Signal specification
General
All values specified below are between the relevant terminal and terminal #9 (power ground).
| U= | DC voltage in volts (V) | ||
|---|---|---|---|
| U bat = | Battery voltage (V) | ||
| U low = | Voltage approximately 0 V |
Scheme 167
| Terminal number | Connector marking | Signal type | Ignition off | Ignition on | Other |
|---|---|---|---|---|---|
| #1 | F | ||||
| #2 | G | Power supply, occupant weight sensor (OWS) | U bat for approximately 1 minute after the ignition key is moved to position 0 (applies only if the driver's door and front passenger door are closed). U bat for approximately 5 minutes (applies if the driver's or front passenger door are opened and left open). Otherwise U low . | U bat | |
| #3 | H | Signal ground, pressure sensor | U low | U low | |
| #4 | J | Power supply, pressure sensor | 4.8-5.2 V for approximately 1 minute after the ignition key is moved to position 0 (applies only if the driver's door and front passenger door are closed). 4.8-5.2 V for approximately 5 minutes (applies if the driver's or front passenger door are opened and left open). Otherwise U low . | 4.8-5.2 V | |
| #5 | K | Signal, pressure sensor | |||
| #6 | A | Signal, seat belt force sensor | |||
| #7 | B | Voltage supply, seat belt force sensor | 4.8-5.2 V for approximately 1 minute after the ignition key is moved to position 0 (applies only if the driver's door and front passenger door are closed). 4.8-5.2 V for approximately 5 minutes (applies if the driver's or front passenger door are opened and left open). Otherwise U low . | 4.8-5.2 V | |
| #8 | C | Signal ground, seat belt force sensor | U low | U low | |
| #9 | D | Power ground, occupant weight sensor (OWS) | U low | U low | |
| #10 | E | LIN bus | During communication the voltage is 0-U bat V. |
Signals, 10-pin connector
V70 XC 2001- / XC70 -2004
- See «Signal specifications»(ref-451724-S07539104532012020900000).
V70 XC 2001- / XC70
- See «Signal specification»(/volvo/v70/ii-2000-2004/remont/passive-restraints/#restraints-specifications-electricalelectronic-xc) .
Scheme 168
Note. It is important to connect the breakout box and check the ground terminals before taking readings.
Two breakout boxes are required to take readings from the SRS control module.
Note. The terminals for connector C are split between breakout boxes 1 and 2. From model year 2003, the connectors are numbered 1-84.
- Terminals #1A-#28A correspond to terminals #1-#28
- Terminals #1B-#28B correspond to terminals #29-#56
- #1C-#28C correspond to #57-#84
| Breakout box | Control module terminal -02 | Control module terminal 03 | Function | Other |
|---|---|---|---|---|
| 1 | #1A | #1 | Signal ground | |
| 2 | #2A | #2 | Signal ground | |
| 3 | #3A | #3 | Front left side impact protection (SIPS) bag (-) | Monitoring signal at normal status. Ignition pulse on deployment. |
| 4 | #4A | #4 | Front left side impact protection (SIPS) bag (+) | Monitoring signal at normal status. Ignition pulse on deployment. |
| 5 | #5A | #5 | Belt tensioner, front left (+) | Monitoring signal at normal status. Ignition pulse on deployment. |
| 6 | #6A | #6 | Belt tensioner, front left (-) | Monitoring signal at normal status. Ignition pulse on deployment. |
| 7 | #7A | #7 | ||
| 8 | #8A | #8 | Side impact sensor, front left | |
| 9 | #9A | #9 | Side impact sensor, front left | |
| 10 | #10A | #10 | ||
| 11 | #11A | #11 | ||
| 12 | #12A | #12 | ||
| 13 | #13A | #13 | ||
| 14 | #14A | #14 | ||
| 15 | #15A | #15 | Rear left seat belt tensioner (-) | Monitoring signal at normal status. Ignition pulse on deployment. |
| 16 | #16A | #16 | Belt tensioner, rear left (+) | Monitoring signal at normal status. Ignition pulse on deployment. |
| 17 | #17A | #17 | ||
| 18 | #18A | #18 | ||
| 19 | #19A | #19 | ||
| 20 | #20A | #20 | ||
| 21 | #21A | #21 | Left inflatable curtain (+) | Monitoring signal at normal status. Ignition pulse on deployment. |
| 22 | #22A | #22 | Left inflatable curtain (-) | Monitoring signal at normal status. Ignition pulse on deployment. |
| 23 | #23A | #23 | ||
