Engine specifications
| Code letters | AVK |
|---|---|
| Displacement (Liters) | 2.976 |
| Output (kw @ RPM) | 162/6300 |
| Torque (Nm at RPM) | 300/3200 |
| Bore (Diameter in mm) | 82.5 |
| Stroke (mm) | 92.8 |
| Compression ratio | 10.3 |
| RON | 98 (1) |
| Injection/ignition system | Bosch Motronic |
| Knock sensor control | Yes |
| Turbocharger | No |
| Exhaust Gas Recirculation (EGR) | No |
| Intake manifold change-over | Yes |
| Camshaft adjustment | Yes |
| Secondary Air Injection | Yes |
| (1) Also Super-unleaded RON 95 is permissible, however with reduced performance. | |
| (1) | Also Super-unleaded RON 95 is permissible, however with reduced performance. |
ENGINE SPECIFICATIONS (1 OF 2)
| Code letters | AVK |
|---|---|
| Valve timing | |
| At 1 mm valve lift and 0 mm valve lash | |
| Intake valve opens after TDC | 20° |
| Intake valve closes after BDC | 50° |
| Exhaust valve opens before BDC | 47° |
| Exhaust valve closes before TDC | 17° |
ENGINE SPECIFICATIONS (2 OF 2)
Scheme 313
- 10-222A Engine support bridge
- 2024A Engine Sling
- 3147 engine support adapter
- 3299 ribbed belt installation tool with 3299/1 claw for tensioner
- VAG1306 drip tray for VAG1202A
- VAG1383A engine/transmission jack
- VAG1202A workshop crane or
- VAS 6100
- T10062 support
- Oil receptacle
Tightening torques
Note. Tightening torques are valid only for nuts and bolts that are lightly greased, oiled, covered with a thin coat of phosphate or blackened. Additional lubricants are permitted, e.g. engine oil or transmission fluid, however no graphite containing lubricants. Do not use any degreased parts. Tightening torque tolerance +/- 15%.
Securing engine/transmission for manual transmission
| Item no. | Bolt | Nm |
|---|---|---|
| 1, 9, 10, 11 | M10 x 60 | 45 |
| 2 | M10 x 150 | 45 |
| 3 | M12 x 130 | 65 |
| 4 | M12 x 80 | 65 |
| 5, 6, 8 | M12 x 90 | 65 |
| 7 | M10 x 100 | 45 |
TORQUE SPECIFICATIONS: ENGINE/MANUAL TRANSMISSION BOLTS
In see scheme 83, A is alignment bushing.
Scheme 314
Securing engine/transmission with automatic transmission 01J
| Item no. | Bolt | Nm |
|---|---|---|
| 1, 10, 11 | M10 x 60 | 45 |
| 2 | M12 x 90 | 65 |
| 3 | M12 x 110 | 65 |
| 4 | M12 x 80 | 65 |
| 5, 6 | M12 x 90 | 65 |
| 7 | M10 x 100 | 45 |
| 8 | M12 x 75 | 65 |
| 9 | M10 x 70 | 45 |
TORQUE SPECIFICATIONS: ENGINE/TRANSMISSION BOLTS (AUTOMATIC TRANSMISSION 01J)
In see scheme 84, A is alignment bushing.
Scheme 315
Securing engine/transmission with automatic transmission 01V
| Item no. | Bolt | Nm |
|---|---|---|
| 1, 9, 10, 11 | M10 x 60 | 45 |
| 2 | M10 x 90 | 45 |
| 3 | M12 x 110 | 65 |
| 4 | M12 x 80 | 65 |
| 5, 6, 8 | M12 x 90 | 65 |
| 7 | M10 x 100 | 45 |
TORQUE SPECIFICATIONS: ENGINE/TRANSMISSION BOLTS (AUTOMATIC TRANSMISSION 01V)
In see scheme 85, A is alignment bushing.
Scheme 316
Scheme 317
Scheme 318
Tightening torque
| Component | Nm |
|---|---|
| Harmonic balancer to crankshaft | 23 |
TIGHTENING TORQUE: HARMONIC BALANCER
Scheme 319
| Component | Nm |
|---|---|
| Toothed belt gear to crankshaft | 200 + 180° (1) , (2) |
| (1) Replace bolt (2) 180° corresponds to 1/2 turn | |
| (1) | Replace bolt |
| (2) | 180° corresponds to 1/2 turn |
TIGHTENING TORQUE: TOOTHED BELT GEAR
| Component | Nm |
|---|---|
| Rear sealing flange to cylinder block | 10 |
TIGHTENING TORQUE: REAR SEALING FLANGE
| Component | Nm |
|---|---|
| Cylinder head cover to cylinder head | 10 |
| Front toothed belt guard to cylinder head cover | 6 (1) |
| (1) Replace bolts. | |
| (1) | Replace bolts. |
TIGHTENING TORQUES: CYLINDER HEAD COVER
| Component | Nm |
|---|---|
| Cylinder head cover to cylinder head | 10 |
| Front toothed belt guard to cylinder head cover | 6 (1) |
| Guide tube for oil dipstick to secondary air line | 10 |
| (1) Replace bolts | |
| (1) |
TIGHTENING TORQUES: RIGHT CYLINDER HEAD COVER
| Component | Nm |
|---|---|
| Spark plugs into cylinder head | 30 |
TIGHTENING TORQUE: SPARK PLUGS
Viscosity classes and oil specifications
See ENGINE OIL, FILLING
