Headlamps, aligning
| WARNING | Adjustment of the headlamp beam is dependent on the legal requirements of the relevant market. Select intended market. |
| CAUTION | Cars equipped with Bi-Xenon lamps or halogen lamps are adjusted in the same way. To ensure that the position sensor for the Bi-Xenon lamps is correctly calibrated calibrate as follows. Vehicles without Four-C see, VIDA, Car communication, function group 3, rear electronic module (REM), Calibrating the Bi-Xenon lamp position sensor Vehicles with Four-C see, VIDA, vehicle communication, function group 7, suspension module (SUM), calibrating the system. |
Note. Select market: See Adjusting, all markets except USA, United Kingdom and Japan See Adjustment, USA See Adjustment, United Kingdom See Adjustment, Japan .
Adjusting, all markets except USA, United Kingdom and Japan
| WARNING | Always adjust the headlamp beam according to the legal requirements of the market. |
Scheme 4
- Ignition and low beam on
- Check the button that controls the lighting level. Set the button to the 0 position
- Check the current. Check that the power supply is sufficient for the desired beam level
- CAUTION: Always adjust the beam with low beam switched on.
Scheme 5
Scheme 6
- Adjust the beam vertically (Y) using an Allen screw, as shown in the illustration
- Adjust the beam horizontally (X) using an Allen screw, as shown in the illustration
- HINT: Use a Ø6 mm Allen screw.
| WARNING | Always adjust the headlamp beam according to the legal requirements of the market. |
