Climate Units - Installation Instructions, Accessories: Overview Volvo V50 I рестайлинг

Automatic HVAC System 7 illustrations ~228 words

Scheme 226

Scheme 226: PREPARATIONS
Scheme 226: PREPARATIONS
  1. Remove the screws and the engine splash guard.

Scheme 227

Scheme 227
Scheme 227
  1. Remove the left front wheel.
  2. Remove the five screws holding the bumper cover in the wing liner on the left and right-hand sides.

Scheme 228

Scheme 228
Scheme 228
  1. Remove the nut holding the left-hand wing liner to the front member.
  2. Bend the front edge of the left-hand wing liner up over the brake calliper.

Scheme 229

Scheme 229
Scheme 229
  1. Push in the center of the five clips (1). Remove the clips.
  2. Remove the two screws (2).

Scheme 230

Scheme 230
Scheme 230
  1. Remove the covers for the nozzles for the headlamp washers on the right and left-hand sides. Carefully grip the cover. Pull the cover out until the catch becomes accessible.

Scheme 231

Scheme 231
Scheme 231
  1. Press the catch up. Remove the cover. Do not damage the painted surfaces or the washer nozzles.

Scheme 232

Scheme 232
Scheme 232
  1. Detach the ends of the bumper cover on the left and right-hand sides. Grasp the end of the bumper cover inside the wing liner. Carefully pull the end of the bumper cover so that the two catches on the inside release.
  2. Remove the bumper cover and air baffle. Pull the bumper cover and air baffle forward until the remaining catches under the lamps release.
  3. Disconnect the connectors for the fog lamps if applicable.
