Interior Equipment - Except Cabriolet Audi A4 B6

Glove compartment, assembly overview

The following list pertains to (Scheme 2).

1. Glove compartment Removing, see «GLOVE COMPARTMENT, REMOVING AND INSTALLING»(/audi/a4/b6-2000-2006/remont/mirrors/#interior-equipment-except-cabriolet__glove-compartment-removing-and-installing)
2. Side cover Pulling off, see «PULLING OFF RIGHT COVER ON INSTRUMENT PANEL»(/audi/a4/b6-2000-2006/remont/mirrors/#interior-equipment-except-cabriolet__pulling-off-right-cover-on-instrument)
3. Bolts (3x) Tightening torque 5 Nm
4. Bolts (2x) Tightening torque 5 Nm
5. Bolts (2x) Tightening torque 5 Nm
6. Electrical harness connector
7. Instrument panel

Glove compartment, removing and installing

The following list pertains to (Scheme 3).

Scheme 2

1. Glove compartment Removing Remove side cover -2-, see «PULLING OFF RIGHT COVER ON INSTRUMENT PANEL»(/audi/a4/b6-2000-2006/remont/mirrors/#interior-equipment-except-cabriolet__pulling-off-right-cover-on-instrument) . Open glove compartment cover. Remove three bolts -3- at top in depressions of glove compartment -1-. Remove outside bolts -5- (2x) out from the side. Remove bolts -4- (2x) from the footwell out from below. Remove glove compartment downward. Remove connector -6- of glove compartment illumination. Disconnect harness connectors to electrical components in glove compartment (if applicable).

Pulling Off Right Cover On Instrument Panel

1. Pull off right cover on instrument panel -arrow- using special tool 3370.

Glove compartment lock, removing and installing

1. Removing

1. Open glove compartment cover.
2. Remove bolt -3- of handle -2- on the cover side.
3. Pull handle -3- off from glove compartment cover.
4. Push pin -4- through and remove the lock -1-.

Glove compartment cover, removing and installing

1. Removing

1. Remove glove compartment, see «STORAGE COMPARTMENTS AND COVERS»(/audi/a4/b6-2000-2006/remont/mirrors/#interior-equipment-except-cabriolet) .
2. Press pin -1- out in direction of arrow at connection between brake for glove compartment cover -2- and glove compartment cover -3-.
3. Open glove compartment cover.

There is a hole on each side near the bracket on the right and left inside the glove compartment.

Scheme 3

1. Knock the pins -2- on left and right out of the glove compartment -1- using a drift (4 mm).
2. Remove glove compartment cover.

Scheme 4

Scheme 5

1. Removing Remove glove compartment, see «STORAGE COMPARTMENTS AND COVERS»(/audi/a4/b6-2000-2006/remont/mirrors/#interior-equipment-except-cabriolet) . Press pin -1- out in direction of arrow at connection between brake for glove compartment cover -2- and glove compartment cover -3-. Remove green connector. Rotate brake for glove compartment cover -1- approx. 90° in cut-out -2- and remove brake for glove compartment cover.

Glove compartment, removing and installing (vehicles with knee bolster)

The following list pertains to (Scheme 10).

1. Glove compartment Removing Remove side cover -3-, see «PULLING OFF RIGHT COVER ON INSTRUMENT PANEL»(/audi/a4/b6-2000-2006/remont/mirrors/#interior-equipment-except-cabriolet__pulling-off-right-cover-on-instrument) . Open glove compartment cover. Remove bolts -4-. Remove glove compartment downward. Disconnect harness connectors to electrical components in glove compartment (if applicable).
2. Instrument panel
3. Side cover Pulling off, see «PULLING OFF RIGHT COVER ON INSTRUMENT PANEL»(/audi/a4/b6-2000-2006/remont/mirrors/#interior-equipment-except-cabriolet)
4. Bolts (9x) Tightening torque 5 Nm

1. Pull off right cover on instrument panel -arrow- using special tool 3370.

Handle for glove compartment lock, removing and installing (vehicles with knee bolster)

1. Removing

1. Open glove compartment cover.
2. Remove bolt -1- of handle -3- on left side of glove compartment.
3. Pull handle -2- off from glove compartment cover.