| 24 | #24A | #24 | ||
| 25 | #25A | #25 | ||
| 26 | #26A | #26 | ||
| 27 | #27A | #27 | Side impact sensor, rear left | |
| 28 | #28A | #28 | Side impact sensor, rear left | |
| 29 | #1B | #29 | ||
| 30 | #2B | #30 | Collision signal | Signal to the central electronic module (CEM) |
| 31 | #3B | #31 | ||
| 32 | #4B | #32 | SRS warning lamp | Activated |
| 33 | #5B | #33 | SRS warning lamp | Deactivated |
| 34 | #6B | #34 | Switch (+) | |
| 35 | #7B | #35 | Driver airbag, stage 1 (-) | Monitoring signal at normal status. Ignition pulse on deployment. |
| 36 | #8B | #36 | Driver airbag, stage 1 (+) | Monitoring signal at normal status. Ignition pulse on deployment. |
| 37 | #9B | #37 | Driver's airbag stage 2 (+) | Monitoring signal at normal status. Ignition pulse on deployment. |
| 38 | #10B | #38 | Driver airbag, stage 2 (-) | Monitoring signal at normal status. Ignition pulse on deployment. |
| 39 | #11B | #39 | Passenger airbag, stage 1 (-) | Monitoring signal at normal status. Ignition pulse on deployment. |
| 40 | #12B | #40 | Passenger airbag, stage 1 (+) | Monitoring signal at normal status. Ignition pulse on deployment. |
| 41 | #13B | #41 | Passenger airbag, stage 2 (+) | Monitoring signal at normal status. Ignition pulse on deployment. |
| 42 | #14B | #42 | Passenger airbag, stage 2 (-) | Monitoring signal at normal status. Ignition pulse on deployment. |
| 43 | #15B | #43 | Switch (-) | |
| 44 | #16B | #44 | ||
| 45 | #17B | #45 | ||
| 46 | #18B | #46 | ||
| 47 | #19B | #47 | ||
| 48 | #20B | #48 | ||
| 49 | #21B | #49 | ||
| 50 | #22B | #50 | ||
| 51 | #23B | #51 | Control modules communication cable (CAN H) | U=2.5-3.5 V |
| 52 | #24B | #52 | Control modules communication cable (CAN H) | U=2.5-3.5 V |
| 53 | #25B | #53 | Communication cable, control modules (CAN L) | U=1.5-2.5 V |
| 54 | #26B | #54 | Communication cable, control modules (CAN L) | U=1.5-2.5 V |
| 55 | #27B | #55 | X-feed voltage from the ignition switch (ignition switch pos. I and II) | Battery voltage approx. 12 V |
| 56 | #28B | #56 | 15-supply voltage (ignition switch pos. II and III) | Battery voltage approx. 12 V |
| 57 | #1C | #57 | ||
| 58 | #2C | #58 | ||
| 59 | #3C | #59 | Side airbag, front right (-) | Monitoring signal at normal status. Ignition pulse on deployment. |
| 60 | #4C | #60 | Side airbag, front right (+) | Monitoring signal at normal status. Ignition pulse on deployment. |
Breakout box 1
| Breakout box | Control module terminal -02 | Control module terminal 03 | Function | Other |
|---|---|---|---|---|
| 1 | #5C | #61 | Belt tensioner, front right (+) | Monitoring signal at normal status. Ignition pulse on deployment. |
| 2 | #6C | #62 | Front right seat belt tensioner (-) | |
| 3 | #7C | #63 | ||
| 4 | #8C | #64 | Side impact sensor, right front | |
| 5 | #9C | #65 | Side impact sensor, right front | |
| 6 | #10C | #66 | ||
| 7 | #11C | #67 | ||
| 8 | #12C | #68 | ||
| 9 | #13C | #69 | ||
| 10 | #14C | #70 | ||
| 11 | #15C | #71 | Rear right seat belt tensioner (-) | Monitoring signal at normal status. Ignition pulse on deployment. |
| 12 | #16C | #72 | Rear right seat belt tensioner (+) | Monitoring signal at normal status. Ignition pulse on deployment. |
| 13 | #17C | #73 | ||
| 14 | #18C | #74 | ||
| 15 | #19C | #75 | ||
| 16 | #20C | #76 | ||
| 17 | #21C | #77 | Right inflatable curtain (+) | Monitoring signal at normal status. Ignition pulse on deployment. |
| 18 | #22C | #78 | Right inflatable curtain (-) | Monitoring signal at normal status. Ignition pulse on deployment. |
| 19 | #23C | #79 | Belt tensioner, rear center (-) | Monitoring signal at normal status. Ignition pulse on deployment. |
| 20 | #24C | #80 | Rear center seat belt tensioner (+) | Monitoring signal at normal status. Ignition pulse on deployment. |
| 21 | #25C | #81 | ||
| 22 | #26C | #82 | ||
| 23 | #27C | #83 | Side impact sensor, right rear | |
| 24 | #28C | #84 | Side impact sensor, right rear |
Breakout box 2
General
All values given below are between the terminals stated in column 2 and the ground terminal on the body for the control module.
