Application of crankshaft bearing shells for cylinder block
Bearing shells with the correct thickness are allocated to the cylinder block in the factory. Colored dots on the bearing shells serve for identifying bearing shell thickness.
Note. The arrow points to the belt pulley side.
Application of bearing shells to cylinder block is marked by a letter beside the respective bearing.
Scheme 352
| Letter at Cylinder block | Color of bearing |
|---|---|
| G = | Yellow |
| B = | Blue |
| S = | Black |
COLOR CODE: CRANKSHAFT BEARING SHELLS FOR CYLINDER BLOCK
Application of crankshaft bearing shells for bearing caps
Bearing shells with the correct thickness are allocated to the bearing caps in the factory. Colored dots on the bearing shells serve for identifying bearing shell thickness.
Allocation of bearing shells to crankshaft is marked with a letter sequence at the crankshaft flank. The first digit, "1" (arrow) identifies the color coding for bearing 1.
Scheme 353
| Letter to crankshaft | Color of bearing |
|---|---|
| G = | Yellow |
| B = | Blue |
| S = | Black |
COLOR CODE: CRANKSHAFT BEARING SHELLS FOR BEARING CAPS
