Climate Units - Specifications, Electrical/electronic: Overview Volvo V50 I рестайлинг

Automatic HVAC System 1 illustration ~140 words

SIGNAL DESCRIPTION

All the values given below are between the terminals stated in column 1 and terminal #A16 in column 2 (signal ground). This applies unless otherwise indicated in brackets.

Note. It is important to connect the breakout box and check the ground connections before starting to measure.

There may be several connections and connectors between the control module and components.

U=DC voltage in volts (V)U AC =AC voltage in volts (V)
U bat =Battery voltage (V)F =Frequency in Hertz (Hz)
U low =Voltage approximately 0 VT =Time in seconds
PWM =Pulse width modulated signal in %

Connector, climate control module (CCM)

Terminal breakout boxTerminal control moduleSignal typeIgnition onIdleMiscellaneous
#25#A115-supply, power supply climate control module (CCM).U batU batPowered via the relay from the central electronic module (CEM)
#26#A2Power supply to indication in the STC/DSTC buttonU batU batPulse width modulation (PWM) signal
#27#A3Signal, STC/DSTC buttonU=0 V when button is pressed in, U bat otherwiseU=0 V when button is pressed in, U bat otherwise
#28#A4Power supply, blower fan passenger compartment temperature sensorU batU batOnly ECC
#29#A5Signal, evaporator temperature sensorU=0.2-4.8 VU=0.2-4.8 VOnly ECC Temperature dependent
#30#A6Signal, passenger compartment temperature sensorU=0.4-4.8 VU=0.4-4.8 VOnly ECC Temperature dependent
#31#A7LIN bus 2Digital signalDigital signalCommunication with components, LIN bus 2
#32#A8CAN L1Digital signalDigital signal
#33#A9CAN L2Digital signalDigital signal
#34#A10CAN H1Digital signalDigital signal
#35#A11CAN H2Digital signalDigital signal
#36#A12LIN bus 1Digital signalDigital signalCommunication with components, LIN bus 1
#37#A13
#38#A14Signal ground, passenger compartment temperature sensor and evaporator temperature sensorU lowU lowOnly ECC
#39#A15
#40#A16Power groundU lowU low

SIGNAL TABLE

Terminal breakout boxTerminal control moduleSignal typeIgnition onIdleMiscellaneous
#A1Power groundU lowU low
#A2LIN busDigital signalDigital signalCommunication with the climate control module (CCM)
#A3
#A4Power supply, seat heating module (SHM)U batU batPowered via the central electronic module (CEM)

SIGNAL TABLE, SEAT HEATING MODULE (SHM) CONNECTOR A

Terminal breakout boxTerminal control moduleSignal typeIgnition onIdleMiscellaneous
#B1Power supply, heating loop seatU batU bat
#B2Signal, temperature sensor seat
#B3Signal ground, temperature sensor seat
#B4Power ground, heating loop seatU lowU low

SIGNAL TABLE, SEAT HEATING MODULE (SHM) CONNECTOR B

Terminal breakout boxTerminal control moduleSignal typeIgnition onIdleMiscellaneous
#C1Power ground, heating loop backrestU lowU low
#C2Power supply, heating loop backrestU batU bat

SIGNAL TABLE, SEAT HEATING MODULE (SHM) CONNECTOR C

Connector, evaporator temperature sensor (Only ECC)

Terminal breakout boxTerminal control moduleSignal typeIgnition onIdleMiscellaneous
#1Signal, evaporator temperature sensor0.2-4.8 V0.2-4.8 VOnly ECC Temperature dependent
#2
#3Signal groundU lowU low

SIGNAL TABLE

Connector damper motor module (DMM)

Terminal breakout boxTerminal control moduleSignal typeIgnition onIdleMiscellaneous
#1Power supplyU batU batPowered via the relay on the central electronic module (CEM)
#2LIN busDigital signalDigital signalCommunication with the climate control module (CCM)
#3Power groundU lowU low

SIGNAL TABLE

Connector passenger compartment temperature sensor (only ECC)

Scheme 9

Scheme 9
Terminal breakout boxTerminal control moduleSignal typeIgnition onIdleMiscellaneous
#21#1
#22#2Power ground, blower fan motorU lowU lowNo grounding via the climate control module (CCM)
#23#3Signal ground, passenger compartment temperature sensorU lowU low
#24#4Power supply, blower fan motorU batU batPower supply only when the connector is connected and there are not faults in the wiring.
#25#5Signal, passenger compartment temperature sensorU=0.4-4.8 VU=0.4-4.8 VTemperature dependent

SIGNAL TABLE

Terminal breakout boxTerminal control moduleSignal typeIgnition onIdleMiscellaneous
#1Power supplyU batU batPowered via the relay on the central electronic module (CEM)
#2LIN busDigital signalDigital signalCommunication with the climate control module (CCM)
#3Power groundU lowU low

SIGNAL TABLE, AIR QUALITY SENSOR (AQS) CONNECTOR (OPTION, ONLY ECC)

Connector switch tunnel console

Breakout box terminalControl module terminalSignal typeIgnition onIdleMiscellaneous
#1Power supplyU batU bat
#2
#3LIN communicationDigital signalDigital signal
#4
#5Power groundU lowU low

SIGNAL TABLE
