Contents Wiring diagrams Section: Anti-Lock/traction Control All sections

Brake Control Module (BCM) Diagnostic Trouble Code (DTC) Diagnostics: Diagnosis Volvo V70 II

Anti-Lock/traction Control 17 illustrations ~12425 words

Diagnostic trouble code (DTC) information

Condition

Scheme 107

Scheme 107: Diagnostic trouble code (DTC) information
Scheme 107: Diagnostic trouble code (DTC) information

In cars with traction control (STC/DSTC/TRACS), the brake control module registers how much the brakes are used and then calculates the temperature of all brake discs. Diagnostic trouble code (DTC) BCM-0061 is stored if the calculated temperature exceeds 450°C.

The diagnostic trouble code (DTC) can be diagnosed while the ignition is switched on.

Substitute Value

  1. Traction control is blocked.

HINT: For information about brake system abbreviations, see Brake system, abbreviations .

Possible Source

  1. Excessive anti-spin control
  2. Brakes applied too long (brakes have been used so much that brake disc temperature has become too high).

Note. This diagnostic trouble code (DTC) is not due to an internal hardware fault in the Brake control module (BCM) and must not be remedied by replacing the control module.

Fault symptom[s]

  1. Anti-spin does not function. NOTE: The anti-spin function is deactivated until the temperature of the brake discs is below 300°C.

Visual inspection of brakes

  1. Remove the front wheels. Check the brakes for the front wheel visually. Check there is no overheating damage to brake caliper, brake pads or brake disc. Replace damaged components. Tell the customer why the anti-spin function was temporarily blocked and why the ABS warning lamp was lit. Remedy as necessary. Other information To remove or replace brake calipers, see «Brake calipers front, replacing»(ref-406847-S25117676152011070100000) To remove or replace brake pads, see «Brake pads front, replacing»(ref-406847-S36468335502011070100000) To remove or replace brake discs, see «Brake disc front, replacing»(ref-406847-S02881809532011070100000) .

Condition

Scheme 108

Scheme 108: Diagnostic trouble code (DTC) information
Scheme 108: Diagnostic trouble code (DTC) information

Note. Only applies to four wheel drive cars with TRACS (traction control system).

The brake control module compares the signals with each other in order to detect a faulty signal from the stop lamp switch or the pedal position sensor. Diagnostic trouble code (DTC) BCM-0065 is stored if the control module registers a faulty signal from the stop lamp switch or the pedal position sensor.

Substitute Value

  1. Traction control is blocked.

HINT: For information about brake system abbreviations, see Brake system, abbreviations .

Possible Source

  1. Short-circuit to ground or supply voltage in the signal cable for the stop lamp switch
  2. Defective stop lamp switch
  3. Defective pedal position sensor.

Fault symptom[s]

  1. Anti-spin does not function.

Checking diagnostic trouble codes in the central electronic module (CEM) and the engine control module (ECM)

If there are diagnostic trouble codes (DTCs) for the brake pedal position sensor or stop lamp switch stored in the engine control module (ECM) or central electronic module (CEM), these must be fault traced first.

Were diagnostic trouble codes (DTCs) stored for the pedal position sensor or the stop lamp switch?

  1. YES OKAY: Troubleshooting has been completed.
  2. NO Refer to «Checking the control module and sensor connectors»(ref-406990-S32259522282011070100000)

If there are diagnostic trouble codes (DTCs) for the brake pedal position sensor or stop lamp switch stored in the engine control module (ECM) or central electronic module (CEM), these must be fault traced first.

Were diagnostic trouble codes (DTCs) stored for the pedal position sensor or the stop lamp switch?

  1. YES OKAY: Troubleshooting has been completed.
  2. NO Refer to «Checking the control module and sensor connectors»(ref-406990-S08715679532011070100000)

Condition

Note. The diagnostic trouble code (DTC) applies only to cars with dynamic stability and traction control (DSTC).

The brake pressure sensors and pedal position sensor have a common internal power supply in the control module.

Diagnostic trouble code (DTC) BCM-0068 is stored if the brake control module (BCM) detects that the voltage to the sensors is incorrect.

The diagnostic trouble code (DTC) can be diagnosed while the ignition is switched on.

Substitute Value

  1. Stability control is blocked
  2. Traction control is blocked
  3. Active yaw control is blocked
  4. TRACS (traction control system) is blocked
  5. Brake assistance is blocked.

HINT: For information about brake system abbreviations, see Brake system, abbreviations .

Possible Source

  1. Short-circuit to ground or supply voltage in the wiring
  2. Defective sensor
  3. Defective brake control module (BCM).

Fault symptom[s]

  1. General warning lamp lit
  2. The anti-spin warning lamp is lit (up to and including 2002 model year)
  3. Anti-spin does not function
  4. The stability control system does not function
  5. The traction control system does not function.

Condition

Scheme 109

Scheme 109: Diagnostic trouble code (DTC) information
Scheme 109: Diagnostic trouble code (DTC) information

Diagnostic trouble code (DTC) BCM-0070 is stored if the brake control module (BCM) detects that the voltage to the pump motor is incorrect.

The diagnostic trouble code (DTC) can be diagnosed while the ignition is switched on.

Substitute Value

  1. The ABS is blocked
  2. Traction control is blocked
  3. Stability control is blocked
  4. Active yaw control is blocked
  5. Brake assistance is blocked.

HINT: For information about brake system abbreviations, see Brake system, abbreviations .

Possible Source

  1. Contact resistance in the terminals
  2. The fuse for the pump motor is defective
  3. Open-circuit in the power supply to the pump motor
  4. Open-circuit in the ground lead for the pump motor
  5. Open-circuit in the power supply (30-supply) to the control module for the pump motor
  6. Defective pump motor
  7. Defective control module.

Fault symptom[s]

  1. General warning lamp lit
  2. The ABS warning lamp is lit
  3. The anti-spin warning lamp is lit (up to and including 2002 model year)
  4. The ABS system does not function
  5. Anti-spin does not function
  6. The stability control system does not function
  7. The traction control system does not function.

Condition

Diagnostic trouble code (DTC) BCM-0071 is stored if the brake control module (BCM) registers that the pump motor does not start or that the signal from the pump motor is missing.

The diagnostic trouble code (DTC) can be diagnosed while the ignition is switched on.

Substitute Value

  1. The ABS is blocked
  2. Traction control is blocked
  3. Stability control is blocked
  4. Active yaw control is blocked
  5. Brake assistance is blocked.

HINT: For information about brake system abbreviations, see Brake system, abbreviations .

Possible Source

  1. Contact resistance in the terminals
  2. The fuse for the pump motor is defective
  3. Open-circuit in the power supply to the pump motor
  4. Open-circuit in the ground lead for the pump motor
  5. Defective pump motor
  6. Defective control module.

Fault symptom[s]

  1. General warning lamp lit
  2. The ABS warning lamp is lit
  3. The anti-spin warning lamp is lit (up to and including 2002 model year)
  4. The ABS system does not function
  5. Anti-spin does not function
  6. The stability control system does not function
  7. The traction control system does not function.

Condition

Diagnostic trouble code (DTC) BCM-0072 is stored if the brake control module (BCM) registers that the pump motor does not start.

The diagnostic trouble code (DTC) can be diagnosed while the ignition is switched on.

Substitute Value

  1. The ABS is blocked
  2. Traction control is blocked
  3. Stability control is blocked
  4. Active yaw control is blocked
  5. Brake assistance is blocked.

HINT: For information about brake system abbreviations, see Brake system, abbreviations .

Possible Source

  1. Contact resistance in the terminals
  2. Defective fuse for the pump motor
  3. Open-circuit in the power supply to the pump motor
  4. Open-circuit in the ground lead for the pump motor
  5. Defective pump motor
  6. Defective control module.

Fault symptom[s]

  1. General warning lamp lit
  2. The ABS warning lamp is lit
  3. The anti-spin warning lamp is lit (up to and including 2002 model year)
  4. The ABS system does not function
  5. Anti-spin does not function
  6. The stability control system does not function
  7. The traction control system does not function.

Condition

Scheme 110

Scheme 110: Diagnostic trouble code (DTC) information
Scheme 110: Diagnostic trouble code (DTC) information

The brake control module (BCM) can register diagnostic trouble code (DTC) BCM-0074 for a number of different fault causes. Diagnostic trouble code (DTC) BCM-0074 is stored

  1. if there is a short-circuit to ground or open-circuit in the control module inlet or outlet valve circuits
  2. if the control module is subject to interference so that its calculations are incorrect
  3. if the control module registers a fault in its internal inlet and outlet valve circuits
  4. if there is a short-circuit to ground, short-circuit to supply voltage or an open-circuit in the inlet valve in the anti-spin circuit
  5. if the control module registers an open-circuit or short-circuit in one of its internal circuits.

Substitute Value

  1. The ABS is blocked
  2. Traction control is blocked
  3. Stability control is blocked
  4. Active yaw control is blocked
  5. Electronic Brake force Distribution is blocked
  6. Brake assistance is blocked.

HINT: For information about abbreviations, see Brake system, abbreviations .

Possible Source

  1. Internal fault in the control module.

Fault symptom[s]

  1. The ABS warning lamp is lit
  2. The warning lamp for brake circuit not functioning is lit
  3. The anti-spin warning lamp is lit (up to and including 2002 model year)
  4. The ABS system does not function
  5. Anti-spin does not function
  6. The stability control system does not function
  7. The traction control system does not function.

Condition

The brake control module (BCM) is programmed at the factory with software for several car models. During the first ignition cycle, the control module reads the vehicle configuration data from the central electronic module (CEM). The brake control module (BCM) then configures itself according to the car model and equipment.

Diagnostic trouble code (DTC) BCM-0076 may be stored if

  1. a brake control module (BCM) is installed that has previously been used in another car
  2. a central electronic module (CEM) is installed that has previously been used in another car
  3. software for another car is downloaded into the brake control module (BCM).

