4.2L V8 5V (Engine Codes: Art, Awn, Bbd): Specifications Audi A6 C5 facelift

Mechanical 2 illustrations ~117 words

Tightening torques

  1. Engine/transmission attaching points (transmission flange shown) Centering sleeves (A and B)
ComponentNm/ ft lb
Dipstick guide tube to cylinder head10/7
Toothed belt guard to cylinder head10/7
Front coolant pipe to cylinder head10/7
Cylinder head cover to cylinder head10/7
Intake manifold to cylinder head10/7
Ignition coil to cylinder head10/7
Combination valve to cylinder head8/71 in. lb
Locating stud for intake manifold7/62 in. lb
Locating bolt for intake manifold gasket0.6/5 in. lb
Exhaust pipe with catalytic converter to exhaust retainer25/18
Exhaust pipe with catalytic converter to exhaust manifold25/18
Double clamp for exhaust pipe40/29

TIGHTENING TORQUES: CYLINDER HEADS

ComponentNm/ft lb
Camshaft Position (CMP) sensor housing10/7
Camshaft Position (CMP) sensor ring23/17

TIGHTENING TORQUES: CMP SENSOR HOUSING

ComponentNm/ft lb
Bearing cap to cylinder head5/4 + 90°
Camshaft adjuster to cylinder head5/4 + 90°
Camshaft Position (CMP) sensor rotor to camshaft23/17
Camshaft Position (CMP) sensor housing to cylinder head10/7

TIGHTENING TORQUES: CAMSHAFTS AND CAMSHAFT ADJUSTERS

ComponentNm/ft lb
Lower oil pan9/80 in. lb
Oil drain plug50/37

TIGHTENING TORQUES: LOWER OIL PAN

Scheme 428

Scheme 428: Removing
Scheme 428: Removing

Scheme 429

Scheme 429
Scheme 429
  1. Remove noise insulation.
  2. Remove dipstick.
  3. Drain engine oil.
  4. Disconnect connector -1- from oil level sensor.
  5. Remove oil pan lower part -arrow-.
  6. Remove oil grid -arrows-.
  7. Loosen bolt for oil pump pulley.
  8. Secure chain tensioner with spring pin -arrow-.
  9. Remove oil pump pulley.
  10. Remove oil pump and take out downward.
ComponentNm/ ft lb
Chain sprocket for oil pump34/25
Grid section9/80 in. lb
Oil pump30/22
Oil pan9/80 in. lb
Oil drain plug50/37

TIGHTENING TORQUES: OIL PUMP

  1. Install lower oil pan. See «INSTALLING»(ref-196260-S05166457532005100700000) .

Oil capacity (with new oil filter)

See ENGINE OIL, FILLING .

CAUTIONDO NOT overfill with oil past the MAX mark on the oil dipstick. Damage to the Three Way Catalytic Converter (TWC) could result.
