Parking heaters 912-B and 912-D

The engine coolant heater is located inside the front fender, in front of the front left wheel arch.

Scheme 7

Scheme 7

Components

  1. Control module.
  2. Fan shroud.
  3. Heat exchanger.
  4. Fuel pump (FP) (in front of the fuel tank).
  5. Water pump.

Scheme 8

Scheme 8

Components on the engine coolant heater

  1. Coolant temperature sensor.
  2. Flame sensor.
  3. Overheat protection thermostat.
  4. Glow plugs.

Scheme 9

Scheme 9: Passenger compartment / Door mirror
  1. 1 Dashboard environment panel.
  2. 2 Outside temperature sensor.
  3. 3 Passenger compartment temperature sensor (ECC).
  4. 4 Sun sensor (ECC).
  5. 5 Climate control unit.
  6. 6 Air quality sensor.
  7. 7 Multifilter / filter.

Scheme 10

Scheme 10: Climate unit
  1. 1 Heat exchanger.
  2. 2 Evaporator.
  3. 3 Blower fan motor.
  4. 4 Power unit.
  5. 5 Air distribution damper motor.
  6. 6 Damper motor temperature right.
  7. 7 Damper motor temperature left.
  8. 8 Recirculation damper motor.
  9. 9 Defroster damper motor (ECC).
  10. 10 Coolant pipe connection; to and from the engine compartment.
  11. 11 Temperature sensor evaporator (left-hand drive cars).
  12. 11 Temperature sensor evaporator (right-hand drive cars).

Scheme 11

Scheme 11: Engine compartment
  1. 1 Compressor.
  2. 2 Compressor - Condenser hoses and pipes.
  3. 3 Condenser.
  4. 4 Hoses and pipes at the junction point of the side member - compressor.
  5. 5 Pipe at the expansion valve - junction point side member.
  6. 6 Expansion valve.
  7. 7 Pipe at the receiver - expansion valve.
  8. 8 Intermediate pipe at the receiver - member / expansion valve.
  9. 9 Receiver.
  10. 10 Service valve.
  11. 11 Service valve filling / emptying.
  12. 12 Pressure sensor.

Engine compartment

  1. Compressor.
  2. Compressor - condenser hoses and pipes.
  3. Condenser.
  4. Hoses and pipes at the junction point of the side member - compressor.
  5. Pipe at the expansion valve - junction point side member.
  6. Expansion valve.
  7. Pipe, receiver - expansion valve.
  8. Intermediate pipe between the receiver-member and the expansion valve.
  9. Accumulator.
  10. Service valve.
  11. Service valve filling / emptying.
  12. Pressure sensor.