Brake for glove compartment cover, removing and installing (vehicles with knee bolster)

Special Tools and Equipment

1. Special hook for front end 3370
2. Removing

1. Open glove compartment.
2. Pull off right cover on instrument panel -arrow- using special tool 3370.
3. Disconnect electrical harness connector -2-.
4. Remove joint pin -1-.
5. Disengage the brake for glove compartment cover -3- in a clockwise direction and remove it. NOTE: Depicted in illustration with glove compartment removed.

Driver-side storage compartment (with and without knee bolster), assembly overview

The following list pertains to see scheme 15.

1. Side cover
2. Bolt Tightening torque: 9 Nm.
3. Bolt Tightening torque: 9 Nm.
4. Left support Only for vehicles with knee bolster
5. Bolts (2x) Tightening torque: 9 Nm.
6. Bolt Tightening torque: 9 Nm.
7. Right support Only for vehicles with knee bolster
8. Bolts (2x) Tightening torque: 9 Nm.
9. Driver-side storage compartment Removing Remove side cover -2-, see «PULLING OFF RIGHT COVER ON INSTRUMENT PANEL»(/audi/a4/b6-2000-2006/remont/mirrors/#interior-equipment-except-cabriolet) . Remove bolts -2- and -8-. Push upper storage compartment on instrument panel to the rear and remove. Unclip diagnostic connector. Remove electrical harness connector at footwell illumination and, if necessary, remove additional loudspeaker. Installing First engage driver-side storage compartment on bottom edge into the guides, then clip it to instrument panel above.

1. Pull off right cover on instrument panel -arrow- using special tool 3370.
2. Disconnect electrical harness connector -2-.
3. Remove bolt -1- and remove angle bracket -3- and additional speaker -4-.

Instrument cluster, removing

1. Remove instrument cluster cover -1- toward rear.

Center armrest, assembly overview

The following list pertains to see scheme 19.

1. Armrest Removing Remove rear ash tray, see «REAR ASHTRAY, ASSEMBLY OVERVIEW»(/audi/a4/b6-2000-2006/remont/mirrors/#interior-equipment-except-cabriolet__rear-ashtray-assembly-overview) . Remove nut -4- in ash tray compartment. For a center armrest with telephone, disconnect harness connector -2- by pressing the catch -3-. Remove center armrest -1-.
2. Connector
3. Locking lugs
4. Nut Tightening torque 26 Nm

Support foot for center armrest, removing and installing

1. Removing

1. Remove center armrest, see «CENTER ARMREST, ASSEMBLY OVERVIEW»(/audi/a4/b6-2000-2006/remont/mirrors/#interior-equipment-except-cabriolet__center-armrest-assembly-overview)
2. Remove center console, see «CENTER CONSOLE, ASSEMBLY OVERVIEW»(/audi/a4/b6-2000-2006/remont/mirrors/#interior-equipment-except-cabriolet__center-console-assembly-overview) .
3. Remove nuts -2- (2x).
4. Tightening torque: 10 Nm.
5. Remove support foot -1-.

Center console, assembly overview

The following list pertains to see scheme 21.

