Climate control module (CCM), replacing (2001-2007) (version 2) Volvo V70 II рестайлинг

Body and Interior Systems - Removal, Replacement, Specifications 8 illustrations ~323 words

Climate control module (CCM), replacing (2001-2007) (version 2)

The illustrations in this service information are used for different model years and/or models. Some variation may occur. However, the essential information is always correct.

Scheme 49

Scheme 49: Preparations
Scheme 49: Preparations

Note. Read out the programmed data before replacing the climate control module. This is done in VIDA vehicle communication. After replacing the climate control module (CCM), the relevant parameters must be programmed.

Move the gear selector/gear selector lever to the rearmost position.

Ignition off.

Remove the key. The key must be removed to ensure that the ignition is not switched on by mistake.

WARNINGAfter the key has been removed, wait three minutes before starting work.

Scheme 50

Scheme 50: Removing the climate control module (CCM)
Scheme 50: Removing the climate control module (CCM)

Detach the panel at the gear selector lever as shown in the illustration.

Twist the panel so that it is as far from the center console as possible.

Scheme 51

Scheme 51
Scheme 51

Remove the lower screws from the bracket.

Angle out the entire infotainment control module (ICM) and the dashboard environment panel as shown in the illustration.

Scheme 52

Scheme 52
Scheme 52

Disconnect the connectors.

Turn the infotainment module with the dashboard environment panel.

Remove the four screws as shown in the illustration.

Scheme 53

Scheme 53
Scheme 53

Press the four clips and remove the infotainment control module by pulling it straight out as shown in the illustration.

Scheme 54

Scheme 54
Scheme 54

Slacken off the two screws at the lower edge of the dashboard environment panel.

Pull the dashboard environment panel straight out from the bracket.

Scheme 55

Scheme 55: Installing the climate control module (CCM)
Scheme 55: Installing the climate control module (CCM)

Install

  1. the dashboard environment panel using the two screws
  2. the infotainment panel so that it hooks into the dashboard environment panel.

Screw the infotainment panel into place using the four screws.

Connect the connectors.

Angle in the upper section of the infotainment control module first. Then screw the lower edge into place using the two lower screws.

Scheme 56

Scheme 56: Removing the front panel
Scheme 56: Removing the front panel

Release the catches. Pull off the front panel.

The front panel has double-sided adhesive tape. Ensure that any remains of the tape are removed from the black panel.
