Interior - Removal, Replacement and Installation: Adjustments Volvo V70 II

Installing the Height Adjustment Drive Shaft

Install

1. the drive shaft
2. the bushing
3. the connector
4. the height adjustment motor. See «Height Adjustment Motor, Front»(ref-406997-S37253676842011070100000) and «Height Adjustment Motor, Rear»(ref-406997-S05957684682011070100000) .

Replacing Front-Rear Adjustment Drive System

Remove

1. the seat, the bracket and front-rear adjustment motor according to «Front-rear adjustment motor»(ref-406997-S06028887592011070100000) .

Scheme 166

1. two screws.

Install

According to Front-Rear Adjustment Motor .

Replacing the Front-Rear Adjustment Motor

For first generation power seats, replace the front-rear adjustment motor. See Front-Rear Adjustment Motor (-2004) or Electric Motor Front-Rear Adjustment, Replacing (2005-).

For second generation power seats, replace the front-rear adjustment motor. See Front-Rear Adjustment Motor (-2004) or Electric Motor Front-Rear Adjustment, Replacing (2005-).

Replacing the motor for front-rear adjustment

Remove

1. the bracket. See «Bracket (cross stay)»(ref-406997-S29005676482011070100000) .

Scheme 167

1. the two screws.

Scheme 168

1. two screws (B)
2. the motor.

Note. Bend the system upwards until it can be dismantled.

Note. Ensure that the rails do not alter position during replacement.

Install

In reverse order.

The seat must be tightened to the floor. Tighten to 48 Nm .

Scheme 169

Press the two catches at the bottom of the protective pad downwards.

Press through the upholstery.

Lift the head restraint upwards while the catches are pressed in.

Press down head restraint until the catches lock.

Note. Check by lifting the head restraint. It should not be possible to move it upwards.

Replacing Height Adjustment Gear Motor, Front

HINT: To facilitate the work read "Tips" Tip .

Remove

1. Use operation «Height Adjustment Motor, Front»(ref-406997-S37253676842011070100000) .

1. four screws.

1. one screw.

Install

In reverse order.

Height Adjustment Gear Motor, Rear

HINT: To facilitate the work read "Tips" Tip .

Replacing the Motor For Front Height Adjustment

For first generation power seats, replace the height adjustment motor. See The Motor For Front Height Adjustment (-2004) or Electric Motor Front Height Adjustment, Replacing (2005-).

For second generation power seats, replace the front height adjustment motor. See Height Adjustment Motor, Front/Rear (-2004) or Electric Motor Front Height Adjustment, Replacing (2005-).

The Motor For Front Height Adjustment

Replacing the motor for height adjustment

Remove

1. the seat from the car and the bracket. See «Bracket (Cross Stay)»(ref-406997-S29005676482011070100000)
2. the connectors. See «Connector»(ref-406997-S40651067382011070100000) .

1. the two screws.

Install

In reverse order.

Replacing the Motor For Rear Height Adjustment

For first generation power seats, replace the rear height adjustment motor. See Rear Height Adjustment Motor (-2004) or Electric motor rear height adjustment, replacing (2005-).

For second generation power seats, replace the rear height adjustment motor. See Height Adjustment Motor, Front/Rear (-2004) or Electric motor rear height adjustment, replacing (2005-).

Rear Height Adjustment Motor

Replacing the Rear Height Adjustment Motor

Remove

1. the seat from the car and the bracket. See «Front seats, replacing (version 1)»(ref-406997-S11504856182011102500000)
2. the connectors. See «Connector»(ref-406997-S40651067382011070100000) .

1. the two screws (seat belt buckle).

1. the two screws.

Install

In reverse order.

Tighten the screws for the seat belt buckle. Tighten to 48 Nm .

Lumber Support Adjustment Knob, Replacing

Note. The illustrations in this service information are used for different model years and/or models. Some variation may occur. However, the essential information in the illustrations is always correct.

See Lumber support adjustment knob, replacing

Installing the electric motor front height adjustment

Note. For tightening torques, see: Tightening torque .

Install

1. the connector
2. the electric motor
3. the 2 M6 screws
4. the 1 M8 screw
5. the front seat. See: «Front seat, replacing»(ref-406997-S25802452132011070100000) .

Scheme 170

Raise the seat to the uppermost position.

Remove

1. the side panel. See: «Side panel front seat, replacing»(ref-406997-S15951237752011070100000)
2. the tie strap (2)
3. the 3 screws (1).

Scheme 171

1. the 1 M6 screw
2. the electric motor.

Remove the connector by sliding it to one side.

Installing the electric motor rear height adjustment

Note. For tightening torques, see: Tightening torque .

Install

1. the connector
2. the electric motor
3. the 3 M6 screws
4. the 1 M6 screw
5. the tie strap
6. the side panel. See: «Side panel front seat, replacing»(ref-406997-S15951237752011070100000) .

Scheme 172

Remove

1. the front seat. See: «Front seat, replacing»(ref-406997-S25802452132011070100000)
2. the 2 M5 screws
3. the electric motor and the mechanical cables.

Scheme 173

Remove the connector by sliding it straight backwards.

Installing the electric motor front-rear adjustment

Note. For tightening torques, see: Tightening torque .

Scheme 174

HINT: If the distance between the two rails differs, secure the short mechanical cable in a power screwdriver and screw until the rails are equal.

Install

1. the connector
2. the electric motor and the mechanical cables
3. the 2 M5 screws
4. the front seat. See: «Front seat, replacing»(ref-406997-S25802452132011070100000) .

Calibrating the occupant weight sensor (OWS)

Installing the Front-Rear Adjustment Motor Drive Shaft

Install the drive shaft.

Install the front-rear adjustment motor. See Installation .

Front-Rear Adjustment Motor

See Front-Rear Adjustment Motor

Height Adjustment Motor, Front

See Height Adjustment Motor, Front

Height Adjustment Motor, Rear

See Height Adjustment Motor, Rear

See Lumber Support Adjustment Knob, Replacing

Installing the Support For the Motor For Front-Rear Adjustment

Install

1. the rubber support
2. the motor for front-rear adjustment. See «Installation»(ref-406997-S11934442252011102600000) .