1. Center console Removing Remove center armrest, see «CENTER ARMREST, ASSEMBLY OVERVIEW»(/audi/a4/b6-2000-2006/remont/mirrors/#interior-equipment-except-cabriolet__center-armrest-assembly-overview) . Remove cover for instrument cluster in front center portion, see «SHIFT COVER AND SHIFTER BOOT, ASSEMBLY OVERVIEW»(/audi/a4/b6-2000-2006/remont/mirrors/#interior-equipment-except-cabriolet__shift-cover-and-shifter-boot-assembly) . Remove radio. See «AUDIO SYSTEM - EXCEPT CABRIOLET»(/audi/a4/b6-2000-2006/remont/entertainment-systems/#radio-system-except-cabriolet) . Unclip button trim -2- above beverage holder of front center console. Pull up hand brake firmly. For automatic transmission, push selector lever all the way to the rear. At the front inside footwell, remove the covers -3- from bolts -4- on right and left sides at the center console side. Remove bolts -4- at the front in footwell on right and left sides of center console. Remove hand brake handle trim See «PARKING BRAKE HANDLE»(/audi/a4/b6-2000-2006/remont/mechanical-hydraulic/#disc-brakes) . Pry out cover -5- from front. Remove two Phillips head screws -7- on connecting piece -6- and remove connecting piece. Do not allow the trim to be pulled away above the hand brake handle as well. For manual transmission: Loosen the securing frame of shifter boot and remove shifter boot, see «SHIFT COVER AND SHIFTER BOOT, ASSEMBLY OVERVIEW»(/audi/a4/b6-2000-2006/remont/mirrors/#interior-equipment-except-cabriolet__shift-cover-and-shifter-boot-assembly) . With automatic transmission: Lever out shift cover upward, see «SHIFT COVER AND SHIFTER BOOT, ASSEMBLY OVERVIEW»(/audi/a4/b6-2000-2006/remont/mirrors/#interior-equipment-except-cabriolet__shift-cover-and-shifter-boot-assembly) . Remove front ash tray, see «FRONT ASHTRAY, ASSEMBLY OVERVIEW»(/audi/a4/b6-2000-2006/remont/mirrors/#interior-equipment-except-cabriolet__front-ashtray-assembly-overview) . Remove the two bolts -8- in ash tray opening. Remove the four bolts -9- around selector mechanism which secure the center console. Disconnect harness connector for cigarette lighter and navigation module. See «NAVIGATION CONTROL HEAD FROM CENTER CONSOLE, ASSEMBLY OVERVIEW»(/audi/a4/b6-2000-2006/remont/mirrors/#interior-equipment-except-cabriolet__navigation-control-head-from-center-console) and «CIGARETTE LIGHTER FROM CENTER CONSOLE, ASSEMBLY OVERVIEW»(/audi/a4/b6-2000-2006/remont/mirrors/#interior-equipment-except-cabriolet__cigarette-lighter-from-center-console-assembly) . Remove two bolts -10- For vehicles with center armrest: Remove hex-combination nut -11-. Remove two hex-combination nuts -12-. Pull center console forcefully backward and remove it from the vehicle. NOTE: Center console may be removed from the diecast part on the instrument panel only with difficulty.
2. Button trim
3. Bolts (2x) Tightening torque 5 Nm
4. Bolt cover (2x)
5. Hand brake cover
6. Connecting piece
7. Bolts (2x) Tightening torque 2 Nm
8. Bolts (2x) Tightening torque 5 Nm
9. Bolts (4x) Tightening torque 5 Nm
10. Bolts (2x) Tightening torque 5 Nm
11. Hex-combination nut (1x) Tightening torque 26 Nm
12. Hex-combination nut (2x) Tightening torque 26 Nm

Cassette storage compartment, assembly overview

The following list pertains to see scheme 22.

1. Cassette storage compartment Removing Remove center console. See «CENTER CONSOLE, ASSEMBLY OVERVIEW»(/audi/a4/b6-2000-2006/remont/mirrors/#interior-equipment-except-cabriolet__center-console-assembly-overview) . Turn the center console around. Pry up tabs -3-. Press on the two spring clips -4- on cassette storage compartment (Risk of injury by sharply-pointed spring clips. Work with caution). Remove cassette storage compartment -1- from recess -2-.
2. Recess for cassette storage compartment in center console
3. Cassette storage compartment tab
4. Spring clips

Shift cover and shifter boot, assembly overview

The following list pertains to see scheme 23.

1. Cover with automatic transmission Removing Pry off shift cover -1-.
2. Cover with manual transmission Removing Pry off shift cover -2-.
3. Shifter boot Removing Unclip securing frame -6-. Turn connecting part -5- to the right, until it disengages. Remove shift knob -4-.
4. Shift knob
5. Connecting part
6. Securing frame

Navigation control head from center console, assembly overview

The following list pertains to see scheme 24.