Substitute Value

  1. Traction control is blocked
  2. Stability control is blocked
  3. Active yaw control is blocked.

HINT: For information about abbreviations, see Brake system, abbreviations .

Possible Source

  1. A brake control module (BCM) from another model has been installed
  2. A central electronic module (CEM) from another model has been installed
  3. Software for another car is downloaded into the brake control module (BCM).

Note. This diagnostic trouble code (DTC) is not due to an internal hardware fault in the Brake control module (BCM) and must not be remedied by replacing the control module.

Fault symptom[s]

  1. The anti-spin warning lamp is lit (up to and including 2002 model year)
  2. General yellow warning lamp lit (from model year 2003 inclusive)
  3. Anti-spin does not function
  4. The stability control system does not function
  5. The traction control system does not function.

Checking diagnostic trouble codes (DTCs) in the central electronic module (CEM)

Note. If the central electronic module (CEM) is incorrectly configured it may affect the brake control module (BCM). Fault-trace the central electronic module (CEM) first if there are diagnostic trouble codes (DTCs) stored in both the control modules.

  1. Ignition on
  2. Read off diagnostic trouble codes (DTCs).

Are diagnostic trouble codes (DTCs) stored in the central electronic module (CEM)?

  1. YES OKAY: Troubleshooting has been completed.
  2. NO Refer to «Checking the software»(ref-406990-S10630632642011070100000)

Erasing diagnostic trouble codes (DTCs)

  1. Ignition on
  2. Erase diagnostic trouble codes (DTCs) from the brake control module (BCM).
  1. Continue Refer to «Reading off diagnostic trouble codes (DTCs)»(ref-406990-S06066152422011070100000)

Reading off diagnostic trouble codes (DTCs)

  1. Ignition off
  2. Wait approximately 15 seconds.
  3. Ignition on
  4. Read off diagnostic trouble codes (DTCs).

Is diagnostic trouble code (DTC) BCM-0076 stored?

  1. YES Refer to «Checking the car configuration»(ref-406990-S03904748142011070100000)
  2. NO OKAY: Troubleshooting has been completed.

Condition

Scheme 111

Scheme 111: Diagnostic trouble code (DTC) information
Scheme 111: Diagnostic trouble code (DTC) information

Note. The diagnostic trouble code (DTC) applies only to cars with dynamic stability and traction control (DSTC).

The yaw rate sensor, lateral accelerometer, accelerometer (only AWD) and angle of lean sensor (only RSC) are integrated in the active yaw control sensor for DSTC. The sensors transmit information to the brake control module (BCM) indicating the size of the yaw angle, the lateral acceleration of the car, the forward acceleration and the lateral angle of lean via its own internal Control area network (CAN). Each sensor has an offset value, correction value, for the individual sensor offset.

Diagnostic trouble code (DTC) BCM-0080, BCM-0081, BCM-0082 or BCM-0083 is stored, depending on the sensor, if the control module registers an incorrect offset value from any of the sensors.

  1. BCM-0080: Lateral accelerometer
  2. BCM-0081: Accelerometer
  3. BCM-0082: Yaw rate sensor
  4. BCM-0083: Angle of lean sensor.

The diagnostic trouble code (DTC) can be diagnosed while the ignition is switched on.

Substitute Value

  1. Traction control is blocked
  2. Stability control is blocked
  3. Active yaw control is blocked
  4. RSC system is blocked (cars equipped with RSC only).

HINT: For information about brake system abbreviations, see Brake system, abbreviations .

Possible Source

  1. Active yaw control sensor incorrectly installed
  2. The active yaw control sensor is loose
  3. The bracket for the active yaw control sensor is bent
  4. Internal fault in the active yaw control sensor.

Note. This diagnostic trouble code (DTC) is not due to an internal hardware fault in the Brake control module (BCM) and must not be remedied by replacing the control module.

Fault symptom[s]

  1. The anti-spin warning lamp is lit (up to and including 2002 model year)
  2. General yellow warning lamp lit (from model year 2003)
  3. Text window and warning symbol/Red symbol and text message
  4. Anti-spin does not function
  5. The stability control system does not function
  6. The traction control system does not function.

See Diagnostic trouble code (DTC) information

See Diagnostic trouble code (DTC) information

See Diagnostic trouble code (DTC) information

Condition

Note. The diagnostic trouble code (DTC) applies only to cars with dynamic stability and traction control (DSTC).

The yaw rate sensor, lateral accelerometer, accelerometer and angle of lean sensor (only RSC) are integrated in the active yaw control sensor for DSTC (dynamic stability and traction control). The sensors transmit information to the brake control module (BCM) indicating the size of the yaw angle, the lateral acceleration of the car, the forward acceleration and the lateral angle of lean via the Control area network (CAN).

Diagnostic trouble code (DTC) BCM-0090, BCM-0091, BCM-0092 or BCM-0093 is stored, depending on the sensor, if the control module registers a faulty signal from any of the sensors.

  1. BCM-0090: Lateral accelerometer
  2. BCM-0091: Accelerometer
  3. BCM-0092: Yaw rate sensor
  4. BCM-0093: Angle of lean sensor.

The diagnostic trouble code (DTC) can be diagnosed while the ignition is switched on.

Substitute Value

  1. Traction control is blocked
  2. Stability control is blocked
  3. Active yaw control is blocked
  4. RSC system is blocked (cars equipped with RSC only).

HINT: For information about brake system abbreviations, see Brake system, abbreviations .

Possible Source

  1. Open-circuit or short-circuit to ground in the wiring for the active yaw control sensor
  2. Internal fault in the active yaw control sensor.

Note. This diagnostic trouble code (DTC) is not due to an internal hardware fault in the Brake control module (BCM) and must not be remedied by replacing the control module.

Fault symptom[s]

  1. The anti-spin warning lamp is lit (up to and including 2002 model year)
  2. General yellow warning lamp lit (from model year 2003)
  3. Anti-spin does not function
  4. The stability control system does not function
  5. The traction control system does not function.

Scheme 112

Scheme 112
Scheme 112

Scheme 113

Scheme 113
Scheme 113
  1. Ignition off. Check the wiring between the active yaw control sensor: terminal #1 and control module terminal #A25 (#A25) terminal #2 and control module terminal #A29 (#A29) terminal #3 and control module terminal #A6 (#A6) terminal #5 and control module terminal #A39 (#A39). check for an open-circuit. HINT: Read off the relevant signal for the diagnostic trouble code (DTC). Check that the value is within its permitted range. Steering wheel angle sensor, offset value. The value must be 0° 17 °/s. Yaw rate sensor, offset value. The value must be 0° 6.0 °/s. Lateral accelerometer, offset value. The value must be 0° 1.7 m/s. Accelerometer, offset value. The value must be 0° 1.7 m/s. If the value is incorrect, this can mean a damaged AYC sensor. Remedy as necessary. Other information Connect the breakout box. To replace the active yaw control sensor, see «ACTIVE YAW CONTROL SENSOR, REPLACING»(ref-406847-S36312531992011070100000) For information about signals, see «Signal specification, brake control module (BCM) with DSTC (dynamic stability and traction control)»(ref-406848-S12183644562011070100000) See «Contents»(ref-406811-S37635188302011070100000)
  1. Continue Refer to «Verification»(ref-406990-S04317398962011070100000)

See Diagnostic trouble code (DTC) information

See Diagnostic trouble code (DTC) information

See Diagnostic trouble code (DTC) information

Checking other diagnostic trouble codes (DTCs)

In the event of communication problems, the fault may exist in other parts of the communications network.

The role of the central electronic module is to generally control the communications network and to store diagnostic trouble codes (DTCs) in the event of communication problems between control modules.

If there are diagnostic trouble codes (DTCs) stored for communication problems in the central electronic module, stop the fault tracing and fault trace the central electronic module.

Were diagnostic trouble codes (DTCs) for communication problems stored in the central electronic module?

  1. YES OKAY: Troubleshooting has been completed.
  2. NO Refer to «Checking diagnostic trouble codes (DTCs)»(ref-406990-S24906807752011070100000)

Checking diagnostic trouble codes (DTCs)

  1. Ignition on
  2. Wait approximately 60 seconds
  3. Read off the status of the diagnostic trouble code (DTC).

Is the status of the diagnostic trouble code (DTC) permanent?

  1. YES Refer to «Checking wiring and terminals»(ref-406990-S22729387392011070100000)
  2. NO Refer to «Intermittent fault»(ref-406990-S35946614462011070100000)

Condition

Note. The diagnostic trouble code (DTC) applies only to cars with all-wheel drive (AWD) and dynamic stability and traction control (DSTC).

The differential electronic module (DEM) indicates to the brake control module (BCM) when four wheel drive is activated. During four wheel drive the brake control module (BCM) must not activate the stability function due to the risk of disrupting the differential electronic module (DEM). A DTC is stored if the Brake control module (BCM) registers that the signal from the Differential electronic module (DEM) is missing, or if the signal indicates that four wheel drive is not working.

The diagnostic trouble code (DTC) can be diagnosed when the ignition is switched on.

Substitute Value

  1. Stability control is blocked
  2. Traction control is blocked (All-wheel drive (AWD) TRACS (Traction Control System) is blocked without a warning lamp lighting)
  3. Active yaw control is blocked.

HINT: Brake system, abbreviations

Possible Source

  1. Open-circuit or short-circuit in the wiring for the control area network (CAN)
  2. Damaged Differential Electronic Module (DEM).

Fault symptom[s]

  1. The anti-spin warning lamp is lit (up to and including 2002 model year)
  2. General yellow warning lamp lit (from model year 2003 inclusive)
  3. Anti-spin does not function
  4. The stability control system does not function
  5. The traction control system does not function.

