Climate Units - Component Location: Overview Volvo V70 II рестайлинг

Introduction, engine coolant heater components

The illustrations in this service information are used for different model years and / or models. Some variation may occur. However, the essential information in the illustrations is always correct.

Introduction, climate control components

The illustrations in this service information are used for different model years and/or models. Some variation may occur. However, the essential information in the illustrations is always correct.

Scheme 1

1. Climate control unit.
2. Outside temperature sensor.
3. Passenger compartment temperature sensor (ECC).
4. Sun sensor (ECC).
5. Climate control unit.
6. Air quality sensor.
7. Multifilter / filter.

Scheme 2

1. Heat exchanger.
2. Evaporator.
3. Fan motor.
4. Power unit.
5. Damper motor module (DMM) air distribution.
6. Damper motor module (DMM) temperature right.
7. Damper motor module (DMM) temperature left.
8. Damper motor module (DMM) recirculation.
9. Damper motor module (DMM) defroster.
10. Coolant pipe terminal; to and from the engine compartment.
11. Temperature sensor, evaporator (left-hand drive cars).
12. Temperature sensor, evaporator (right-hand drive cars).

Scheme 3

1. Fan motor.
2. Evaporator.
3. Switch, fan speed.
4. Evaporator housing, lower.
5. Drain hose.
6. Pipe at the rear expansion valve - engine compartment.
7. Cable harness.