1. Navigation control head Removing Remove center console. See «CENTER CONSOLE, ASSEMBLY OVERVIEW»(/audi/a4/b6-2000-2006/remont/mirrors/#interior-equipment-except-cabriolet__center-console-assembly-overview) . Turn the center console -4- around. Remove two bolts -3- on navigation control head -1-. Disconnect harness connector -2-. Remove navigation control head -1- from recess -5-.
2. Connector
3. Bolts (2x) Tightening torque 2 Nm
4. Center console
5. Recess

Cigarette lighter from center console, assembly overview

The following list pertains to see scheme 25.

1. Cigarette lighter Removing Remove center console. See «CENTER CONSOLE, ASSEMBLY OVERVIEW»(/audi/a4/b6-2000-2006/remont/mirrors/#interior-equipment-except-cabriolet__center-console-assembly-overview) . Turn the center console -4- around. Remove two bolts -3- on cigarette lighter -1- Disconnect harness connector -2-. Remove cigarette lighter -1- from recess -5-.
2. Connector
3. Bolts (2x) Tightening torque 2 Nm
4. Center console
5. Recess

Footwell trim, removing and installing

1. Removing

1. Insert screwdriver beneath release ring on expanding rivet -2-. Lower part of expanding rivet closes.
2. Lever expanding rivet -2- from footwell trim -1-.
3. Remove footwell trim from its mount -3-.

Trim on parking brake lever, assembly overview

The following list pertains to see scheme 27.

1. Hand brake trim Removing Release parking brake. Disengage trim on parking brake lever -1- and remove it. Pull up hand brake firmly. Remove two bolts -3- on carrier -2- and remove carrier. Installing Pull up hand brake firmly. Place carrier on parking brake lever. Next tighten bolts -3- by hand. Release parking brake fully. Tighten both bolts -3-. Engage trim on parking brake -1- at rear in its mounts -4-. Press trim on parking brake -1- firmly.
2. Carrier
3. Bolts (2x) Tightening torque 4 Nm.
4. Trim mounts

Parking brake lever handle, removing

1. Lever out securing pin -2- in direction of arrow -A-.
2. Remove parking brake lever handle -1- in direction of arrow -B-.

Cellular phone holder in center console, assembly overview

The following list pertains to see scheme 29.

1. Threaded hole piece Clipped into center console from rear
2. Center console with holes for base plate Drilling holes afterward, see «HOLES FOR CELLULAR PHONE HOLDER ON CENTER CONSOLE, DRILLING»(/audi/a4/b6-2000-2006/remont/mirrors/#interior-equipment-except-cabriolet__holes-for-cellular-phone-holder-on)
3. Mounting plate
4. Ground plate for cellular phone handset
5. Bolts (6x) Tightening torque: 0.5 Nm
6. Bolts (2x) Tightening torque: 1.5 Nm
7. Harness connector

Note. Make sure harness connector is seated correctly.

Scheme 6

Holes for cellular phone holder on center console, drilling

As a replacement part, the center console is supplied without holes for the cellular phone holder. The holes must be drilled afterward.

1. Remove center console. See «CENTER CONSOLE, ASSEMBLY OVERVIEW»(/audi/a4/b6-2000-2006/remont/mirrors/#interior-equipment-except-cabriolet__center-console-assembly-overview) .
2. Drill the holes to the following specifications: 10 mm 6 mm 20 mm 100 mm 31 mm 8 mm 5 mm 9 mm
3. Clip the threaded hole piece -Item 1 - (see «CELLULAR PHONE HOLDER IN CENTER CONSOLE, ASSEMBLY OVERVIEW»(/audi/a4/b6-2000-2006/remont/mirrors/#interior-equipment-except-cabriolet__cellular-phone-holder-in-center-console) ) from behind into center console and tighten the cellular phone holder to 1.5 Nm.

