Body Frame - General Information: Overhaul Volvo V50 I рестайлинг

ASSEMBLY

Spot welding is mainly used when the bodies are manufactured, and use of this method should always be aimed for with a repair.

Unless otherwise specified in the method, the distance between the welds must be the same as the original design.

Scheme 55

There are a number of other assembly methods that are illustrated with the following symbols

1. Spot weld/spot weld with the location of the weld and lens diameter specified with color (may be replaced with 2)
2. Plug weld (may be replaced with 1)
3. Seam weld/Seam weld with weld length specified in mm
4. Step weld/Step weld with weld length followed by length between welds specified in mm. Always start and finish with the weld.
5. Tack weld
6. Glue.

Spot welding is mainly used when the bodies are manufactured, and use of this method should always be aimed for with a repair.

Unless otherwise specified in the method, the distance between the welds must be the same as the original design.

There are a number of other assembly methods that are illustrated with the following symbols

1. Spot weld/spot weld with the location of the weld and lens diameter specified with color (may be replaced with 2)
2. Plug weld (may be replaced with 1)
3. Seam weld/Seam weld with weld length specified in mm
4. Step weld/Step weld with weld length followed by length between welds specified in mm. Always start and finish with the weld.
5. Tack weld
6. Glue.