In the event of communication problems, the fault may exist in other parts of the communications network.

The role of the central electronic module is to generally control the communications network and to store diagnostic trouble codes (DTCs) in the event of communication problems between control modules.

If there are diagnostic trouble codes (DTCs) stored for communication problems in the central electronic module, stop the fault tracing and fault trace the central electronic module.

Were diagnostic trouble codes (DTCs) for communication problems stored in the central electronic module?

  1. YES OKAY: Troubleshooting has been completed.
  2. NO Refer to «Fault-tracing information»(ref-406990-S21981401962011070100000)

Condition

Note. The diagnostic trouble code (DTC) applies only to cars with all-wheel drive (AWD) and dynamic stability and traction control (DSTC).

The differential electronic module (DEM) indicates to the brake control module (BCM) when four wheel drive is activated. During four wheel drive the brake control module (BCM) must not activate the stability function due to the risk of disrupting the differential electronic module (DEM). A DTC is stored if the Brake control module (BCM) registers that the difference in speed between the front and rear wheels is too great.

The diagnostic trouble code (DTC) can be diagnosed when the ignition is switched on.

Substitute Value

  1. Stability control is blocked
  2. Active yaw control is blocked.

HINT: Brake system, abbreviations

Possible Source

  1. Damaged Differential Electronic Module (DEM).

Note. This diagnostic trouble code (DTC) is not due to an internal hardware fault in the Brake control module (BCM) and must not be remedied by replacing the control module.

Fault symptom[s]

  1. The anti-spin warning lamp is lit (up to and including 2002 model year)
  2. General yellow warning lamp lit (from model year 2003 inclusive)
  3. Anti-spin does not function
  4. The stability control system does not function.

In the event of communication problems, the fault may exist in other parts of the communications network.

The role of the central electronic module is to generally control the communications network and to store diagnostic trouble codes (DTCs) in the event of communication problems between control modules.

If there are diagnostic trouble codes (DTCs) stored for communication problems in the central electronic module, stop the fault tracing and fault trace the central electronic module.

Were diagnostic trouble codes (DTCs) for communication problems stored in the central electronic module?

  1. YES OKAY: Troubleshooting has been completed.
  2. NO Refer to «Fault-tracing information»(ref-406990-S02221663632011070100000)

See Diagnostic trouble code (DTC) information

HINT: In the event of communication problems, the fault may exist in other parts of the communications network. The role of the central electronic module is to generally control the communications network and to store diagnostic trouble codes (DTCs) in the event of communication problems between control modules.

HINT: If there are diagnostic trouble codes (DTC) stored in the central electronic module these must be fault traced accordingly.

  1. Ignition on
  2. Wait approximately 60 seconds
  3. Read off diagnostic trouble codes (DTCs). If there are diagnostic trouble codes (DTCs) for communication problems stored for the brake control module in the central electronic module, these must be fault traced first.

Were diagnostic trouble codes (DTCs) stored in the central electronic module?

  1. YES OKAY: Troubleshooting has been completed.
  2. NO Refer to «Checking diagnostic trouble codes (DTCs)»(ref-406990-S34426380652011070100000)
  1. Ignition on
  2. Wait approximately 60 seconds
  3. Read off the status of the diagnostic trouble code (DTC).

Is the status of the diagnostic trouble code (DTC) permanent?

  1. YES Refer to «Checking wiring and terminals»(ref-406990-S38706484952011070100000)
  2. Refer to «Intermittent fault»(ref-406990-S26975639472011070100000)

Condition

Note. The diagnostic trouble code (DTC) applies only to cars with dynamic stability and traction control (DSTC).

The control modules in the car continually transmit and receive information over the data network (Controller Area Network).

Diagnostic trouble code (DTC) BCM-0097 is stored if the brake control module (BCM) registers that the signal from the central electronic module (CEM), which contains information about the vehicle type, has been absent for more than 27 seconds after the ignition is switched on.

The diagnostic trouble code (DTC) can be diagnosed when the ignition is switched on.

Substitute Value

  1. Traction control is blocked
  2. Stability control is blocked
  3. Active yaw control is blocked.

HINT: For information about abbreviations, see Brake system, abbreviations .

Possible Source

  1. A brake control module (BCM) from another model has been installed
  2. A central electronic module (CEM) from another model has been installed.

Fault symptom[s]

  1. The anti-spin warning lamp is lit (up to and including 2002 model year)
  2. General yellow warning lamp lit (from model year 2003 inclusive)
  3. Anti-spin does not function
  4. The stability control system does not function
  5. The traction control system does not function.

In the event of communication problems, the fault may exist in other parts of the communications network.

The role of the central electronic module is to generally control the communications network and to store diagnostic trouble codes (DTCs) in the event of communication problems between control modules.

If there are diagnostic trouble codes (DTCs) stored for communication problems in the central electronic module, stop the fault tracing and fault trace the central electronic module.

Were diagnostic trouble codes (DTCs) for communication problems stored in the central electronic module?

  1. YES OKAY: Troubleshooting has been completed.
  2. NO Refer to «Checking diagnostic trouble codes (DTCs) in the engine control module (ECM)»(ref-406990-S14840092512011070100000)

Checking diagnostic trouble codes (DTCs) in the engine control module (ECM)

The diagnostic trouble code (DTC) is stored because the torque signal or engine speed signal from the engine has been missing for more than 500 ms. The signals are used by the brake control module for control the stability function.

If there are any diagnostic trouble codes (DTCs) stored for the engine control module (ECM), these must be fault traced first.

Were diagnostic trouble codes (DTCs) for the engine control module (ECM) stored?

  1. YES OKAY: Troubleshooting has been completed.
  2. NO Refer to «Checking diagnostic trouble codes (DTCs)»(ref-406990-S23915339292011070100000)
  1. Ignition on
  2. Wait approximately 60 seconds
  3. Read off the status of the diagnostic trouble code (DTC).

Is the status of the diagnostic trouble code (DTC) permanent?

  1. YES Refer to «Checking wiring and terminals»(ref-406990-S28968088552011070100000)
  2. NO Refer to «Intermittent fault»(ref-406990-S13997321102011070100000)

Condition

Scheme 114

Scheme 114: Diagnostic trouble code (DTC) information
Scheme 114: Diagnostic trouble code (DTC) information

Note. The diagnostic trouble code (DTC) applies only to cars with stability and traction control (STC) / dynamic stability and traction control (DSTC).

Diagnostic trouble code (DTC) BCM-0100 is stored if the brake control module (BCM) registers that the engine speed or torque signal from the engine control module (ECM) is missing for more than 500 ms.

Substitute Value

  1. Traction control is blocked
  2. Stability control is blocked
  3. Active yaw control is blocked.

HINT: For information about abbreviations, see Brake system, abbreviations .

Possible Source

  1. Open-circuit or short-circuit in the cable for the control area network (CAN)
  2. Fault in the engine management system.

Fault symptom[s]

  1. The anti-spin warning lamp is lit (up to and including 2002 model year)
  2. General yellow warning lamp lit (from model year 2003 inclusive)
  3. Anti-spin does not function
  4. The stability control system does not function
  5. The traction control system does not function.

In the event of communication problems, the fault may exist in other parts of the communications network.

The role of the central electronic module is to generally control the communications network and to store diagnostic trouble codes (DTCs) in the event of communication problems between control modules.

If there are diagnostic trouble codes (DTCs) stored for communication problems in the central electronic module, stop the fault tracing and fault trace the central electronic module.

Were diagnostic trouble codes (DTCs) for communication problems stored in the central electronic module?

  1. YES OKAY: Troubleshooting has been completed.
  2. NO Refer to «Fault-tracing information»(ref-406990-S38323709562011070100000)

Condition

Note. The diagnostic trouble code (DTC) applies only to cars with stability and traction control (STC) / dynamic stability and traction control (DSTC).

The engine control module (ECM) transmits a signal via the Control area network (CAN) which indicates whether the engine speed signal to the brake control module (BCM) is correct or not. The brake control module (BCM) uses the engine speed (RPM) signal during control of the stability function.

Diagnostic trouble code (DTC) BCM-0101 is stored if the brake control module (BCM) registers that the engine control module (ECM) has transmitted a signal indicating that the engine speed (RPM) signal is implausible.

The diagnostic trouble code (DTC) can be diagnosed after the engine has been started.

Substitute Value

  1. Traction control is blocked
  2. Stability control is blocked
  3. Active yaw control is blocked.

HINT: For information about abbreviations, see Brake system, abbreviations .

Possible Source

  1. Fault in the engine management system.

Note. This diagnostic trouble code (DTC) is not due to an internal hardware fault in the Brake control module (BCM) and must not be remedied by replacing the control module.

Fault symptom[s]

  1. The anti-spin warning lamp is lit (up to and including 2002 model year)
  2. General yellow warning lamp lit (from model year 2003 inclusive)
  3. Anti-spin does not function
  4. The stability control system does not function
  5. The traction control system does not function.

Condition

Scheme 115

Scheme 115: Diagnostic trouble code (DTC) information
Scheme 115: Diagnostic trouble code (DTC) information

The brake pedal position sensor transmits a signal to the brake control module about the position of the brake pedal and the speed at which it is pressed. The brake control module uses the signal to activate the brake assistance function during emergency braking.

Diagnostic trouble code (DTC) BCM-0103 is stored if the control module registers a faulty signal from the pedal position sensor.

The diagnostic trouble code (DTC) can be diagnosed when the ignition is switch on and if the signal from the pedal position sensor is more than 4.85 V or less than 0.15 V for too long.

Substitute Value

  1. Brake assistance is blocked.

HINT: For information about abbreviations, see Brake system, abbreviations .

Possible Source

  1. Open-circuit in the signal cable
  2. Short-circuit to ground or supply voltage in the wiring
  3. Incorrectly installed sensor
  4. Defective sensor
  5. Internal fault in the control module.