Note. It is important to connect the breakout box and check the ground terminals before taking readings. The adapter has two terminals for the breakout box. The signals in the 84-pin connector are split between adapter terminals A and B. For some VIDA fault-tracing, the connectors are numbered #1A-#28A, #1B-#28B and #1C-#28C. This is because fault-tracing is used from previous model years. From and including model year 2003, the connectors are numbered #1-#84.
- Terminals #1A-#28A correspond to terminals #1-#28
- Terminals #1B-#28B correspond to terminals #29-#56
- Terminals #1C-#28C correspond to terminals #57-#84.
| U= | DC voltage in volts (V) | ||
|---|---|---|---|
| U bat = | Battery voltage (V) | ||
| U low = | Voltage approximately 0 V |
| Terminal control module -02 | Terminal control module 03 | Breakout box terminal | Signal type | Ignition on | Other | ||
|---|---|---|---|---|---|---|---|
| #1A | #1 | #1 | |||||
| #2A | #2 | #2 | |||||
| #3A | #3 | #3 | Front left side impact protection (SIPS) bag (-) | Monitoring signal at normal position. Ignition pulse on activation. | |||
| #4A | #4 | #4 | Front left side impact protection (SIPS) bag (+) | Monitoring signal at normal position. Ignition pulse on activation. | |||
| #5A | #5 | #5 | Front left seat belt tensioner (+) | ||||
| #6A | #6 | #6 | Front left seat belt tensioner (-) | Monitoring signal at normal position. Ignition pulse on activation. | |||
| #7A | #7 | #7 | Signal ground | U low | |||
| #8A | #8 | #8 | Side impact sensor, left front (-) | ||||
| #9A | #9 | #9 | Side impact sensor, left front (+) | ||||
| #10A | #10 | #10 | |||||
| #11A | #11 | #11 | Not used | Monitoring signal at normal position. Ignition pulse on activation. | |||
| #12A | #12 | #12 | Not used | Monitoring signal at normal position. Ignition pulse on activation. | |||
| #13A | #13 | #13 | Not used | Monitoring signal at normal position. Ignition pulse on activation. | |||
| #14A | #14 | #14 | Not used | Monitoring signal at normal position. Ignition pulse on activation. | |||
| #15A | #15 | #15 | Rear left seat belt tensioner (-) | Monitoring signal at normal position. Ignition pulse on activation. | |||
| #16A | #16 | #16 | Rear left seat belt tensioner (+) | Monitoring signal at normal position. Ignition pulse on activation. | |||
| #17A | #17 | #17 | |||||
| #18A | #18 | #18 | |||||
| #19A | #19 | #19 | |||||
| #20A | #20 | #20 | |||||
| #21A | #21 | #21 | Left inflatable curtain (+) | Monitoring signal at normal position. Ignition pulse on activation. | |||
| #22A | #22 | #22 | Left inflatable curtain (-) | Monitoring signal at normal position. Ignition pulse on activation. | |||
| #23A | #23 | #23 | |||||
| #24A | #24 | #24 | |||||
| #25A | #25 | #25 | Seat belt buckle left front (+) | ||||
| #26A | #26 | #26 | Seat belt buckle left front (-) | ||||
| #27A | #27 | #27 | Side impact sensor, left rear (-) | ||||
| #28A | #28 | #28 | Side impact sensor, left rear (+) | ||||
| #1B | #29 | #29 | Not used | Monitoring signal at normal position. Ignition pulse on activation. | |||
| #2B | #30 | #30 | Collision | Signal to CEM and PHM | |||
| #3B | #31 | #31 | Diagnostic production | ||||
| #4B | #32 | #32 | Not used | Monitoring signal at normal position. Ignition pulse on activation. | |||
| #5B | #33 | #33 | Not used | Monitoring signal at normal position. Ignition pulse on activation. | |||
| #6B | #34 | #34 | Not used | Monitoring signal at normal position. Ignition pulse on activation. | |||
| #7B | #35 | #35 | Driver airbag, stage 1 (-) | Monitoring signal at normal position. Ignition pulse on activation. | |||
| #8B | #36 | #36 | Driver airbag, stage 1 (+) | Monitoring signal at normal position. Ignition pulse on activation. | |||
| #9B | #37 | #37 | Driver airbag, stage 2 (+) | Monitoring signal at normal position. Ignition pulse on activation. | |||
| #10B | #38 | #38 | Driver airbag, stage 2 (-) | Monitoring signal at normal position. Ignition pulse on activation. | |||
| #11B | #39 | #39 | Passenger airbag, stage 1 (-) | Monitoring signal at normal position. Ignition pulse on activation. | |||
