Ignition and Control Systems - Removal, Replacement and Installation: Removal & Installation Volvo S80 I

Removal and Installation

Note. As the illustrations in this service information are used for different model years and / or models, some variation may occur. However, the essential information in the illustrations is always correct.

Scheme 1

Remove the boost pressure sensor which is on the pipe coming from the charge air cooler (CAC).

Note. As the illustrations in this service information are used for different model years and / or models, some variation may occur. However, the essential information in the illustrations is always correct.

Scheme 2

Drain the fuel injection system. See Fuel system pressure release .

Remove the charge air pipe over the engine. Seal the openings.

Remove the cover over the fuel rail.

Scheme 3

Remove

1. the tie strap for the cable for the sensor
2. the screw for the sensor
3. the sensor.

Fuel pressure sensor, replacement

See Fuel pressure sensor, replacement

Pressure sensor, fuel tank, replacement

See Pressure sensor, fuel tank, replacement

See Pressure sensor, fuel tank, replacement

See Pressure sensor, fuel tank, replacement

See Pressure sensor, fuel tank, replacement