Fault symptom[s]

  1. General warning lamp lit.

Scheme 116

Scheme 116
Scheme 116

Scheme 117

Scheme 117
Scheme 117
  1. Ignition off
  2. Check the brake control module (BCM) and pedal position sensor connectors. Check for contact resistance and oxidation
  3. Reinstall the components, reconnect the connectors etc.
  4. Connect the breakout box to the brake control module (BCM)
  5. Ignition on
  6. Read off the position and speed of the pedal position sensor. Depress the brake pedal. Check that the signals are updated. The signal for the pedal position sensor must increase as the brake pedal is pressed further. Press the brake pedal at different speeds. Check that the speed signal is updated. Other information Connect the breakout box. See «Contents»(ref-406811-S37635188302011070100000)

Was the signal updated?

  1. YES OKAY: Troubleshooting has been completed.
  2. NO Refer to «Checking wiring and sensors»(ref-406990-S40285976672011070100000)

Condition

Scheme 118

Scheme 118: Diagnostic trouble code (DTC) information
Scheme 118: Diagnostic trouble code (DTC) information

Note. The diagnostic trouble code (DTC) applies only to cars with dynamic stability and traction control (DSTC).

The control module for the steering angle sensor transmits signals from the steering wheel angle sensor on the Control area network (CAN) from where it is retrieved by the brake control module (BCM). A reference signal is calculated using the signals from the wheel sensors, the yaw rate sensor and the lateral accelerometer. Diagnostic trouble code (DTC) BCM-0106 is stored if the brake control module (BCM) registers that the reference signal is outside its permitted range.

Substitute Value

  1. Stability control is blocked
  2. Active yaw control is blocked
  3. Traction control is blocked.

HINT: For information about abbreviations, see Brake system, abbreviations .

Possible Source

  1. Incorrect front wheel alignment
  2. Incorrectly installed steering wheel angle sensor
  3. Defective steering wheel angle sensor.

Note. This diagnostic trouble code (DTC) is not due to an internal hardware fault in the Brake control module (BCM) and must not be remedied by replacing the control module.

Fault symptom[s]

  1. The anti-spin warning lamp is lit (up to and including 2002 model year)
  2. Anti-spin does not function
  3. The stability control does not function
  4. The traction control system does not function.

Note. If diagnostic trouble codes (DTCs) are stored for the control module for the steering angle sensor, wheel sensors or active yaw control sensor (including the yaw sensor and lateral accelerometer), these must be fault traced first.

Are diagnostic trouble codes (DTCs) stored for the steering angle sensor, wheel sensors or active yaw control sensor?

  1. YES OKAY: Troubleshooting has been completed.
  2. NO Refer to «Checking diagnostic trouble codes (DTCs)»(ref-406990-S19869409792011070100000)
  1. Ignition off. Check whether the active yaw control sensor is loose or incorrectly installed. See «ACTIVE YAW CONTROL SENSOR, REPLACING»(ref-406847-S36312531992011070100000) .

Is the active yaw control sensor secure?

  1. YES Refer to «Checking the connectors»(ref-406990-S42527981092011070100000)
  2. NO Refer to «Verification»(ref-406990-S08158586212011070100000)

Condition

Scheme 119

Scheme 119: Diagnostic trouble code (DTC) information
Scheme 119: Diagnostic trouble code (DTC) information

Note. The diagnostic trouble code (DTC) applies only to cars with dynamic stability and traction control (DSTC).

The control module for the steering angle sensor is initiated by turning the steering wheel in either direction within 120 seconds of the car being started. The brake control module (BCM) retrieves the signals from the steering wheel angle sensor on the Control area network (CAN). Diagnostic trouble code (DTC) BCM-0108 is stored if the brake control module (BCM) registers that the control module for the steering wheel angle sensor has not be initialized within 120 seconds of start and the vehicle speed exceeds 10 km/h.

Substitute Value

  1. Active yaw control is blocked.

HINT: For information about abbreviations, see Brake system, abbreviations .

Possible Source

  1. After starting the driver has driven straight ahead for more than two minutes and then switched off the ignition which has led to the steering wheel angle sensor not being initiated
  2. Internal fault in the steering angle sensor.

Note. This diagnostic trouble code (DTC) is not due to an internal hardware fault in the Brake control module (BCM) and must not be remedied by replacing the control module.

Fault symptom[s]

  1. The anti-spin warning lamp is lit (up to and including 2002 model year)
  2. General yellow warning lamp lit (from model year 2003 inclusive)
  3. The traction control system does not function.

Condition

Scheme 120

Scheme 120: Diagnostic trouble code (DTC) information
Scheme 120: Diagnostic trouble code (DTC) information

Note. The diagnostic trouble code (DTC) applies only to cars with dynamic stability and traction control (DSTC).

The control module for the steering angle sensor is initiated by turning the steering wheel in either direction within 120 seconds of the car being started. The brake control module (BCM) retrieves the signals from the steering wheel angle sensor on the Control area network (CAN). Diagnostic trouble code (DTC) BCM-0108 is stored if the brake control module (BCM) registers that the control module for the steering wheel angle sensor has not be initialized within 120 seconds of start and the vehicle speed exceeds 10 km/h.

Substitute Value

  1. Active yaw control is blocked.

HINT: For information about abbreviations, see Brake system, abbreviations .

Possible Source

  1. After starting the driver has driven straight ahead for more than two minutes and then switched off the ignition which has led to the steering wheel angle sensor not being initiated
  2. Internal fault in the steering angle sensor.

Note. This diagnostic trouble code (DTC) is not due to an internal hardware fault in the Brake control module (BCM) and must not be remedied by replacing the control module.

Fault symptom[s]

  1. The anti-spin warning lamp is lit (up to and including 2002 model year)
  2. General yellow warning lamp lit (from model year 2003 inclusive)
  3. The traction control system does not function.

Condition

Note. The diagnostic trouble code (DTC) applies only to cars with dynamic stability and traction control (DSTC).

The control module for the steering angle sensor transmits a status signal to the brake control module (BCM).

Diagnostic trouble code (DTC) BCM-0109 is stored if the brake control module (BCM) receives a message from the steering angle sensor indicating an internal fault.

Substitute Value

  1. Traction control is blocked
  2. Stability control is blocked
  3. Active yaw control is blocked.

HINT: For information about abbreviations, see Brake system, abbreviations .

Possible Source

  1. Internal fault in the control module for the steering wheel angle sensor.

Note. This diagnostic trouble code (DTC) is not due to an internal hardware fault in the Brake control module (BCM) and must not be remedied by replacing the control module.

Fault symptom[s]

  1. The anti-spin warning lamp is lit (up to and including 2002 model year)
  2. General yellow warning lamp lit (from model year 2003 inclusive)
  3. Anti-spin does not function
  4. The stability control system does not function
  5. The traction control system does not function.

Condition

Note. The diagnostic trouble code (DTC) applies only to cars with dynamic stability and traction control (DSTC).

The control module for the steering angle sensor transmits a status signal to the brake control module (BCM).

Diagnostic trouble code (DTC) BCM-0109 is stored if the brake control module (BCM) receives a message from the steering angle sensor indicating an internal fault.

Substitute Value

  1. Traction control is blocked
  2. Stability control is blocked
  3. Active yaw control is blocked.

HINT: For information about abbreviations, see Brake system, abbreviations .

Possible Source

  1. Internal fault in the control module for the steering wheel angle sensor.

Note. This diagnostic trouble code (DTC) is not due to an internal hardware fault in the Brake control module (BCM) and must not be remedied by replacing the control module.

Fault symptom[s]

  1. The anti-spin warning lamp is lit (up to and including 2002 model year)
  2. General yellow warning lamp lit (from model year 2003 inclusive)
  3. Anti-spin does not function
  4. The stability control system does not function
  5. The traction control system does not function.

Condition

Note. The diagnostic trouble code (DTC) applies only to cars with dynamic stability and traction control (DSTC).

Diagnostic trouble code (DTC) BCM-0111 is stored if the brake control module (BCM) registers that the wheel or steering wheel alignment is incorrect.

Substitute Value

  1. Traction control is blocked
  2. Stability control is blocked
  3. Active yaw control is blocked.

HINT: For information about abbreviations, see Brake system, abbreviations .

Possible Source

  1. Incorrect wheel alignment
  2. Incorrect steering wheel alignment
  3. Defective steering wheel angle sensor.

Note. This diagnostic trouble code (DTC) is not due to an internal hardware fault in the Brake control module (BCM) and must not be remedied by replacing the control module.

Fault symptom[s]

  1. The anti-spin warning lamp is lit (up to and including 2002 model year)
  2. General yellow warning lamp lit (from model year 2003 inclusive)
  3. Anti-spin does not function
  4. The stability control system does not function
  5. The traction control system does not function.

Condition

Note. The diagnostic trouble code (DTC) applies only to cars with dynamic stability and traction control (DSTC).

When calibrating the sensors included in the stability function (active yaw control), a check sum is controlled in the brake control module (BCM). At start up, the control module checks the stored check sum against a calculated check sum.

Diagnostic trouble code (DTC) BCM-0112 is stored if the check sums do not correspond.

The diagnostic trouble code (DTC) can be diagnosed while the ignition is switched on.

Substitute Value

  1. Traction control is blocked
  2. Stability control is blocked
  3. Active yaw control is blocked.

HINT: For information about abbreviations, see Brake system, abbreviations .

Possible Source

  1. Interference or static that has affected the brake control module (BCM).
  2. Defective control module.

Fault symptom[s]

  1. The anti-spin warning lamp is lit (up to and including 2002 model year)
  2. General yellow warning lamp lit (from model year 2003 inclusive)
  3. Anti-spin does not function
  4. The stability control system does not function
  5. The traction control system does not function.

