed, or if the control module has been replaced, the control module must be coded. Coding is checked via VAS 5051 or VAG1551 scan tool. During control module identification a 5-digit code must always be displayed. Incorrect coding may lead to higher emissions and increased strain on the automatic transmission resulting from harsh gearshift jolts.
Scheme 84
Scheme 85
- Connect vehicle diagnostic, testing and information system VAS 5051 or VAG1551 scan tool and select engine electronics control module by entering address word "01". See «VEHICLE DIAGNOSTIC, TESTING AND INFORMATION SYSTEM VAS5051 OR VAG1551, CONNECTING AND SELECTING FUNCTIONS»(ref-216437-S40962647232006020800000) . When doing this the ignition must be switched ON. Indicated on display
- Press buttons -0- and -7- to select function "Code Control Module" and confirm entry with -Q- button. Indicated on display
- Input appropriate code number for this vehicle and confirm with -Q- button.
Determine the code number according to the following example
| USA; LEV (emission standard) | 07 | |||
|---|---|---|---|---|
| All-wheel drive with ESP | 7 | |||
| Automatic transmission | 5 | |||
| Audi A8 | 3 | |||
| Code number | 07 | 7 | 5 | 3 |
ECM CODE NUMBER EXAMPLE: ENGINE CODES AUX, AKB
The display of VAG1551 will show the control module coding (example).
Scheme 86
Scheme 87
- Press --> button. Indicated on display
- Press buttons -0- and -6- to select function "End Output" and confirm entry with -Q- button.
- Switch ignition off and then on again. NOTE: The next time the ignition is switched ON the newly entered coding will be activated.
