HVAC - Design & Function: Removal & Installation Volvo V70 II рестайлинг

Removal

Remove

1. the soundproofing panel. See «Soundproofing panel, replacing»(ref-407132-S05296992152011070100000)

Scheme 568

Remove

1. the screws for the cover
2. the cover.

Pull the air cleaner (ACL) downwards / away.

Scheme 569

Install the air cleaner (ACL). There are 2 alternative positions for the air cleaner (ACL). See the illustration above.

The pollen filter (standard) must be installed in the smaller compartment (1).

The multi filter (cars with an air quality sensor) must be installed in the wider compartment (2).

Note. Install either the pollen filter or the multi filter. Both filters must not be together.

Install

1. the screws. The front left screw must not be tightened to more than 0.8 Nm
2. the soundproofing panel. See «Soundproofing panel, replacing»(ref-407132-S05296992152011070100000)