Reading off the status of the diagnostic trouble code (DTC)

  1. Ignition on
  2. Wait approximately 60 seconds
  3. Read off diagnostic trouble codes (DTCs). If the status of the diagnostic trouble code (DTC) has changed from permanent to intermittent the fault is no longer active. Try a new active yaw control sensor if the status of the diagnostic trouble code (DTC) is permanent. Other information To replace the active yaw control sensor, see «ACTIVE YAW CONTROL SENSOR, REPLACING»(ref-406847-S36312531992011070100000) .

Is the status of the diagnostic trouble code (DTC) intermittent?

  1. YES OKAY: Troubleshooting has been completed.
  2. NO Refer to «Verification»(ref-406990-S41450372902011070100000)

Condition

Note. The diagnostic trouble code (DTC) applies only to cars with dynamic stability and traction control (DSTC).

The brake control module receives a signal from the central electronic module (manual transmissions) or from the transmission control module (TCM) (automatic transmission) with information about the selected gear. If back-up (reverse) gear is selected, the stability function cannot be activated.

Diagnostic trouble code (DTC) BCM-0113 is stored if the brake control module registers that the signal is distorted, missing or receives a signal indicating that back-up (reverse) gear is selected when the car is being driven forward for more than one second.

The diagnostic trouble code (DTC) can be diagnosed when speed exceeds 40 km/h and the vehicle is driven straight ahead followed by a turn.

Substitute Value

  1. None.

Possible Source

  1. Open-circuit or short-circuit in the circuit for the back-up (reversing) lamp switch (manual transmission)
  2. Interference in the Control area network (CAN)
  3. Short-circuit or open-circuit on the Control area network (CAN).

Note. This diagnostic trouble code (DTC) is not due to an internal hardware fault in the Brake control module (BCM) and must not be remedied by replacing the control module.

Fault symptom[s]

  1. None.

Checking diagnostic trouble codes (DTCs) in the central electronic module

If there are diagnostic trouble codes (DTCs) stored in the central electronic module for communication problems or for the back-up (reversing) lamp, these must be fault traced first.

Were diagnostic trouble codes (DTCs) stored for communication problems or for the back-up (reversing) lamp in the central electronic module?

  1. YES OKAY: Troubleshooting has been completed.
  2. NO Refer to «Checking the transmission»(ref-406990-S17753937132011070100000)

Condition

Note. The diagnostic trouble code (DTC) applies only to cars with dynamic stability and traction control (DSTC).

Diagnostic trouble code (DTC) BCM-0114 is stored if the brake control module (BCM) registers that the signal from the active yaw control sensor is missing or faulty.

Substitute Value

  1. Traction control is blocked
  2. Stability control is blocked
  3. Active yaw control is blocked.

HINT: For information about abbreviations, see Brake system, abbreviations .

Possible Source

  1. Contact resistance in the terminals
  2. Open-circuit in the wiring between the brake control module (BCM) and the active yaw control sensor
  3. The active yaw control sensor is not connected
  4. Internal fault in the active yaw control sensor.

Note. This diagnostic trouble code (DTC) is not due to an internal hardware fault in the Brake control module (BCM) and must not be remedied by replacing the control module.

Fault symptom[s]

  1. The anti-spin warning lamp is lit (up to and including 2002 model year)
  2. General yellow warning lamp lit (from model year 2003 inclusive)
  3. Anti-spin does not function
  4. The stability control system does not function
  5. The traction control system does not function.

In the event of communication problems, the fault may exist in other parts of the communications network.

The role of the central electronic module is to generally control the communications network and to store diagnostic trouble codes (DTCs) in the event of communication problems between control modules.

If there are diagnostic trouble codes (DTCs) stored for communication problems in the central electronic module, stop the fault tracing and fault trace the central electronic module.

Were diagnostic trouble codes (DTCs) for communication problems stored in the central electronic module?

  1. YES OKAY: Troubleshooting has been completed.
  2. NO Refer to «Checking diagnostic trouble codes (DTCs) in the control module for the steering angle sensor»(ref-406990-S22136782322011070100000)

Checking diagnostic trouble codes (DTCs) in the control module for the steering angle sensor

If there are diagnostic trouble codes (DTCs) stored in the control module for the steering angle sensor, these must be fault-traced first.

Were diagnostic trouble codes (DTCs) stored in the control module for the steering angle sensor?

  1. YES OKAY: Troubleshooting has been completed.
  2. NO Refer to «Checking wiring and terminals»(ref-406990-S42708859752011070100000)

In the event of communication problems, the fault may exist in other parts of the communications network.

The role of the central electronic module is to generally control the communications network and to store diagnostic trouble codes (DTCs) in the event of communication problems between control modules.

If there are diagnostic trouble codes (DTCs) stored for communication problems in the central electronic module, stop the fault tracing and fault trace the central electronic module.

Were diagnostic trouble codes (DTCs) for communication problems stored in the central electronic module?

  1. YES OKAY: Troubleshooting has been completed.
  2. NO Refer to «Checking diagnostic trouble codes (DTCs) in the control module for the steering angle sensor»(ref-406990-S30614849402011070100000)

If there are diagnostic trouble codes (DTCs) stored in the control module for the steering angle sensor, these must be fault-traced first.

Were diagnostic trouble codes (DTCs) stored in the control module for the steering angle sensor?

  1. YES OKAY: Troubleshooting has been completed.
  2. NO Refer to «Checking wiring and terminals»(ref-406990-S39021257872011070100000)

Condition

Note. The diagnostic trouble code (DTC) applies only to cars with dynamic stability and traction control (DSTC).

The control module for the steering angle sensor transmits a signal via the Control area network (CAN) which indicates to the brake control module (BCM) whether the function of the steering wheel angle sensor is correct or not.

Diagnostic trouble code (DTC) BCM-0115 is stored if the brake control module (BCM) registers that the signal from the steering angle sensor is missing.

The diagnostic trouble code (DTC) can be diagnosed when the ignition is switched on.

Substitute Value

  1. Traction control is blocked
  2. Stability control is blocked
  3. Active yaw control is blocked.

HINT: For information about abbreviations, see Brake system, abbreviations .

Possible Source

  1. Disruption or open-circuit on the Control area network (CAN)
  2. The steering angle sensor is not connected on the Control area network (CAN)
  3. Internal fault in the steering angle sensor.

Fault symptom[s]

  1. The anti-spin warning lamp is lit (up to and including 2002 model year)
  2. General yellow warning lamp lit (from model year 2003 inclusive)
  3. Anti-spin does not function
  4. The stability control system does not function
  5. The traction control system does not function.

Condition

Note. The diagnostic trouble code (DTC) applies only to cars with dynamic stability and traction control (DSTC).

The control module for the steering angle sensor transmits a signal via the Control area network (CAN) which indicates to the brake control module (BCM) whether the function of the steering wheel angle sensor is correct or not.

Diagnostic trouble code (DTC) BCM-0115 is stored if the brake control module (BCM) registers that the signal from the steering angle sensor is missing.

The diagnostic trouble code (DTC) can be diagnosed when the ignition is switched on.

Substitute Value

  1. Traction control is blocked
  2. Stability control is blocked
  3. Active yaw control is blocked.

HINT: For information about abbreviations, see Brake system, abbreviations .

Possible Source

  1. Disruption or open-circuit on the Control area network (CAN)
  2. The steering angle sensor is not connected on the Control area network (CAN)
  3. Internal fault in the steering angle sensor.

Fault symptom[s]

  1. The anti-spin warning lamp is lit (up to and including 2002 model year)
  2. General yellow warning lamp lit (from model year 2003 inclusive)
  3. Anti-spin does not function
  4. The stability control system does not function
  5. The traction control system does not function.
  1. Ignition off
  2. Check the connectors for the brake control module (BCM) and the active yaw control sensor. Check for contact resistance and oxidation
  3. Ignition on
  4. Wait approximately 60 seconds
  5. Read off the status of the diagnostic trouble code (DTC). If the status of the diagnostic trouble code (DTC) is intermittent, the cause of the fault was probably contact resistance or oxidation in the connectors for the control module or the active yaw control sensor. Other information To disconnect the connector for the active yaw control sensor, see «ACTIVE YAW CONTROL SENSOR, REPLACING»(ref-406847-S36312531992011070100000) See «Contents»(ref-406811-S37635188302011070100000) .

Is the status of the diagnostic trouble code (DTC) permanent?

  1. YES Refer to «Checking the wiring»(ref-406990-S06543141492011070100000)
  2. NO OKAY: Troubleshooting has been completed.
  1. Ignition off
  2. Reconnect the components, connectors etc.
  3. Test drive the car. See «Test Drive Form (DSTC (dynamic stability and traction control) /brake control module), description»(ref-406985-S08515396952011070100000)
  4. Ignition on
  5. Read off diagnostic trouble codes (DTCs). The brake control module (BCM) is faulty if the status of the diagnostic trouble code (DTC) is still permanent. Install the old active yaw control sensor and replace the control module Other information To replace the control module, see «Brake Control Module (BCM), replacing»(ref-406847-S13549546932011070100000) .

Is the status of the diagnostic trouble code (DTC) permanent?

  1. YES OKAY: Troubleshooting has been completed.
  2. NO Refer to «Information»(ref-406990-S35535457042011070100000)

Condition

Diagnostic trouble code (DTC) BCM-0116 is stored if the brake control module (BCM) registers that the communication with the active yaw control sensor is not functioning.

Substitute Value

  1. Traction control is blocked
  2. Stability control is blocked
  3. Active yaw control is blocked.

HINT: For information about abbreviations, see Brake system, abbreviations .

Possible Source

  1. The cables for Control area network (CAN) communication are short-circuited to each other
  2. Short-circuit to ground or supply voltage in the cables for Control area network (CAN) communication
  3. Internal fault in the active yaw control sensor
  4. Internal fault in the brake control module (BCM).

