CLIMATE UNITS (B5254T7, AW55-50/51SN, L. H. D; 2011)

Note. The graphics in this service information are used for different model years and/or models. Some variation may occur. However, the essential information in the graphics is always correct.

Scheme 140

Scheme 140: LOCATING THE CLIMATE CONTROL SYSTEM COMPONENTS IN THE PASSENGER COMPARTMENT / DOOR MIRROR
  1. Climate control unit (ECC or MCC)
  2. Outside temperature sensor (left-hand side)
  3. Passenger compartment temperature sensor (ECC)
  4. Sun sensor (ECC)
  5. Climate control unit
  6. Air quality sensor (AQS).

Scheme 141

Scheme 141: LOCATION OF THE CLIMATE CONTROL UNIT COMPONENTS
  1. Heat exchanger
  2. Evaporator
  3. Fan motor
  4. Damper motor module (DMM) air distribution
  5. Damper motor module (DMM) temperature, right-hand
  6. Damper motor module (DMM) temperature, left-hand
  7. Damper motor module (DMM) recirculation
  8. Damper motor module (DMM) defroster
  9. Evaporator temperature sensor
  10. Air cleaner (ACL) passenger compartment.

Scheme 142

Scheme 142: LOCATING COMPONENTS IN THE ENGINE COMPARTMENT
  1. Compressor
  2. The pipe/hose between the compressor and the condenser
  3. Condenser
  4. Service valve HT, draining/vacuum pumping
  5. Pipe/hose between condenser and expansion valve
  6. The pipe between the expansion valve and the evaporator
  7. Service valve LT, draining/filling/vacuum pumping
  8. Pipe/hose between evaporator and receiver
  9. Receiver
  10. Pipe/hose between receiver and compressor
  11. 2 pressure sensors.

Scheme 143

Scheme 143: LOCATION OF COMPONENTS

Overview, passenger compartment

  1. Climate control module (CCM)
  2. Switch for STC/DSTC (not for C70 (06-))
  3. Passenger compartment temperature sensor with blower fan
  4. Seat heating module (SHM) left
  5. Seat heating module (SHM) right.

Scheme 144

Scheme 144

Overview, climate control unit

  1. Damper motor module (DMM) recirculation
  2. Damper motor module (DMM) temperature right. Only applies to vehicles equipped with ECC
  3. Damper motor module (DMM) defroster
  4. Damper motor module (DMM) air distribution
  5. Damper motor module (DMM) temperature left
  6. Air quality sensor (AQS)
  7. Evaporator temperature sensor, Only applies to vehicles equipped with ECC

Scheme 145

Scheme 145: COMPONENT LOCATION

Overview, passenger compartment

  1. Climate control module (CCM)
  2. Switch tunnel console front
  3. Switch tunnel console rear
  4. Passenger compartment temperature sensor with blower fan
  5. Seat heating module (SHM) left
  6. Seat heating module (SHM) right.

Overview, climate control unit

  1. Damper motor module (DMM) recirculation
  2. Damper motor module (DMM) temperature right
  3. Damper motor module (DMM) defroster
  4. Damper motor module (DMM) air distribution
  5. Damper motor module (DMM) temperature left
  6. Air quality sensor (AQS)
  7. Evaporator temperature sensor Only applies to vehicles equipped with ECC
