Pull the cable up to the brake lever
Take hold of the welding rod. Pull the mechanical cable with the sleeve through the bodywork and up to the parking brake lever.
Remove the welding rod.
Install the rubber seal against the bodywork
- press the rubber grommet up until it seals
- work up the heat shield. Install both the screws.
Scheme 200
Install
- the cable end on the segment
- the adjuster nut at the parking brake lever.
Install the center console
See Parking brake lever, replacing .
Install the brake disc and the brake caliper with the holder
Install the disc locating pin. Tighten to 8 Nm .
Tighten the caliper holder mounting screws. Tighten to 60 Nm . Use new mounting screws.
Install the wheel
See Installing wheels .
Adjust the parking brake
First tension the cable by pulling the lever to 400 N .
Adjusting the parking brake. Adjust the handbrake .