Fault symptom[s]

  1. The anti-spin warning lamp is lit (up to and including 2002 model year)
  2. General yellow warning lamp lit (from model year 2003 inclusive)
  3. Anti-spin does not function
  4. The stability control system does not function
  5. The traction control system does not function.

Condition

There are two different active yaw control sensors. One is for two wheel drive cars, the other is for four wheel drive cars. Diagnostic trouble code (DTC) BCM-0117 is stored if the brake control module (BCM) registers that the installed active yaw control sensor is not correct for this car.

Substitute Value

  1. Traction control is blocked
  2. Stability control is blocked
  3. Active yaw control is blocked.

HINT: For information about abbreviations, see Brake system, abbreviations .

Possible Source

  1. An incorrect active yaw control sensor had been installed.

Note. This diagnostic trouble code (DTC) is not due to an internal hardware fault in the Brake control module (BCM) and must not be remedied by replacing the control module.

Fault symptom[s]

  1. The anti-spin warning lamp is lit (up to and including 2002 model year)
  2. General yellow warning lamp lit (from model year 2003 inclusive)
  3. Anti-spin does not function
  4. The stability control system does not function
  5. The traction control system does not function.

Condition

Note. The diagnostic trouble code (DTC) applies only to cars with dynamic stability and traction control (DSTC).

Diagnostic trouble code (DTC) BCM-0118 is stored if the brake control module (BCM) registers that the power supply from the active yaw control sensor exceeds 17 V.

Substitute Value

  1. Traction control is blocked
  2. Stability control is blocked
  3. Active yaw control is blocked.

HINT: For information about abbreviations, see Brake system, abbreviations .

Possible Source

  1. Short-circuit to supply voltage in the power supply cable
  2. Internal fault in the active yaw control sensor.

Note. This diagnostic trouble code (DTC) is not due to an internal hardware fault in the Brake control module (BCM) and must not be remedied by replacing the control module.

Fault symptom[s]

  1. The anti-spin warning lamp is lit (up to and including 2002 model year)
  2. General yellow warning lamp lit (from model year 2003 inclusive)
  3. Anti-spin does not function
  4. The stability control system does not function
  5. The traction control system does not function.

Condition

Note. The diagnostic trouble code (DTC) applies only to cars with dynamic stability and traction control (DSTC).

Diagnostic trouble code (DTC) BCM-0119 is stored if the brake control module (BCM) registers that the power supply to the active yaw control sensor is below 6 V 0.5 V.

Substitute Value

  1. Traction control is blocked
  2. Stability control is blocked
  3. Active yaw control is blocked.

HINT: For information about abbreviations, see Brake system, abbreviations .

Possible Source

  1. Contact resistance in the terminals on the active yaw control sensor
  2. Short-circuit to ground in the wiring
  3. Open-circuit in the wiring
  4. Internal fault in the active yaw control sensor

Note. This diagnostic trouble code (DTC) is not due to an internal hardware fault in the Brake control module (BCM) and must not be remedied by replacing the control module.

Fault symptom[s]

  1. The anti-spin warning lamp is lit (up to and including 2002 model year)
  2. General yellow warning lamp lit (from 2003)
  3. Anti-spin does not function
  4. The stability control system does not function
  5. The traction control system does not function.

Checking the status of the diagnostic trouble code (DTC)

  1. Ignition off
  2. Check the connectors for the brake control module (BCM) and the active yaw control sensor. Check for contact resistance and oxidation
  3. Test drive the car. See «Test Drive Form (DSTC (dynamic stability and traction control) /brake control module), description»(ref-406985-S08515396952011070100000)
  4. Ignition on
  5. Wait approximately 60 seconds
  6. Read off diagnostic trouble codes (DTCs). If the status of the diagnostic trouble code (DTC) intermittent, the cause of the fault was probably contact resistance or oxidation in the connectors for the control module or the active yaw control sensor. Other information Remove the control module connector. To access the active yaw control sensor, see «ACTIVE YAW CONTROL SENSOR, REPLACING»(ref-406847-S36312531992011070100000) See «Contents»(ref-406811-S37635188302011070100000)

Is the status of the diagnostic trouble code (DTC) intermittent?

  1. YES OKAY: Troubleshooting has been completed.
  2. NO Refer to «Checking the wiring»(ref-406990-S12457347002011070100000)

Condition

Note. The diagnostic trouble code (DTC) applies only to cars with dynamic stability and traction control (DSTC).

The yaw rate sensor, lateral accelerometer, accelerometer (only AWD) and angle of lean sensor (only RSC) are integrated in the active yaw control sensor. This in turn is connected to the brake control module (BCM) via its own Control area network (CAN) cable. The sensors transmit information to the brake control module (BCM) indicating the size of the yaw angle, the lateral acceleration of the car, the forward acceleration and the car's lateral angle of lean.

Diagnostic trouble code (DTC) BCM-0121, BCM-0125, BCM-0127 or BCM-0129 is stored, depending on the sensor, if the control module registers that the signal from any of the sensors is outside its permitted range.

  1. BCM-0121: Yaw rate sensor
  2. BCM-0125: Lateral acceleration sensor
  3. BCM-0127: Tilt angle sensor
  4. BCM-0129: Accelerometer.

Substitute Value

  1. Traction control is blocked
  2. Stability control is blocked
  3. Active yaw control is blocked
  4. RSC is blocked (cars equipped with RSC only).

HINT: For information about abbreviations, see Brake system, abbreviations .

Possible Source

  1. Interference or noise on the wiring has disrupted the active yaw control sensor calculations
  2. The power supply to the active yaw control sensor is too low
  3. Incorrect wheel alignment
  4. Internal fault in the active yaw control sensor.

Note. This diagnostic trouble code (DTC) is not due to an internal hardware fault in the Brake control module (BCM) and must not be remedied by replacing the control module.

Fault symptom[s]

  1. The anti-spin warning lamp is lit (up to and including 2002 model year)
  2. General yellow warning lamp lit (from model year 2003)
  3. Anti-spin does not function
  4. The stability control system does not function
  5. The traction control system does not function.

Condition

Note. The diagnostic trouble code (DTC) applies only to cars with dynamic stability and traction control (DSTC).

The active yaw control sensor is supplied with 12 V. The signal voltage of the sensors to the brake control module (BCM) is approximately 2.5 V for a stationary car. The control module compares the voltage with a reference value.

Diagnostic trouble code (DTC) BCM-0123 is stored if the voltage is outside the reference value or if an internal fault in the active yaw control sensor is registered.

Substitute Value

  1. Traction control is blocked
  2. Stability control is blocked
  3. Active yaw control is blocked.

HINT: For information about abbreviations, see Brake system, abbreviations .

Possible Source

  1. Signals which disrupt the active yaw control sensor
  2. Voltage to the active yaw control sensor is too low
  3. Internal fault in the active yaw control sensor.

Fault symptom[s]

  1. The anti-spin warning lamp is lit (up to and including 2002 model year)
  2. General yellow warning lamp lit (from model year 2003 inclusive)
  3. Anti-spin does not function
  4. The stability control system does not function
  5. The traction control system does not function.

See Diagnostic trouble code (DTC) information

See Diagnostic trouble code (DTC) information

See Diagnostic trouble code (DTC) information

See Diagnostic trouble code (DTC) information

Condition

Scheme 121

Scheme 121: Diagnostic trouble code (DTC) information
Scheme 121: Diagnostic trouble code (DTC) information

Note. This diagnostic trouble code (DTC) applies only to vehicles with dynamic stability and traction control (DSTC).

The brake pressure sensors transmit signals to the brake control module (BCM) indicating the pressure in the brake system. If the control module registers an incorrect signal from any brake pressure sensor, then trouble code BCM-0130 or BCM-0133 is generated depending on sensor.

Note. When cables to the brake pressure sensors are physically interchanged when installing, troubleshoot both sensors when trouble code BCM-0130 or BCM-0133 is detected.

Substitute Value

  1. Traction control is blocked.
  2. SC is blocked.
  3. Active yaw control is blocked.

HINT: For more information about abbreviations, see: Brake system, abbreviations

Possible Source

  1. Open-circuit in the wiring.
  2. Wiring is short-circuited to ground or supply voltage.
  3. Damaged pressure sensor.
  4. Internal fault in the control module.

Fault symptom[s]

  1. Warning light anti-spin on (applies to model year -2002)
  2. General yellow warning light on (applies to model year 2003-)
  3. Anti-spin not working
  4. Stability function is not working
  5. Anti skid function is not working

See Diagnostic trouble code (DTC) information

Condition

Note. The diagnostic trouble code (DTC) applies only to ABS systems equipped with dynamic stability and traction control (DSTC).

Brake pressure sensors 1 and 2 provide a signal with the brake system pressure to the brake control module (BCM). Diagnostic trouble code (DTC) BCM-0136 is stored if the control module registers that the signal from any of the pressure sensors is outside its permitted range.

Substitute Value

  1. Traction control is blocked
  2. Stability control is blocked
  3. Active yaw control is blocked.

HINT: For information about abbreviations, see Brake system, abbreviations .

Possible Source

  1. Open-circuit in the ground lead
  2. Fault in the brake circuit
  3. Defective pressure sensor.

Fault symptom[s]

  1. The anti-spin warning lamp is lit (up to and including 2002 model year)
  2. General yellow warning lamp lit (from model year 2003 inclusive)
  3. Anti-spin does not function
  4. The stability control system does not function
  5. The traction control system does not function.

Condition

Note. This diagnostic trouble code (DTC) applies only to brake systems with dynamic stability and traction control (DSTC).

The active yaw control sensor is supplied with 12 V.

Diagnostic trouble code (DTC) BCM-0138 is stored if the brake control module (BCM) registers that the supply voltage to the active yaw control sensor is too high or too low.