Note. After installation, check whether the glove compartment will open

Scheme 7

Holder for telephone handset on center console, assembly overview

The following list pertains to see scheme 31.

1. Threaded hole piece Clipped into center console from rear
2. Center console with holes for base plate Drilling holes afterward, see «HOLES FOR TELEPHONE HANDSET HOLDER ON CENTER CONSOLE, DRILLING»(/audi/a4/b6-2000-2006/remont/mirrors/#interior-equipment-except-cabriolet__holes-for-telephone-handset-holder-on)
3. Mounting plate for handset mount
4. Bolts (4x) Tightening torque: 0.5 Nm
5. Handset mount
6. Telephone Handset -R37
7. Ground plate
8. Bolt Tightening torque: 1.5 Nm
9. Harness connector NOTE: Make sure harness connector is seated correctly.
10. Bolt Tightening torque: 1.5 Nm

Holes for telephone handset holder on center console, drilling

As a replacement part, the center console is supplied without holes for the telephone handset holder. The holes must be drilled afterward.

1. Remove center console. See «CENTER CONSOLE, ASSEMBLY OVERVIEW»(/audi/a4/b6-2000-2006/remont/mirrors/#interior-equipment-except-cabriolet__center-console-assembly-overview) .
2. Drill the holes to the following specifications: 10 mm 6 mm 22 mm 101 mm 25 mm 16 mm 5 mm 8 mm
3. Clip the threaded hole piece -Item 1 - (see «HOLDER FOR TELEPHONE HANDSET ON CENTER CONSOLE, ASSEMBLY OVERVIEW»(/audi/a4/b6-2000-2006/remont/mirrors/#interior-equipment-except-cabriolet__holder-for-telephone-handset-on-center) ) from behind into center console and tighten the telephone handset holder to 1.5 Nm.

Note. After installation, check whether the glove compartment will open

Scheme 8

Center part of instrument panel, assembly overview

The following list pertains to see scheme 33.

1. Center part of instrument panel Removing Remove center console. See «CENTER CONSOLE, ASSEMBLY OVERVIEW»(/audi/a4/b6-2000-2006/remont/mirrors/#interior-equipment-except-cabriolet__center-console-assembly-overview) . Remove front ash tray. See «FRONT ASHTRAY, ASSEMBLY OVERVIEW»(/audi/a4/b6-2000-2006/remont/mirrors/#interior-equipment-except-cabriolet__front-ashtray-assembly-overview) . Remove radio and radio trim. See «AUDIO SYSTEM - EXCEPT CABRIOLET»(/audi/a4/b6-2000-2006/remont/entertainment-systems/#radio-system-except-cabriolet) . Remove A/C control head and heater controls. See «A/C CONTROL HEAD -E87-, REMOVING AND INSTALLING»(/audi/a4/b6-2000-2006/remont/automatic-hvac-system/#air-conditioning__ac-control-head-e87-removing-and) . Remove button trim. See «SWITCH STRIP COVER AND TRIM, ASSEMBLY OVERVIEW»(/audi/a4/b6-2000-2006/remont/mirrors/#interior-equipment-except-cabriolet__switch-strip-cover-and-trim-assembly) . Remove bolts -2- on center part of instrument panel. Remove bolts -3- on center part of instrument panel. Remove center part of instrument panel.
2. Bolts (2x) Tightening torque 5 Nm
3. Bolts (2x) Tightening torque 5 Nm

Special Tools and Equipment

1. Special hook for front end 3370
2. T10057 radio removal tool

Removing

1. Open glove compartment.
2. Carefully remove trim -1- toward rear using special hook 3370.
3. Insert radio removal tool T10057 at the catches -2- (2x) and remove beverage holder / storage compartment -1-.
4. Disconnect harness connectors for storage compartment and beverage holder.

Switch strip cover and trim, assembly overview

The following list pertains to see scheme 38.

