Using And Removing Volvo S60 I

Using And Removing

The table can be used both when the armrest is folded up and when it is folded down.

Removal

1. Fold up the armrest with the table until the armrest is in the folded in position
2. Carefully pull the table out from the gap at the lower edge of the armrest.

1. Fold up the rear center armrest
2. Insert the angled end of the table in the gap in the lower edge of the armrest.

Scheme 327

1. Fold down both the table and the armrest.

Scheme 328

1. Press the table backwards as far as it will go.

Scheme 329

1. Fold up the armrest again.

The table can be used both when the armrest is folded up and when it is down.

1. Remove the cover. Using a coin or similar, insert the coin in the groove. Carefully twist the cover loose.

Scheme 330

Scheme 331

Position 1

1. Take the shorter screw and three thin washers from the kit
2. Slide two thin washers onto the screw
3. Slide the screw through the mounting
4. Slide a thin washer onto the screw.

Position 2

1. Take the longer screw and the three thin and the slightly larger washers from the kit
2. Slide two thin washers onto the screw
3. Slide the screw through the mounting
4. Slide the slightly larger washer and then the remaining thin washer onto the screw.

Finally

1. Secure the mounting in place. Tighten the screws a quarter turn.

Scheme 332

1. Secure the waste paper basket on the mounting from above and down as shown.

Scheme 333

1. Take the rail, the hooks and the end stop from the kit
2. Thread the hooks onto the rail. Insert the end stop
3. Take the two mounting plates and the screws from the kit
4. Mount the plates in the outer holes of the rails. Use the screws. The long section of the mounting plate must point forwards
5. Lift the rail. Insert the mounting plates in the two large rectangular holes on the underside of the parcel shelf.

Scheme 334

1. Turn the mounting plates 90°, so that the long section points inwards in the car and is over the edge of the holes in the parcel shelf
2. Slide the rail to the rear edge of the rectangular holes. Check that no wiring is trapped on the upper side of the parcel shelf. Tighten the rail to the parcel shelf.

Scheme 335

1. Take the rail, the hooks and the end stop from the kit
2. Thread the hooks onto the rail. Insert the end stop
3. Take the two mounting plates and the screws from the kit
4. Mount the plates in the outer holes of the rails. Use the screws. The long section of the mounting plate must point outwards
5. Lift the rail. Insert the mounting plates in the two outer holes on the underside of the parcel shelf
6. Center the mounting plates over the holes. Pull the rail backwards to the rear edge of the holes. Secure the rail using the two screws.

Scheme 336

1. Take the rail, the hooks and the end stop from the kit
2. Thread the hooks onto the rail. Insert the end stop
3. Take the two mounting plates and the screws from the kit
4. Mount the plates in the rail's penultimate holes. Use the screws. The long section of the mounting plate must point inwards.
5. Lift the rail. Slide the left-hand mounting plate into the left-hand hole on the underside of the parcel shelf. Then slide the right-hand mounting plate into the hole second from the right
6. Slide the rail as far to the right as possible so that the mounting plates are over the panel surfaces between the holes. Pull the rail backwards to the rear edge of the holes. Secure the rail using the two screws.

Scheme 337

1. Take the rail, the hooks and the end stop from the kit
2. Thread the hooks onto the rail. Insert the end stop
3. Take the two mounting plates and the screws from the kit
4. Mount the plates in the rail's inner holes. Use the screws. The long section of the mounting plate must point forwards in the car.
5. Lift up the rail and insert both mounting plates in the holes in the parcel shelf until the screws engage.
6. Now turn the plates so that they can be inserted into the holes.
7. Pull the rail backwards towards the rear edge of the holes, until the screws engage. The rear section of the plates may require lifting to go over insulation on top of the parcel shelf.
8. Tighten using the two screws.

Scheme 338

Carrier bags can be removed in two ways

1. by carefully moving the hooks to one side
2. by lifting the handles for the carrier bags backwards, upwards and then forwards.