Substitute Value

  1. Traction control is blocked
  2. Stability control is blocked
  3. Active yaw control is blocked.

HINT: For information about abbreviations, see Brake system, abbreviations .

Possible Source

  1. Contact resistance or oxidation in the terminals or connections
  2. Short-circuit to ground or to supply voltage in the power supply wiring for the active yaw control sensor
  3. Open-circuit in the power supply cable for the active yaw control sensor
  4. Internal fault in the active yaw control sensor
  5. Internal fault in the control module.

Fault symptom[s]

  1. The anti-spin warning lamp is lit (up to and including 2002 model year)
  2. General yellow warning lamp lit (from model year 2003 inclusive)
  3. Anti-spin does not function
  4. The stability control system does not function
  5. The traction control system does not function.

Condition

Note. This diagnostic trouble code (DTC) applies only to brake systems with dynamic stability and traction control (DSTC).

During stability control the brake control module (BCM) transmits a signal to the pressure build-up valve. The valve opens and releases atmospheric pressure into the brake power booster. This increases the brake pressure in the brake system automatically. The function is used for traction control and in active brake assistance.

Diagnostic trouble code (DTC) BCM-0139 is stored if the control module registers an implausible signal from the pressure build-up valve.

Substitute Value

  1. Traction control is blocked
  2. Stability control is blocked
  3. Active yaw control is blocked
  4. Brake assistance is blocked.

HINT: For information about abbreviations, see Brake system, abbreviations .

Possible Source

  1. Contact resistance or oxidation in the terminals or connections
  2. Short-circuit to ground or supply voltage in the wiring
  3. Incorrectly installed sensor
  4. Defective pressure build-up valve
  5. Internal fault in the control module.

Fault symptom[s]

  1. General warning lamp lit
  2. The anti-spin warning lamp is lit (up to and including 2002 model year)
  3. Anti-spin does not function
  4. The stability control system does not function
  5. The traction control system does not function.

Condition

Note. This diagnostic trouble code (DTC) applies only to brake systems with dynamic stability and traction control (DSTC).

The pedal pressure sensor is located in the power brake booster and informs the brake control module (BCM) when the brake pedal is pressed. The control module uses the information to disengage active yaw control and active brake assistance if the functions are activated and the driver presses the brake pedal.

Diagnostic trouble code (DTC) BCM-0140 is stored if the control module registers an implausible signal from the pedal pressure sensor.

Substitute Value

  1. Traction control is blocked
  2. Stability control is blocked
  3. Active yaw control is blocked
  4. Brake assistance is blocked.

HINT: For information about abbreviations, see Brake system, abbreviations .

Possible Source

  1. Contact resistance or oxidation in the terminals or connections
  2. Open-circuit in the wiring
  3. Short-circuit to ground or supply voltage in the wiring
  4. Defective pedal pressure sensor
  5. Defective brake control module (BCM).

Fault symptom[s]

  1. The anti-spin warning lamp is lit (up to and including 2002 model year)
  2. General warning lamp lit
  3. Anti-spin does not function
  4. The stability control system does not function
  5. The traction control system does not function.

Condition

Note. The diagnostic trouble code (DTC) applies only to cars with dynamic stability and traction control (DSTC).

Diagnostic trouble code (DTC) BCM-0145 is stored If the brake control module (BCM) registers that the stability function operates for more than 15 seconds non-stop.

Substitute Value

  1. Traction control is blocked
  2. Stability control is blocked
  3. Active yaw control is blocked.

HINT: For information about abbreviations, see Brake system, abbreviations .

Possible Source

  1. Incorrectly installed steering wheel
  2. Incorrect wheel alignment
  3. Loose or incorrectly installed active yaw control sensor
  4. Defective active yaw control sensor.

Note. This diagnostic trouble code (DTC) is not due to an internal hardware fault in the Brake control module (BCM) and must not be remedied by replacing the control module.

Fault symptom[s]

  1. The anti-spin warning lamp is lit (up to and including 2002 model year)
  2. General yellow warning lamp lit (from model year 2003 inclusive)
  3. Anti-spin does not function
  4. The stability control system does not function
  5. The traction control system does not function.

Condition

Note. The diagnostic trouble code (DTC) applies only to cars with dynamic stability and traction control (DSTC).

Diagnostic trouble code (DTC) BCM-0146 is stored if the brake control module (BCM) registers that the factory test was not completed.

Substitute Value

  1. Traction control is blocked
  2. Stability control is blocked
  3. Active yaw control is blocked.

HINT: For information about abbreviations, see Brake system, abbreviations .

Possible Source

  1. Active yaw control operation during the factory test
  2. Factory test not completed satisfactorily.

Note. This diagnostic trouble code (DTC) is not due to an internal hardware fault in the Brake control module (BCM) and must not be remedied by replacing the control module.

Fault symptom[s]

  1. The anti-spin warning lamp is lit (up to and including 2002 model year)
  2. General yellow warning lamp lit (from model year 2003 inclusive)
  3. Anti-spin does not function
  4. The stability control system does not function
  5. The traction control system does not function.

Test cycle not approved

See Test cycle not approved

Condition

The brake pedal position sensor is part of "Active brake assistance". The sensor transmits a signal to the brake control module about the position of the brake pedal and the speed at which it is pressed. These signals are required to determine how much brake power is required in each brake situation.

The pedal position sensor is included on cars without brake assistance and is then used by the control module to check the operation of the stop lamp switch.

Diagnostic trouble code (DTC) BCM-0147 is stored if the control module registers a faulty signal from the pedal position sensor.

The diagnostic trouble code (DTC) can be diagnosed after the brake pedal has been depressed to the maximum, the engine has been started, and the brake pedal released. After having been stationary for approximately 10 seconds and then driven faster than 10 km/h for at least 10 seconds. Then stopped the car by braking.

Substitute Value

  1. Brake assistance is blocked.

HINT: For information about abbreviations, see Brake system, abbreviations .

Possible Source

  1. Open-circuit in the wiring
  2. Short-circuit to ground or supply voltage in the wiring
  3. Incorrectly installed pedal position sensor
  4. Defective pedal position sensor
  5. Defective brake control module.

Fault symptom[s]

  1. General yellow warning lamp lit.

Condition

The control module for the steering angle sensor communicates with the brake control module (BCM) with data which is transmitted in "small packages". Each package has an ID number.

Diagnostic trouble code (DTC) BCM-0148 is stored if the brake control module (BCM) registers an ID number that does not correspond to what the brake control module (BCM) expects.

The diagnostic trouble code (DTC) can be diagnosed when the ignition is switched on.

Substitute Value

  1. Traction control is blocked
  2. Stability control is blocked
  3. Active yaw control is blocked.

HINT: For information about abbreviations, see Brake system, abbreviations .

Possible Source

  1. Disruption or intermittent open-circuit on the Control area network (CAN)
  2. Internal fault in the control module for the steering wheel angle sensor.

Note. This diagnostic trouble code (DTC) is not due to an internal hardware fault in the Brake control module (BCM) and must not be remedied by replacing the control module.

Fault symptom[s]

  1. The anti-spin warning lamp is lit (up to and including 2002 model year)
  2. General yellow warning lamp lit (from model year 2003 inclusive)
  3. Anti-spin does not function
  4. The stability control system does not function
  5. The traction control system does not function.
  1. Ignition on
  2. Read off the status of the diagnostic trouble code (DTC).

Is the status of the diagnostic trouble code (DTC) intermittent?

  1. YES Refer to «Intermittent fault»(ref-406990-S24549412182011070100000)
  2. NO Refer to «Fault-tracing information»(ref-406990-S07143122542011070100000)

In the event of communication problems, the fault may exist in other parts of the communications network.

The role of the central electronic module is to generally control the communications network and to store diagnostic trouble codes (DTCs) in the event of communication problems between control modules.

If there are diagnostic trouble codes (DTCs) stored for communication problems in the central electronic module, stop the fault tracing and fault trace the central electronic module.

Were diagnostic trouble codes (DTCs) for communication problems stored in the central electronic module?

  1. YES OKAY: Troubleshooting has been completed.
  2. NO Refer to «Checking diagnostic trouble codes (DTCs)»(ref-406990-S42664787142011070100000)

Condition

Diagnostic trouble code (DTC) BCM-0150 is stored if the brake control module (BCM) registers that the stop (brake) lamp switch is not activated when the brake pedal is depressed.

There are diagnostics for this diagnostic trouble code (DTC) when the ignition is on and in the following cases

  1. Braking from a speed in excess of 40 km/h to standstill 3 times in succession within the same ignition cycle without control
  2. The brake pedal is kept pressed down and the stop lamp switch is activated for longer than 6 minutes.

Substitute Value

  1. None.

Possible Source

  1. Mechanical fault in the stop lamp switch.

Note. This diagnostic trouble code (DTC) is not due to an internal hardware fault in the Brake control module (BCM) and must not be remedied by replacing the control module.

Fault symptom[s]

  1. None.

Condition

The control modules in the car continually transmit and receive information over the data network (Controller Area Network). When the brake control module (BCM) is supplied with voltage the CAN controller which handles Controller Area Network communication is initialized.

Diagnostic trouble code (DTC) BCM-0151 is stored if initialization of the CAN controller fails.

The diagnostic trouble code (DTC) can be diagnosed while the ignition is switched on.

Substitute Value

  1. Traction control is blocked
  2. Stability control is blocked
  3. Active yaw control is blocked
  4. All communication to and from the brake control module (BCM) is shut off.

HINT: For information about abbreviations, see Brake system, abbreviations .