1. Cover Removing Open radio flap -3-. Open front ash tray. Carefully unclip cover -1- beginning from the bottom at mounting clips -5- (6x).
2. Switch strip trim Removing Carefully unclip switch strip trim -2- beginning from the bottom at mounting clips -4- (4x).
3. Radio flap
4. Mounting clip
5. Mounting clip

Front ashtray, assembly overview

The following list pertains to see scheme 39.

1. Front ashtray Removing For manual transmission: Lever out shift cover upward and remove shifter boot. See «SHIFT COVER AND SHIFTER BOOT, ASSEMBLY OVERVIEW»(/audi/a4/b6-2000-2006/remont/mirrors/#interior-equipment-except-cabriolet__shift-cover-and-shifter-boot-assembly) . With automatic transmission: Lever out shift cover upward. See «SHIFT COVER AND SHIFTER BOOT, ASSEMBLY OVERVIEW»(/audi/a4/b6-2000-2006/remont/mirrors/#interior-equipment-except-cabriolet__shift-cover-and-shifter-boot-assembly) . Remove two bolts -2- at ashtray. Remove ashtray -1-. Disengage trim -3- from ashtray -1-. Unclip storage compartment trim -4-.
2. Bolts (2x) Tightening torque 5 Nm
3. Ashtray trim
4. Storage compartment trim

Rear ashtray, assembly overview

The following list pertains to see scheme 40.

Scheme 9

1. Rear ashtray Removing Unclip cover -2-. Disengage rear ashtray -1-. Unclip seat heater switch mount -3- if installed.
2. Cover
3. Switch mount Removing and installing, see «REMOVING/INSTALLING SWITCH MOUNT»(/audi/a4/b6-2000-2006/remont/mirrors/#interior-equipment-except-cabriolet__removinginstalling-switch-mount)

Removing/Installing Switch Mount

1. Remove rear ashtray.
2. Press catches -arrow A- on left and right to the outside and swing switch mount to the rear -arrow B-.
3. Disengage switch mount below at rear of center console.
4. Disconnect electrical harness connectors.
5. Unclip switches -1- and -2-.

Interior rear view mirror, removing and installing

1. Removing When removing, turn rear view mirror -1- around 60 to 90 ° -arrow B-, until locking spring disengages and remove mirror -arrow A-.
2. Installing When installing, position mirror -1- at 60 to 90 ° offset to installation position -arrow A- and turn -arrow B- until retaining spring engages.

Scheme 10

Scheme 11

1. Removing Unclip cable channel cover -3-. Remove connector from retainer and disconnect. NOTE: Do not use cable channel -2- to turn mirror. When removing, rotate mirror -1- about 60 to 90 ° -arrow B- until retaining spring releases and remove mirror -arrow A-.
2. Installing NOTE: Do not use cable channel -2- to turn mirror. When installing, position mirror -1- at 60 to 90 ° offset to installation position -arrow A- and turn -arrow B- until retaining spring engages.

Scheme 12

Scheme 13

1. Removing Unclip cable channel cover -2-. Remove connector from retainer and disconnect. Pull rear view mirror -1- down at an angle -arrow- to release from retaining plate (retaining springs in base of mirror).
2. Installing NOTE: Do not use cable channel -2- to turn mirror. When installing, position mirror -1- at 60 to 90 ° offset to installation position -arrow A- and turn -arrow B- until retaining spring engages.

Automatic day/night interior rear view mirror, testing function

Test requirements

1. Rear view mirror installed.
2. Ignition switched on.
3. Reverse gear not selected.

Test sequence

1. Cover photo sensor on front of mirror (or tape).
2. Use a light source (flashlight) to direct light onto the photo sensor on rear of mirror. The interior rear view mirror must darken within a few seconds.

Interior rear view mirror with compass (only USA), calibrating

Setting of North is integrated in interior rear view mirror via a world-zone dependent magnetic field.

The compass directions N, NE, E, SE, S, SW, W and NW are shown in the digital display. see scheme 48

A new rear view mirror, or a rear view mirror which has had no current for a long period of time, must be initially calibrated prior to use (nothing or a "C" appears in display).

