DTC P1298: ELD Circuit High Voltage Acura TL IV facelift

Testing & Diagnostics 3 illustrations ~516 words

Note. Before you troubleshoot, record all freeze data and any on-board snapshot, and review the general troubleshooting information (see GENERAL TROUBLESHOOTING INFORMATION ).

Scheme 202

Scheme 202: DTC P1298: ELD Circuit High Voltage
Scheme 202: DTC P1298: ELD Circuit High Voltage

Scheme 203

Scheme 203
Scheme 203

Scheme 204

Scheme 204
Scheme 204
  1. Start the engine, and let it idle.
  2. Check the ELD in the DATA LIST with the HDS. Is 0.2 A or less indicated? YES - Go to step 3. NO - Intermittent failure, the system is OK at this time. Check for poor connections or loose terminals at the ELD and the ECM/PCM.
  3. Turn the ignition switch to LOCK (0), or press the engine start/stop button to select the OFF mode.
  4. Disconnect the ELD 3P connector.
  5. Turn the ignition switch to ON (II), or press the engine start/stop button to select the ON mode.
  6. Measure the voltage between ELD 3P connector terminal No. 1 and body ground. Is there battery voltage? YES - Go to step 7. NO - Repair open in the wire between the No. 13 ACG (15 A) fuse in the driver's under-dash fuse/relay box and the ELD, then go to step 13 .
  7. Turn the ignition switch to LOCK (0), or press the engine start/stop button to select the OFF mode.
  8. Jump the SCS line with the HDS.
  9. Disconnect ECM/PCM connector A (49P).
  10. Check for continuity between ECM/PCM connector terminal A10 and ELD 3P connector terminal No. 3. Is there continuity? YES - Go to step 11. NO - Repair open in the wire between the ECM/PCM (A10) and the ELD, then go to step 13 .
  11. Check for continuity between ELD 3P connector terminal No. 2 and body ground. Is there continuity? YES - Go to step 12. NO - Repair open in the wire between the ELD and G301 (see «CONNECTOR TO FUSE/RELAY BOX INDEX»(ref-512380-S35566041542012103100000) ), then go to step 13 .
  12. Replace the ELD (see «ELD Replacement»(ref-512332-S02713439312012103100000) ).
  13. Turn the ignition switch to ON (II), or press the engine start/stop button to select the ON mode.
  14. Reset the ECM/PCM with the HDS.
  15. Do the ECM/PCM idle learn procedure (see «ECM/PCM IDLE LEARN PROCEDURE»(ref-512362-S04299387872012103100000) ).
  16. Check for Pending or Confirmed DTCs with the HDS. Is DTC P1298 indicated? YES - Check for poor connections or loose terminals at the ELD and the ECM/PCM, then go to step 17. NO - Troubleshooting is complete. If any other Pending or Confirmed DTCs are indicated, go to the indicated DTC's troubleshooting.
  17. Update the «ECM/PCM»(ref-512332-S15795428962012103100000) if it does not have the latest software (see «ECM/PCM Update»(ref-512332-S15795428962012103100000) ), or substitute a known-good ECM/PCM (see «SUBSTITUTING THE ECM/PCM»(ref-512356-S00793962012012103100000) ).
  18. Check for Pending or Confirmed DTCs with the HDS. Is DTC P1298 indicated? YES - Check for poor connections or loose terminals at the ELD and the ECM/PCM. If the ECM/PCM was updated, substitute a known-good ECM/PCM (see «SUBSTITUTING THE ECM/PCM»(ref-512356-S00793962012012103100000) ), then recheck. If the ECM/PCM was substituted, go to step 1 . NO - If the ECM/PCM was updated, troubleshooting is complete. If the ECM/PCM was substituted, replace the original «ECM/PCM»(ref-512332-S08907075282012103100000) (see «ECM/PCM Replacement»(ref-512332-S08907075282012103100000) ). If any other Pending or Confirmed DTCs are indicated, go to the indicated DTC's troubleshooting.
