Engine coolant heater, component location
The information below applies to cars manufactured up to week 38, 2001 inclusive.
Information for cars manufactured from week 39, 2001 inclusive. See Engine coolant heater, component location .
Scheme 4
Location in the car
The heater is located inside the front fender, in front of the front left wheel arch.
Scheme 5
Components
1. Control module.
2. Fan shroud.
3. Heat exchanger.
4. Fuel pump.
5. Water pump.
Scheme 6
Heater components
1. Coolant temperature sensor.
2. Flame sensor.
3. Overheat protection thermostat.
4. Glow plugs.