Possible Source

  1. Internal fault in the brake control module (BCM).

Fault symptom[s]

  1. The anti-spin warning lamp is lit (up to and including 2002 model year)
  2. General yellow warning lamp lit (from model year 2003 inclusive)
  3. The stability control system does not function
  4. The traction control system does not function.
  1. Ignition off
  2. Check the brake control module (BCM) connector. Check for contact resistance and oxidation
  3. Reinstall the components, reconnect the connectors etc.
  4. Ignition on
  5. Wait approximately 60 seconds
  6. Read off the status of the diagnostic trouble code (DTC). Replace the brake control module (BCM) if the status of the fault is permanent. Other information Access the control module connector. To replace the brake control module (BCM), see «Brake Control Module (BCM), replacing»(ref-406847-S13549546932011070100000) See «Contents»(ref-406811-S37635188302011070100000)

Was the status of the diagnostic trouble code (DTC) permanent?

  1. YES OKAY: Troubleshooting has been completed.
  2. NO Refer to «Information»(ref-406990-S19038171592011070100000)

Condition

The steering wheel angle sensor is initialized when the steering wheel is moved at least 5° within a certain amount of time of the ignition being switched on.

Diagnostic trouble code (DTC) BCM-A030 is stored if the steering angle is not initialized after 2 minutes driving at a speed above 10 km/h.

The initialization can be run before the ignition is switched off even after diagnostic trouble code (DTC) BCM-A030 has been stored. The anti spin warning lamp then goes out. Diagnostic trouble code (DTC) BCM-0108 is also stored if the initialization is not completed before the ignition is switched off.

Substitute Value

  1. Active yaw control is blocked.

Possible Source

  1. The steering wheel angle sensor is uninitiated after two minutes driving above 10 km/h.

Note. This diagnostic trouble code (DTC) is not due to an internal hardware fault in the Brake control module (BCM) and must not be remedied by replacing the control module.

Fault symptom[s]

  1. The anti-spin warning lamp is lit (up to and including 2002 model year)
  2. General yellow warning lamp lit (from model year 2003 inclusive)
  3. The traction control system does not function.

If diagnostic trouble code (DTC) BCM-A030 is stored on its own it must be erased.

If diagnostic trouble code (DTC) BCM-0108 is stored at the same time as BCM-A030, read off the diagnostic trouble codes (DTCs) from the control module for the steering angle sensor. Fault-trace the system.

Select an option

  1. Diagnostic trouble code (DTC) BCM-A030 is stored on its own Refer to «Erasing diagnostic trouble codes (DTCs)»(ref-406990-S21990511392011070100000)
  2. Diagnostic trouble codes (DTCs) BCM-0108 and BCM-A030 are stored at the same time. OKAY: Troubleshooting has been completed.
  1. Ignition on. Erase diagnostic trouble codes (DTCs).

Condition

Scheme 122

Scheme 122: Diagnostic trouble code (DTC) information
Scheme 122: Diagnostic trouble code (DTC) information

The steering wheel angle sensor is initialized when the steering wheel is moved at least 5° within a certain amount of time of the ignition being switched on.

Diagnostic trouble code (DTC) BCM-A030 is stored if the steering angle is not initialized after 2 minutes driving at a speed above 10 km/h.

The initialization can be run before the ignition is switched off even after diagnostic trouble code (DTC) BCM-A030 has been stored. The anti spin warning lamp then goes out. Diagnostic trouble code (DTC) BCM-0108 is also stored if the initialization is not completed before the ignition is switched off.

Substitute Value

  1. Active yaw control is blocked.

Possible Source

  1. The steering wheel angle sensor is uninitiated after two minutes driving above 10 km/h.

Note. This diagnostic trouble code (DTC) is not due to an internal hardware fault in the Brake control module (BCM) and must not be remedied by replacing the control module.

Fault symptom[s]

  1. The anti-spin warning lamp is lit (up to and including 2002 model year)
  2. General yellow warning lamp lit (from model year 2003 inclusive)
  3. The traction control system does not function.

If diagnostic trouble code (DTC) BCM-A030 is stored on its own it must be erased.

If diagnostic trouble code (DTC) BCM-0108 is stored at the same time as BCM-A030, read off the diagnostic trouble codes (DTCs) from the control module for the steering angle sensor. Fault-trace the system.

Select an option

  1. Diagnostic trouble code (DTC) BCM-A030 is stored on its own Refer to «Erasing diagnostic trouble codes (DTCs)»(ref-406990-S33410163332011070100000)
  2. Diagnostic trouble codes (DTCs) BCM-0108 and BCM-A030 are stored at the same time. OKAY: Troubleshooting has been completed.
  1. Ignition on. Erase diagnostic trouble codes (DTCs).

Diagnostic trouble code (DTC) information BCM-A031

Condition

Scheme 123

Scheme 123: Diagnostic trouble code (DTC) information BCM-A031
Scheme 123: Diagnostic trouble code (DTC) information BCM-A031

After the steering wheel angle sensor has been initialized, a check of the plausibility of the steering wheel angle is run.

The diagnostic trouble code (DTC) is stored if the check is not approved and speed exceeds 50 km/h.

The feasibility check can be performed after the relevant diagnostic trouble code is generated, but before the ignition is switched off. If the check is not complete within one minute, BCM-0111 is also generated.

Substitute Value

  1. Active yaw control is blocked.

Possible Source

  1. The plausibility check of the steering wheel angle is not approved.

Note. This diagnostic trouble code (DTC) is not due to an internal hardware fault in the Brake control module (BCM) and must not be remedied by replacing the control module.

Fault symptom[s]

  1. Anti-spin warning lamp lit
  2. General warning lamp lit
  3. Anti skid function is not working

If diagnostic trouble code (DTC) BCM-A031 is stored on its own it must be erased.

If diagnostic trouble code (DTC) BCM-0111 is stored at the same time as BCM-A031, read off the diagnostic trouble codes (DTCs) from the control module for the steering angle sensor. Fault-trace the system.

Select an option

  1. Diagnostic trouble code (DTC) BCM-A031 is stored on its own Refer to «Erasing diagnostic trouble codes (DTCs)»(ref-406990-S34463655482011070100000)
  2. Diagnostic trouble codes (DTCs) BCM-0111 and BCM-A031 are stored at the same time. OKAY: Troubleshooting has been completed.
  1. Ignition on. Erase diagnostic trouble codes (DTCs).

Diagnostic trouble code (DTC) information BCM-A032

Condition

The diagnostic trouble code (DTC) is stored in the subsequent operating cycle (ignition off and ignition on) if the brake control module (BCM) performs an extended start up check of the DSTC system due to a number of different faults during the previous operating cycle.

Substitute Value

  1. None.

Possible Source

  1. The diagnostic trouble code (DTC) has been stored in the previous operating cycle.

Note. This diagnostic trouble code (DTC) is not due to an internal hardware fault in the Brake control module (BCM) and must not be remedied by replacing the control module.

Fault symptom[s]

  1. The information lamp is lit.

Checking the diagnostic trouble codes (DTCs)

If diagnostic trouble code (DTC) BCM-A032 is stored on its own it must be erased.

If diagnostic trouble code (DTC) BCM-0145 is stored at the same time as BCM-A032, fault-tracing must be carried out according to the relevant information for diagnostic trouble code (DTC) BCM-0145.

Select an option

  1. Only BCM-A032 stored Refer to «Erasing diagnostic trouble codes (DTCs)»(ref-406990-S02453893072011070100000)
  2. Diagnostic trouble codes (DTCs) BCM-0145 and BCM-A032 are stored at the same time. OKAY: Troubleshooting has been completed.
  1. Ignition on. Erase diagnostic trouble codes (DTCs).

Diagnostic trouble code (DTC) information BCM-E000

Condition

The control modules transmit and receive information via a standardized serial communication method - CAN (Control Area Network). The diagnostic trouble code (DTC) is stored if the control module registers serious interference (CAN communication blocked).

Note. In the event of system communication problems, it is not possible to communicate with the control module. Therefore it will only be possible to read off the fault if it is intermittent.

Substitute Value

  1. The control module shuts itself off ("bus-off") HINT: The control module will remain shut off until the power supply is broken (15, 30, X). When the power supply is connected the control module will make a new attempt to communicate.

Possible Source

  1. Short-circuit between the control area network (CAN) wiring
  2. Open-circuit in the control area network (CAN) wiring
  3. Internal fault in the control module
  4. Internal fault in another control module in the same part of the control area network (CAN).

Fault symptom[s]

  1. The ABS warning lamp is lit
  2. No ABS function
  3. Message in the display.

See Diagnostic trouble code (DTC) information BCM-E000

Diagnostic trouble code (DTC) information BCM-E003

Condition

The control module compares its configuration ID with the signal configuration transmitted on the control area network (CAN) by the central electronic module (CEM). If the configuration IDs do not correspond the fault code is stored. The diagnostic trouble code (DTC) is also stored if the communication between the control module and the central electronic module (CEM) is interrupted.

Note. In the event of an open-circuit in both the control area network (CAN) cables, it is not possible to communicate with the control module. Therefore it will only be possible to read off the diagnostic trouble code (DTC) if this type of fault is intermittent. When the diagnostic trouble code (DTC) is stored, the control module responds to the diagnostic command, however normal control area network (CAN) communication does not work. ("Expulsion mode")

Substitute Value

  1. None.

Possible Source

  1. Faulty control area network (CAN) configuration ID. (The node is not intended for this car, for example a used control module with different software/hardware.)
  2. Open-circuit in the control area network (CAN) wiring between the control module and the central electrical module (CEM).

Note. This diagnostic trouble code (DTC) is not due to an internal hardware fault in the Brake control module (BCM) and must not be remedied by replacing the control module.

Fault symptom[s]

  1. The ABS warning lamp is lit
  2. No ABS function
  3. Message in the display.

See Diagnostic trouble code (DTC) information BCM-E003

Reading off diagnostic trouble codes (DTC)

  1. Ignition on. Read off the diagnostic trouble code (DTC) that is stored in the car. Make a note of the code. Report the code to VIDA customer support.

More articles — Brake Control Module (BCM) Diagnostic Trouble Code (DTC) Diagnostics
