Tightening torques
In reverse order.
The front screw. Tighten to 25 Nm .
The rear screw, the nut and the washer. Tighten to 20 Nm .
Secure the screw using blue Loctite.
Scheme 397
- Ignition off
- Remove the combined instrument panel according to «Combined instrument panel»(ref-407132-S35878152592011070100000)
- Cut off the tie strap for the control module
- Detach the control module. Disconnect the connector.
The screw for the brake and throttle arm must be tightened to 8 Nm .
Note. Apply Loctite Normal to the screw
Scheme 398
Remove the parking brake lever according to Replacing the parking brake lever .
Note. Spacers are positioned between the mounting and the plate to prevent play between the parking brake lever and the hand control
