Panel, B-post, replacing
Remove
- the front sill trim panel. See «The front sill trim panel»(ref-441129-S24632292392011121500000)
- the rear sill trim panel. See «The rear sill trim panel»(ref-441129-S26374206112011121500000)
- the end mounting from the front seat seatbelt. See «Seat belt buckle end mounting»(ref-406997-S31834981152011070100000) , (non-power seats only)
- the end mounting on the front seat seatbelt on power seats: Release the catches from underneath.
Move the seat as far forward as possible.
Detach the weatherstrip at the panel: Pull straight to the side.
Scheme 265
Pull at the lower section so that the panel comes inwards in the car.
Pull straight downwards, press the steel clips (both sides) and release the section that protrudes inwards at the top.
Pull downwards until the panel releases.
Lift upwards until the panel is free
Thread the seat belt through the panel.