Calibration of a new compass

1. Switch ignition on.
2. "C" must appear in display.
3. If there is no "C", press adjustment switch on underside of mirror using a thin object (e.g. pencil) until "C" appears in display.
4. Drive slowly at approx. 10 km/h around in a circle 2 to 3 times until a compass direction is displayed.
5. Press adjustment switch on underside of mirror using a thin object (e.g. pencil) until the number of your zone appears in display.
6. Refer to the adjacent card for your zone.
7. A compass direction appears in the display after a few seconds.

Calibration of an already existing compass

1. Switch ignition on.
2. "C" must appear in display.
3. If there is no "C", press adjustment switch on underside of mirror using a thin object (e.g. pencil) until "C" appears in display.
4. Drive slowly at approx. 10 km/h around in a circle 2 to 3 times until a compass direction is displayed.

Zone adjustment

1. Switch ignition on.
2. Press adjustment switch on underside of mirror using a thin object (e.g. pencil) until the number of your zone appears in display.
3. Refer to the adjacent card for your zone.
4. A compass direction appears in the display after a few seconds.

Retaining plate for interior rear view mirror, adhering

Repair method using glass/metal glue

Special Tools and Equipment

1. Glass/metal glue set D 000 703 A1

1. Glass scraper (commercially available)
2. Standard blade

Scheme 14

1. Interior rear view mirror dimension -a- = 153 mm (upper edge of front sheet to center adhering plate on mirror support).

Procedure

1. Pull mirror plate out of mirror base.
2. Using a wire brush, remove any remaining adhesive from mirror plate.
3. Sand the three spacer knobs on the adhesive surface. Use sandpaper (360/400 grit) on level surface.
4. Maintain sanded surface free of dirt and grease.
5. Using glass scraper, scrape adhesive and primer down to ceramic layer on windshield.

1. Clean adhesive surface with adhesive remover D 002 000 10 or cleaning solution D 009 401 04.
2. Cut nylon mesh to exact dimensions of mirror base.

Note. Wear rubber gloves.

1. Spread thick layer of adhesive evenly on mirror base.
2. Lay nylon mesh on mirror base.
3. While applying more adhesive, use tube to tap lightly on nylon mesh. 30 seconds are available between applying adhesive to nylon mesh and pressing onto windshield.
4. Press mirror base (without force) onto windshield and hold for 15 seconds.
5. Use a towel to remove excess adhesive. NOTE: Install rear view mirror after 15 minutes.

See also:
• AUDIO SYSTEM - EXCEPT CABRIOLET
• PARKING BRAKE HANDLE
• A/C CONTROL HEAD -E87-, REMOVING AND INSTALLING
• GLOVE COMPARTMENT, REMOVING AND INSTALLING
• PULLING OFF RIGHT COVER ON INSTRUMENT PANEL
• STORAGE COMPARTMENTS AND COVERS
• REAR ASHTRAY, ASSEMBLY OVERVIEW
• CENTER ARMREST, ASSEMBLY OVERVIEW
• CENTER CONSOLE, ASSEMBLY OVERVIEW
• SHIFT COVER AND SHIFTER BOOT, ASSEMBLY OVERVIEW
• FRONT ASHTRAY, ASSEMBLY OVERVIEW
• NAVIGATION CONTROL HEAD FROM CENTER CONSOLE, ASSEMBLY OVERVIEW
• CIGARETTE LIGHTER FROM CENTER CONSOLE, ASSEMBLY OVERVIEW
• HOLES FOR CELLULAR PHONE HOLDER ON CENTER CONSOLE, DRILLING
• CELLULAR PHONE HOLDER IN CENTER CONSOLE, ASSEMBLY OVERVIEW
• HOLES FOR TELEPHONE HANDSET HOLDER ON CENTER CONSOLE, DRILLING
• HOLDER FOR TELEPHONE HANDSET ON CENTER CONSOLE, ASSEMBLY OVERVIEW
• SWITCH STRIP COVER AND TRIM, ASSEMBLY OVERVIEW
• REMOVING/INSTALLING SWITCH MOUNT