| #12B | #40 | #40 | Passenger airbag, stage 1 (+) | Monitoring signal at normal position. Ignition pulse on activation. | |||
| #13B | #41 | #41 | Passenger airbag, stage 2 (+) | Monitoring signal at normal position. Ignition pulse on activation. | |||
| #14B | #42 | #42 | Passenger airbag, stage 2 (-) | Monitoring signal at normal position. Ignition pulse on activation. | |||
| #15B | #43 | #43 | Not used | Monitoring signal at normal position. Ignition pulse on activation. | |||
| #16B | #44 | #44 | Not used | Monitoring signal at normal position. Ignition pulse on activation. | |||
| #17B | #45 | #45 | Not used USA/CDN | ||||
| #18B | #46 | #46 | Front impact sensor left front (-) (Only V70/XC70 USA/CDN) | ||||
| #19B | #47 | #47 | Front collision sensor left front (+) (Only V70/XC70 USA/CDN) | ||||
| #20B | #48 | #48 | |||||
| #21B | #49 | #49 | Front impact sensor right front (-) (Only V70/XC70 USA/CDN) | ||||
| #22B | #50 | #50 | Not used USA/CDN | ||||
| #23B | #51 | #51 | CAN H | During communication the voltage is 2.5-4.0 V. | |||
| #24B | #52 | #52 | CAN H | During communication the voltage is 2.5-4.0 V. | |||
| #25B | #53 | #53 | CAN L | During communication the voltage is 1.0-2.5 V. | |||
| #26B | #54 | #54 | CAN L | During communication the voltage is 1.0-2.5 V. | |||
| #27B | #55 | #55 | X-supply | U bat | Ignition position I and II. | ||
| #28B | #56 | #56 | 15 supply | U bat | Ignition position II and III. | ||
| #1C | #57 | #57 | LIN bus. (Only V70/XC70 USA/CDN) | During communication the voltage is 0-U bat V. | |||
| #2C | #58 | #58 | |||||
| #3C | #59 | #59 | Front right side impact protection (SIPS) bag (-) | Monitoring signal at normal position. Ignition pulse on activation. | |||
| #4C | #60 | #60 | Front right side impact protection (SIPS) bag (+) | Monitoring signal at normal position. Ignition pulse on activation. | |||
Adapter terminal A
| Terminal control module -02 | Terminal control module 03 | Breakout box terminal | Signal type | Ignition on | Other |
|---|---|---|---|---|---|
| #5C | #61 | #1 | Front right seat belt tensioner (+) | Monitoring signal at normal position. Ignition pulse on activation. | |
| #6C | #62 | #2 | Front right seat belt tensioner (-) | Monitoring signal at normal position. Ignition pulse on activation. | |
| #7C | #63 | #3 | Signal ground | U low | |
| #8C | #64 | #4 | Side impact sensor, right front (-) | ||
| #9C | #65 | #5 | Side impact sensor, right front (+) | ||
| #10C | #66 | #6 | |||
| #11C | #67 | #7 | Not used | Monitoring signal at normal position. Ignition pulse on activation. | |
| #12C | #68 | #8 | Not used | Monitoring signal at normal position. Ignition pulse on activation. | |
| #13C | #69 | #9 | Not used | Monitoring signal at normal position. Ignition pulse on activation. | |
| #14C | #70 | #10 | Not used | Monitoring signal at normal position. Ignition pulse on activation. | |
| #15C | #71 | #11 | Rear right seat belt tensioner (-) | Monitoring signal at normal position. Ignition pulse on activation. | |
| #16C | #72 | #12 | Rear right seat belt tensioner (+) | Monitoring signal at normal position. Ignition pulse on activation. | |
| #17C | #73 | #13 | |||
| #18C | #74 | #14 | |||
| #19C | #75 | #15 | |||
| #20C | #76 | #16 | |||
| #21C | #77 | #17 | Right inflatable curtain (+) | Monitoring signal at normal position. Ignition pulse on activation. | |
| #22C | #78 | #18 | Right inflatable curtain (-) | Monitoring signal at normal position. Ignition pulse on activation. | |
| #23C | #79 | #19 | Rear center seat belt tensioner (-) | Monitoring signal at normal position. Ignition pulse on activation. | |
| #24C | #80 | #20 | Rear center seat belt tensioner (+) | Monitoring signal at normal position. Ignition pulse on activation. | |
| #25C | #81 | #21 | Seat belt buckle right front (+) | ||
| #26C | #82 | #22 | Seat belt buckle right front (-) | ||
| #27C | #83 | #23 | Side impact sensor, right rear (-) | ||
| #28C | #84 | #24 | Side impact sensor, right rear (+) |
Adapter terminal B
See also:
• Signal specification
